Breville the Barista Pro BES878 User manual

the Barista Pro™
Instruction Book - BES878

2
BREVILLE
RECOMMENDS
SAFETY FIRST
At Breville we are very safety
conscious. We design and
manufacture consumer
products with the safety of you,
our valued customer, foremost
in mind. In addition we ask
that you exercise a degree of
care when using any electrical
appliance and adhere to the
following precautions.
IMPORTANT
SAFEGUARDS
READ ALL
INSTRUCTIONS BEFORE
USE AND SAVE FOR
FUTURE REFERENCE
•Carefully read all
instructions before
operating and save for
future reference.
•Do not touch hot surfaces.
Use handles or knobs as
advised in this instruction
book.
•To protect against
fire, electric shock and
injury to persons do not
immerse the power cord,
plug, or appliance itself
in water or other liquids.
•Close supervision is
necessary when any
appliance is used by
or near children.
•If the appliance is to be:
- left unattended
- cleaned
- moved
- assembled or
- stored
2Breville Recommends
Safety First
6 Components
8 Features
10 Assembly
11 Functions
18 Care & Cleaning
22 Troubleshooting
Contents

3
Always switch off the
appliance by pressing
the POWER button to
off and unplug from the
power outlet.
•Always allow the appliance
to cool before cleaning,
moving or storing.
•It is recommended to
regularly inspect the
appliance and power cord.
Do not use the appliance
if there is damage to the
power cord or plug, or after
the appliance malfunctions
or has been damaged in
any way.
Immediately stop use
and call Breville
Consumer Support.
•The use of accessory
attachments not
recommended by Breville
may result in fire, electric
shock or injury to persons.
•Do not let the power cord
hang over the edge of a
table or counter-top, or
touch hot surfaces.
•Do not place the
appliance near the edge
of a table or counter-top.
Ensure the surface is level,
clean and free of water
and other substances.
•Do not place the
appliance on or near a
hot gas or electric burner.
Do not place it in, or allow
it to come in contact with
a heated oven.
•Do not operate the
appliance if it is in
an enclosed space,
or within a cupboard.
•This appliance is
recommended for
household use only.
Do not use this appliance
for anything other than
its intended use. Do not
use outdoors. Do not use
in moving vehicles or
boats.

4
SPECIFIC
INSTRUCTIONS
FOR BES878
•It is recommended to plug
the espresso machine into
a properly grounded and
dedicated circuit, separate
from other electrical
appliances.
•Avoid contact with
moving parts.
•Check bean hopper
for presence of foreign
objects before using.
•Use only cold water in
the water tank. Do not
use any other liquids. Do
not use highly filtered,
demineralized or distilled
water as this may affect
the taste of the coffee and
how the espresso machine
operates.
•Ensure the portafilter
is firmly inserted and
secured into the group
head before starting an
extraction. Never remove
the portafilter during the
extraction process.
•Caution must be used
during descaling as hot
steam may be released.
Before descaling, turn
off the machine, allow
to cool for at least 1 hour
and ensure the drip tray is
empty and fully inserted.
For instructions, refer
to the 'Descaling' section
on page 19.
•Do not attempt to open
or service the espresso
machine.
•For any maintenance
other than cleaning,
call Breville Consumer
Support or visit a Breville
Authorized Servicer.
SPECIFIC
INSTRUCTIONS FOR
WATER FILTER
•Filter cartridge should
be kept out of reach of
children.
•Store filter cartridges
in a dry place in the
original packaging.
•Protect cartridges from
heat and direct sunlight.

5
•Do not use damaged
filter cartridges.
•Do not open filter
cartridges.
•If you are absent for a
prolonged period of time,
empty the water tank and
replace the cartridge.
SHORT CORD
INSTRUCTIONS
Your Breville appliance is
fitted with a short power
cord to reduce personal
injury or property damage
resulting from pulling,
tripping or becoming
entangled with a longer
cord. Longer detachable
power cords or extension
cords are available and
may be used if care is
exercised. If an extension
cord is used, (1) the marked
electrical rating of the
cord set or extension cord
should be at least as great
as the electrical rating of
the appliance, (2) the cord
should be arranged so
that it will not drape over
the counter-top or table
where it can be pulled
on by children or tripped
over unintentionally and
(3) the extension cord
must include a 3-prong
grounding plug.
BREVILLE ASSIST®
PLUG
Your Breville appliance
comes with a unique
Assist®Plug, conveniently
designed with a finger hole
to ease removal from the
power outlet.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS

6
Components
A. ½lb (250g) bean hopper
With locking system for easy removal, storage
and transfer of coffee beans.
B. Integrated conical burr grinder
C. GRIND SIZE selector
30 espresso grind settings from fine
to coarse.
D. POWER button
E. Integrated removable 54mm tamper
F. Grinder outlet
G. Grinding cradle
H. 54mm stainless steel portafilter
With commercial style spouts.
I. Storage tray (located behind drip tray)
For storage of accessories.
J. Removable drip tray grid
K. Removable drip tray
With tray full indicator.
L. 68 fl.oz (2L) removable water tank
With replaceable water filters
to reduce scale and impurities.
M. Steam dial
Selector control for steam and hot water.
N. LCD display
With grinding and extracting
progress animations.
O. Control panel
With MENU, GRIND AMOUNT/ FILTER
SIZE, 1 CUP and 2 CUP buttons.
P. Group head
Q. Dedicated hot water outlet
For making Americanos and
pre-heating cups.
R. Extra-tall cup clearance
S. 360° swivel steam wand
Easily adjusts to the perfect position
for texturing milk.
A
B
J
E
O
P
Q
L
M
N
R
S
D
I
K
C
F
G
H

7
ACCESSORIES
1. Stainless steel milk jug
With MIN and MAX markings.
2. Dual wall filter baskets (1 cup & 2 cup)
Use with pre-ground coffee.
3. Single wall filter baskets (1 cup & 2 cup)
Use when grinding fresh whole coffee beans.
4. Water filter and filter holder
All parts of the Barista Pro™
that come into contact with coffee,
water and milk are BPA Free.
1
6
5
7 8 9
2 3
4
5. Cleaning disc
6. Cleaning tablets
7. Cleaning brush
8. The Razor™ precision dose trimming tool
9. Steam wand and filter basket cleaning tool

8
THERMOJET™ HEATING SYSTEM
Innovative heating system achieves ideal
extraction temperature in 3 seconds.
INTEGRATED CONICAL BURR
GRINDER
Stainless steel conical burrs maximize
ground coffee surface area for a full espresso
flavor. Upper and lower burrs are removable
for cleaning.
ADJUSTABLE GRIND SIZE
30 espresso grind settings from fine to coarse
for optimal extraction.
ADJUSTABLE GRIND AMOUNT
Adjust the amount of fresh ground coffee
dosed into the filter basket to suit the fineness
or coarseness of the grind.
AUTOMATIC DOSING
The grinder will dispense the required
amount of ground coffee for a single or double
cup dose.
HANDS FREE GRINDING
Auto stop for hands free grinding directly into
the portafilter.
THE RAZOR™ DOSE TRIMMING TOOL
Patented twist blade trims down the puck
to the right level for precision dosing and a
consistent extraction.
ADJUSTABLE SHOT TEMPERATURE
CONTROL
For optimum coffee flavor.
PID TEMPERATURE CONTROL
Electronic PID temperature control
for increased temperature stability.
INSTANT HOT WATER
Dedicated hot water outlet for making
Americanos and pre-heating cups.
LOW PRESSURE PRE-INFUSION
Applies low water pressure at the start
of the extraction to gently expand grinds
for an even extraction.
VOLUMETRIC CONTROL
Pre-set 1 & 2 cup volumes, manual over-ride
or programmable shot volumes.
DRY PUCK FEATURE
Removes excess water from the ground coffee
in the filter basket after extraction for easy
disposal of the coffee puck.
LARGE DRIP TRAY
With more usable workspace.
Barista ProTM
Features

9
Assembly
BEFORE FIRST USE
Machine Preparation
Remove and discard all labels and packaging
materials attached to your espresso machine.
Ensure you have removed all parts and
accessories before discarding the packaging.
Remove the packaging and the plastics
bags containing the water filter and water
filter holder.
Clean the water tank, portafilter, filter baskets,
milk jug and drip tray using warm water and a
gentle dish washing liquid. Rinse well, then dry
thoroughly before reassembling.
INSTALLING THE WATER FILTER
• Remove the water filter and water filter holder
from the plastic bag.
• Soak the filter in cold water for 5 minutes.
• Wash the filter holder with cold water.
• Set the reminder for next month of
replacement. We recommend to replace the
filter after 2 months.
• Insert the filter into the filter holder.
• Install the assembled filter holder in the water
tank, ensuring it is clicked into place.
• Fill the water tank with cold water before
sliding back into position on the back of the
machine and locking into place.
• Refer to Care & Cleaning on page 18 for
further instruction on installing the filter.
NOTE
DO NOT use highly filtered, demineralized or
distilled water in this machine. This may affect
the taste of the coffee.
NOTE
For replacement water filters, visit the Breville
webpage or contact Breville Consumer Support.
FILLING THE WATER TANK
• Ensure the water filter is securely fitted
inside the water tank.
• Use the handle at the top of the water
tank to assist in lifting it up and away
from the machine.
MAX
MIN
• Fill the water tank with cold potable tap
water to below the MAX marking indicated
on the side of the water tank.
• Replace the water tank back on the machine,
pressing down to ensure that it is properly
positioned and attached to the machine.
MAX
MIN
NOTE
Replace the water daily. The water tank should be
filled with fresh, cold tap water before each use.

10
Assembly
ATTACHING THE HOPPER
Insert the bean hopper into position on top
of the machine.
Turn the dial to lock the hopper into place.
Fill with fresh coffee beans.
FIRST USE CYCLE
A first use cycle must be completed before
the initial use of the machine. The first use
cycle rinses the machine and primes the
heating system.
1. Fill the water tank.
2. Ensure machine is fully assembled with
the bean hopper, drip tray and water tank
securely attached to the machine.
3. Press the POWER button. The machine will
beep and go into FIRST CYCLE mode.
4. The LCD will display FLUSH and the 1 CUP
button will be illuminated.
PRE-INFUSE
SHOT
STEAM
SEC
AMOUNT
MANUAL
PAUSED
HOT
WATER
FLUSH
RESET
DEFAULTS
DESCALE
IN
PROGRESS
FILL
TANK
GRIND
DOUBLE
SINGLE
LOCK
HOPPER
GRIND
SIZE
SHOT TEMP
FASTER
POUR
SLOWER
POUR
CUSTOM
HOTTER
COOLER
CUSTOM
FILTER SIZE
MENU
EXIT
G
R
I
N
D
A
M
O
U
N
T
5. Press the 1 CUP button. The LCD will show
a count down for the remaining time of the
first use cycle.
6. Once complete, the machine will go into
READY mode.

11
Functions
TURNING OFF THE MACHINE
To turn the machine off, press the POWER
button. Alternatively, the machine has
auto-off, if it is not used for 30 minutes.
FILTER BASKETS
This machine includes 4 filter baskets;
2 x Single Wall and 2 x Dual Wall.
Single Wall filter baskets should be used when
grinding fresh whole coffee beans. They allow
you to experiment with grind, dose and tamp
to create a more balanced espresso.
1 CUP 2 CUP
Dual Wall filter baskets should be used when
using pre-ground coffee. They regulate the
pressure and help to optimize the extraction
regardless of the grind, dose and tamp pressure
or freshness.
1 CUP 2 CUP
Regardless of whether you use Single Wall
or Dual Wall filters baskets, use the 1 CUP
basket when brewing a single cup and the
2 CUP basket when brewing two cups or a
stronger single cup or mug.
You will need to adjust the grind amount and
size if switching from a single to a double
basket, or vice versa.
The provided filter baskets are designed for:
1 CUP basket = approx. 8 – 10g
2 CUP basket = approx. 19 – 22g
NOTE
You may need to experiment with how much
coffee is dosed into the filter basket or how
long the grinder needs to run to achieve the
correct dose. For example; when using a finer
espresso grind with the Single Wall filter
baskets, you may need to increase the grind
amount to ensure the filter basket is correctly
dosed.

12
THE GRIND
When grinding coffee beans, the grind size
should be fine, but not too fine. The grind size
will affect the rate at which water flows through
the ground coffee in the filter basket and the
taste of the espresso.
If the grind is too fine (looks like powder
and feels like flour when rubbed between
the fingers), the water will not flow through
the coffee, even when under pressure. The
resulting espresso will be OVER EXTRACTED,
dark in color and bitter in flavor.
If the grind is too coarse, the water will flow
through the ground coffee in the filter basket
too quickly. The resulting espresso will be
UNDER EXTRACTED and lacking in color
and flavor.
SETTING THE GRIND SIZE
This machine has 30 grind settings to select
from, with the size selected displayed on the
LCD screen. The default grind size is 15.
When adjusting the grind size, a bar will
display on the LCD indicating a faster or
slower pour.
PRE-INFUSE
SHOT
STEAM
SEC
AMOUNT
MANUAL
PAUSED
HOT
WATER
FLUSH
RESET
DEFAULTS
DESCALE
IN
PROGRESS
FILL
TANK
GRIND
DOUBLE
SINGLE
LOCK
HOPPER
GRIND
SIZE
SHOT TEMP
FASTER
POUR
SLOWER
POUR
CUSTOM
HOTTER
COOLER
CUSTOM
Use the GRIND SIZE selector on the left side
of the machine to adjust the grind size.
FINER
COARSER
DOSING THE COFFEE
• Fill the hopper with fresh coffee beans.
• Insert the required filter basket into the
portafilter.
• Place the portafilter into the grinding cradle.
• If required, press the FILTER SIZE button to
select the filter basket size; Single or Double.
• If required, turn the GRIND AMOUNT
dial to change the grind time; clockwise
to increase the time and anti-clockwise to
decrease.
NOTE
The default grind times are 9.5 seconds for a
1 cup filter and 13 seconds for a 2 cup filter.
• Press and release the portafilter to activate
the automatic dosing. The LCD will show the
filter basket filling.
PRE-INFUSE
SHOT
STEAM
AMOUNT
MANUAL
PAUSED
HOT
WATER
FLUSH
RESET
DEFAULTS
DESCALE
IN
PROGRESS
FILL
TANK
GRIND
DOUBLE
SINGLE
LOCK
HOPPER
SHOT TEMP
FASTER
POUR
SLOWER
POUR
CUSTOM
HOTTER
COOLER
CUSTOM
SEC
GRIND
SIZE
• If you need to pause the grinding function,
press and release the portafilter. The LCD
will show PAUSED, it will remain paused for
15 seconds before returning to READY mode.
• Press and release the portafilter to resume
grinding.
NOTE
It is normal for the portafilter to appear
overfilled with ground coffee.
MANUAL DOSING
To manually dose the coffee, press and hold
the portafilter in the grinding cradle until the
desired amount of ground coffee has been
dosed. To stop grinding, release the portafilter.
The timer will count up, displaying the grind
time.

13
TAMPING THE GROUND COFFEE
• Remove the portafilter from the
grinding cradle.
• Tap the portafilter several timers to
collapse and distribute the coffee evenly
in the filter basket.
• Using the tamper, tamp down firmly (approx.
15-20kg of pressure). The amount of pressure
is not as important as the consistent pressure
every time.
• As a guide, the top edge of the cap on
the tamper should be level with the top
of the filter basket AFTER the coffee has
been tamped.
NOTE
We recommend quality 100% Arabica beans
with a ‘Roasted On’ date stamped on the bags,
not a ‘Best Before’ or ‘Use By’ date. Coffee
beans are best consumed between 5 – 20 days
after the ‘Roasted On’ date. Stale coffee may
pour too quickly from the portafilter and taste
bitter and watery.
TRIMMING THE DOSE
The Razor™precision dose trimming tool
allows you to trim the puck to the right level
for a consistent extraction.
• Insert the Razor™dose trimming tool into
the filter basket until the shoulders of the
tool rest on the rim of the basket. The blade
of the dose trimming tool should penetrate
the surface of the tamped coffee.
• Rotate the Razor™dose trimming tool back
and forth while holding the portafilter on
an angle over a knock box to trim off excess
coffee grinds. Your filter basket is now dosed
with the correct amount of coffee.
• Wipe excess coffee from the rim of the filter
basket to ensure a proper seal is achieved in
the group head.
PURGING THE GROUP HEAD
Before placing the portafilter into the group
head, run a short flow of water through the
group head by pressing the 1 CUP button.
This will stabilize the temperature prior to
extraction and preheat the portafilter for a
consistent shot temperature.
INSERTING THE PORTAFILTER
Place the portafilter underneath the group head
so that the handle is aligned with the INSERT
position. Insert the portafilter into the group
head and rotate the handle towards the centre
until firm resistance is felt.
LOCK TIGHT

14
EXTRACTING ESPRESSO
• As a guide the espresso will start to flow after 8–10 seconds (infusion time) and should be the
consistency of dripping honey.
• If the espresso starts to flow after less than 6 seconds, you have either under dosed the filter
basket and /or the grind is too coarse. This is an UNDER EXTRACTED shot.
• If the espresso starts to drip but doesn’t flow after 15 seconds, the grind is too fine. This is an
OVER EXTRACTED shot.
• Flow starts after 8-12 secs
• Flow slow like warm honey
• Crema is golden brown with a fine
mousse texture
• Espresso is dark brown
SOLUTIONS SOLUTIONS
Tamp using 15-20kgs
of pressure. The top
edge of metal cap on the
tamper should be level
with the top of the filter
basket AFTER tamping.
Trim the puck to the
right level using the
Razor
™ precision dose
trimming tool.
• Flow starts after 1-7 secs
• Flow fast like water
• Crema is thin and pale
• Espresso is pale brown
• Tastes bitter/sharp, weak and watery
• Flow starts after 13 secs
• Flow drips or not at all
• Crema is dark and spotty
• Espresso is very dark brown
• Tastes bitter and burnt
REMOVE USED
GRINDS
Used grinds will form
a coffee 'puck'. If the
puck is wet, refer to
the 'Under Extraction'
section.
RINSE FILTER
BASKET
Keep the filter basket
clean to prevent
blockages. Without
ground coffee in the filter
basket, lock the
portafilter into the
machine and run hot
water through.
AFTER EXTRACTION
CORRECT EXTRACTION UNDER EXTRACTION OVER EXTRACTION
Tamp using 15-20kgs
of pressure. The top
edge of metal cap on the
tamper should be level
with the top of the filter
basket AFTER tamping.
Trim the puck to the
right level using the
Razor
™ precision dose
trimming tool.
ALWAYS TAMP TO LINE
Adjust & re-test
Adjust & re-test
DECREASE
GRIND AMOUNT
ALWAYS TAMP TO LINE
Adjust & re-test
Adjust & re-test
INCREASE
GRIND AMOUNT
Adjust & re-testAdjust & re-test
LOCK TIGHT
SEC
GRIND
DOUBLE
SEC
GRIND
DOUBLE
GRIND GRIND DOSE TAMP
OVER EXTRATED
BITTER • ASTRINGENT Too fine Too much
Use razor to trim Too heavy
BALANCED Optimum 8–10g (1 cup)
19–22g (2 cup) 15–20kg
UNDER EXTRACTED
UNDERDEVELOPED • SOUR Too coarse Too little
Increase dose & use razor to trim Too light

15
PRE-PROGRAMMED SHOT VOLUME –
1 CUP
Press the 1 CUP button once, the button will
flash, indicating that it has been selected. The
LCD will display PRE-INFUSE and the shot
clock will start counting up. Once pre-infusion
is complete, the shot will start extracting.
A pre-set single espresso volume of approx.
30ml will be extracted. The machine will
automatically stop once the pre-set volume
has been extracted.
PRE-INFUSE SHOT
STEAM
SEC
AMOUNT
MANUAL
PAUSED
HOT
WATER
FLUSH
RESET
DEFAULTS
DESCALE
IN
PROGRESS
FILL
TANK
GRIND
DOUBLE
SINGLE
LOCK
HOPPER
SHOT TEMP
FASTER
POUR
SLOWER
POUR
CUSTOM
HOTTER
COOLER
CUSTOM
GRIND
SIZE
PRE-PROGRAMMED SHOT VOLUME –
2 CUP
Press the 2 CUP button once, the button will
flash, indicating that it has been selected and
the LCD will display PRE-INFUSE and the shot
clock will start counting up. Once pre-infusion
is complete, the shot will start extracting. A
pre-set double espresso volume of approx.
60ml will be extracted. The machine will
automatically stop once the pre-set volume has
been extracted.
PRE-INFUSE
SHOT
STEAM
SEC
AMOUNT
MANUAL
PAUSED
HOT
WATER
FLUSH
RESET
DEFAULTS
DESCALE
IN
PROGRESS
FILL
TANK
GRIND
DOUBLE
SINGLE
LOCK
HOPPER
SHOT TEMP
FASTER
POUR
SLOWER
POUR
CUSTOM
HOTTER
COOLER
CUSTOM
GRIND
SIZE
MANUAL PRE-INFUSION &
EXTRACTION
Press and hold the 1 CUP or 2 CUP button
for the desired pre-infusion time. Release the
button to commence the extraction. Press the
flashing button to stop the extraction.
PRE-INFUSE SHOT
STEAM
SEC
AMOUNT
MANUAL
PAUSED
HOT
WATER
FLUSH
RESET
DEFAULTS
DESCALE
IN
PROGRESS
FILL
TANK
GRIND
DOUBLE
SINGLE
LOCK
HOPPER
GRIND
SIZE
SHOT TEMP
FASTER
POUR
SLOWER
POUR
CUSTOM
HOTTER
COOLER
CUSTOM
GRIND
SIZE
PROGRAMMING ESPRESSO SHOT
• Press the MENU button to enter the
main menu.
PRE-INFUSE
SHOT
STEAM
SEC
AMOUNT
MANUAL
PAUSED
HOT
WATER
FLUSH
RESET
DEFAULTS
DESCALE
IN
PROGRESS
FILL
TANK
GRIND
DOUBLE
SINGLE
LOCK
HOPPER
SHOT TEMP
FASTER
POUR
SLOWER
POUR
CUSTOM
HOTTER
COOLER
CUSTOM
GRIND
SIZE
• Use the GRIND AMOUNT dial to navigate
through the menu to the custom or
custom . To select, press the dial.
• Press the desired CUP button to start the
default pre-infusion. To customize the
pre-infusion, press and hold the same
CUP button for the desired pre-infusion
time. Release the button to commence the
extraction.
• To stop the extraction at the desired level,
press the CUP button. The LCD and CUP
button will stop flashing and the machine will
beep to indicate that the custom setting has
been remembered. The machine will then
return to READY mode. The custom setting
can now be activated by pressing the desired
CUP button selected.
ADJUSTING SHOT TEMPERATURE
• Press the MENU button to enter the
main menu.
• Use the GRIND AMOUNT dial to navigate
the menu and press to select SHOT TEMP.
PRE-INFUSE
SHOT
STEAM
SEC
AMOUNT
MANUAL
PAUSED
HOT
WATER
FLUSH
RESET
DEFAULTS
DESCALE
IN
PROGRESS
FILL
TANK
GRIND
DOUBLE
SINGLE
LOCK
HOPPER
GRIND
SIZE
SHOT TEMP
FASTER
POUR
SLOWER
POUR
CUSTOM
HOTTER
COOLER
CUSTOM
GRIND
SIZE
• Use the GRIND AMOUNT dial to increase
or decrease the shot temperature as displayed
on the LCD.
• Press the dial to confirm the desired
temperature. The machine will return to
READY mode.

16
RESETTING TO DEFAULTS
• Press the MENU button to enter the
main menu.
• Use the GRIND AMOUNT dial to navigate
the menu and select RESET DEFAULTS.
• The machine will beep.
• The GRIND AMOUNT, FILTER SIZE, SHOT
TEMP, 1 CUP and 2 CUP SHOT settings will
all return to the default settings. The machine
will return to READY mode.
USING HOT WATER OUTLET
The hot water function can be used to pre-heat
cups or to add hot water manually.
To activate the hot water, turn the STEAM
dial to .
PRE-INFUSE
SHOT
STEAM
SEC
AMOUNT
MANUAL
PAUSED
HOT
WATER
FLUSH
RESET
DEFAULTS
DESCALE
IN
PROGRESS
FILL
TANK
GRIND
DOUBLE
SINGLE
LOCK
HOPPER
SHOT TEMP
FASTER
POUR
SLOWER
POUR
CUSTOM
HOTTER
COOLER
CUSTOM
GRIND
SIZE
• The LCD will show that HOT WATER has
been activated.
• To stop the hot water, turn the dial back to the
centre, vertical position.
• The hot water will stop after 60 seconds, but
the dial must be turned back manually to the
standby position.
TEXTURING MILK
It is recommended to momentarily purge the
steam wand prior to texturing milk.
Position the steam wand over the drip tray
and turn the STEAM dial to the . The LCD
will display STEAM when activated. Turn the
STEAM dial back to a vertical position to stop
steaming.
Different brands and types of milk and milk
alternatives will texture differently.
• Start with fresh cold milk.
• Fill the milk jug to between the MIN and
MAX markings.
• Lift the steam wand and insert into the milk
jug with the steam wand tip 1-2cm below the
surface of the milk, close to the right-hand
side of the jug at a 3 o’clock position.
• Turn the STEAM dial to the .
• Keep the steam wand tip just under the
surface of the milk until the milk is spinning
clockwise, producing a vortex (whirlpool
effect).
• With the milk spinning, slowly lower the jug.
This will bring the steam wand tip to the
surface of the milk and start to introduce air
into the milk.
• Gently break the surface of the milk with the
tip to get the milk spinning fast enough.
• Keep the steam wand tip at or slightly
below the surface, continuing to maintain
the vortex. Texture the milk until sufficient
volume is obtained.
• Lift the jug to lower the tip beneath the
surface but keep the vortex spinning. The
milk is at the correct temperature (140-149°F
/ 60-65°C) when the jug is hot to touch.
• Once the desired temperature has been
achieved, turn the STEAM dial back to the
vertical position.
• Remove the steam wand from the milk jug.
• Wipe the steam wand with a clean, damp
cloth. Then return to lowered position over
the drip tray.
CAUTION: BURN HAZARD
Pressurized steam can still be released, even
after machine has been switched off.
Children must always be supervised.
NOTE
Ensure the STEAM dial is in the vertical
position before removing the steam wand from

17
ADJUSTING CONICAL BURRS
Some types of coffee may require a wider grind range to achieve an ideal extraction or brew.
A feature of your Barista Pro™ is the ability to extend this range with an adjustable upper burr. We
recommend making only one adjustment at a time.
6
77
F
I
N
E
C
O
A
R
S
E
4
PUSH
2
AIR TIGHT
CONTAINER
53
13
15
88
F
I
N
E
C
O
A
R
S
E
9
F
I
N
E
C
O
A
R
S
E
4
5
6
7
8
10
F
I
N
E
C
O
A
R
S
E
11 12
Lock upper burr
Hold hopper over container & turn
dial to release beans into container
Align hopper
into position
Run grinder
until empty
Remove hopperUnlock hopper
Move adjustable
top burr, 1 number,
coarser or finer
Remove wire
handle from both
sides of the burr
Align the number
with the handle
opening
Remove upper
burr
Insert wire
handle from both
sides of the burr
Push upper burr
firmly into
position
Align hopper
into position
Lock hopper Check your
extraction
14
1
the milk jug.
NOTE
When the machine creates steam, a pumping
noise can be heard. This is normal operation.
NOTE
Use only the supplied stainless steel milk jug to
froth milk using this machine. The use of other
containers may lead to dangerous conditions.
STEAM WAND PURGING
After texturing milk, it is recommended to
purge the steam wand. With the steam wand
positioned over the drip tray and turn the
STEAM dial to the , and allow the machine
to purge. Turn the STEAM dial back to a
vertical position to stop steaming.

18
Care & Cleaning
CAUTION:
To prevent damage to the appliance, do not use alkaline cleaning agents when cleaning, use a soft
cloth and mild detergent.
REPLACING THE WATER FILTER
2
Rinse filter and
mesh
2 43 6
Replace water tank
Assemble Set date + 2 months Install filter in tank
5
Soak for
5 minutes
1
MAX
MIN
The water filter provided helps to prevent scale build up which over time can affect the
performance of your machine. Replacing the water filter every 2 months will reduce the need to
de-scale the machine.
If you live in a hard water area, we recommend changing the water filter more frequently.
• Remove the water filter from the plastic bag.
• Soak the filter in cold water for 5 minutes.
• Rinse the filter and mesh under cold running water.
• Set the reminder for the next month of replacement. We recommend replacing the filter after 2
months.
• Insert the filter into the filter holder.
• Install the assembled filter holder in the water tank, ensuring it is locked into place.
• Fill the water tank with cold water before sliding back into position on the back of the machine
and locking into place.
NOTE
Replacement water filters can be purchased from the Breville website or by contacting Breville
Consumer Support.

19
FLUSH CLEANING CYCLE
The LCD will display a FLUSH alert when a
cleaning cycle is required. The cleaning cycle is
separate from descaling.
PRE-INFUSE
SHOT
STEAM
SEC
AMOUNT
MANUAL
PAUSED
HOT
WATER
FLUSH
RESET
DEFAULTS
DESCALE
IN
PROGRESS
FILL
TANK
GRIND
DOUBLE
SINGLE
LOCK
HOPPER
GRIND
SIZE
SHOT TEMP
FASTER
POUR
SLOWER
POUR
CUSTOM
HOTTER
COOLER
CUSTOM
1. Insert the cleaning disc into the filter basket
in the portafilter.
2. Place a cleaning tablet on top of the
cleaning disc.
3. Lock the portafilter into the group head.
4. Empty the drip tray and replace onto the
machine.
5. Fill the water tank to the MAX line then
reattach to the machine.
6. Press the MENU button to enter the
main menu.
7. Use the GRIND AMOUNT dial to navigate
the menu to FLUSH, then press to select.
The 1 CUP button will illuminate.
8. Press the 1 CUP button to start the cleaning
cycle. The remaining time for the cleaning
cycle will be displayed on the LCD.
9. Once the cleaning cycle is complete, the
machine will beep and return to READY
mode. If any of the cleaning tablet remains
in the cleaning disc, repeat the cycle.
10. Empty and rinse the portafilter, cleaning
disc and drip tray.
DESCALING
After regular use, hard water can cause
mineral build up in and on many of the
inner functioning components, reducing the
brewing flow, brewing temperature, power of
the machine, and the taste of the espresso. The
LCD will display a DESCALE alert, when a
descaling cycle is required.
1. Empty the drip tray and reattach to the
machine. Remove the water tank from the
machine and remove the filter from the
water tank.
2. Fill the water tank to the DESCALE line
indicated and add the descaling agent to
the water. Reattach the water tank to the
machine.
3. Press the MENU button to enter the main
menu. Use the GRIND AMOUNT dial to
navigate the menu to DESCALE, then press
to select. The 1 CUP button will illuminate.
4. Press the 1 CUP button to start the
descaling cycle. The descale cycle cleans in
3 stages; coffee, hot water and steam. After
each stage is complete, the machine will
beep . The STEAM DIAL must be manually
turned to the HOT WATER and STEAM
position when indicated on the LCD.
PRE-INFUSE
SHOT
STEAM
SEC
AMOUNT
MANUAL
PAUSED
HOT
WATER
FLUSH
RESET
DEFAULTS
DESCALE
IN
PROGRESS
FILL
TANK
GRIND
DOUBLE
SINGLE
LOCK
HOPPER
GRIND
SIZE
SHOT TEMP
FASTER
POUR
SLOWER
POUR
CUSTOM
HOTTER
COOLER
CUSTOM
5. Once the descale cycle is complete, the
machine needs to complete a rinse cycle.
The 1 CUP button will illuminate. As with
the descale cycle, the STEAM DIAL must
be manually turned to correct position
when indicated on the LCD.
6. Remove and empty the drip tray then
replace onto the machine. Empty any
remaining descaling liquid from the water
tank, then fill the water tank to the MAX
line and reattached to the machine.
7. Press the 1 CUP button to commence the
rinse cycle. The rinse cycle is also 3 stages.
The LCD will show which stage it is up to.
After each stage, the machine will beep.
8. Once the rinse cycle is complete, the
machine will beep and return to READY
mode.
9. Remove and rinse the drip tray and water
tank. Dry thoroughly before replacing them
on the machine.

20
CLEANING THE CONICAL BURR GRINDER
This grinder cleaning cycle removes oil build-up on the burrs which can impede performance.
Unlock hopper
Empty hopper Replace hopper Lock hopper Run grinder
empty
Unlock hopper Remove hopper
Remove top burr
Unlock top burr
Clean top burr
with brush
Clean lower
burr with brush
Clean chute
with brush
12
3 75
PUSH
2
11109988
L
O
C
K
A
L
I
G
N
41 6
ADVANCED CLEANING FOR THE CONICAL BURR GRINDER
This step is only required if there is a blockage between the grinding burrs and the grinder outlet.
Remove hopper
Set GRIND SIZE
to 1 (finest)
Use 10mm socket.
Rotate clockwise to
loosen the nut only
Set GRIND SIZE
to 30 (coarsest)
Unlock & remove
top burr
Remove nut, spring
& flat washer.
Carefully remove
lower burr
Remove grind fan
& washers
using long-nose
pliers
Insert & lock top
burr
Set GRIND SIZE
to 15. Replace &
lock hopper
Clean chute
with brush
Unblock the grinds
exit chute using the
brush or a pipe
cleaner
Insert washers &
grind fan using
long-nose pliers
Insert lower burr
(drive pin &
cavity to align).
Insert flat washer
& spring washer
Rotate counter-
clockwise to
tighten nut
12
TIGHTEN NUT
5
13 14
1 3
LOOSEN NUT
6
SPRING
WASHER
FLAT
WASHER
7
1. GRIND FAN
2. METAL WASHER
3. FELT WASHER
3
2
1
88 99 10
1. FELT WASHER
2. METAL WASHER
3. GRIND FAN
1
2
3
11
SPRING
WASHER
FLAT
WASHER
42
WARNING
Care should be taken as the grinder burrs are extremely sharp.
