Breville Moments User manual

Breville Moments™
hot drink maker

2
!This appliance generates heat during use. Adequate precaution must be taken to
prevent the risk of burns, scalds, res or other damage to persons or property caused
by touching the exterior whilst in use or during cooling.
!Never use this appliance for anything other than its intended use. This appliance is for
household use only. Do not use this appliance outdoors.
!Always ensure that hands are dry before handling the plug or switching on the
appliance.
!Always use the appliance on a stable, secure, dry and level surface.
!Do not position the appliance under a cupboard or shelf to prevent the risk of injury
from released steam.
!This appliance must not be placed on or near any potentially hot surfaces (such as a
gas or electric hob).
!Do not use the appliance if it has been dropped, if there are any visible signs of
damage or if it is leaking.
!Ensure the appliance is switched off and unplugged from the supply socket after use
and before cleaning. Always allow the appliance to cool before cleaning or storing.
!Never immerse any part of the appliance or power cord and plug in water or any other
liquid.
!Never let the power cord hang over the edge of a worktop, touch hot surfaces or
become knotted, trapped or pinched.
!Never leave the appliance unattended when in use.
!Never place anything on top of the appliance.
!Never ll the water boiler with any liquid other than water. To prevent damage, never
use the appliance without water.
!Never ll the milk tank above the MAX marking.
product safety
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Thisappliancecanbeusedbychildrenagedfrom8yearsandaboveandpersons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user maintenance shall not
be made by children unless they are older than 8 and supervised. Keep the
appliance and its cord out of the reach of children aged less than 8 years.
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
Ensure that the appliance control lever is in the OFF position when the
milk tank assembly is detached from the main housing unit.
Never use the appliance without the mixing chamber in place, or remove
the mixing chamber while the appliance is turned on.

3
parts
1. Mixing chamber and lid
2. Quick ll funnel
3. Steam pipe
4. Milk pipe
5. Milk tank
6. Milk tank housing
7. Drip tray
8. Milk level window
9. Water boiler cap
10. Hinged lid
11. Control lever
12. Location guide
1
2
3
4
5
6
7
9
8
10
11
12
MILK TANK ASSEMBLY MAIN HOUSING UNIT

4
Remove your Breville Moments™ hot drink maker carefully from the box. Remove any
packaging and promotional material and position the unit on a dry, level, secure work
surface away from the edge.
Before using for the rst time, wash the milk tank assembly.
Cleaning the milk tank assembly
All parts of the milk tank assembly are dishwasher safe. DO NOT put the water boiler cap
in the dishwasher.
Always remove the milk tank assembly as one complete unit.
For clarity, all of the unit’s parts that must be cleaned regularly are coloured red, or are
transparent or stainless steel.
1. Lift the unit’s hinged lid and gently pull out the milk tank assembly using the
indentation underneath the drip tray.
2. Lift out the milk tank from its housing and separate the quick ll funnel and mixing
chamber assembly.
3. Pull out the mixing chamber from the quick ll funnel and remove the mixing chamber
lid by turning it anti‑clockwise. Do not try to remove the mixing chamber when it is
in position on the milk tank assembly because there is a tab that prevents you from
doing this.
cleaning
w
e
q

5
4. Pull out the milk pipe from its connector on the steam pipe (coloured red) underneath
the quick ll funnel.
5. Remove the steam pipe from the quick ll funnel by pulling the tab.
6. Lift out the drip tray (coloured red) using the side tabs and remove the stainless steel
drip tray cover.
7. Wash the parts in the dishwasher, or by hand in warm soapy water. Wipe dry before
reassembling (perform steps 1 to 6 in reverse order, with reference to Reassembling
the steam and milk pipe on page 6.)
y
r t
cleaning

6
Reassembling the steam and milk pipe
1. Locate the dip at the front of the steam pipe before pivoting downwards into position
on the quick ll funnel.
2. Insert the milk pipe into its connector on the steam pipe.
cleaning
wq
Cleaning the main unit
Wipe the outside of the unit with a damp soapy cloth, then wipe dry with a soft cloth.
If the Breville Moments™ hot drink maker is not going to be used for a period of time, the
water boiler can be emptied. Make sure that the unit is turned off and unplugged, and has
been allowed to cool before commencing. Remove all loose parts. Empty any remaining
water by tipping upside down over a sink.

7
before first use
To ensure that any residue left over from the manufacturing process is removed, ush the
unit with clean water as described in the following procedure:
1. Reassemble the milk tank assembly after initial cleaning and push rmly into position
on the main housing unit using the location guide.
2. Make sure that the control lever is in the OFF position ( ).
3. Remove the water boiler cap by turning it anti‑clockwise and lifting off. Fill the
boiler with a maximum of 400ml of water and replace the cap securely by turning it
clockwise.
4. Lift the unit’s hinged lid and half ll the milk tank with clean water by pouring directly
into the quick ll funnel. Lower the hinged lid and click into place. Place your mug or
cup on the drip tray under the dispensing nozzle.
wq
e
r

8
5. Plug the unit into the mains supply and switch on. Turn the control lever to the HEAT
UP position ( ). The power indicator light will ash. After approximately 3 minutes
the power indicator light will remain on to show that the water is hot.
Note that the time taken for the water to heat fully will depend on the amount of water
in the boiler.
6. To start cleaning, turn the control lever anti‑clockwise and hold in the DISPENSE
position ( ). Clean water will be ushed through the unit into the cup. When all of
the water from the milk tank has ushed through, turn the control lever to the OFF
position ( ). A small amount of water will continue to be dispensed. Remove and
empty the cup.
Your Breville Moments™ hot drink maker is now clean and ready for use.
before first use
t
y

9
DO NOT USE FRESH OR GROUND COFFEE PRODUCTS. YOUR
BREVILLE MOMENTS™HOT DRINK MAKER IS DESIGNED TO USE INSTANT
COFFEE AND HOT CHOCOLATE. FOR BEST RESULTS ADD MALTED MILK
DRINK PRODUCTS DIRECTLY TO THE CUP. DO NOT USE SACHETS OF INSTANT
CAPPUCCINO OR LATTE IN THIS UNIT.
To prevent damage, never use your Breville Moments™hot drink maker without
water.
The time taken for your Breville Moments™ hot drink maker to heat the water fully
will depend on the amount of water in the water boiler.
For safety purposes, the water boiler cap cannot be removed when pressure builds
in the water boiler as a result of the water heating. The water boiler cap will spin
freely if you try to remove it during use. You must wait for the unit to cool down
fully before removing the cap.
Ensure that the control lever is in the OFF position when the milk tank assembly is
detached from the main housing unit.
Do not operate the unit without the mixing chamber in place on the milk tank
assembly.
1. If you have not used the unit for a while, check that there is water in the boiler. The
maximum ll capacity is 400ml. If the unit was disassembled after last use, make
sure that the milk tank assembly is fully inserted into the main housing unit.
2. Plug the unit into the mains supply, and turn the control lever to the HEAT UP
position ( ). The power indicator light will ash.
making coffee
q w

10
3. Lift the hinged lid and ll the milk tank with milk using the quick ll funnel, up to the
level required. The maximum capacity will provide 2 large mugs or 4 cups. DO NOT
EXCEED THE MAXIMUM LEVEL. You can add more milk easily if you want to make
more drinks. Lower the hinged lid and click into place.
4. Remove the mixing chamber lid by turning it anti‑clockwise. Use a teaspoon to add
the instant coffee into the front of the mixing chamber (look for the embossed spoon
for guidance). Only add enough coffee to brew ONE cup at a time. You can adjust
the quantity to suit your own taste, but you may nd that you need more coffee than
when making it with water.
Replace the lid of the mixing chamber by turning it clockwise to secure the correct lid
orientation.
e r
making coffee
