Hitecsa KUBIC Series User manual

07.16 207477 Rev.108
Installation, Operation and Maintenance Manual
Cooling Only
Heat Pump
RMXCA RMXCBA
ROOF TOP UNITS –AXIAL FAN
Models: 1402.2 │1602.2 │2002.2 │2402.2 │3002.2 │3502.2 │4002.2 │4502.2
Cooling Capacities from: 46,1 to 178,4 KW
Heating Capacities from: 46,8 to 193,5 KW

2
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
Thank you for trusting in Hitecsa Products. Our company has been offering the market an extended range of specialized units for
air conditioning and cooling installations for over 30 years. Our approach is based on efficiency, adaptability, usability and practical
solutions. This has been the hallmark of our product catalogue.
The versatility of our factory allows us to contribute solutions, almost tailored to each project’s specifications, in search of a
solution to every problem that arises in design and implementation of air conditioning installations.
From all of us at Hiplus Aire Acondicionado, once again, thank you very much

3
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
INTRODUCTION.................................................................................................................................................................4
SAFETY PRECAUTIONS...................................................................................................................................................5
RECEPTION .......................................................................................................................................................................6
INSPECTION WHEN RECEIVING .................................................................................................................................6
RIGGING........................................................................................................................................................................6
STORAGE......................................................................................................................................................................6
INSTALLATION LOCATION ..............................................................................................................................................7
UNIT SETTLEMENT (KG)..............................................................................................................................................7
SERVICE AREA(M).......................................................................................................................................................7
START UP ........................................................................................................................................................................12
OPERATIONAL LIMITS...............................................................................................................................................13
DRAINAGE ..................................................................................................................................................................14
AIR DUCTWORK.........................................................................................................................................................14
INDOOR TRANSMISSION ADJUSTMENT..................................................................................................................15
COMPRESSOR LUBRICANT......................................................................................................................................16
STD TECHNICAL FEATURES........................................................................................................................................17
RCF MODULE TECHNICAL FEATURES ........................................................................................................................18
VRC MODULE TECHNICAL FEATURES ........................................................................................................................19
DIMENSIONS ...................................................................................................................................................................20
MODELS 1402.2 –1602.2 STD....................................................................................................................................20
MODELS 2002.2 –3002.2 STD...................................................................................................................................21
MODELS 3502.2 STD ..................................................................................................................................................22
MODELS 4002.2 -4502.2 STD.....................................................................................................................................23
MODELS 1402.2 –1602.2 RCF....................................................................................................................................24
MODELS 2002.2 –3002.2 RCF....................................................................................................................................25
MODELS 3502.2 RCF..................................................................................................................................................26
MODELS 4002.2 –4502.2 RCF....................................................................................................................................27
MODELS 1402.2 –1602.2 VRC....................................................................................................................................28
MODELS 2002.2 –3002.2 VRC....................................................................................................................................29
MODELS 3502.2 VRC..................................................................................................................................................30
MODELS 4002.2 –4502.2 VRC....................................................................................................................................31
ACCESSORIES –RAIN KIT.............................................................................................................................................32
REFRIGERANT CHARGE................................................................................................................................................35
MAINTENANCE................................................................................................................................................................36
ANNEX: SAFETY FILE R410A ........................................................................................................................................37
INDEX

4
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
INTRODUCTION
The content of this manual is designed to ensure proper installation, adjustment and maintenance of the unit, therefore:
• Read the instructions carefully.
• The unit must be installed, verified and repaired by appropriately qualified personnel in accordance with current
legislation.
• The manufacturer is not liable for warranty and will not respond to possible failures of the unit if unauthorized electrical
or mechanical modifications are found. Manipulation and unauthorized repairs or modifications of the unit will
automatically void the warranty.
• Pay attention due to security considerations when installing the unit.
• Ensure that the characteristics of the main wiring correspond to the required written on the nameplate of the unit.
• Keep this manual and the wiring diagram carefully and make sure they are available for viewing by an operator
whenever necessary.
• Some packaging materials (plastic envelopes, expanded polystyrene, etc.) are potentially dangerous and should be
kept out of reach of children. Recycle packaging materials in accordance with local law.
• Units must be used only for the purpose for which they were designed. The manufacturer is not liable in the case of
applications other than the specified use.
• Unplug the equipment in case of breakdown or malfunction.
• If repairs are needed, use only authorized service centers HITECSA also always use original spare parts. The use of
non-original parts and / or unauthorized service centers may provoke risk situations for the unit.
Regulations and certifications
CERTIFICATION ISO 9001: 2008: Always trying to achieve maximum customer satisfaction, HIPLUS AIR
CONDITIONING SL has obtained the ISO 9001: 2008 Quality System activity refers to production, this results in an
ongoing determination to improve the quality and reliability of our products; commercial activities, design, raw materials,
production and after-sales service are the means to achieve our goal.
CE RATING: Our machines have the CE mark in accordance with the essential requirements of applicable European
directives and latest amendments, and with national legislation of each country.
EUROVENT CERTIFICATION: HITECSA participates in the EUROVENT Certification program. Go to our website to
know more about certification of our products.

5
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
SAFETY PRECAUTIONS
•Installation and maintenance of air conditioning equipment can be dangerous because system is it has high temperature
of some elements and it includes electrical components.
• Only qualified and trained service personnel should install, start up and do maintenance on air conditioning equipment.
• During every visit follow recommendations from the Installation Operation Maintenance, what is shown on unit’s
stickers and take general legal safety precautions .
• Strictly abide by any and all safety codes.
• Use safety goggles, proper work gloves and any other work safety accessory recommended for any particular task.
• For brazing operations use a quenching cloth and keep a fire extinguisher at a close distance.
• When repairing the unit use only original spare parts and install them properly in the same place where have been
located old parts.
• Do not install the unit in explosive atmosphere.
• These units are designed to operate using 100% recycled air. For installations that use the support of ambient air,
please consult with our comercial department.
• This product contains flourine-based greenhouse gases.
Before starting installation, service or maintenance switch off the main system power
switch to avoid electrical shock.
Before accessing the inside of the unit through the electric box, it is
MANDATORY to unplug the electrical supply hose that MUST BE FREE of voltage
for this operation.
ATTENTION
ATTENTION

6
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
RECEPTION
INSPECTION WHEN RECEIVING
• When the receiving the equipment, it is advisable to examine it carefully.
• Inspect the received equipment for damage or missing elements. If units are damaged or shipment is incomplete,
immediately file the claim with the shipping company.
• Check if unit nameplate voltage is correct and agrees with local power supply.
• In the case of detecting any damage or anomaly, it is recommended to contact HITECSA.
RIGGING
• Before moving the unit, make sure that all panels are well fixed and sturdy.
• Raise and lower the unit carefully
•Raise and set down the equipment carefully.
• During the transport never tip or roll the unit more than 15 degrees.
•To lift the unit, a crane can be used. Suggestions for the transport company are found below.
• When unit is being lifted, make sure it is balanced and stable, keep in mind that the heaviest part is where the
compressor is installed
•All units come with a proper rigging maneuver schematic, specific to that model of the Kubic series, to the likeness of
the one shown below.
STORAGE
• If the equipment must be stored before installation, certain precautions must be adopted to prevent damage, corrosion
or deterioration:
• Do not place the machine in areas exposed to ambient temperatures exceeding 40 ° C and preferably not give direct
sunlight.
• Minimum storage temperature is 8 ° C
• Maximum Relative Humidity: 90%
Fig.1

7
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
INSTALLATION LOCATION
• Check if the surface is able to support the unit’s weight.
• Verify that the service area is the correct one for that specific model.
• Check if service area is indicated for these units and sufficient fresh air supply to condenser.
• Choose a location free of dust and foreign matter which, can clog or damage condenser coil.
• Consult and respect all regulations concerning installation of air conditioning systems.
UNIT SETTLEMENT (Kg)
• Ensure that the unit is properly leveled.
• In the case to place the unit above the bed this must have sufficient surface and strength to support the weight of the
unit.
• Make sure the drains are working properly.
• Use of dampers is recommended to reduce noise and vibration transmission.
SERVICE AREA (m)
► MODELS 1402.2 –3002.2 STD

8
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
► MODEL 3502.2 STD
► MODELS 4002.2 –4502.2 STD

9
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
► MODELS 1402.2 –3002.2 RCF
► MODEL 3502.2 RCF

10
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
► MODELS 4002.2 - 4502.2 RCF
► MODELS 1402.2 –3002.2 VRC

11
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
► MODEL 3502.2 VRC
► MODELS 4002.2 - 4502.2 VRC

12
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
START UP
• Start up is to be performed by qualified, technical personnel.
.
• Make a start-up checklist and use it to check up for service and maintenance. Record chilled water inlet and outlet
temperatures and pressures, outdoor air temperature, volts and amps of each compressor and fan motor, suction and
discharge pressure of each compressor.
• Keep in mind that, after 4 hours of system operation, it is necessary to clean the air filters.
• Closely supervise at least 3 cooling cycle operations.
1.Power Supply 400V ~3N 50Hz
2.Disconnect Switch
3.Control
POWER SUPPLY
230 v AC
3
2
BELDEN TYPE
BRAIDDING AND SHIELDED
1
L N T
• Ensure that all electrical connections are correct.
• Ensure that all panels are secured with screws.
• Check for oil or coolant leaks.
• Ensure that the unit is level.
• Check if areas for service and maintenance are clear.
• Check that the drain is not blocked.
• Check if the crankcase heater for each compressor is in operation for 24 hours before commissioning.
• Check air filters are clean and placed correctly.
• Check grills, diffusers, air ducts and tarpaulins.
• Ensure that the power supply is in accordance with what is stated on the serial plate.
• Verify that fans are rotating in the correct direction.
PRIOR TO START UP

13
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
OPERATIONAL LIMITS
► COOLING MODE
KUBIC series
1402.2
1602.2
2002.2
2402.2
3002.2
3502.2
4002.2
4502.2
Outdoor max temperature. Interior 27º C BS /
19º C BH
ºC
48
46
50
47
45
47
47
45
Outdoor max temperature. In downloading
ºC
50
50
50
50
50
50
50
50
Outdoor max temperature. Indoor 20º C BS*
ºC
18
19
18
19
20
19
19
20
Max Temperature. Inlet Indoor battery.
Outdoor 38º C BS
ºC
33
34
32
33
34
33
33
34
Mín Temperature. Inlet indoor battery
.Outdoor 35º C BS
ºC
17
18
17
18
18
18
18
18
► HEATING MODE
KUBIC series
1402.2
1602.2
2002.2
2402.2
3002.2
3502.2
4002.2
4502.2
Outdoor min Temperature. Indoor 20º C BS
ºC
-8 BH
-7 BH
-8 BH
-7 BH
-6 BH
-7 BH
-7 BH
-6 BH
Min Temperature. Inlet indoor battery Outdoor
7º C BS
ºC
13
13
14
13
13
13
13
13
Units can work at maximum altitude of 1500 m.
For other conditions, please consult us.
*For lower temperatures it is necessary to use the condensation control, supplied as optional.
• The electrical power supply to the unit should agree with data on the plate. Unit start-up at incorrect voltage and
damages resulting from that are not covered by Hitecsa guarantee.
• When making electrical connections always use the unit’s wiring diagram.
• Verify that the compressor crankcase heater can be energized before unit start up.
• Unit current supply should be within ±5% of Voltage and Amperes indicated on the unit nameplate.
• Do not operate unit at different current from the one shown on unit plate
• The installer has to install line protection elements according to local laws and regulations.
•The interconnecting wires have to be in protection tube or inside groove channel.
Before to access inside the unit through the electric box, it is MANDATORY to
unplug the electrical supply hose that MUST BE FREE of voltage for this
operation.
ATTENTION
N

14
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
DRAINAGE
• The Kubic units are factory equipped with a condensate drain water pan tilted as recommended by ASHRAE (11mm /
m) to prevent excessive water accumulation and subsequent bacteria flourishing.
• Additionally, Kubic models ranging from 1402.2 up to 3002.2 have drains built into each battery in order to avoid excess
condensate accumulation in the zone where the unit’s compressors are located. A siphon should be used on both drains
to aid the flow of liquid. However, total evacuation of condensates through these drains is not guaranteed. In order to
obtain the best possible drainage conditions, we strongly recommend the unit be fitted with the external condensate tray
accessory.
• Kubic series models 3502.2 up to 4502.2 the aforementioned drains are only installed when the condensate tray
accessory option is requested.
•All drains are fitted with 3/4" gas connections.
•The indoor drain (of condensate water) has an MPT 3/4” pipe
connection. The outdoor recovery drain (of condensate water) has MPT
3/4” pipe connection.
• Condensate evacuation line diameter should be equal or larger
than unit drain connection depending on line length and general
building configuration.
• The condensate line should be pitched a minimum 2% for proper water
evacuation.
• If the drain line is at below 0 temperatures, then is necessary to install thermal insulation or an electric wire heater to
prevent freezing which would damage the tube
• It is convenient to install trap with proper dimensions.
• With the condensate tray option, 2 drains are added in the outdoor section with a 3/4” male MPT connection.
AIR DUCTWORK
• Air duct dimensions are determined in function of air flow and available external static pressure.
• A qualified technician should design air ductwork layout.
• Use air ducts made of nonflammable materials, which in the case of fire will not emit toxic gases. It is advisable
to use insulated sheet metal ducts.
• Use flexible connections between air ducts and the unit to avoid vibrations and noise transmission.

15
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
INDOOR TRANSMISSION ADJUSTMENT
• Adjust transmission so that the indoor motor consumption reaches its nominal value.
• If consumption is below the nominal value, then the airflow in the unit is too low.
- To change fan speed
1. In order to remove belt, move motor along its track
2. Loosen pulley set screws and rotate, if it is necessary, move flange.
3. Tighten set screws.
4. Replace belt in pulley channel.
5. Tighten belt using tensor screw.

16
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
- To align fan and motor pulleys:
1. Loosen fan pulley set screw.
2 Slide fan pulley along the shaft and align with motor using a ruler to be parallel with the belt.
3 Tighten the fan pulley set screw.
COMPRESSOR LUBRICANT
Compressors designed for 410A use POE oils. Each compressor manufacturer is using different oil for its products.
Compressors are designed for 410A use synthetic Each compressor manufacturer is using different oil for
his products. The compressor or system cannot remain open to atmosphere more than 15 minutes. Compared to
the mineral oil used with R22 compressors polyoilester lubricants absorb more than 100 times more the moisture.
Mineral oils or alkylbenzene-type synthetic oils are used for R22. Because R410A is not very soluble with conventional
oils, the latter tend to accumulate in the refrigerator circuit .That is why ester-type synthetic lubricants (POE,polyester)
which are highly soluble with R410A are used. Oils of this type are very hygroscopic, so they need to be handled more
carefully than conventional oils. Also, these synthetic oils deteriorate when they are mixed with mineral or alkylbenzene-
type oils and obstruct the capillaries or cause a breakdown in the compressor. Do not mix them under any circumstance.

17
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
STD TECHNICAL FEATURES
KUBIC series
1402.2
1602.2
2002.2
2402.2
3002.2
3502.2
4002.2
4502.2
CAPACITIES
Cooling capacities (1)
kW
46,1
52,4
65,1
79,1
86,9
113,6
125,3
134,8
Power Input (3)
kW
15,5
19,2
21,2
27,7
32,7
39,5
44,4
49,9
EER coefficient
kW/ kW
2,97
2,73
3,07
2,86
2,66
2,88
2,82
2,70
Heating capacities (2)
kW
46,8
53,9
66,1
80,4
88,7
119,1
132,7
143,0
Power Input (3)
kW
13,3
16,6
18,0
24,0
27,8
35,6
41,4
45,8
COP coeficient
kW/ kW
3,52
3,25
3,67
3,35
3,19
3,35
3,21
3,12
REFRIGERANT
Type
R-410A
PCA (4)
2088
Load
Kg
12,5
13,2
14
15,6
16
31
32
33
COMPRESSOR
Type
Scroll
Quantitty
2
Number of refrigerant circuits
2
Number of stages (5)
2
Oil type
Danfoss POE 160 SZ
INDOOR FAN CIRCUIT
Type
Un
Outdoor Axial Rotor Exterior
Quantity
Un
2
4
Nominal air flow
m3/h
31724
39332
46556
60088
Available static pressure
Pa
0
Diameter
mm
710
800
710
Power
kW
1,25/0,97
1,9/1,2
1,25/0,97
Speed
rpm
950/825
890/690
950/825
INDOOR CIRCUIT
Nominal air flow
m3/h
9000
10200
11500
14000
15500
21000
23000
25000
Available static pressure
Pa
100
125
150
Quantity / Size
---
15/15
2 x 15/11
2 x 18/18
Power
kW
1,5
2,2
2,2
4
4
4
5,5
5,5
Speed
rpm
616
677
712
802
860
642
673
707
Condensates drainage
Ø
Junction 3/4"
ELECTRICALS CAHRACTERISTICS
Power supply
400V -3N 50Hz
Max. power input
kW
22,6
26,7
30,6
34,4
40,4
56,3
63,5
69,7
Start-up current
A
72,8
90,1
96,9
192,5
202,1
261,2
295,1
327,2
DIMENSIONS
Length
mm
2886
3900
Width
mm
2219
2219
Height
mm
1240
1900
TRANSPORT
Weight
Kg
944
975
1023
1043
1072
1594
1704
1721
Shipping
Un x 20”/40”/40”HQ
2 / 4 / 8
(1) Calculated according to the standard UNE-EN-14511, for indoor temperature conditions of 27ºC, 50% HR and 35ºC outdoor temperature.
(2) Calculated according to the standard UNE-EN-14511, for indoor temperature conditions of 20ºC and 6ºC BH outdoor temperature.
(3) Total power input by compressor and motor fans in normal conditions, calculated according to the standard UNE-EN-14511.
(4) Climatic warming potential of one kg of fluorinated greenhouse gas in relation to a kg of carbon dioxide over a period of 100 years.
(5) The number of stages is increased by one with free-cooling (FC)

18
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
RCF MODULE TECHNICAL FEATURES
MODULE WITH THERMODYNAMICS RECOVERY
KUBIC series
1402.2
1602.2
2002.2
2402.2
3002.2
3502.2.
4002.2
4502.2
CAPACITIES
Cooling capacity (1)
kW
64,1
71,1
87,4
103,5
116,4
152,0
164,8
178,4
Power input(3)
kW
20,3
23,9
26,8
34,4
41,6
49,7
55,7
63,1
EER coefficient
kW/ kW
3,16
2,97
3,26
3,01
2,80
3,06
2,96
2,83
Heatinc capacities (2)
kW
67,4
76,8
89,2
106,0
120,8
163,8
177,6
193,5
Power input (3)
kW
17,1
19,9
22,7
28,2
34,4
42,4
48,6
54,8
COP coefficient
kW/ kW
3,94
3,85
3,92
3,76
3,51
3,86
3,65
3,53
REFRIGERANT
Type
R-410A
PCA (4)
2088
Load
Kg
12,6 + 3,3
13,2 + 3,5
14 + 4
15,6 + 4
16 + 4,3
15,5 + 6
16,5 + 6
16,5 + 6,5
COMPRESSOR
Type
Scroll
Quantity
3
Cooling circuits quantity
3
Stages number (5)
3
Oil type
Danfoss POE 160 SZ
OUTDOOR FAN CIRCUIT
Type
Un
Axial Rotor Exterior
Quantity
Un
2
4
Nominal air flow
m3/h
31724
31724
39332
39332
39332
39332
39332
39332
Static pressure available (5)
Pa
0
Diameter
mm
710
800
710
Power
kW
1,25/0,97
1,9/1,2
1,25/0,97
Speed
rpm
950/825
890/690
950/825
INTERIOR CIRCUIT
Nominal air flow
m3/h
9500
10200
11500
14000
15500
21000
23000
25000
Static pressure available
Pa
100
100
125
125
125
150
150
150
Quantity / Size
---
15/15
2 x 15/11
2 x 18/18
Power
kW
1,5
2,2
2,2
4
4
5,5
5,5
7,5
Speed
rpm
649
726
712
802
860
716
756
798
Condensates removal
Ø
Junction 3/4"
RETURN CIRCUIT
Nominal air flow
m3/h
9000
10200
11500
14000
15500
21000
23000
25000
Static pressure available
Pa
75
75
100
100
100
100
100
100
Quantity / Size
---
15/15
2 x 15/11
2 x 18/18
Power
kW
1,5
2,2
2,2
4
5,5
4
5,5
7,5
Speed
rpm
616
681
731
835
897
661
703
746
Condensates drainage
Ø
Junction 3/4"
ELECTRICAL FEATURES
Power supply
400V -3N 50Hz
Max. power input
kW
30,0
34,3
39,5
46,9
53,7
72,4
80,4
89,2
Start up current
A
96,6
115,9
142,0
262,6
268,6
335,7
374,0
418,9
DIMENSIONS
Length
mm
3988
5845
Width
mm
2219
2219
Height
mm
1240
1900
TRANSPORT
Weight
Kg
1315
1353
1417
1445
1531
2373
2519
2549
Shipping
Un x 20”/40”/40”HQ
1 / 3 / 6
All data measured for a renewal flow of 90%
(1) Nominal cooling: Outdoor air temperature: 35 ºC. Indoor air wet temperature: 19 ºC.
(2) Nominal pump: Outdoor air wet temperature: 6 ºC. Indoor air temperature 20 ºC.
(3) Motor fans and compressors power input in previous conditions.
(4) Climatic warming potential of one kg of fluorinated greenhouse gas in relation to a kg of carbon dioxide over a period of 100 years.
(5) The number of stages is increased by one with free-cooling (FC).

19
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
VRC MODULE TECHNICAL FEATURES
MODULE WITH CENTRIFUGAL RETURN FAN
KUBIC series
1402.2
1602.2
2002.2
2402.2
3002.2
3502.2
4002.2
4502.2
CAPACITIES
Cooling capacities (1)
kW
48,2
54,9
68,0
82,8
91,0
118,7
131,1
141,2
Power input (3)
kW
17,2
21,4
23,2
30,8
36,5
43,3
49,3
55,7
EER coefficient
kW/ kW
2,80
2,56
2,93
2,69
2,49
2,74
2,66
2,53
Heating capacities (2)
kW
48,4
56,7
67,3
83,2
93,3
121,2
137,3
150,4
Power input (3)
kW
14,9
18,8
19,9
27,0
31,5
39,4
46,5
51,9
COP coefficient
kW/ kW
3,24
3,01
3,38
3,09
2,96
3,08
2,95
2,90
REFRIGERANT
Type
R-410A
PCA (4)
2088
Load
Kg
12,5
13,2
14,1
15,4
16,2
31,0
32,0
33,0
COMPRESSOR
Type
Scroll
Quantity
2
Number of refrigerant circuits
2
Number of stages (5)
2
Oil type
Danfoss POE 160 SZ
OUTDOOR FAN CIRCUIT
Type
Un
Axial Rotor Exterior
Quantity
Un
2
4
Nominal air flow
m3/h
31724
31724
39332
39332
39332
39332
60088
60088
Available static pressure
Pa
0
Diameter
mm
710
800
710
Power
kW
1,25 / 0,97
1,9 / 1,2
1,25 / 0,97
Speed
rpm
950/825
890/690
950/825
INDOOR CIRCUIT
Nominal air flow
m3/h
9000
10200
11500
14000
15500
21000
23000
25000
Available static pressure
Pa
100
100
125
125
125
150
150
150
Quantity / Size
---
15/15
2 x 15/11
2 x 18/18
Power
kW
1,5
2,2
2,2
4
5,5
4
5,5
5,5
Speed
rpm
616
677
712
802
860
642
673
860
Condensates drainage
Ø
Junction 3/4"
RETURN CIRCUIT
Nominal air flow
m3/h
9000
10200
11500
14000
15500
21000
23000
25000
Available static pressure
Pa
75
75
100
100
100
100
100
100
Quantity / Size
---
15/15
2 x 15/11
2 x 18/18
Power
kW
1,5
2,2
2,2
3
4
4
4
5,5
Speed
rpm
5,75
604
602
686
742
568
603
637
Condensates removal
Ø
Junction 3/4"
ELECTRICAL FEATURES
Power supply
400V -3N 50Hz
Max. power input
kW
23,7
28,1
32,3
37,2
44,0
59,0
66,8
73,8
Start-up current
A
76,0
95,0
102,3
208,4
220,1
273,5
310,7
346,7
DIMENSIONS
Length
mm
3988
5845
Width
mm
2219
2219
Height
mm
1240
1900
TRANSPORT
Weight
Kg
1233
1265
1347
1376
1442
2238
2380
2405
Shipping
Un x 20”/40”/40”HQ
1 / 3 / 6
All data measured for a flow renovation at 25 %.
(1) Nominal cooling capacity: Outdoor temperature: 35 ºC. Dry indoor temperature: 19 ºC.
(2) Nominal heating capacity: Wet outdoor temperature: 6 ºC. Indoor temperature: 20 ºC.
(3) Motor fans and compressors power input in previous conditions.
(4) Global warming potential of one kg of fluorinated gas of greenhouse effect relative to one kilogram of carbon dioxide over a period of 100 years.
(5) The number of stages is increased by one with free-cooling (FC).

20
07.16 207477 Rev.108
ROOF TOP UNITS –AXIAL FAN
RMXCA/RMXCBA
DIMENSIONS
MODELS 1402.2 –1602.2 STD
WEIGHT DISTRIBUTION (kg)
KUBIC
R1
R2
R3
R4
R5
R6
1402.2
193
133
119
198
182
119
1602.2
199
138
119
204
196
119
CENTRE OF GRAVITY (mm)
KUBIC
X
Y
Z
1402.2
1267
1147
604
1602.2
1269
1148
604
LEGEND
Standard air supply
Optional air supply
Standard air return
Optional air return
Electrical board
Switch
Electricity supply
Condensate drainage Ø3/4”
Anchorage silent block: M12
Mouth profile: 25 mm
Equipment chassis width: 130mm
3
1
2
2
1
4
5
6
