Bresser Temeo io User manual

GB
INSTRUCTION MANUAL
Temeo io
Art. No. 7000004

2
A
Fig. 1
B

3
Fig. 2
Fig. 3
H
G
I
J
1)
B
C D
E
F

4
About this Instruction Manual
These operating instructions are to be
considered a component of the device. Please
read the safety instructions and the operating
instructions carefully before use. Keep these
instructions for renewed use at a later date. When
the device is sold or given to someone else, the
instruction manual must be provided to the new
owner/user of the product.
This product is intended only for private use. It was
developed as an electronic medium for the use of
multimedia services.
General Warnings
RISK OF CHOKING!
Keep packaging material, like plastic bags and
rubber bands, out of the reach of children, as these
materials pose a choking hazard.
RISK OF ELECTRIC SHOCK!
This device contains electronic components that
operate via a power source (batteries). Children
should only use the device under adult supervision.
Only use the device as described in the manual;
otherwise, you run the risk of an electric shock.
RISK OF CHEMICAL BURN!!
Leaking battery acid can lead to chemical burns.
Avoid contact of battery acid with skin, eyes and
mucous membranes. In the event of contact, rinse

5
the affected region immediately with a plenty of
water and seek medical attention.
RISK OF FIRE/EXPLOSION!
Use only the recommended batteries. Do not short-
circuit the device or batteries, or throw them into
a fire. Excessive heat or improper handling could
trigger a short-circuit, a fire or an explosion.
NOTE!
Do not disassemble the device. In the event of a
defect, please contact your dealer. The dealer will
contact the Service Centre and can send the device
in to be repaired, if necessary.
Do not immerse the unit in water.
Do not subject the unit to excessive force, shock,
dust, extreme temperature or high humidity, which
may result in malfunction, shorter electronic life
span, damaged batteries and distorted parts.
Use only the recommended batteries. Always replace
weak or empty batteries with a new, complete set of
batteries at full capacity. Do not use batteries from
different brands or with different capacities. Remove
the batteries from the unit if it has not been used for
a long time.
The manufacturer is not liable for damage related to
improperly installed batteries!

6
SCOPE OF DELIVERY (Fig. 1)
Main unit (A), remote sensor (B), instruction manual
Required batteries (not included with purchase):
4 pieces of micro batteries (1.5V, type AAA)
PARTS OVERVIEW
Main Unit (Fig. 2)
(1) Display – Temperature trend, indoor- and
outdoor temperature, as well as current time.
(3) MIN/MAX/+ button – Changes the value for one
setting. Allows switching between MIN and MAX
values. Press and hold for 2 seconds to initialize
receiving the RC signal from the remote sensor.
(3) SET button – Enter time and date setting mode.
(4) Battery compartment
(5) Table stand – Add if station is to be placed on
a flat surface.
Remote sensor (Fig. 3)
(6) Outdoor temperature
(7) Battery compartment
(8) Wall mount hole – This hole makes it possible
to mount the remote sensor on a wall.
(9) °C/°F button – This button selects between
Celsius (°C) and Fahrenheit (°F).
(10) Table stand – Foldable. Use this stand to
place the device on a flat surface

7
BEFORE YOU START
IMPORTANT!
1. Insert batteries for remote units before doing so
for the main unit.
2. Place the main unit as close as possible to the
remote unit.
3. Position the remote unit and main unit within the
effective transmission range.
When changing batteries always change batteries
in the main unit as well as all remote units and
replace them in the correct order, so the remote
connection can be re-established. If batteries
are exchanged in only one of the devices (i.e. the
remote sensor) the signal can’t be received or can’t
be received correctly.
Note, that the effective range is vastly affected by
building materials and position of the main and
remote units. Due to external influences (various
RC devices and other sources of interference), the
maximum distance can be greatly reduced. In such
cases we suggest to position the main unit and the
remote sensor at other places. Sometimes all it
takes is a relocation of one of these components
of a few inches!
Though the remote unit is weather proof, it should
be placed away from direct sunlight, rain or snow.
DE
GB
FR
IT
ES
Garantie / Warranty

8
POWER SUPPLY
Remote sensor
1. Open the battery compartment door.
2. Install 2 batteries (AAA size 1.5V) strictly
according to the polarities shown.
3. Reinsert the battery compartment door.
Main unit
1. Open the battery compartment door.
2. Install 2 batteries (AAA size 1.5V) strictly
according to the polarities shown.
3. Reinsert the battery compartment door.
Low battery warning
When it is time to replace the batteries, the
respective low battery indicator will be shown
next to the indoor temperature display (batteries
for main unit) or near to the outdoor temperature
(batteries for remote sensor).
USING TABLE STAND OR WALL MOUNTING
The main unit can be placed on a flat surface. The
remote unit also can be placed on a flat surface or
mounted on a wall using the recessed screw hole.
OPERATION
Receiving measurements and time signal
Once batteries are placed in the remote unit, it
will start transmitting temperature readings at
roughly 45 second intervals. As soon as batteries

9
are installed in the main unit it will start searching
for a signal from the remote sensor for about 3
minutes. Upon successful reception of the signal,
the outdoor temperature will be displayed on the
main unit. The main unit will automatically update
its readings at about 45 second intervals.
Temperature
1. Press the SET/°F/°C button to switch the
displayed temperature between °C and °F.
2. Once the battery is installed, the main unit
will start displaying the interior measurement
information. The main unit will display the
information from the remote sensor for the first
time approximately 3 minutes after the power
supply was established.
Max/Min records of temperature and humidity
1. Press the MIN/MAX/+ button repeatedly to
switch between the current temperature and the
values of the MIN and MAX recordings.
2. In MIN/MAX temperature display mode, hold
MIN/MAX/+ button to reset all indoor and
outdoor MIN/MAX records to current values.
3. The MIN/MAX temperature values will be
recorded automatically.
4. The MIN/MAX temperature records automatically
will be reset at 0:00 o’clock (12:00 a.m.) every day.
Temperature trend
The temperature trend is calculated from the values
DE
GB
FR
IT
ES
Garantie / Warranty

10
of different measurement periods and will be
displayed as follows:
Rising
Steady
Falling
Main unit signal receiving check
The transmission range is about 30 meters from the
remote station to the main unit (in open area). The
main unit should receive the temperature/humidity
information from the transmitter within 3 minutes
after set-up.
Should the main unit not receive information from
transmitter within 3 minutes after setting up, please
check following steps:
1. Press and hold MIN/MAX/+ button for 2-3 sec to
re-start receiving from the transmitter; the data
will normally be received within 3 minutes.
2. If the first step does not yield a desirable solution,
please remove the batteries and re-install them
(hardware reset).
At the same time, please make sure the following:
1. The main unit as well the as transmitter should be
at least 5~6.5 feet (1.5~2 meters) away from any
interfering sources, such as computer monitors or
TV sets.
2. The main unit should not stand close to metal
window frames.

11
3. Please do not using other electrical products,
such as headphones or speakers, operating on
the same signal frequency (433.92 MHz).
4. Electrical devices operating on the same signal
frequency may also cause interference. This can
include devices used in the neighborhood as well.
Manual time setting
1. Press and hold the SET/°F/°C button in normal
display mode for 2 seconds to enter into time
setting mode.
2. The figure to be set will start flashing.
3. Press MIN/MAX/+ button to change the value.
4. Press SET button to confirm and go to the next
value to be changed.
5. The setting order is 12/24hr >> hours >> minutes
>> save and exit.
6. If there is no operation for 30 seconds, the existing
setting will be saved and the device returns to
normal display mode. Press SET button again to
confirm and exit setting.
Sensor function
1. Press °C/°F to change the temperature display of
the transmitter
3. Once the weather station receives radio signals
from the sensor, the temperature value will be
updated on the base unit every 1-2 minutes.
DE
GB
FR
IT
ES
Garantie / Warranty

12
TROUBLESHOOTING
Signal disconnection
If without obvious reasons the display of the
outdoor temperature goes blank, please check the
following:
1. The remote unit is still in place.
2. The batteries of both the remote unit and main
unit are not empty. Replace batteries with new
ones if necessary.
Note: When the temperature falls below freezing
point, the batteries of outdoor units will freeze,
lowering their voltage supply, effective range, and
life span.
3. All units required are within range and the path is
clear of obstacles and interference. Shorten the
distance if necessary.
Transmission collision
Signals from other household devices, such as door
bells, home security systems and entry controls,
may interfere with those of this product and
cause temporarily reception failure. This is normal
and does not affect the general performance
of the product. The transmission and reception
of temperature readings will resume once the
interference recedes.

13
SPECIFICATIONS
Measurement
Indoor temperature range: 0~50° C
Outdoor Temperature Range: -20~60° C
Resolution for temperature: 0.1° C
Transmission
Transmission range between transmitter and main
unit: 30meters (in open area)
Radio frequency: 433.92 MHz
Power supply
Main unit: 2x AAA 1.5V battery
Remote sensor: 2x AAA 1.5V battery
CLEANING AND MAINTENANCE
Before cleaning the device, disconnect it from the
power supply (remove batteries)!
Only use a dry cloth to clean the exterior of the
device. To avoid damaging the electronics, do not
use any cleaning fluid.
DISPOSAL
Dispose of the packaging materials properly,
according to their type, such as paper or
cardboard. Contact your local waste-disposal service
or environmental authority for information on the
proper disposal.
DE
GB
FR
IT
ES
Garantie / Warranty

14
Do not dispose of electronic devices in the
household garbage!
As per Directive 2002/96/EC of the European
Parliament on waste electrical and electronic
equipment and its adaptation into German law, used
electronic devices must be collected separately and
recycled in an environmentally friendly manner.
In accordance with the regulations concerning
batteries and rechargeable batteries,
disposing of them in the normal household waste is
explicitly forbidden. Please make sure to dispose of
your used batteries as required by law — at a local
collection point or in the retail market. Disposal in
domestic waste violates the Battery Directive.
Batteries that contain toxins are marked with a sign
and a chemical symbol. "Cd" = cadmium, "Hg" =
mercury, "Pb" = lead.
EC DECLARATION OF CONFORMITY
Bresser GmbH has issued a "Declaration of
Conformity" in accordance with applicable
guidelines and corresponding standards. This can
be viewed any time upon request.

15
GB WARRANTY & SERVICE
The regular guarantee period is 2 years and begins on the
day of purchase. To benefit from an extended voluntary
guarantee period as stated on the gift box, registration
on our website is required. You can consult the full
guarantee terms as well as information on extending
the guarantee period and details of our services at
www.bresser.de/warranty_terms. Would you like detailed
instructions for this product in a particular language?
Then visit our website via the link below (QR code) for
available versions. Alternatively you can also send an
email to [e-mail] or leave a message on
+49 (0) 28 72 – 80 74-220*. Please always state your
name, precise address, a valid phone number and email
address, as well as the article number and name.
*Number charged at local rates in Germany (the amount you will be charged per
phone call will depend on the tariff of your phone provider); calls from abroad
will involve higher costs.
www.bresser.de/7000004

Bresser GmbH
Gutenbergstr. 2 · DE-46414 Rhede
Germany
www.bresser.de · [e-mail] Errors and technical changes reserved. / Manual_7000004_Temeo-io_en_BRESSER_v052020a
www.bresser.de/start/bresser
