1 Imprint
Bresser GmbH
Gutenbergstr. 2
46414 Rhede
Germany
http://www.bresser.de
If you wish to submit a warranty claim or service request, please refer to the “Warranty” and “Service”
information in this document. Please be aware that any requests or submissions sent directly to the
manufacturer cannot be processed.
Errors excepted. Subject to technical modifications.
© 2018 Bresser GmbH
All rights reserved.
Reproduction of this document, including extracts, in any form (photocopied, printed etc.) or the use
and distribution of this document by electronic means (image file, website etc.) is not permitted without
the prior written consent of the manufacturer.
The terms and brand names of the respective companies used in this document are protected by
brand, patent or product law in Germany, the European Union and/or other countries.
2 Validation
This document is valid for the products with the following part numbers:
7060100
Version of manual: v012018
Name of manual: Manual_7060100_MyTime-Crystal-P-Colour_en_BRESSER_v012018a
Information is always provided for service requests.
3 Features
• Color display of the weather trend by means of 3D symbols in a crystal look
• Projection of the current time onto walls or ceilings
• Temperatur und Luftfeuchtigkeit (indoor and outdoor)
• Date and weekday display
• Alarm clock with snooze function
• Switchable illumination
• Incl. remote sensor, power adapter and cable
4 About this manual
NOTICE
This instruction manual should be considered part of the device.
Before using the equipment, read the safety instructions and operating instructions carefully.
Keep this instruction manual in a safe place to refer to at a later date. If the equipment is sold or
passed on, the instruction manual must also be passed on to each subsequent owner of the product.

5 / 16
5 General safety instructions
DANGER
Risk of electric shock
This device has electronic parts operated via a power source (power supply and/or batteries). Im-
proper use of this product can cause an electric shock. An electric shock can cause serious or poten-
tially fatal injuries. The following safety information must be observed at all times.
• Children must only use the device under adult supervision! Only use the device as described in the
manual; otherwise, you run the risk of an electric shock.
• Disconnect the device from the power supply by pulling the power plug when it is not used or in
case of longer interruption of operation and before starting any work on maintenance and cleaning.
• Position your device so that it can be disconnected from the power supply at any time. The power
socket should be installed near the device and should be easily accessible as the mains cable
plug is used to disconnect the device from the power supply.
• To disconnect the device from the power supply, always pull on the plug. Never pull on the cable.
• Before starting up the device, check the device, the cables and the connections for signs of dam-
age.
• Never use a damaged device or a device with damaged live parts. Damaged parts must be imme-
diately replaced by an authorised service company.
• Only use the device in complete dry environment and do not touch it with wet or moist parts of
your body.
DANGER
Risk of suffocation
Improper use of this product can result in suffocation. This is particularly dangerous for children. The
following safety information must be observed at all times.
• Keep packaging materials (plastic bags, rubber bands etc.) away from children. They can cause
suffocation.
• This product contains small parts that could be swallowed by children. There is a risk of choking!
DANGER
Risk of explosion
Improper use of this product can cause an explosion. The following safety information must be ob-
served at all times to prevent an explosion.
• Do not expose the device to high temperatures. Use only the supplied power supply or the recom-
mended batteries. Do not short-circuit the device or batteries or throw them into a fire! Excessive
heat or improper handling could trigger a short circuit, a fire, or an explosion.
NOTICE
Risk of damage to property
Improper handling can result in damage to the device and/or to the accessories. Always observe the
following safety information when using the device.
• Never disassemble the device. In the event of a fault, please contact your specialist retailer. The
specialist retailer will contact the service centre and send the device for repair if necessary.
• Do not expose this device to higher temperatures and protect it from water and high humidity.

6 / 16
• Do not immerse the unit in water!
• Protect the device from severe shocks!
• For this device only use accessories and spare parts that comply with the technical information.
• Use only the recommended batteries. Always replace weak or empty batteries with a new, com-
plete set of batteries at full capacity. Do not use batteries from different brands or with different ca-
pacities. Remove the batteries from the unit if it has not been used for a long time.
• Never use rechargeable batteries.
NOTICE
Risk of voltage damage!
The manufacturer is not liable for voltage damage due to improperly inserted batteries or through the
use of an improper power adapter!
6 Parts overview and scope of delivery
23
5
1
15
11
6710
14 12
13
8
9
4
16 17
18
19 19 23
24
20
21
22
26
25
A
B
C
Illustration1: Parts overview for base station (top) and remote sensor (bottom)

7 / 16
1 LCD 2 SNOOZE/LIGHT button (snooze function
and temporary bright display and projec-
tion)
3 Projector lens (projection of current time
or alarm time)
4 Projector arm (rotatable by 180 degrees)
5 Weather trend display with 3D holography
effect / Perspex pillar (Red, green, white
or blue light display depending on the
weather trend)
6 MODE button (time mode selection)
7 MAX/MIN button (switch between highest,
lowest or current value display)
8 UP/°C/°F button (value setting upwards or
display change)
9 DOWN button (value setting downwards) 10 ALARM/SET button (alarm time setting or
display change)
11 CHANNEL button (channel selection) 12 Battery compartment cover (Base station)
13 DC connection socket for coaxial/barrel
connector
14 Battery compartment
15 Focusing wheel 16 Function indicator (data transmission)
17 Wall mount 18 Battery compartment cover (Remote
sensor)
19 Fixing screw (battery compartment cover) 20 RESET button (initialize data transmis-
sion)
21 Channel selector switch 22 Battery compartment (Remote sensor)
23 Sealing frame 24 TX button
25 DC power adapter with EU mains plug. 26 DC coaxial/barrel connector
Scope of delivery
Base station (A), remote sensor (B), power adapter (C), 5 pcs. micro batteries (1.5V, AAA type)
Also recommended (not included):
small Philips screwdriver
7 Screen display
123
4
5
6
18
17
16
14
7
8
9
15 13
10
12
11
28
29
19
27 26 25
24
23
22
21
20
Illustration2: Screen display for the base station

8 / 16
1 Current time (hours) 2 Current time (minutes)
3 Snooze function enabled 4 Alarm enabled
5 Battery level (base station) 6 Current time (seconds)
7 Indoor temperature 8 Relative humidity (indoor) in %
9 Temperature trend (indoor) (rising, steady
or falling)
10 Relative humidity (outdoor) in %
11 Selected channel for remote sensor 12 Temperature unit (°C or °F selectable)
13 Outdoor temperature 14 Battery level (remote sensor)
15 Temperature trend (outdoor) 16 Weekday
17 Month 18 Day
19 Alarm time (minutes) 20 Symbol for alarm time setting
21 Highest or lowest value for indoor temper-
ature (depending on 18)
22 Highest or lowest value for indoor humidity
(depending on 23)
23 Symbol for highest (MAX) or lowest (MIN)
value (indoor)
24 Highest or lowest value for outdoor humid-
ity (depending on 25)
25 Symbol for highest (MAX) or lowest (MIN)
value (outdoor)
26 Highest or lowest value for outdoor tem-
perature (depending on 25)
27 Symbol for channel rotation 28 Year
29 Alarm time (hours)
8 Before starting operation
NOTICE
Avoid connectivity disruptions!
To avoid connectivity disruptions between the devices, consider the following points before starting
operation.
1. Place base station (receiver) and remote sensor (sender) together as close as possible.
2. Set up power supply for the base station and wait until the indoor temperature is displayed.
3. Set up power supply for the remote sensor.
4. Position the base station and the remote sensor within the effective transmission range.
5. Ensure that the base station and remote sensor are assigned to the same channel.
When changing batteries always change batteries in the main unit as well as all remote units and re-
place them in the correct order, so the remote connection can be re-established. If either of the
devices is mains-powered, the power supply must be disconnected for a short moment also for this
device when exchanging the batteries. If batteries are exchanged in only one of the devices (i.e. the
remote sensor) the signal can’t be received or can’t be received correctly.
Note, that the effective range is vastly affected by building materials and position of the main and re-
mote units. Due to external influences (various RC devices and other sources of interference), the
maximum distance can be greatly reduced. In such cases we suggest to position the main unit and the
remote sensor at other places. Sometimes all it takes is a relocation of one of these components of a
few inches! Though the remote unit is weather proof, it should be placed away from direct sunlight,
rain or snow.
9 Setting up power supply
Base station
1. Put the DC connector into the connection socket of the base station.
2. Put the mains plug into the power outlet.
3. The device is energized directly.

9 / 16
4. Wait until the indoor temperature is displayed on the base station.
NOTICE!For permanent operation, mains power supply is recommended. Alternatively a
power supply with batteries is also possible. Proceed as follows:
5. Remove the battery compartment cover.
6. Insert the batteries into the battery compartment. Ensure that the battery polarity (+/-) is correct.
7. Replace the battery compartment cover.
8. Wait until the indoor temperature is displayed on the base station.
NOTICE!When switching from mains power supply to battery power supply or vice versa,
the power supply is being disabled for a short moment for technical reasons. In this process
all settings made previously, will be deleted.
Remote sensor
1. Loosen the screws at the battery compartment cover with a small Philips screwdriver and remove
the cover.
NOTICE!Make sure not to lose the thin silicone sealing frame when removing the battery
compartment cover. It is an important protection against water infiltration and often ad-
heres at the battery compartment cover.
2. Insert the batteries into the battery compartment. Ensure that the battery polarity (+/-) is correct.
3. Set the channel selector switch to the desired channel (1, 2 or 3).
NOTICE!This weather station can be operated with up to 3 remote sensors. Each remote
sensor being connected must be operated on a different channel. If only one remote sensor
is connected, it should be operated on channel 1. Always press TX button after changing the
channel.
4. Press RESET button. The function indicator lights up for a short moment.
5. Put the sealing frame back onto the edge of the battery compartment.
6. Replace the cover and retighten it with the screws.
10 Manual time setting
1. Press and hold SET button for approx. 2 seconds to change to time setting mode.
2. Digits to be set are flashing.
3. Press UP or DOWN button to change the value.
4. Press SET button to confirm and continue to the next setting.
5. Settings order: Hours > Minutes > Change day/month display > Language > Year > Month >
12/24-hours mode
6. Finally press the SET button to save the settings and exit the setting mode.
11 Alarm setting
1. Press MODE button to switch to alarm time display.
2. Press and hold ALARM button for approx. 2 seconds to enter the alarm time setting mode (AL).
3. Digits to be set are flashing.
4. Press UP or DOWN button to change the value.
5. Press ALARM button to confirm and continue to the next setting.
6. Settings order: Hours > Minutes
7. Finally press the ALARM button to save the settings and exit the setting mode. Alarm will be activ-
ated automatically. The symbol will be displayed.
8. Press MODE button in normal display mode to display the alarm time.

10 / 16
9. Press ALARM button during the alarm time display to disable the alarm. The symbol will not be
displayed.
12 Snooze function
1. When the alarm sounds, press SNOOZE button to activate the snooze function. The alarm will
sound again in 5 minutes.
2. Press ALARM button when the alarm sounds to interrupt the alarm until the alarm time will be
reached again.
3. The alarm will be turned off automatically if no button is pressed within 2 minutes.
13 Receiving measurements automatically
Once the power supply is enabled, the base station will display the measurement readings. Readings
from the remote sensor will be displayed within 3 minutes after powering it on.
Read the detailed manual for more information about readings (see download information on page 2).
14 Manual measurement display
1. Press MAX/MIN button several times to display the stored values one after another.
2. Display order: Current values > MAX (highest values) > MIN (lowest values)
3. When displaying highest or lowest values, press and hold MAX/MIN button for approx. 3 seconds
to delete all saved values.
15 3D weather trend display
The weather trend for the next 12 hours is calculated from the measured values. It is displayed in col-
our through the 3D symbols of the perspex pillar:
1234
Illustration3: Weather trend indicators
1 Sunny (red) 2 Partly cloudy (green)
3 Cloudy (white) 4 Rain (blue)
16 MAX/MIN Weather data
The main unit saves highest and lowest value records for indoor and outdoor temperature as well as
for humidity for 24 hours:
1. Press MAX/MIN button several times to display the stored values one after another.
2. Display order: Highest values > Lowest values > Current values
3. All values of the current recording period will automatically be deleted after 24 hours.
