Breville Juice & Blend BJB840 User manual

Juice & Blend
Instruction Book
BJB840
The Juice & Blend
Instruction Booklet

CONGRATULATIONS
On the purchase of your new
Breville Juice & Blend

3
CONTENTS
4Breville recommends safety first
7How to Use as a Juice Extractor
8Know your Breville Juice Extractor
10 Assembling the Juice Extractor
13 Operating the Juice Extractor
17 Disassembling the Juice Extractor
20 Cleaning the Juice Extractor
22 Juice Extractor Troubleshooting
27 How to Use as a Blender
28 Know your Breville Blender
30 Assembling the Blender
33 Operating the Blender
37 Disassembling the Blender
39 Cleaning the Blender
41 Blending tips
43 Blender Troubleshooting
47 Recipes
69 One year limited warranty

4
BREVILLE RECOMMENDS SAFETY FIRST
READ ALL INSTRUCTIONS
BEFORE USE AND SAVE FOR
FUTURE REFERENCE
• Carefully read all instructions before
operating the appliance for the first time
and save for future reference.
• Remove and safely discard any
packaging materials and promotional
labels before using the appliance for the
first time.
• To eliminate a choking hazard for young
children, remove and safely discard the
protective cover fitted to the power plug
of this appliance.
• To protect against electrical shock, do not
immerse the power cord, power plug or
motor base in water or any other liquid.
• Always use the appliance on a dry,
level surface.
• Do not use the appliance on a sink
drain board.
• Do not place the appliance near the
edge of a bench or table during
operation. Vibration during operation
may cause the appliance to move.
• Do not place the appliance on or near
a hot gas or electric burner, or where it
could touch any other source of heat.
• Unwind the power cord fully before use.
• Do not allow the power cord to hang
over the edge of a table or counter, touch
hot surfaces or become knotted.
• Always ensure the appliance is
completely assembled before
connecting to the power outlet and
operating. The appliance will not turn on
unless properly assembled. Follow the
instructions provided in this book.
• Always make sure the safety locking
bar is securely in place before the motor
is turned on. Do not unfasten the safety
locking bar while the appliance is
in operation.
• Always avoid contact with moving parts.
• Strictly follow the care and cleaning
instructions described in this book.
• This appliance is for household use only.
Do not use the appliance for anything
other than its intended purpose as
described in this book. Do not use
outdoors. Do not use in moving
vehicles or boats.
• The use of attachments not sold or
recommended by Breville may cause fire,
electric shock or injury.
• Do not leave the appliance unattended
when in use.
IMPORTANT SAFEGUARDS
At Breville we are very safety conscious. We design and manufacture consumer products with
the safety of you, our valued customer, foremost in mind. In addition we ask that you exercise
a degree of care when using any electrical appliance and adhere to the following precautions.

5
BREVILLE RECOMMENDS SAFETY FIRST
5
WHEN USING THE
APPLIANCE AS A
JUICE EXTRACTOR
• Do not operate the juice extractor
without the pulp container in place
• Do not use the juice extractor if the
rotating filter basket is damaged.
• Do not touch the small sharp teeth and
blades in the center of the filter basket.
• Do not touch the blade in the feed chute.
• Do not push produce into the feed chute
with your fingers. Always use the food
pusher provided.
• Do not load feed chute with food before
the motor is running.
• Do not juice stone fruit unless seeds
and/or stones have been removed.
• Always switch the juice extractor off
after each use. Ensure the motor stops
completely and unplug the power cord
from the wall outlet before attempting
to move the appliance, before cleaning,
disassembling, assembling and when
storing the appliance.
WARNING
Super wide feed chute. Do not place
hands or foreign objects down feed
chute, always use food pusher provided.
WHEN USING THE
APPLIANCE AS A BLENDER
• Do not place hands in the blending jug
unless the appliance is disconnected
from the power outlet. A spatula may
be used but only when the blender is
not running.
• Always operate the blender with the
blender jug lid in place.
• Do not use the blender for any purpose
other than food or beverage preparation.
• Do not process boiling liquids. Let the
liquid cool slightly before placing in the
blending jug.
• Always switch the blender off after
each use. Ensure the motor stops
completely and unplug the power cord
from the wall outlet before attempting
to move the appliance, before cleaning,
disassembling, assembling and when
storing the appliance.
WARNING
Blender blades are sharp.
Handle carefully.

6
BREVILLE RECOMMENDS SAFETY FIRST
IMPORTANT SAFEGUARDS FOR
ALL ELECTRICAL APPLIANCES
• Fully unwind the power cord before use.
• Do not let the power cord hang over
the edge of a bench or table, touch hot
surfaces or become knotted.
• To protect against electric shock do not
immerse the power cord, power plug or
appliance in water or any other liquid.
• The appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning
use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure
that they do not play with the appliance.
• It is recommended to regularly inspect
the appliance. To avoid a hazard do not
use the appliance if power cord, power
plug or appliance becomes damaged in
any way. Return the entire appliance to
the nearest authorised Breville Service
Centre for examination and/or repair.
• Any maintenance other than cleaning
should be performed at an authorised
Breville Service Centre.
• This appliance is for household use only.
Do not use this appliance for anything
other than its intended use. Do not use
in moving vehicles or boats. Do not use
outdoors. Misuse may cause injury.
• The installation of a residual current
device (safety switch) is recommended
to provide additional safety protection
when using electrical appliances. It
is advisable that a safety switch with
a rated residual operating current
not exceeding 30mA be installed in
the electrical circuit supplying the
appliance. See your electrician for
professional advice. SAVE THESE
INSTRUCTIONS

HOW TO USE AS A
JUICE EXTRACTOR

8
KNOW YOUR BREVILLE JUICE EXTRACTOR
A
B
E
F
N
L
M
G
HI
J
K
c
D

9
KNOW YOUR BREVILLE JUICE EXTRACTOR
A. Food pusher
B. Juicer cover with extra wide
feed chute
C. Pulp container with integrated handle
D. Juicing speed guide (not shown)
E. Filter basket
F. Filter bowl surround
G. Motor drive coupling
H. Motor base
I. Safety locking arm
J. START | STOP button and speed
control dial
K. Overload protection reset button
(underside of the motor base)
L. Juicing jug lid
M. 1.2L juicing jug
N. Nylon cleaning brush

ASSEMBLING
your Breville Juice Extractor

11
PAGE HEADER.....ASSEMBLING THE JUICE EXTRACTOR
ASSEMBLING THE
JUICE EXTRACTOR
Before using the Juice Extractor for the
first time, remove and safely discard any
packaging material and promotional labels.
Ensure the power cord is unplugged from
the wall outlet.
Wipe the Motor Base with a damp cloth.
Dry thoroughly.
Wash the Filter Bowl Surround, Filter Basket,
Juicer Cover, Food Pusher, Juice Jug, Juice
Jug Lid and Pulp Container in warm soapy
water with a soft cloth or nylon brush. Rinse
and dry thoroughly. Alternatively, place
these parts, excluding the Food Pusher, in
the dishwasher.
1. Place the Motor Base on a flat dry
surface such as a bench top. Ensure
the power cord is unplugged from the
wall outlet.
2. Place the Filter Bowl Surround on top
of the Motor Base.
3. Align the arrows on the Filter Basket
with the arrows on the Motor Drive
Coupling and push down until it clicks
into place. Ensure the Filter Basket is
fitted securely inside the Filter Bowl
Surround and onto the Motor Base.
4. Lower the Juicer Cover, positioning the
rim within the Filter Bowl Surround.

12
PAGE HEADER.....ASSEMBLING THE JUICE EXTRACTOR
5. Raise the Safety Locking Arm and lock
into the two grooves on either side of the
Juicer Cover. The Safety Locking Arm
should now be in a vertical position.
6. Slide the Food Pusher down the Feed
Chute by aligning the groove in the
Food Pusher with the small protrusion
on the inside top of the Feed Chute.
7. Place the Pulp Container into position
by tilting slightly.
TIP
To minimize clean up, place a plastic
freezer bag (or plastic grocery bag)
into the Pulp Container to collect
the pulp.
8. Place the provided Juice Jug under
the spout on the right hand side.
Ensure the Juice Jug Lid is used to
avoid any splatter.
NOTE
A glass could also be used to
collect juice.

OPERATING
your Breville Juice Extractor

14
OPERATING THE JUICE EXTRACTOR
OPERATING THE JUICE EXTRACTOR
1. Wash and prepare your selection of fruit
and/or vegetables :
Fruits with hard or inedible skins such as
citrus fruit, melons and kiwi fruit should
be peeled before juicing. Pineapple
can be juiced with or without the rind
removed.
Fruits with pits, hard seeds or stones
such as nectarines, peaches, mangoes,
apricots, plums and cherries must be
pitted before juicing.
2. Ensure the Juice Extractor is correctly
assembled with the Safety Locking Arm
securely locked into the vertical position
and the Juice Jug under the spout.
NOTE
As a safety precaution, the Juice
Extractor will not operate if the Safety
Locking Arm is not securely locked
into the vertical position.
3. Plug the power cord into a 230V/240V
power outlet. Then turn the power on at
the outlet. The START | STOP button
surround will illuminate.
NOTE
The button surround will illuminate
for 2 minutes before entering stand-
by mode. To re-activate the Juice
Extractor out of stand-by mode, press
or turn the START | STOP button.
FOOD TO BE JUICED Speed
Apples 5
Apricots (stone removed) 2
Beetroot (cleaned, trimmed) 5
Blueberries 1
Broccoli 4
Brussel sprouts (trimmed) 5
Cabbage 4
Carrot 5
Cauliflower 4
Celery 5
Cucumber, soft skinned 4
Fennel 5
Grapes (seedless) 1
Kiwi fruit (peeled) 2
Mangoes (peeled, stone re-
moved)
2
Melons (peeled) 1
Nectarines (stone removed) 2
Oranges (peeled) 3
Peaches (stone removed) 2
Pears hard (stalks removed) 5
Pears soft (stalks removed) 2
Pineapple 5
Plums (stone removed) 2
Raspberries 1
Tomatoes 1
Watermelon (peeled) 1

15
OPERATING THE JUICE EXTRACTOR
4. Rotate the speed control dial to
the desired speed. Use the speed
selector table on page 14 as a guide for
juicing different fruit and vegetables.
For your convenience, a juicing speed
guide is also printed on the inside of
the Pulp Container.
NOTE
The SMOOTHIE, ICE and PULSE
settings can only be selected when
the appliance is assembled as a blender.
5. Push the START | STOP button. With
the motor running and while the
Food Pusher, gently guide food down
the Feed Chute. Do not exert excess
pressure. To extract the maximum
amount of juice, always push the Food
Pusher down slowly.
IMPORTANT:
Do not load the Feed Chute with food
until the motor is running.
TIPS
• A small amount of lemon juice
can be added to the fruit and/or
vegetables to inhibit browning.
• When juicing herbs, sprouts or
leafy green vegetables, either wrap
them together to form a bundle
or juice them in the middle of a
combination of ingredients on low
speed to obtain the best extraction.
If only juicing herbs or leafy green
vegetables, the juice yield will be
low due to the nature of centrifugal
juicing. It is advised to juice them
with a combination of other fruits
and vegetables.
• When juicing different ingredients
of varying textures, start with the
softer textured ingredients on low
speed then change to high speed for
harder textured ingredients. This
assists in extracting the maximum
amount of juice by clearing the
Filter Basket between ingredients.
6. As fruits and vegetables are processed,
juice will flow into the Juice Jug and the
separated pulp will accumulate in the
Pulp Container.
NOTE
The Pulp Container can be emptied
during juicing by turning the Juice
Extractor off and then carefully
removing the Pulp Container. Replace
the empty Pulp Container into
position before continuing to juice.
Do not allow the Pulp Container
to over-fill as this may affect the
operation of the appliance.

16
OPERATING THE JUICE EXTRACTOR
7. Immediately after each use, use the
provided nylon brush to thoroughly
clean the fine mesh holes of the Filter
Basket and rinse the remaining
removable parts under running water.
For more cleaning information, refer
to ‘Cleaning the Juice Extractor’ on
page 20.
The Breville Juice & Blend is fitted with
protection devices as a safety precaution to
prevent both personal injury and damage to
the appliance.
OVERLOAD PROTECTION
This protection device safeguards against
overloading the motor with excessive loads.
If overloading occurs, the Overload
Protection will automatically de-activate
the motor. When this occurs, unplug the
power cord from the wall outlet and press
the OVERLOAD RESET button found on the
underside of the Motor Base. This will reset
the Overload Protection, enabling you to
reconnect the power cord to the wall outlet
and recommence normal use.
OVERHEAT PROTECTION
This protection device safeguards
against overheating of the motor with
excessive loads.
If overheating occurs, the START | STOP
button surround will flash red and the
Overheat Protection will automatically
de-activate the motor. When this occurs,
unplug the power cord from the wall outlet
and allow the appliance to cool for at least 15
minutes. Then reconnect the power cord to
the wall outlet and recommence normal use.
ELECTRONIC PROTECTION
This protection device will automatically
de-activate the motor if the motor is stalled.
If the motor stalls, the START | STOP button
surround will flash red and the Electronic
Protection will automatically de-activate
the motor. When this occurs, unplug the
power cord from the wall outlet and clear the
Feed Chute. Either too much food is being
processed at one time or the pieces are not
small enough. Try trimming food, cutting
food into smaller pieces of even size and/
or processing a smaller amount per batch.
Then reconnect the power cord to the wall
outlet and recommence normal use.

DISASSEMBLING
your Breville Juice Extractor

18
PAGE HEADER.....DISASSEMBLING THE JUICE EXTRACTOR
DISASSEMBLING THE
JUICE EXTRACTOR
1. Ensure the Juice Extractor is turned off,
the power is switched off at the power
outlet and the power cord is unplugged
from the power outlet.
2. Grip the handle around the top rim
of the Pulp Container, then pivot the
bottom of the Pulp Container away from
the Juice Extractor.
3. Pull the Safety Locking Arm downwards
and over the grooves on either side of
the Juicer Cover.
4. Remove the Food Pusher from the
Feed Chute.
5. Lift the Juicer Cover off the Filter
Bowl Surround.
6. To remove the Filter Bowl Surround,
hold the Motor Base then turn the Filter
Bowl Surround by the Juice Spout. The
Filter Bowl Surround should lift off the
Motor Base with the Filter Basket still
in place.
7. To remove the Filter Basket from the
Filter Bowl Surround, turn the Filter
Bowl Surround upside down over
the sink.

19
PAGE HEADER.....DISASSEMBLING THE JUICE EXTRACTOR
WARNING
The Filter Basket contains a titanium
reinforced cutting disc with ultra
sharp blades and teeth. Do not touch
blades and teeth when handling the
Filter Basket.

CLEANING
your Breville Juice Extractor
