Breville the Oracle Touch BES990DBL1BUS1 User manual

the Oracle‰Touch
EN INSTRUCTION BOOK FR-CA MANUEL D'INSTRUCTIONS ES-MX MANUAL DE INSTRUCCIONES

2
BREVILLE
RECOMMENDS
SAFETY FIRST
At Breville we are very safety
conscious. We design and
manufacture consumer
products with the safety of you,
our valued customer, foremost
in mind. In addition we ask
that you exercise a degree of
care when using any electrical
appliance and adhere to the
following precautions.
IMPORTANT
SAFEGUARDS
READ ALL
INSTRUCTIONS BEFORE
USE AND SAVE FOR
FUTURE REFERENCE
• Carefully read all
instructions before
operating and save for
future reference.
• Do not touch hot
surfaces. Use handles or
knobs as advised in this
instruction book.
• To protect against fire,
electric shock and injury
to persons do not immerse
the power cord, plug, or
appliance itself in water or
other liquids.
• Close supervision is
necessary when any
appliance is used by or
near children.
2 Breville recommends safety first
7 Components
9 Oracle Touch Features
10 Assembly
11 Functions
17 Tips
20 Care & Cleaning
24 Troubleshooting
Contents

3
• If the appliance is to be:
- left unattended
- cleaned
- moved
- assembled or
- stored
Always switch off the
appliance by pressing
the POWER button to
off and unplug from the
power outlet.
• Unplug from outlet when
not in use and before
cleaning. Allow to cool
before putting on or
taking off parts, and before
cleaning the appliance.
• It is recommended to
regularly inspect the
appliance and power cord.
Do not use the appliance
if there is damage to the
power cord or plug, or after
the appliance malfunctions
or has been damaged
in any way.
Immediately stop
use and call Breville
Consumer Support.
• The use of accessory
attachments not
recommended by Breville
may result in fire, electric
shock or injury to persons.
• Do not let the power cord
hang over the edge of a
table or counter-top, or
touch hot surfaces.
• Do not place the appliance
near the edge of a table
or counter-top. Ensure
the surface is level, clean
and free of water and
other substances.
• Do not place the appliance
on or near a hot gas or
electric burner. Do not
place it in, or allow it to
come in contact with a
heated oven.
• This appliance is
recommended for
household use only. Do
not use this appliance for
anything other than its
intended use. Do not use
outdoors. Do not use in
moving vehicles or boats.

4
NOTICE TO
CUSTOMERS
REGARDING
MEMORY
STORAGE
Please note that in order to
better serve our customers,
internal memory storage
has been imbedded into
your appliance. This
memory storage consists
of a small chip to collect
certain information about
your appliance including
the frequency of use of the
appliance and the manner
in which your appliance is
being used. In the event
your appliance is returned
for service, the information
collected from the chip
enables us to quickly and
efficiently service your
appliance. The information
collected also serves
as a valuable resource
in developing future
appliances to better serve
the needs of our consumers.
The chip does not collect
any information regarding
the individuals who use the
product or the household
where the product is used.
If you have any questions
regarding the memory
storage chip please contact
us at [e-mail]
SPECIFIC
INSTRUCTIONS
FOR BES990
• It is recommended to plug
the espresso machine
into a properly grounded
and dedicated circuit,
separate from other
electrical appliances.
• Avoid contact with
moving parts.
• Check bean hopper for
presence of foreign objects
before using.
• Use only cold water in
the water tank. Do not
use any other liquids. Do
not use highly filtered,
demineralized or distilled
water as this may affect

5
the taste of the coffee
and how the espresso
machine operates.
• Ensure the portafilter
is firmly inserted and
secured into the group
head before starting an
extraction. Never remove
the portafilter during the
extraction process.
WARNING
To avoid the risk of injury,
do not open the brew
chamber during the
brew process.
• Use caution after milk
texturing as the auto purge
function will purge hot
steam when the steam
wand is lowered.
• Caution must be used
during descaling as hot
steam may be released.
Before descaling, turn
off the machine, allow
to cool for at least 1 hour
and ensure the drip tray is
empty and fully inserted.
For instructions, refer
to 'Descale', page 20.
• Do not attempt to
open or service the
espresso machine.
• For any maintenance
other than cleaning,
call Breville Consumer
Support or visit a Breville
Authorized Servicer.
SPECIFIC
INSTRUCTIONS
FOR WATER
FILTER
• Filter cartridge should
be kept out of reach
of children.
• Store filter cartridges
in a dry place in the
original packaging.
• Protect cartridges from
heat and direct sunlight.
• Do not use
damaged filter cartridges.
• Do not open
filter cartridges.
• If you are absent for a
prolonged period of time,
empty the water tank and
replace the cartridge.

6
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
SHORT CORD
INSTRUCTIONS
Your Breville appliance is
fitted with a short power
cord to reduce personal
injury or property damage
resulting from pulling,
tripping or becoming
entangled with a longer
cord. Longer detachable
power cords or extension
cords are available and may
be used if care is exercised.
If an extension cord is used,
(1) the marked electrical
rating of the cord set or
extension cord should
be at least as great as the
electrical rating of the
appliance, (2) the cord
should be arranged so
that it will not drape over
the counter-top or table
where it can be pulled
on by children or tripped
over unintentionally and
(3) the extension cord
must include a 3-prong
grounding plug.
BREVILLE ASSIST®PLUG
Your Breville appliance
comes with a unique
Assist®Plug, conveniently
designed with a finger hole
to ease removal from the
power outlet.
CSA DUTY CYCLE
MARKING
The Canadian Standards
Authority requires any
appliances capable of
drawing over 1500W to be
marked with a ‘duty cycle’
in minutes. For the BES990,
this ‘duty cycle’ represents
the maximum time for
which the appliance will
draw over 1500W during
any 2 hour period of
use. It does not indicate
the appliance is unsafe
for continuous use or is
required to be switched off
at certain intervals during
normal use.

7
Components
A. Integrated conical burr grinder
with removable ½lb bean hopper
B. Top-fill 84 fl.oz (2.5L) removable water
tank with integrated water filter and backlit
level indicator
C. Grind size dial
adjust grind size to suit your coffee beans
D. Touch screen control panel
displays current settings and provides
touch interface
E. Grind outlet
with auto grind, dose & tamp function
F. Heated 58mm group head with
embedded element
G. 58mm full stainless steel portafilter
H. Drop down swivel foot
lifts the machine upwards
for easy maneuverability
I. Heated cup warming tray
J. Cool touch steam wand
with integrated temperature sensor
for automatic frothing
K. Dedicated hot water outlet
delivers hot water for Americano
and pre-heating cups
L. Descale access point
M. Tool storage tray
houses accessories when not in use
N. Removable drip tray
with Empty Me! indicator
G
H
E
D
F
B
C
A
J
L
N
M
K
I

8
Rating Information
A. Stainless steel milk jug
B. 2 cup filter basket
C. 1 cup filter basket
D. Water filter holder with filter
E. Cleaning disc
F. Mini grinds bin
G. Grinder burr brush
H. Grind outlet brush & tamp
removal magnet
I. Cleaning tool for steam wand tip
J. Two allen keys
K. Steam wand cleaning powder
L. Water hardness test strip
M. Espresso cleaning tablets
N. Descaling powder
ACCESSORIES
120 V~60 Hz 1650 W
A
E
F
I
G
HJ
D
C
K
L
M
B
N

9
COLOR TOUCH SCREEN
CONTROL PANEL
Swipe & Select from the drinks menu.
Adjust your coffee strength, milk texture
or milk temperature, then save it as your
personal favorite.
HANDS FREE AUTOMATIC
GRIND, DOSE & TAMP
Automatically grinds, doses and tamps the
required amount of coffee, mess free.
GRIND SIZE DIAL
Adjustable grind settings from fine to coarse
for optimal espresso extraction.
PRECISION CONICAL BURRS
Maximize ground coffee surface area for a full
espresso flavor.
AUTOMATIC HANDS FREE
MILK TEXTURING
Automatically textures milk to the selected
temperature and style from silky smooth
latté to creamy cappuccino. Automatic purge
removes residual milk from the steam wand
when returned to the downward position.
SIMULTANEOUS COFFEE & STEAM
Two stainless steel boilers each dedicated to
espresso and steam for simultaneous milk
texturing and espresso extraction.
PRECISION CONTROL
Electronic PID Temperature Control
Electronic temperature control delivers precise
water temperature for optimum espresso flavor.
Actively Heated Group Head
Commercial size 58mm group head with
embedded element for thermal stability
during extraction.
Regulated Extraction Pressure
Over pressure valve (OPV) limits maximum
pressure for optimal espresso flavor.
Low Pressure Pre-Infusion
Gradually increases water pressure to gently
expand grinds for an even extraction.
Dual Pumps
Dedicated Italian made espresso and steam
boiler pumps.
Programmable Shot Temperature
Adjust water temperature to achieve optimal
espresso flavor depending on coffee origin and
degree of roast.
ADDITIONAL FEATURES
Auto Start
Switches machine on at a specified time.
Auto Off
Switches machine off after a specified time
from 0.5 to 8 hours.
Oracle Touch
Features

10
Assembly
BEFORE FIRST USE
Machine Preparation
Remove and discard all labels and packaging
materials attached to your espresso machine.
Ensure you have removed all parts and
accessories before discarding the packaging.
Remove the plastic bag containing the water
filter and water filter holder. Clean parts and
accessories (water tank, portafilter, filter basket,
jug) using warm water and a gentle dish
washing liquid. Rinse well then dry thoroughly.
TIP
To easily manoeuvre your machine, use the
drop down swivel foot located under the drip
tray. When turned to UNLOCK, the swivel
foot drops down & lifts the machine upwards,
making it easier to access the removable
water tank or reposition the machine to
another location.
INSTALLING THE WATER FILTER
• Remove the water filter and water filter holder
from the plastic bag.
• Soak the filter in cold water for 5 minutes.
• Wash the filter holder with cold water.
• Set the reminder for next month of
replacement. We recommend to replace the
filter after 3 months.
• Insert the filter into the two parts of the
filter holder.
• To install the assembled filter holder into the
water tank, align the base of the filter holder
with the adapter inside the water tank.
Push down to lock into place.
• Fill the water tank with cold water before
sliding back into position at the back of the
machine and locking into place.
NOTE
Replacing the water filter after three months or
10.6 USgal / 40L will reduce the need to descale
the machine. Filter can be purchased
at Breville webpage.
NOTE
DO NOT use highly filtered, demineralised or
distilled water in this machine. This may affect
the taste of the coffee.
