Bretford EDUIMS Configuration guide

EDUIMS
INTERACTIVE MEDIA
STATION
Assembly Instructions
022-3188 - Qty 1
Bottom Frame Assembly
022-3187 - Qty 1
Upper Frame Assembly 022-3655
Qty 1
Support
Assembly
010-7267 - Qty 2
Vertical Support Panel
010-7266 - Qty 1
Bottom Support
Panel RH
010-7264 - Qty 1
Main Support
017-1480 - Qty 2
Monitor Support Tube
010-7265 - Qty 1
Bottom Support
Panel LH
030-1990 - Qty 1
770N Gas Spring
010-4953 - Qty 2
Hook Bar
060-1465 - Qty 1
Handle Assembly
060-1466 - Qty 2
Storage Bucket
010-6227 - Qty 1
Laptop Tray
010-6127 - Qty 1
Cable Retention
Bracket
E6 Unit - Qty 1
060-0926 - Qty 1
Articulating Arm

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
2
030-0304 - Qty 16
1/4-20 X 5/8” Combo
Trus Screw
030-0913 - Qty 16
Flat Washer
030-0538 - Qty 10
1/4-20 x 1 1/4” Carriage Bolt
030-0207 - Qty 16
1/4-20 Hex Nut
030-1204 - Qty 8
10-32 KEPS Nut W/ Tooth
030-0865 - Qty 4
#6 x 1/2” Button Pin-In
Hd Screws
030-0354 - Qty 2
10-32 x 1 1/2” Button
Sockets Screws
015-0176 - Qty 4
4” Stem Caster w/Brake
030-1657 - Qty 8
10-32 x 1.25”L Button Hd Screw
030-0291 - Qty 4
#10-32 x 1/2” Truss Head Screw
030-1026 - Qty 2
1/4-20 x 3/4” Phillips Screw
012-0692 - Qty 2
Black Vinyl Cap
012-0696 - Qty 2
1” Knurled Knob
030-1569 - Qty 2
Foam Pad
030-1571 - Qty 4
1” Square Black
Foam
030-1621 - Qty 2
Foam Pad
030-0240 - Qty 2
1/4” Lockwasher
030-0272 - Qty 2
1/4-20 x 1/2” Carriage
Bolt
010-4956 - Qty 2
Stop Bracket
010-6228 - Qty 2
Outer Bracket
030-0845 - Qty 4
M4 x 0.7 20mm
Pan Hd Screw
030-1267 - Qty 4
M4 Nut
Courtesy Monitor
Hardware Pack
044-2124 - Qty 1

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
3
1
Lock
Lock
Lock
022-3188
(1)x
015-0176
(4)x
TWO PERSON ASSEMBLY REQUIRED

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
4
2
Correct Position
Faces
shorter
side
030-0538
(4) 2x
030-0207
(4) 2x
022-3187
(1)x

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
5
030-1990
(1)x
030-0538
(1)x
030-0207
(1)x
3

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
6
022-3655
(1)x
4

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
7
030-0207
(1)x
030-0538
(1)x

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
8
5
010-7267
(2)x
030-0304
(12)x
010-7265
(1)x
010-7266
(1)x

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
9
6
030-0913
(16)x
030-1657
(8)x
017-1480
(2)x
030-1204
(8)x

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
10
7
030-0207
(4)x
1st hole
from bottom
3rd hole
from bottom
030-0304
(4)x
010-7264
(1)x

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
11
8
Attach both hook bars onto the back of your monitor using the mounting holes built into the case. A
courtesy hardware pack has been provided with several metric screw sizes. You may need to purchase
additional metric screws from your local hardware store for a monitor with different mounting screw size.
Top
Bottom
Screws provided in
courtesy hardware
pack #044-2124.
010-4913
(2)x

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
12
9
TWO PERSON ASSEMBLY REQUIRED
MONITOR
NOT SHOWN
FOR CLARITY
Hook monitor onto main support bar as shown.

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
13
10
Attach the stop brackets to the hook
bars as shown with security screws
using the driver bit provided.
030-0865
(2) 2x
010-4956
(1) 2x

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
14
11
Center your monitor horizontally and then tighten in place with screws
010-0354
(2)x

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
15
060-1465
(1)x
030-0291
(4)x
12

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
16
13
E6 Unit
(1)x

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
17
14
When attaching the cable to the cylinder,
be very careful not to pull up on the
lever. By doing this it may cause the
cylinder to spring up.
Hook end of cable onto cylinder Slide in place
030-1611
(1)x

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
18
15
010-6127
(1)x

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
19
16
Slide cable through hole in
handle assembly

Interactive Media Station 031-10725 Rev. 01 11.09.16
Assembly Instructions
20
17
Slide cable through eye lit hole
and slide into slot
Bottom View
