Breville the PopFan LFA100 User manual

Instruction Book - Suits all LFA100 Models
the PopFan™
LFA100_ANZ_IB_C20_FA.indd 1 5/6/20 1:24 pm

2
BREVILLE
RECOMMENDS
SAFETY FIRST
At Breville we are very safety
conscious. We design and
manufacture consumer
products with the safety of you,
our valued customer, foremost
in mind. In addition, we ask
that you exercise a degree
of care and adhere to the
following precautions.
IMPORTANT
SAFEGUARDS
READ ALL INSTRUCTIONS
BEFORE USE AND SAVE
FOR FUTURE REFERENCE
• Carefully read all instructions
before operating the fan for
the first time and save for
future reference.
• Remove and safely discard
any packaging material and
promotional labels before
using the fan for the first time.
• To eliminate a choking hazard
for young children, remove and
safely discard the protective
cover fitted to the power plug
of this fan.
• When unpacking the fan,
check to see you have received
all the items listed in the
parts list, before discarding
the packaging.
• Do not place the fan near
the edge of a bench or table
during operation. Ensure that
the surface is level, stable,
clean and free of water and
other substances.
• Do not place this fan on or near
a heat source, such as hot plate,
oven or heaters.
• Position the fan at a minimum
distance of 20cm away from
walls, curtains and other heat
or steam sensitive materials
and provide adequate space
above and on all sides for
air circulation.
2 Breville Recommends Safety First
6 Components
7 Control Panel
8 Operation
10 Care, Cleaning & Storage
Contents
LFA100_ANZ_IB_C20_FA.indd 2 5/6/20 1:24 pm

3
• Do not let the USB cable hang
over the edge of a bench or
table, touch hot surfaces or
become knotted.
• This fan is for household
use only. Do not use this fan
for anything other than its
intended use. Do not use in
moving vehicles or boats.
Do not use outdoors.
Misuse may cause injury.
• The fan is not intended for use
by persons (including children)
with reduced physical,
sensory or mental capabilities,
or lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
• Children should be supervised
to ensure that they do not play
with the appliance.
• Always ensure the fan is
properly assembled before
use. Follow the instructions
provided in this book.
• This fan is intended for
household use only and not for
commercial or industrial use.
• Disconnect the USB cable
before assembling or before
cleaning and when the fan is
not in use.
• Avoid touching moving parts
of the fan. When adjusting
the movement of the front
grille, ensure the louvre knob
is the part being rotated.
Ensure to only rotate the
louvre knob for 0.5 to 1.5
turn in counterclockwise
direction as the front grille
may disassemble.
• Never insert fingers, pencils or
any other objects through the
guards whenever the power
plug is connected, in particular
while the fan is switched on.
• Do not operate in the presence
of explosives and/or flammable
fumes or liquids.
• Always turn the fan OFF when
the fan is not in use.
• Do not unplug the fan by
pulling on the USB cable.
• Never carry the fan by the
USB cable. Use the carry
strap provided.
• Never yank the USB connector
to disconnect the USB cable
from the USB port; instead,
grasp the USB connector and
pull to disconnect. Do not twist
or pull the USB cable around
sharp edges or corners.
• Please ensure the fan is in
collapsible format if hanging
on the wall. The fan will not be
balanced if hung on the wall in
LFA100_ANZ_IB_C20_FA.indd 3 5/6/20 1:24 pm

4
another format. Please ensure
to use a picture hanging hook
that can withstand a weight of
at least 0.70kg.
• Allow the fan blade to stop
completely before cleaning and
maintenance unless otherwise
specified in this booklet.
• The battery is non-replaceable.
• To prevent damage to the fan,
do not use alkaline cleaning
agents when cleaning, uses a
soft cloth and mild detergent.
• Do not place anything, on top
of the fan when assembled,
when in use and when stored.
• Any maintenance other than
cleaning should be performed
at an authorised Breville
Service Centre.
• Store the unit out of reach
of children.
• Keep the fan clean. Follow the
cleaning instructions provided
in this book.
PLEASE READ THE
FOLLOWING WHEN
CHARGING THE FAN WITH
USB POWER ADAPTOR
• Use only an electrical safety
compliant, DC 5V 2A (or
a minimum of 10W), USB
power adaptor.
• Fully unwind the USB cable
before attaching to the fan and
the USB power adaptor prior
to charging.
• Connect the fan to the USB
power adaptor with the USB
cable provided.
• Do not, under any
circumstances, modify the
USB power adapter. Follow the
safety instructions provided by
the USB power adaptor.
• To protect against electric
shock, do not immerse the USB
cable, USB power adaptor or
fan in water or any other liquid
or allow moisture to come in
contact with the part, unless
it is recommended in the
cleaning instructions.
LFA100_ANZ_IB_C20_FA.indd 4 5/6/20 1:24 pm

5
• It is recommended to regularly
inspect the fan, USB cable and
USB power adaptor. To avoid a
hazard, do not use the fan, USB
cable and power adaptor if they
become damaged in any way. If
the fan is faulty, return the fan
and the USB cable provided to
the nearest authorized Breville
service centre for examination
and / or repair.
• During electrical storms, while
charging, the USB adaptor
should be disconnected from
the power source at the wall
socket to prevent any electrical
surges that may arise during
the storm and which may
inadvertently cause damage to
the USB adaptor and electronic
componentry inside the fan.
LFA100_ANZ_IB_C20_FA.indd 5 5/6/20 1:24 pm

6
A. Front grille frame
B. Rotating front grille
C. Louvre knob
D. Tube storage groove
E. Base
F. Control panel with LED indicator lights
G. Rear grille
H. Fan blade
I. Angle adjusting pivot
J. Tube
K. Collapsible stand pivot
L. Carry strap
M. USB Port
N. USB Cable
Components
G
I
J
K
L
M
N
H
A
B
F
D
C
E
LFA100_ANZ_IB_C20_FA.indd 6 5/6/20 1:24 pm

7
A. POWER ON/OFF button
B. FAN SPEED button
C. FAN SPEED and CHARGING LIGHTS
Control Panel
B
A
C
LFA100_ANZ_IB_C20_FA.indd 7 5/6/20 1:24 pm

8
oOperation
OPERATING YOUR BREVILLE FAN
BEFORE FIRST USE
Before using your Breville fan for the first
time, remove all packaging material and
promotional labels. Check for any missing or
damaged parts as per the components list.
ADJUSTING THE POSITION OF
YOUR FAN
The fan can be used in a collapsible format or
in any angle up to an upright position. The
angle of the fan head can also be adjusted from
horizontal to vertical positions. To unfold, pull
the top half of the fan up towards the carry
strap found on the back of the base, then use
the angle adjusting pivot and collapsible stand
pivot to adjust the angle of the tube and the
fan head based on preference. Position the
fan accordingly.
HANGING YOUR FAN
When fully collapsed, the fan can hang on the
wall using the carry strap provided. The fan
can be hung to be used and stored. Install a
picture hanging hook (not provided) that can
withstand a weight of at least 0.70kg. Ensure
the hanging hook is positioned at least 20cm
away from other appliances or objects that may
damage the fan.
nNOTE:
• If the fan is hung for the purpose of operation,
it will need to be turned ON first, before it is
then collapsed and hung onto the wall.
• If the fan is in use while hanging, the breeze
will be reduced considerably, due to the
compact position.
• Ensure the fan is fully collapsed when hung on
the wall. The fan will not be balanced if hung
on the wall incorrectly.
nCHARGING YOUR FAN
The fan can be charged using the USB cable
provided and a compatible electronic device
or DC 5V 2A (or a minimum of 10W) USB
power adaptor.
1. Place the fan on a flat surface, close to a USB
power outlet port.
2. Connect the fan to the USB power outlet port
by using the USB cable supplied.
3. The indicator lights on the fan will start to
flash to indicate the fan is charging.
4. Once all indicator lights illuminate and
no lights remain flashing, the fan has
fully charged.
5. Disconnect the USB cable from the USB
power outlet and the fan once charged. If
using a USB power adaptor, switch off the
power from the power point and unplug the
USB power adaptor prior to disconnecting
the USB cable. To check the battery life
while the fan is OFF, press and hold the
button for 2 seconds and the LED lights will
illuminate to show the current charging level
of the battery.
LFA100_ANZ_IB_C20_FA.indd 8 5/6/20 1:24 pm

9
nNOTE:
• If the ON/OFF button is pressed and the fan
does not turn on, all LED indicator lights will
simultaneously flash 5 times, and the fan will
need to be recharged.
• To prolong the life of the battery, it is not
recommended to operate the fan while the
fan is charging.
RUNNING TIME ON BATTERY
Fan Speed Duration
Speed 1 Approx. 15 Hours
Speed 4 Approx. 4 Hours
ADJUSTING THE FAN SPEED
The fan speed can be adjusted from Speed 1 to
Speed 4.
1. Press the button and the fan will start on
the lowest setting, Speed 1.
2. To change the fan speed, press the
button repeatedly, the light/s corresponding
with the selected speed will illuminate.
The fan will start automatically.
nNOTE:
The fan is fitted with a power saving feature.
Lights will turn off after 60 seconds if no
control buttons are touched. Touching any
button will turn the lights on.
nNOTE:
If the battery is not sufficiently charged while
the fan is in operation, it will simultaneously
flash 5 times before turning off automatically.
3. To switch the fan off at any time during
operation, press the button.
USING THE ROTATING
FRONT GRILLE
To use the rotating front grille, turn the louvre
knob counter-clockwise 0.5 – 1.5 times and
let go. The front grille should start to rotate
clockwise on its own. To stop the front grille
from rotating, turn the louvre knob clockwise
0.5 – 1.5 times.
nNOTE:
Do not rotate the louvre knob more than
recommended (0.5 to 1.5 times) as the rotating
front grille may swing loudly or disassemble.
LFA100_ANZ_IB_C20_FA.indd 9 5/6/20 1:24 pm

10
C
Care, Cleaning
& Storage
Always turn the Breville fan off and ensure
the fan is not connected to the USB cable
prior to cleaning. As dust build up can cause
performance issues, it is recommended you
clean the fan at least once a month, depending
on use.
To clean the outside of the fan, wipe the
exterior with a soft, damp cloth. Never use an
abrasive cleaner.
To clean the fan blades and remove dust
that may have accumulated, use a soft,
damp cloth or a vacuum cleaner using the
brush attachment.
STORAGE
When not in use, fold the fan to its compact
position. Store the fan and the USB cable in a
cool, clean and dry location.
LFA100_ANZ_IB_C20_FA.indd 10 5/6/20 1:24 pm

11
Note
LFA100_ANZ_IB_C20_FA.indd 11 5/6/20 1:24 pm

Australian Customers
Phone: [phone]
Web: www.breville.com
New Zealand Customers
Phone: [phone]
Web: www.breville.com
Breville Customer Service Centre
Breville, the Breville logo and PopFan are trademarks of Breville Pty. Ltd.
All other brands may be trademarks of their respective owners.
Breville’s products are distributed in New Zealand under license. A.B.N. 98 000 092 928.
Due to continued product improvement, the products illustrated/photographed in this booklet
may vary slightly from the actual product.
LFA100 ANZ – C20
LFA100_ANZ_IB_C20_FA.indd 12 5/6/20 1:24 pm
