the Smart AirTM Connect Purifier
Instruction Book - LAP308

2
BREVILLE
RECOMMENDS
SAFETY FIRST
At Breville we are very safety
conscious. We design and
manufacture consumer
products with the safety of you,
our valued customer, foremost
in mind. In addition, we ask that
you exercise a degree of care
and adhere to the following
precautions.
SPECIFICATIONS
Filter Life Approx. 6 months
Microbe ShieldTM Life Approx. 10,000 hours
Product Dimension 231 x 391mm
For Room Size 30 to 40m²
Noise Level 30~60dB
Power Consumption 30W
Weight 4kg
OS Compatibility Android®5.0 or later and
iOS 9.0 or later
IMPORTANT
SAFEGUARDS
READ ALL
INSTRUCTIONS BEFORE
USE AND SAVE FOR
FUTURE REFERENCE
• Remove and safely discard
any packaging material and
promotional labels before
using the air purifier and filter
for the first time.
• To eliminate a choking
hazard for young children,
remove and safely discard the
protective cover fitted to the
power plug of this air purifier.
• When unpacking the air
purifier, check to see you have
received all the items listed in
the parts list, before discarding
the packaging.
• This air purifier is intended for
household use only and not for
commercial or industrial use.
• Do not use outdoors.
• Always ensure the air purifier
is properly assembled before
use. Follow the instructions
provided in this book.
2 Breville Recommends Safety First
6 Components
7 Control Panel
8 Features
8 Assembly
9 Functions
11 WI-FI Connectivity
12 Care, Cleaning & Storage
14 Troubleshooting
Contents

3
• Do not place the air purifier
near the edge of a bench
or table during operation.
Ensure the surface is level,
clean and free of water.
• Keep the power cord out of
heavy traffic areas. To avoid
fire hazard, never put the
cord under rugs, near heat
registers, radiator, stoves or
heaters.
• To protect against electrical
hazards, do not immerse in
water or other liquids. Do
not use the air purifier in the
immediate surroundings of
a bath, a shower or a
swimming pool.
• Children should be
supervised to ensure they do
not play with the air purifier.
• Always turn off and unplug
the air purifier before moving,
opening the grill, changing
filters, cleaning or whenever
the air purifier is not in use.
• Do not unplug the air purifier
by pulling on the power cord.
Always unplug using the
power plug.
• Never insert fingers, pencils
or any other objects through
the guards whenever the
power plug is connected,
in particular, while the air
purifier is switched on.
• Do not run the power cord
under carpeting or cover the
power cord with rugs, runners
or the like. Arrange the power
cord away from traffic areas
and where it will not be
tripped over.
• Do not route power cord
under furniture or appliances.
• Do not operate the air purifier
with a damaged power cord
or plug, or if the air purifier
has been dropped or
damaged in any manner.
Take the air purifier to your
nearest Breville service centre
for examination, electrical or
mechanical adjustment or
repair.
• Do not use the air purifier
with an external timer,
programmer or any other
device that switches the air
purifier on automatically
since a fire risk may exist if
the air purifier is covered or
positioned incorrectly.
• Do not place anything on
top of the air purifier when
assembled, when in use and
when stored.
• Never block the air openings,
grills/outlets or place on a soft
surface such as a bed or sofa,
as this could cause the unit to
tip over, blocking the air inlet
or outlet opening.
• Do not attempt to repair

4
or adjust any electrical or
mechanical functions on this
unit. Doing so will void your
warranty. Other than the filter,
the inside of the unit contains
no user serviceable parts. All
servicing should be performed
by qualified personnel only.
• This air purifier contains a
UV-C emitter.
• Unintended use of the
appliance or damage to the
housing may result in the
escape of dangerous UV-C
light radiation. UV-C light
radiation may, even in little
doses, cause harm to the eyes
and skin.
• Keep the air purifier and
dust filters clean. Follow the
cleaning instructions
provided in this book.
IMPORTANT
SAFEGUARDS FOR
ALL ELECTRICAL
APPLIANCES
• Fully unwind the power cord
before use.
• Connect only to a 230V or
240V power outlet.
• Do not let the power cord
hang over the edge of a bench
or table, touch hot surfaces or
become knotted.
• To protect against electric
shock, do not immerse the
power cord, power plug or
appliance in water or any
other liquid or allow moisture
to come in contact with the
part, unless it is recommended
in the cleaning instructions.
• The appliance is not
intended for use by persons
(including children) with
reduced physical, sensory
or mental capabilities, or
lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
• Children should be
supervised to ensure that they
do not play with the appliance.
• It is recommended to
regularly inspect the
appliance. To avoid a hazard,
do not use the appliance if
power cord, power plug or
appliance becomes damaged
in any way. Return
the entire appliance to
the nearest authorized
Breville Service Centre for
examination and/or repair.
• Any maintenance other than

5
cleaning should be performed
at an authorised Breville
Service Centre.
• This appliance is for
household use only.
Do not use this appliance
for anything other than its
intended use. Do not use in
moving vehicles or boats.
Do not use outdoors.
Misuse may cause injury.
• The installation of a residual
current device (safety switch)
is recommended to provide
additional safety protection
when using electrical
appliances. It is advisable that
a safety switch with a rated
residual operating current not
exceeding 30mA be installed
in the electrical circuit
supplying the appliance.
See your electrician for
professional advice.
• During electrical storms,
the appliance should be
disconnected from the power
source at the wall socket
to prevent any electrical
surges that may arise during
the storm and which may
inadvertently cause damage
to the appliance and its
electronic componentry.
• Always turn the appliance to
the off position, switch off
at the power outlet and
unplug at the power outlet
when the appliance is not
in use.
• Before cleaning, always turn
the appliance to the off
position, switch off at the
power outlet, unplug at the
power outlet and remove the
power cord, if detachable,
from the appliance and allow
all parts to cool.
• Do not place this appliance
on or near a heat source, such
as hot plate, oven or heaters.
• Position the appliance at a
minimum distance of 20cm
away from walls, curtains and
other heat or steam sensitive
materials and provide
adequate space above and on
all sides for air circulation.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS

6
Components
A. Air Outlet
B. Control Panel
C. Main Housing Body
D. Air Quality Sensor
E. Air Inlet
F. Microbe ShieldTM Light and Light Guard
G. 3-Layer Filter
H. Base Plate
I. Locking Knob
NOT PICTURED
Power Cord
A
B
C
D
E
G
F
H
I

7
TIMER SPEED
M
I
C
R
O
B
E
S
H
I
E
L
D
2H 4H 8H LOW MED HIGH
TURBO
RESET
FILTER
AUTO
Control Panel
A. Power On/Off
B. Microbe ShieldTM/Night Mode/Reset Filter
C. Timer
(up to 8 hours)
D. Fan Speed
(includes 4 speed modes; Low, Medium, High and Turbo)
E. Air Quality Sensor Light
E
D
B
A
C
+
Hold for 5 seconds to activate
Wi-Fi pairing

8
YOUR BREVILLE AIR PURIFIER
Your Breville Smart AirTM Connect Purifier
improves your indoor air quality using
4 distinct levels of protection.
1. A Pre-Filter
Captures larger airborne particles such as
human hair, pet dander and dust particles.
2. A True HEPA Filter
Traps up to 99.97% of allergens and
airborne contaminants down to 0.3 microns
in size. These include lung-damaging dust,
mould spores, plant spores, and pollen.
3. An Activated Carbon Membrane
Along with assisting in the capture of
dust, smoke, pollen and other airborne
allergens, the activated carbon membrane
helps to neutralise odours in the home and
to eliminate fumes emitted by household
products as well as other volatile organic
compounds (VOC’s) that might be found
in the air.
4. Microbe ShieldTM Technology
Microbe ShieldTM technology uses a
shortwave UV-C light specially designed
to target germs and bacteria from the
incoming air as it passes through the air
purifier before releasing the air back into
the surrounding area. The Microbe ShieldTM
function can be turned on and off according
to preference.
Assembly
Features
BEFORE FIRST USE
• Remove and safely discard any packaging
material or promotional labels attached to
your air purifier and filter.
• Remove the filter from the air purifier
(see REPLACING THE FILTER on page 11)
and take it out of the plastic bag. Then
re-insert the filter into the air purifier.
• Select a flat and level location for the
air purifier.
• For proper air flow, locate the unit at least
20cm from any wall or furniture.
• Ensure the air inlet and outlets are not
blocked before use.
• Plug the power plug into a 230V OR 240V
power outlet and turn on the power outlet.
IMPORTANT
When moving the air purifier, always lift the
unit using two hands and set down gently on
a flat and level surface.

9
Functions
OPERATING YOUR AIR PURIFIER
1. Press the POWER button to turn on and
the On/Wi-Fi reset light will illuminate.
2. The air quality sensor light will illuminate,
usually starting with a blue light until it has
time to sense the air quality and then it may
change to an alternate colour.
3. To adjust how the air purifier operates,
follow the directions below.
SensAirTM LIVE PURITY CONTROL
• Your Breville Smart AirTM Connect Purifier has
a built-in air quality sensor to detect changes
to air quality in the surrounding area.
• The SensAirTM indicator light around the
control panel will change colours according
to the quality of the surrounding air.
Grade Air Quality Colour of Light
1Very Good Blue
2Good Yellow
3Fair Orange
4Poor Red
Microbe ShieldTM/NIGHT MODE/
RESET FILTER
The Microbe ShieldTM Mode, Night Mode
and Reset Filter utilise the same button on
the control panel. Pressing the Microbe
ShieldTM/NIGHT/RESET FILTER button will
cycle through the Microbe ShieldTMand Night
Modes.
Microbe ShieldTM
• Press the Microbe ShieldTM/NIGHT MODE/
RESET FILTER button until the Microbe
ShieldTM indicator light illuminates to turn
Microbe ShieldTMon.
• To turn off the Microbe ShieldTM during night
mode, press the Microbe ShieldTM/NIGHT
MODE/RESET FILTER button again. Microbe
ShieldTM will turn off automatically, and the
lights will remain dimmed.
• To turn off night mode, press the Microbe
ShieldTM/NIGHT MODE/RESET FILTER
button again. All lights should return to normal.
• Alternatively, press again until the light
extinguishes to turn off this function.
Filter Reset
• When the filter reset light blinks continuously,
this is indicating that the filter needs to
be replaced.
• To reset the indicator after the filter has been
replaced, press and hold the Microbe ShieldTM/
Night Mode/Filter Reset button for 5 seconds
and the filter reset light will turn off.
Night Mode
• To turn on Night Mode, press the Microbe
ShieldTM/NIGHT MODE/RESET FILTER
button until the night indicator light starts
to blink.
• After 10 blinks, all indicator lights on
the control panel will turn off as the unit
enters night mode and the fan speed will
automatically change to Low.
• Press any button on the control panel to
re-engage the control panel and turn off night
mode. The indicator light will extinguish.

10
FAN SPEED/TURBO MODE
NOTE
The air purifier will resume in the last
programmed setting once it has been turned
off, even if turned off at the power outlet. If the
last programmed setting was Night mode, once
turned on, the control panel will illuminate
with the Night indicator light blinking as a
reminder that Night mode has been set.
• Press the FAN SPEED button repeatedly
until the desired speed is illuminated on the
control panel.
• There are 4 fan speeds: Low, Medium, High
and Turbo.
• The purifier has reached Turbo mode when
all three lights are illuminated on the control
panel at the same time.
NOTE
When changing the fan speed, the unit may
take a few seconds to adjust.
TIMER
• The air purifier can be set to operate for
timed intervals of 2 hours, 4 hours and 8
hours, stopping automatically when the
selected operating time has elapsed. If no
timer is set, the air purifier will continuously
operate until it is manually switched off.
• Press the TIMER button repeatedly until
the desired interval hours are illuminated on
the control panel.
• For continuous operation, press the
TIMER button repeatedly until there are no
lights illuminated under the timer intervals.
AUTO MODE
• When in Auto mode, the air purifier will
automatically adjust the speed to help filter
the air based on the sensor reading.
• To set to Auto, press the POWER button
continuously until the Auto indicator light
illuminates.
• Press the POWER button or the Fan
Speed button, to turn Auto off and beneath
Auto indicator light will extinguish.
IMPORTANT
Turning the unit On and Off will require
cycling through the Auto mode.
FILTER RESET
• The Filter reset light will blink continuously
indicating that the filter needs to be replaced.
• Replace the filter according to the directions
found under Replacing the Filter in this book.
• Once the filter is replaced, press and hold
the Microbe ShieldTM/Night Mode/Filter
Reset button for 5 seconds to reset the Filter
Reset light.
• The built-in timer for the filter reset is 4,320
operating hours.
NOTE
For best performance, the filter should be
cleaned at least monthly as per the Instructions
found in the Care, Cleaning & Storage section
of this book.

11
Wi-Fi
Connectivity
The Breville Smart AirTM Connect Purifier can
offer remote operation by using a home Wi-Fi
connection and the Breville Home Connect™
app downloaded to a compatible mobile
phone. through the Google Play store or Apple
App store.
To go straight to the appropriate app store,
scan the QR code below.
For instructions on how to use the app, scan the
QR code below, refer to the Quick Start Guide
that can be found in the box or go to
tinyurl.com/HomeConnectQuickStart.
NOTE
The Breville Home Connect™ app is
compatible with mobile phones running
Android®5.0 or later and iOS devices 9.0
or later.
NOTE
To control the purifier using the app, the
purifier must be plugged into an active power
outlet and switched on at the power outlet.
If the purifier is turned OFF or disconnected
from the power outlet, then the app cannot
connect to the purifier via the network.
CONNECT YOU PURIFIER TO WI-FI
1. Ensure the mobile device is connected to a
home Wi-Fi network.
2. To set up the purifier, turn the purifier on
at the power outlet. The purifier must be
turned on via the control panel. Press and
hold the and buttons at the same
time for 5 seconds, until the symbol light
is flashing rapidly. The purifier is now ready
to connect.
3. Log into your Breville Home Connect™
app account and stay on the “Home” page.
To add the purifier to the list, touch ‘Add
Device’ or the symbol found in the top
right-hand corner of the screen. Follow the
prompts in the app.
4. If the connection is successful, the purifier
will appear in the main page of the app
and the symbol light on the purifier will
illuminate.

12
Care, Cleaning
& Storage
The air purifier and filter should be cleaned at
least once every month. Ensure the air purifier
is switched off and disconnected from the
power outlet and allow all parts to cool before
cleaning or storing.
• Use a clean, dry cloth to clean all external
surfaces of the air purifier.
• Store the air purifier in an upright position.
Do not store anything on top of the air
purifier.
NOTE
More frequent cleaning may be required
depending on environmental conditions.
BREVILLE RECOMMENDS
• Always ensure the air purifier is turned
off, switched off at the power outlet and
unplugged and allow the unit to cool
before performing any cleaning or filter
replacement.
8 DO NOT stick any foreign objects or your
fingers inside the air inlet/outlet of this unit.
8 DO NOT use gasoline, benzine, thinner,
harsh cleaners, etc. on and/or in the unit
while cleaning as they will damage the unit.
8 NEVER use alcohol or other solvents
on this unit.
CLEANING THE SENSOR
• It is important to keep the air quality sensor
clean for best performance.
• The air quality sensor is situated behind a
grill at the rear of the unit.
• Gently vacuum the air quality sensor grill
using a small hand brush tool. Cleaning
should occur regularly, at least once a month.
• If more dust can be seen on the sensor
behind the grill then remove the cover by
using the raised tab on the edge of the cover.
Push inwards and outwards simultaneously
to open the cover, noting that it will be tight.
• Gently vacuum the metal shield of the air
quality sensor using the hand brush tool.
• Replace the cover when clean, ensuring it
clicks into place.
WARNING
The air quality sensor is fragile and can be
damaged if excessive force is used during
cleaning. Please use extra care when cleaning.
FILTER CLEANING AND REPLACING
WARNING
The filter is not washable. Do not immerse any
part of the air purifier in water as it will cause
damage.
• The Pre-filter should be cleaned at least once
every month using a vacuum cleaner. Gently
vacuum using a hand-tool attachment such
as a brush or upholstery tool. Clean more
often if required.
• Do not attempt to clean the carbon filter with
a vacuum as this can cause damage.
• Do not use any solutions, hard bristle
brushes or sharp objects to clean as this
can cause damage.
• Replace the filter as indicated using the
instructions following.

13
REPLACING THE FILTER
Your Smart AirTM Connect Purifier filter should
be replaced in the time frames indicated below.
• The filter life is approximately 6 months if
used 24 hours daily, or 12 months if used
12 hours daily.
• The filter life may vary to this timing
depending on environmental conditions.
• Remove all packaging from the replacement
filter and place the filter into the unit as
described below.
1. Carefully, turn your air purifier upside down
and remove the locking knob from the base
of the unit.
2. Remove the base plate.
3. Remove the used filter, being careful that
any residue or debris that may fall from the
filter will not cause damage.
4. Insert the replacement filter into the unit,
ensuring that it is correctly fitted and
centred.
5. Replace the base plate and refasten the
locking knob.
6. Return the air purifier to an upright
position.
7. Turn on the air purifier then press and hold
the Microbe ShieldTM/Night Mode/Filter
Reset button for 5 seconds to reset the Filter
Reset light.
NOTE
There is no top or bottom on the filter. The
filter can be placed into the unit either way.
NOTE
If the filter is not in place or not fitted correctly,
the air purifier will not operate.
WARNING
Unintended use of the air purifier or damage
to the housing may result in the escape of
dangerous Microbe ShieldTM UV-C radiation
which is dangerous to the eyes and skin.
Never operate the UV-C light outside of the air
purifier.
UV-C LIGHT CARE
The replacement of the UV-C light must be
undertaken at an authorised Breville service
centre. Please contact Breville Customer
Service Centre for further support.
REPLACEMENT FILTERS
Replacement filters can be purchased from
the Breville website^ or at participating retail
outlets.
See the table below for the replacement
product code to suit this Breville AirPurifier.
Breville AirPurifier
Model No.
Filter Replacement
Product Code
the Easy AirTM Connect
LAP158WHT
LAP015WHT
the Smart AirTM Connect
LAP308WHT
LAP030WHT
the Smart Air PlusTM
Connect
LAP508WHT
LAP050WHT
^Delivery charges may apply.
Please contact Breville Customer Service
Centre for further support.
Only use the original Breville filter specially
intended for this appliance. Do not use any
other filters.

14
Troubleshooting
MINI TROUBLESHOOTING GUIDE
Before carrying out any of the following service
checks, unplug the unit from the mains.
PROBLEM WHAT TO DO
Unit will not start. • Check that the power plug is connected to a power outlet
and the outlet is turned on.
• Check that air purifier is assembled correctly.
• Check that the filter is fitted correctly in place.
Insufficient air flow. • Check that the filters are clean.
• Check for any obstructions in the air inlet and/or outlet.
Excessive noise. • Check for any foreign objects that may be in contact with the fan.
• Check if the filter is clogged and ready for replacement.
• Check that the air purifier has been assembled correctly and the
locking knob has been tightened.
• Check that the unit is on a level surface.
UV-C Light not illuminating • Contact Breville service centre for UV-C light replacement.

15
NOTE

Australian Customers
Phone: [phone]
Web: www.breville.com
New Zealand Customers
Phone: [phone]
Web: www.breville.com
Breville Customer Service Centre
Breville, the Breville logo, Master Every Moment, Smart Air, SensAir, Breville Home Connect and
the Microbe Shield logo are trademarks of Breville Pty. Ltd. A.B.N. 98 000 092 928.
Copyright Breville Pty. Ltd. 2020.
Due to continued product improvement, the products illustrated/photographed in this booklet
may vary slightly from the actual product.
LAP308 ANZ A20
