Breville Multi Mash BSB380 User manual

BSB380
the Multi Mash™
Instruction Booklet
BSB380_IB_B13_FA.indd 2 8/02/13 4:21 PM

CONGRATULATIONS
on the purchase of your new
Breville product
BSB380_IB_B13_FA.indd 2 8/02/13 4:21 PM

3
CONTENTS
4Breville recommends safety first
7Know your Breville product
9Operating your Breville product
13 Care, cleaning & storage for your
Breville product
15 Recipes
BSB380_IB_B13_FA.indd 3 8/02/13 4:21 PM

4
BREVILLE RECOMMENDS SAFETY FIRST
At Breville we are very safety conscious. We design and
manufacture consumer products with the safety of you, our
valued customer, foremost in mind. In addition we ask that you
exercise a degree of care when using any electrical appliance
and adhere to the following precautions.
READ ALL
INSTRUCTIONS
BEFORE USE AND
SAVE FOR FUTURE
REFERENCE
• Remove any packaging
material and promotional
stickers before using the
masher for the first time.
• Do not place the masher
near the edge of a bench
or table during operation.
Ensure the surface is level,
clean and free of water,
flour, etc.
• Do not place the masher on
or near a hot gas or electric
burner, or where it could
touch a heated oven.
• If using the masher to puree
hot food in a saucepan
over heat, remove the
saucepan from the heat
source and ensure the
power cord and body of
appliance are also kept
away from any heat source.
• Always make sure the
masher is completely
and properly assembled
before operating.
• Ensure the masher is
turned off at the trigger
switch, the power is
switched off at the power
outlet and the cord is
unplugged from the power
outlet before attempting
to attach any of the
accessories.
• Always ensure the mashing
leg is securely fitted onto
the masher motor body
before operating.
• Do not use attachments
other than those provided
with the masher.
• Do not attempt to operate
the masher by any method
other than those described
in this booklet.
• Do not operate the
appliance continuously for
more than 1 minute. Allow
the motor to rest for
1 minute between each use.
IMPORTANT SAFEGUARDS
BSB380_IB_B13_FA.indd 4 8/02/13 4:21 PM

5
5
BREVILLE RECOMMENDS SAFETY FIRST
• When using heavy loads,
the appliance should not be
operated for more than
30 seconds.
• Recipes in this instruction
booklet are not considered
heavy loads.
• Always ensure the masher
is turned off, the power is
switched off at the power
outlet and the cord is
unplugged from the power
outlet before attempting to
move the appliance, when
not in use, if left unattended
and before disassembling,
cleaning or storing.
• If food becomes lodged
around the mashing
blade or in the adjustable
texture section, release
the ON button, switch the
power off at the power
outlet and unplug the cord.
Use a spatula to dislodge
the food.
• To protect against electric
shock do not immerse the
motor body, cord or power
plug in water or any
other liquid.
SAVE THESE
INSTRUCTIONS
• Do not remove the masher
from ingredients during
operation. Ensure the
appliance is switched off and
has stopped turning before
removing, to avoid contact
with moving blade or whisk.
• Do not leave the masher
unattended when in use.
• Keep the appliance clean.
Follow the cleaning
instructions provided in
this book.
• Do not use the masher with
wet hands.
BSB380_IB_B13_FA.indd 5 8/02/13 4:21 PM

6
BREVILLE RECOMMENDS SAFETY FIRST
IMPORTANT
SAFEGUARDS FOR
ALL ELECTRICAL
APPLIANCES
• Unwind the cord fully
before use.
• Do not let the cord hang
over the edge of a table or
counter, touch hot surfaces
or become knotted.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way
and understand the
hazards involved.
• Keep the appliance
and its cord out of reach
of children.
• Children shall not play with
the appliance.
• Cleaning and user
maintenance shall not be
made by children without
supervision.
• It is recommended to
regularly inspect the
appliance. Do not use the
appliance if power supply
cord, plug or appliance
becomes damaged in any
way. Return the entire
appliance to the nearest
authorised Breville service
centre for examination
and/or repair.
• Any maintenance, other
than cleaning, should be
performed at an authorised
Breville Service Centre.
• This appliance is for
household use only. Do
not use this appliance for
anything other than its
intended use. Do not use in
moving vehicles or boats.
Do not use outdoors.
• The installation of a
residual current device
(safety switch) is
recommended to provide
additional safety protection
when using electrical
appliances. It is advisable
that a safety switch with a
rated residual operating
current not exceeding
30mA be installed in
the electrical circuit
supplying the appliance.
See your electrician for
professional advice.
BSB380_IB_B13_FA.indd 6 8/02/13 4:21 PM

KNOW
your Breville product
BSB380_IB_B13_FA.indd 7 8/02/13 4:21 PM

8
PAGE HEADER.....
KNOW YOUR BREVILLE PRODUCT
A. Speed Control Dial
B. Easy Grip Trigger Switch
C. Motor Body
D. Detachable Gear Box
E. Detachable Mashing Leg
A
B
C
E
D
BSB380_IB_B13_FA.indd 8 8/02/13 4:22 PM

ASSEMBLY & OPERATION
of your Breville product
BSB380_IB_B13_FA.indd 9 8/02/13 4:22 PM

10
PAGE HEADER.....
ASSEMBLY & OPERATION
ASSEMBLY OF THE POTATO
MASHER LEG
Before first use
Remove any packaging material and
promotional labels. Wash blade and two
parts of the mashing leg before use.
CAUTION
Never immerse the motor body or
gearbox in water or any other liquid.
NOTE
If the variable masher leg is already
assembled start from step 3.
1. Holding the outer leg and insert the
gearbox making sure ALIGN arrows
are aligned.
2. Hold both outer leg and gearbox firmly
with one hand and insert inner leg until
it clicks and locks into place.
3. Rotate gearbox while holding outer leg
to lock into place until it clicks.
BSB380_IB_B13_FA.indd 10 8/02/13 4:22 PM
