Breville the BrevillePrecision Brewer Thermal User manual

the BrevillePrecision Brewer™Thermal
Instruction Book - BDC450

2
BREVILLE
RECOMMENDS
SAFETY FIRST
At Breville we are very safety
conscious. We design and
manufacture consumer
products with the safety of you,
our valued customer, foremost
in mind. In addition we ask
that you exercise a degree of
care when using any electrical
appliance and adhere to the
following precautions.
IMPORTANT
SAFEGUARDS
READ ALL
INSTRUCTIONS BEFORE
USE AND SAVE FOR
FUTURE REFERENCE
• Carefully read all instructions
before operating and save
for future reference.
• Remove any packaging
material and promotional
labels or stickers before
using the Breville Precision
Brewer for the first time.
• To eliminate a choking
hazard for young children,
remove and safely discard the
protective cover fitted to the
power plug of this appliance.
• Do not place the product near
the edge of a bench or table
during operation. Ensure the
surface is level, clean and free
of water and other substances.
• Do not let the cord hang
over the edge of a bench or
table, or become knotted.
Keep away from hot gas or
electric burner, or where it
could touch a heated oven.
2 Breville Recommends
Safety First
7 Components
9 Features
9 Assembly
10 Operation
14 Programming
15 Tips
18 Care & Cleaning
19 Troubleshooting
Contents

3
• This appliance can be
used by children aged from
8 years and above if they have
been given supervision or
instruction concerning use
of the appliance in a safe way
and understand the hazards
involved. Cleaning and user
maintenance shall not be
made by children unless
they are aged from 8 years
and above and supervised.
Keep the appliance and its
cord out of reach of children
aged less than 8 years.
• Appliances can be used by
persons with reduced physical,
sensory or mental capabilities
or lack of experience and
knowledge if they have
been given supervision
or instruction concerning
use of the appliance in a
safe way and understand
the hazards involved.
• Children shall not play
with the appliance.
• Keep the appliance and its cord
out of reach of children aged
less than 8 years. Cleaning
and user maintenance shall
not be made by children
without supervision.
• Regularly inspect the
supply cord, plug and actual
appliance for any damage. If
found damaged in any way,
immediately cease use of
the appliance and return the
entire appliance to the nearest
authorised Breville Service
Centre for examination,
replacement or repair.
• Keep the appliance and
accessories clean. Follow
the cleaning instructions
provided in this book. Any
procedure not listed in this
instruction booklet should be
performed at an authorised
Breville Service Centre.
• The installation of a residual
current device (safety switch)
is recommended to provide
additional safety protection
when using electrical
appliances. It is advisable
that a safety switch with a
rated residual operating
current not exceeding
30mA be installed in the
electrical circuit supplying the
appliance. See your electrician
for professional advice.
•Misuse may cause injury.

4
NOTICE TO CUSTOMERS
REGARDING MEMORY
STORAGE
Please note that in order to
better serve our customers,
internal memory storage
has been imbedded into
your appliance.
This memory storage
consists of a small chip to
collect certain information
about your appliance
including the frequency of
use of the appliance and
the manner in which your
appliance is being used. In
the event your appliance
is returned for service,
the information collected
from the chip enables us
to quickly and efficiently
service your appliance.
The information collected
also serves as a valuable
resource in developing
future appliances to better
serve the needs of our
consumers. The chip does
not collect any information
regarding the individuals
who use the product or
the household where the
product is used. If you have
any questions regarding the
memory storage chip please
contact us at privacy@
breville.com
SPECIFIC
INSTRUCTIONS
FOR BDC450
• This appliance is
recommended for household
use only. Do not use this
appliance for any purpose
other than its intended use.
Do not use in moving vehicles
or boats. Do not use outdoors.
• If the appliance is to be:
−left unattended
−cleaned
−moved
−assembled; or
−stored
• Ensure the product is properly
assembled before first use.
• Do not operate the appliance
without water in the water
tank. Use only cold, preferably
filtered water. Do not fill the
appliance with any other
liquids for brewing operations.

5
• Ensure the supplied mesh
basket filter or a paper filter
(8-12 cup, flat base basket style
with ~ 8.25cm base) is placed
in the coffee basket before
using the appliance. Do not
use the mesh basket filter in
conjunction with a paper filter.
• Before starting a brew cycle:
−Check that the carafe drip
stop moves up and down
freely.
−Completely empty the carafe
and securely lock the carafe
lid in place.
−Insert and seat the carafe
under the drip stop.
−Ensure the filter basket is
empty and properly fit in
place.
• During a brew cycle:
−Do not remove the carafe
or remove the filter basket
while the unit is in a brew
cycle. Failure to follow the
above may lead to scalding or
serious injury.
• Some surfaces may be hot,
use caution when touching or
lifting the unit or accessories.
• Use only carafe handle when
lifting the carafe. The carafe
is designed for use with
this appliance only. It must
never be used on a range
top or in a microwave.
• Scalding may occur if the
carafe lid or basket is removed
during the brewing cycle.
CAUTION
Risk of injury. Proper
installation/removal of basket
is required to reduce the risk of
splashing of hot water.
• Always ensure the carafe lid is
securely locked in place onto
the carafe before pouring.
• Do not use the carafe with
a cracked, loose, weakened
or damaged handle.
• Do not use the filter basket
with a cracked, loose, weakened
or damaged handle.
• Do not touch hot surfaces.
Use the handle for lifting
and carrying the carafe.
• Always wait until the
machine has cooled before
removing the brew basket.
• Do not set a hot carafe on a wet,
cold or heat sensitive surface.

6
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
• Do not use harsh or abrasive
materials when cleaning any
part of this appliance such as
steel wool or scoring pads.
• To protect against fire,
electric shock, and injury
to persons, do not immerse
cord, plug or appliance in
water or any other liquid.
• Always switch the appliance
off by removing the power
plug from the power outlet
before attempting to move
the appliance, when the
appliance is not in use and
before cleaning and storing.
Allow to cool before putting
on or taking off parts, and
before cleaning the appliance.
• The use of attachments
not sold or recommended
by Breville may cause fire,
electric shock or injuries.
• Proper installation of filter
basket, showerhead seal, and
showerhead locking ring is
required to reduce the risk
of splashing of hot water.
• To prevent damage to
the appliance do not use
alkaline cleaning agents
when cleaning, use a soft
cloth and a mild detergent.
• Heating element surface
is subject to residual
heat after use.
• The appliance shall not be
placed in a cabinet when in use.

7
A. Tank lid
B. Water tank
C. LCD display
D. SELECT dial
E. START|CANCEL button
F. AUTO START button
G. Brew basket
H. Showerhead
I. Showerhead ring
J. Drip stop lever
K. Carafe lid
L. Carafe
Components
BH
I
C
D
E
F
AG
J
K
L

8
A
D
E
F
G
B
C
A. Cone filter basket insert
B. Mesh basket filter
C. Brew basket
D. Breville coffee measuring scoop
E. Flat bottom basket filter paper pack (10 pieces)
F. Water hardness test strip
(see page 10 for directions)
ACCESSORIES

9
Your Breville Precision Brewer has been
designed to make coffee of the highest quality,
just the way you like it, no matter what style of
coffee you enjoy.
Fast: Brew up to 12 cups (1.8L) as fast as the
brewer can deliver the water in the tank.
Gold (recommended): This mode is to
automatically set all the brew parameters
to meet "Gold Cup" standard set by SCA
(Specialty Coffee Association).
Strong: Brew settings are automatically
adjusted so you get a stronger cup of coffee.
Tip: for strong coffee, increase the amount of
ground coffee you normally use.
MyBrew: Brew up to 12 cups (1.8L) having
total control over all the variables, brew water
temperature, bloom time, water delivery speed,
so you get coffee just the way you like it.
Cold Brew: Brew up to 600ml of Cold Brew
coffee with the flexibility to adjust steeping
time between 0-24 hours and have the coffee
automatically delivered into your favorite
vessel.
Features Assembly
BEFORE FIRST USE
Unpack all parts and accessories before
removing and safely discarding all packaging
material and promotional labels. Ensure the
power cord is unplugged from the power outlet.
Wipe the exterior stainless steel housing with
a soft, damp cloth. Wash the lid, brew basket,
cone filter insert, mesh basket filter, and carafe
in warm, soapy water and a soft cloth. Do not
use abrasive cleansers, pads or cloths which can
scratch the surface. Rinse and dry thoroughly.
Press carafe drip stop ensuring it can freely
move up and down.

10
Operation
BREWING A CARAFE
Ensure the brew basket is clean and the drip
stop seal in the bottom of the basket is clean
and free of coffee particles.
1. Select the correct basket & filter for the
amount of coffee you’re making. When
brewing between 2 and 8 cups, we
recommend you use the Cone shaped filter
basket insert with paper filter (Cone paper
filter is not included). When brewing more
than 8 cups, use mesh basket filter or flat
bottom brew basket with large paper filter.
2 - 8
CUPS
OR OR
✔
8+
CUPS
✔
CAUTION
Filling the basket without a mesh basket filter
or filter paper may cause the basket to overflow
during the brewing cycle.
2. The LCD will display the basket setting -
"Basket" or "Cone". To change the basket
type, rotate the SELECT dial to Settings &
press the dial. Rotate the SELECT dial to the
basket type, press the SELECT dial to set.
3. Fill the water tank with fresh cold water up
to the MAX marking on the water tank.
WATER HARDNESS SETTING &
FLUSHING
1. Ensure that the empty coffee basket and
empty carafe (with assembled lid) are
inserted into the machine.
2. Fill the water tank with fresh cold water to
the MAX mark on the water tank. Plug into
power outlet.
3. When first turned on, the machine will
show 'SEt HArdnESS' on LCD, asking you
water hardness level. Press SELECT dial
once. Dip the water hardness test strip into
the filled water tank for 1 second, remove
and wait for 1 minute to reveal the result.
Rotate SELECT dial and press the dial to
select the level according to the number
of dots shown on the strip. To reset water
hardness, please refer to FACTORY RESET
(page 18).
4. The machine will show ‘FLUSH Unit’
on LCD. Press SELECT dial once. The
machine will dispense all the water from
the tank, through the system & into the
empty carafe. After flushing, empty the
basket and carafe.

11
NOTE
Coffee with superior taste & clarity will come
from using a paper filter.
NOTE
The mesh basket filter will allow some fine
coffee grounds to brew into the coffee. This
will appear as sediment in the cup or carafe.
This is normal. Only use the mesh basket filter
provided as others may cause the machine to
overflow.
7. Lock the carafe lid and place the carafe
under the drip stop outlet.
A
L
I
G
N
A
R
R
O
W
S
T
U
R
N
T
O
P
O
U
R
CAUTION
The carafe MUST be in place before you brew
with water level higher than ‘SINGLE CUP’
line. Otherwise the coffee basket will overflow.
NOTE
Always ensure your carafe is clean and empty
before brewing. Residual coffee will affect the
taste and liquid in the carafe will cause it to
overflow.
NOTE
Always ensure your carafe is EMPTY before
brewing to prevent overflow.
NOTE
This machine will brew all the water in the tank.
Ensure the tank does not contain an excess
amount of water.
4. For the very best tasting coffee, we
recommend using freshly roasted whole
bean coffee and grind with a burr grinder
directly before you brew. The grind should
be medium/coarse, never use coffee ground
for espresso as your coffee basket may
overflow.
5. Grind enough coffee beans for the volume
you’re making. For a full 1.8L carafe, we
recommend 99g of coffee, approximately
12 level Breville measuring scoops.
Roughly 1 scoop for every 150ml.
Refer coffee/water ratio chart on page 14.
6. Insert the correct filter paper, cone or flat
bottom, or mesh basket, into the brew
basket, then, add your ground coffee. Insert
the brew basket into the machine.
NOTE
Never use both mesh basket filter and paper
filter at the same time.

12
• Bloom Time: Coffee bloom occurs
when hot water hits the ground coffee.
This setting allows you to adjust how long
the bloom time lasts. We recommend
30-60 seconds. During this time
the brewing cycle pauses to allow
coffee to naturally bloom. See ‘TIPS’
for more about Bloom Time.
• Bloom Volume: You can adjust
the amount of water dispensed
before the blooming starts.
• Brewing Temp: You can adjust the
temperature of the brew water being
delivered to the ground coffee to suit
your favorite coffee. See “TIPS” for more
about setting brew water temperature.
• Flow Rate: You can adjust brewing time
to control contact time by adjusting the
water delivery speed. Choose between
Slow, Medium, and Fast (default).
• POUR OVER: If you are using the Pour
Over Adapter (accessory can be purchased
separately), this must be turned on.
• COLD BREW: Cold Brew coffee is brewed
differently to traditional coffee. It uses cold,
not hot water. Your brewer uses the “Full
Immersion” method of brewing cold brew
which steeps the water and coffee together
over an extended duration – typically
between 4 - 14 hours. This method creates an
intense smooth coffee with little bitterness.
Brew ratios are also different, and much
higher than normal. Breville recommends
a brew ratio 2-3 times higher than average,
approximately 3 Breville scoops to every
150ml of water.
• See ‘TIPS’ for step-by-step guide
of brewing Cold Brew.
• Brew time is adjustable.
8. Rotate the SELECT dial to the desired
mode. Press the START|CANCEL button.
The machine will display the progress:
• The machine will remind you to insert
either cup or carafe where applicable
• Heating: the heating system is being
pre-heated to the optimal temperature
• Blooming: the bloom phase of
preparation is in progress
• Brewing: brew water at the correct/
selected temperature is being
delivered to the ground coffee
9. When your coffee is ready, the machine will
beep 3 times. The machine will display the
“Time since brewed”.
NOTE
A small amount of water remains in the
tank after brewing. This is part of the normal
operation.
NOTE
Never fill the water tank once the coffee
machine has started a brewing cycle.
BREW MODES
• FAST: This mode is to deliver the fastest
brewed coffee. This coffee machine is one
of the fastest 12 cup (1.8L) brewers.
• GOLD (recommended): This mode meets the
SCA (Specialty Coffee Association)'s rigorous
technical requirements using the cone filter
basket.
• STRONG: This brewing mode delivers a
stronger tasting coffee.
• MY BREW: Allows you to customize every
brew setting.

13
NOTE
DO NOT fill the water tank more than
SINGLE CUP line or the volume of the cup
used to receive the coffee. It will overflow as
the machine brews until the water tank
becomes empty.
2. Place your empty cup underneath the
brew basket outlet.
3. We recommend using cone filter basket
insert for single cups. It ensures proper
contact between the brew water and the
ground coffee.
4. To change the basket type, rotate the
SELECT dial to Settings and press to enter
the Settings mode and select "Basket Type".
5. Rotate the dial to select “Cone”, and press
dial to select. “Cone” will be displayed on
the LCD.
6. Insert the Cone filter basket into the brew
basket. Use the alignment marks as a guide.
7. Place a cone shaped paper filter into the
cone filter basket.
8. Grind the correct amount of whole bean
coffee for the amount you are brewing.
1 level Breville scoop of ground coffee is
suitable for 150ml of water.
9. Select desired brewing mode, Fast, Gold,
MyBrew or Strong.
10. Press START|CANCEL to begin brewing.
SINGLE CUP/SMALLER VOLUMES
(LESS THAN 4 CUPS, 600ML)
1. Your Breville Precision Brewer will
recognize when the brewer has less than
4 cups (600ml) of water & will adjust the
brew settings, automatically, to make
the best possible tasting coffee. Fill your
cup with fresh cold water and then pour it
into the water tank, ensuring the water
level stays below the SINGLE CUP line.

14
Programming
AUTO START
Allows you to automatically start brewing at
preset time.
1. Set filter basket type for the amount of coffee
you're brewing.
2. Select your brewing mode.
3. Fill the water tank with enough fresh cold
water for the amount of coffee you're brewing.
4. Insert the brew basket with your desired
insert or paper filter and add coffee.
5. Insert the appropriate cup or the carafe with
the lid locked in place into the machine.
6. Press the AUTO START button.
FAST
GOLD
SET CLOCK STANDBY
KEEP WARM
EXIT
DESCALE
SOUND
SETTINGS
COLD BREW
MYBREW
POUROVER
STRONG
BLOOM TIME
BLOOM VOL.
BREW TEMP.
FLOW RATE
CUSTOMIZE
CARAFE LID
REMOVE
FILL
AUTO START
TANK!
TIME SINCE BREW
MIN
HEATING BLOOMING BREWING
AM
PM
HR
MAX
AT
7. The machine will prompt you to set the
time for Auto Start. Rotate the SELECT dial
to adjust Auto Start time press SELECT
dial to set. Auto Start is now set and the
machine will enter Auto Start mode, brewing
automatically at the set Auto Start time.
NOTE
If the clock hasn’t been set, the machine will
prompt you to set the clock. Ensure the clock is
correct. The clock will reset every time the unit
is unplugged.
8. Pressing START|CANCEL will cancel Auto
Start.
SETTINGS
• SET CLOCK: Set the time displayed on LCD.
• SOUND: Sound volume is adjustable and also
can be turned off.
• STANDBY: Adjust time to automatically enter
STANDBY mode after a period of no use.
• FILTER TYPE: Factory setting is Flat basket,
adjustable when using the Cone filter basket
insert.
ENTERING STANDBY MODE
AT ANY TIME
Press the START|CANCEL button for
3 seconds.
DEGREE INDICATION PREFERENCE
(°C/°F)
To switch between °F and °C, press SELECT
dial and AUTO START button together. Rotate
SELECT dial to select, then press SELECT dial
to set.
CHILD-LOCK
To prevent children from possible danger,
child-lock feature is available. Press and hold
AUTO START button for 5 seconds. LCD will
display “CL” when it is locked. Repeat this again
or unplug the unit to unlock.

15
Tips
WHOLE BEANS
• FRESH IS BEST! Freshly roasted, quality
coffee is key to making great tasting coffee.
Peak flavour potential is 5-20 days after roast.
Always look for a “Roasted On” date on the
bag. Avoid coffee with a “Best Before” or
“Use By” date as you never know when it
was roasted.
• Coffee flavour and strength are a personal
preference. Vary the type of coffee beans and
the amount of ground coffee to achieve your
preferred taste.
• Freshly ground beans are the key to
making coffee with more flavour and body.
Pre-ground coffee will have lost most of its
flavour and aromatics, so always grind right
before you brew for superior taste.
• Store coffee beans in a dark, cool and dry
place. Vacuum seal if possible.
• Buy coffee beans in small batches to reduce
the storage time and store no more than one
week’s supply at any time.
COFFEE/WATER RATIO
We recommend 1 level Breville scoop of coffee grounds per 150ml cup of water. Adjust the amount
according to your individual taste. The maximum capacity for pre-ground coffee is 12 level Breville
scoops. Exceeding this amount may cause the coffee basket to overflow.
Cups of coffee
(150ml cup) 1 2 3 4 5 6 7 8 9 10 11 12
Spoons of coffee
grinds
1
(8.25g)
2
(16.5g)
3
(24.75g)
4
(33g)
5
(41.25g)
6
(9.5g)
7
(57.75g)
8
(66g)
9
(74.25g)
10
(82.5g)
11
(90.75g)
12
(99g)
Water amount 150ml 300ml 450ml 600ml 750ml 900ml 1.05L 1.2L 1.35L 1.5L 1.65L 1.8L
PRE-GROUND COFFEE
• Pre-ground coffee is convenient, but will
never taste as good as coffee ground right
before you brew. We recommend investing in
a quality burr grinder so you can grind fresh
whole bean coffee right before you brew and
enjoy superior tasting coffee.
• The grind will affect the rate at which the
water flows through the coffee in the coffee
basket and therefore the taste of the coffee.
If the grind is too fine the water will not flow
through the coffee and may clog or overflow
the coffee basket. It may pass through the
mesh basket filter leaving sediment in the
cup or carafe. The resulting coffee will be
over extracted, too dark and bitter. If the
grind is too coarse the water will flow through
the coffee too quickly. This will result in an
under-extracted coffee lacking in flavour.
• Always use “drip filter grind” suitable for
use with a drip coffee machines. Never use
“Espresso grind” as the finer grind size may
cause the coffee basket to block and will be
over-extracted.

16
BLOOMING
• When coffee is roasted, CO2is trapped inside
the bean. Coffee grounds release this CO2
when hot water hits them, and this is called
“blooming”. Your Brewer can automatically
adjust bloom time by controlling the water
flow. Blooming can have an impact on the
aromas and flavours of the brewed cup. If the
coffee is overly bitter shorten bloom time,
and if it’s sour make it a little longer.
PRE-HEATING
• Pre-heat the carafe or cup for best results.
A pre-heated carafe or cup will help maintain
the coffee’s optimal temperature and keep
coffee hotter for longer. Fill with hot water for
about 30 seconds then discard the water.
WATER QUALITY
• Fresh, good-tasting water is essential for a
perfect cup. If the water contains excessive
sediment, or has an ‘off’ taste or odor, we
recommend using filtered water.
COLD BREW
Your Brewer will produce a maximum of
600ml of Cold Brew. Due to the long duration
(typically 4-14 hours) of the brewing process we
recommend setting the machine up overnight
so the Cold Brew will be ready in the morning.
1. Fill the tank with your desired volume of
water ensuring this is below the
COLD BREW line.
2. Remove the basket, and ensure both the
cone insert and mesh basket filter are
removed. Add a large paper filter and
then coffee at 2-3 times of regular ratio
(approximately 12 scoops for 600ml).
Reinsert the basket into the machine.
3. Remove the lid from the carafe and re-insert
– the lid must not be on the carafe during
the brewing process, alternatively, use
another vessel.
4. Navigate to the COLD BREW setting and
press START|CANCEL. The machine will
then begin brewing the water without the
heating element. Once this is complete a
countdown timer will display on the LCD
indicating when the Cold Brew is finished.
At this point the machine will automatically
dispense the Cold Brew into the waiting
carafe.
NOTE
Brew Time for Cold Brew can easily be
adjusted to your preference, anywhere between
5min – 24hrs.
NOTE
Do not add ice to the tank. Cold, chilled water
should be added.
NOTE
Ensure the carafe lid is removed for Cold Brew
mode.

17
POUR OVER (Pour Over Accessory Kit can be purchased separately)
The pour over adapter is to let your Precision Brewer accommodate your favourite pour
over dripper.
Fit 'Pour Over'
showerhead.
Caution:
Showerhead
may be hot.
Note:
You can customise
settings for
BLOOM TIME,
BLOOM VOL,
BREW TEMP &
FLOW RATE using
the select dial.
Refit showerhead
ring.
Mount adapter.
Remove basket
and carafe.
Dose with ground
coffee.
Pour Over mode
is activated.
Fill to cup volume.Place dripper on
adapter.
Use case as stand
for cup.
Rotate SELECT dial to choose
'POUR OVER' & press SELECT.
Start brewing.
DRIPPER
Rotate SELECT dial to
customise settings.
Start brewing.
Unscrew
showerhead ring.
Remove
showerhead.
788
56 4
99 10 11
13 15
12 14
1 2 3

18
DESCALING
After regular use, hard water can cause
mineral build up in internal components,
reducing the brewing flow, brewing temperature,
power of the machine, and taste of the coffee.
We recommend to descale regularly. When
LCD shows “DESCALE” (flashing), descaling
cycle is needed.
NOTE
It takes approximately 15 minutes to complete
descaling cycle.
1. Empty the tank. Prepare a descale solution in
accordance with manufacturer's instructions.
Pour this solution into the empty water tank.
2. Place the basket and the carafe into position
under the drip stop outlet (Ensure the carafe
is empty and the lid is securely locked).
3. Press SELECT button for 3 seconds to start
descaling cycle. LCD with show “dSL” for
1 second and then tell remaining time of
descaling cycle.
4. When the descaling process is finished, the
LCD screen will go back to the main menu.
To completely remove residual water in the
tank, invert the machine and brew with fresh
water twice. Discard the water from the carafe
and rinse thoroughly.
NOTE
We recommend to brew through again after
descaling to brew out the residue descale
solution.
NOTE
You cannot stop the descaling process mid cycle.
Force stop by unplugging the cord from the
power outlet.
FACTORY RESET
This is to reset the machine to the factory settings,
including water hardness setting. Hold the
START button, the SELECT button, and
AUTO START button altogether for 3 seconds.
When LCD shows “rES” (flashing), press
SELECT button to start. Then next prompt
asks “YES” or “no” to confirm. Rotate and press
SELECT dial/button.
Always turn the coffee machine off and remove
the plug from the power outlet before cleaning.
CLEANING THE OUTER HOUSING
The outer housing and LCD screen can be
cleaned with a soft, damp cloth. Apply cleaner
to the cloth and not the LCD surface. Polish
with a soft, dry cloth. Cleaning and drying with
dry paper towels or abrasive cloths and cleaners
may scratch the surface.
CLEANING THE COFFEE BASKET AND
MESH BASKET FILTER
Remove the coffee basket. Discard any ground
coffee and filter paper. The coffee basket and
mesh basket filter can be rinsed under running
water. Ensure the fine holes of the mesh basket
filter are clear. For a deeper clean, wash the
coffee basket and mesh basket filter in warm,
soapy water with a soft bristled brush.
CAUTION
The coffee basket, mesh basket or paper filter
may still be very hot after brewing. Use caution
and allow to cool before removing.
CLEANING THE CARAFE
After each use, empty the carafe. Do not let
brewed coffee stand overnight as this can cause
the carafe to stain. Rinse the carafe and carafe
lid under warm running water. For a deeper
clean, we recommend regularly washing the
carafe in warm, soapy water using a soft bristled
brush. Do not use abrasive cleansers, pads or
cloths which can scratch the surface. Rinse and
dry thoroughly.
CLEANING THE SHOWERHEAD
Simply wipe down the showerhead area
periodically. However, if a more thorough clean
is required, the Showerhead can be removed by
unlocking the Showerhead Ring. Rotate clockwise
then remove the Showerhead for cleaning. Once
complete, reinstall the Showerhead.
Care & Cleaning

19
Troubleshooting
PROBLEM POSSIBLE CAUSE WHAT TO DO
Coffee too strong
or weak
•
Amount of coffee and water is not
correct (1 spoon : 150ml cup).
•
Check correct amount of coffee or
water is used.
Coffee leaking
from basket
when removed
•
The basket drip-stop seal doesn’t
cover the gap properly due to
foreign material.
•
Check that there is no obstruction in
the basket drip-stop seal.
Wash out the basket seal by turning
the basket upside down, and pressing
down and rinsing into the seal to clear
any particles obstructing that area.
Coffee overflowing
from the basket
(CAUTION:
If the basket
has overflowed
remove slowly and
with caution)
•
Carafe is not inserted.
• Amount of coffee and water is not
correct (1 spoon : 150ml cup).
• Grind size is too fine.
• Too much grinds in the basket.
• No paper in the basket.
• Putting paper into mesh basket
filter.
• Pour Over mode selected when
using the default brewing basket.
•
If you are brewing with carafe, check
that the carafe is inserted.
• Check that the correct amount of
coffee and water is used for the
operation.
• Correct grind size/amount.
• Use mesh basket filter without paper
and other baskets with paper.
• Deselect the Pour Over mode in the
Mybrew menu.
‘FILL TANK’ on
LCD screen
•
Water tank is empty or not enough
water to brew the selected volume.
• Sensors may be dirty.
•
Open the lid and pour the desired
amount of cold, preferably filtered
water.
• While the tank is empty wipe the
sensor prisms in the tank with a cloth.
Auto Start does
not function
•
Auto Start does not repeat after it
has been activated.
•
Re-engage the Auto Start mode for
each time that it needs to be used.
Shows ‘CLOCK’
when Auto Start
is pressed
•
Current time should be set before
setting Auto Start.
•
Set the current time before using Auto
Start.
Clock does not
remember time
•
Clock is cleared every time the unit
is unplugged.
•
Keep the unit plugged.
Auto Start starts
at the wrong time
•
Current time is not correct.
•
Check that the current time is correct.
Carafe overfilling
•
Carafe is not completely empty
before brewing.
• Amount of water is too much.
•
Check that the carafe is empty before
brewing.
• Check that the MAX line on the water
tank is not exceeded.
• Ensure water runs freely through
carafe lid.

20
PROBLEM POSSIBLE CAUSE WHAT TO DO
LCD shows 'FILL
TANK' when there
is water in the tank
•
Check that the unit is not in direct
sunlight or direct bright lighting.
•
Move unit away from the light source.
Brew doesn’t start
•
There is no water in the water tank.
• Each brewing mode has different
water amount limits, and it does not
brew when the amount is beyond
the limit.
•
Check that the water tank is filled.
• Check the water amount limits for
each mode.
Showerhead falls out
•
The showerhead may loosen and
fall out from time to time if not
inserted or tightened correctly.
•
Please wash the showerhead ring and
seal and re-insert.
The mesh filter
in the water tank
loosens and floats
•
Mesh filter is not inserted or
tightened correctly.
•
Call Breville Consumer Support.
Carafe drip stop
stays down
•
The drip stop is stuck.
•
Pull the drip stop back up.
• Clean the drip stop for any foreign
objects of coffee grinds or stains.
• If the problem persists and drip stop
does not return to top position please
call Breville Consumer Support.
Unit produces
excessive steam
while brewing or
runs for extended
periods with only
steam output
•
Brewing performance is affected by
scale accumulated by hard water.
• Brewing temperature profile is not
properly set.
•
Descale the unit.
• Call Breville Consumer Support if
problem persists.
‘DESCALE’ on LCD
screen (flashing)
•
Brewing performance is affected by
scale accumulated by hard water.
•
Descale the unit.
Unit shows "too hot"
•
Unit has been run too many times
back to back and the components
are overheated.
•
Let unit rest for at least 20mins before
starting another cycle.
COLD BREW modes
are disabled
•
If the water is more than 600ml,
these modes are disabled.
•
Reduce the amount of water
in the tank.
