Breville DuraCeramic VST070 User manual

deep ll sandwich toaster
DuraCeramic™coated plates

2
product safety
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children unless they are older
than 8 and supervised.
Keep the appliance and its cord out of reach of children less than 8 years
old.
Bread can burn therefore do not use the appliance near or below
combustible materials such as curtains. Never use the appliance below wall
cupboards or shelves.
Never operate the appliance by means of an external timer or separate
remote-control system.
Do not touch the metal parts of the appliance during use as they may
become very hot.
Never use this appliance for anything other than its intended use. This
appliance is for household use only. Do not use this appliance outdoors.
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
!Always ensure that hands are dry before handling the plug or switching on the
appliance.
!Always use the appliance on a stable, secure, dry and level surface.
!Care is required when using the appliance on surfaces that may be damaged by heat.
The use of an insulated pad is recommended.
!This appliance must not be placed on or near any potentially hot surfaces (such as a
gas or electric hob).
!Never let the power cord hang over the edge of a worktop, touch hot surfaces or
become knotted, trapped or pinched.
!Do not use the appliance if it has been dropped or if there are any visible signs of
damage.
!Ensure the appliance is switched off and unplugged from the supply socket after use
and before cleaning.
!Always allow the appliance to cool before cleaning or storing.
!Do not immerse the main body, cord set or plug in water or liquid of any kind.
!Never leave the appliance unattended when in use.

3
features
1 Latch–holdsthelidrmlyclosedduringcooking
2 Handle
3 Powerlight(green)
4 Ready-to-cooklight(amber)
5 Topcookingplatereleasebutton
6 Bottomcookingplatereleasebutton
7 RemovablecookingplateswithDuraCeramic™coatingand
cut-and-sealaction
8 Dualtemperaturecontrol
Due to our policy of continuous improvement, the actual product may differ slightly from the one illustrated in these instructions.
er
q
wt
y
i u
Beforerstuse
• Unpack your sandwich toaster. You may wish to keep the packaging for future use.
• Remove and wash the cooking plates thoroughly to remove any impurities or
residues that may be left over from the manufacturing process (follow the directions
under Care and Cleaning).
• Clean the outside of your sandwich toaster with a soft damp cloth which has been
wrung almost dry in warm soapy water. The cover can be polished with a soft dry
cloth.
Note that the rst time you use your sandwich toaster, you may notice a slight burning
smell and a little smoke. This is completely normal and will soon disappear.

4
using your sandwich toaster
DuraCeramic™coatedcookingplates
The cooking plates feature the exclusive DuraCeramic™coating. This specialised natural
ceramic coating is designed to transfer heat quicker and more efciently than standard
non-stick coatings – meaning faster cooking times for your delicious home-cooked
snacks. In addition, the DuraCeramic™coating is scratch resistant and 4 times more
durable than standard non-stick coatings – this is a product built to last. Peace of mind
comes from the fact that the DuraCeramic™coating is PTFE and PFOA free, so this
exclusive coating is durable and easy to clean.
DuraCeramic™coating – designed to handle whatever you throw at it with ease.
Dualtemperaturecontrol
The dual temperature control allows you to change the heat setting for cooking different
types of food.
The Low heat setting is ideal for cooking foods with a high sugar content
(e.g. pastries and cookies). Why not look out for chilled, ready-rolled prepared pastries,
danishes, and cookie doughs? These are ideal for the sandwich toaster and take minutes
to prepare and cook.
The High heat setting is recommended for making toasties.
Importantpoints:
• Alwaysallowa2cmgaparoundthesandwichlling.
• Neveroverllyourtoastie,especiallywhenusingingredientsthatcontainfood
colouring,orcolouredcheeses.Toomuchllingcanleakoutandmaystain
thesandwichtoaster’shousing.
Recipe ideas
• Tuna Melt (tuna, onion, mayonnaise
and cheese)
• Cheese and tomato
• Cheese, beans and ham
• Turkey, stufng and cranberry
• Ham, Brie, mushrooms and rocket
• Steak and mushrooms
• BLT (bacon, lettuce and tomato)
• Bacon and cheese
• Chicken, red pepper and Brie
• Sweet chilli chicken
• Sausage and scrambled eggs
• Camembert and cranberry
• Chocolate and banana
• Banana and plum
• Toffee and apple
Making toasties is easy and fun, they can be as creative or as simple as you like and
make great snacks whether eaten at home or on the go.
Using basic ingredients delicious sweet or savoury meals can be made in minutes,
perfect for any time of the day. Here are some classic toasted sandwich recipes that you
may wish to try.

5
using your sandwich toaster
Breads
For best results, use a supermarket own-label, medium, white sliced bread. For variety,
why not try using wholemeal bread, Danish-style bread, seeded breads, sourdough and
fruit breads.
Cheeses
Classic cheeses that melt easily like Cheddar, Gruyère and Emmental make excellent
toasties. We’ve included some different cheeses in our recipes but why not experiment
and get creative with your own favourite cheeses!
Theperfecttoastie
Even if you are already familiar with using a sandwich toaster, it’s worth following the
guidelines below.
1. Plug your sandwich toaster in to the mains supply socket and switch the socket on
if required. The green power light will come on and your sandwich toaster will start
heating up.
2. Select the required heat setting (Low or High) using the dual temperature control.
3. When your sandwich toaster is fully heated the amber ready-to-cook light will come
on. This light will come on and go out during cooking.
4. Spread the OUTSIDE of the bread with butter or a spread suitable for cooking.
5. Place the two lower slices of bread onto the bottom plate ‘buttered’ side down. Face
the crusts of the bread to the left and right as shown below.

6
6. Add the lling. The deeper cooking plates allow you to use more of your favourite
ingredients but always allow a 2cm gap around the lling as shown below. This will
allow your sandwich toaster to form a good seal and prevent the lling from leaking
out.
For best results, the maximum amount of cheese, when used as a single ingredient,
should not exceed 60g. If you add other ingredients, reduce the amount of cheese to
compensate for them.
7. Place the remaining bread on top with the buttered side on the outside (this will give
your toastie a lovely golden colour during cooking).
8. Close and latch the lid and allow to cook for approx 4–5 minutes until golden and
cooked. Leave the sandwich in the toaster for more or less time according to taste.
9. Release the latch and open the lid. Watch out for escaping steam—use a tea towel
or wear oven gloves. Remove the cooked sandwich with a non-metallic spatula.
Don’t use a metal blade as this can damage the ceramic surface of the plates.
10. Once cooked, take care when eating as llings, especially fruit or tomato, can be
very hot.
using your sandwich toaster

7
HIGH TEMPERATURE COOKING
THE BASIC 3: CHEESE AND HAM, CHEESE AND TOMATO, CHEESE AND
ONION - MAKES 2
Cheeseandham Cheeseandtomato Cheeseandonion
4 slices of bread
Sliced medium cheddar
2 slices of ham
4 slices of bread
Sliced medium cheddar
2 medium tomatoes
4 slices of bread
Sliced medium cheddar
Finely sliced onion rings
To make, follow the directions on page 5 under The perfect toastie.
Other great avours include cheese and pickle, cheese and Marmite, mature cheese and
chutney.
LIGHTER LUNCH TOASTIE - Makes 2
4 slices of Danish-style lower fat bread
3 tbsp reduced fat cottage cheese
2 tbsp nely chopped red pepper
Finely sliced red onion
Ground black pepper
Low fat spread
This toastie is a lower fat/healthier option which replaces the cheddar cheese with a low
fat cottage cheese. Alternatively replace the standard cheddar with a half fat alternative
widely available from larger supermarkets.
To make, combine the lling ingredients in a small dish then add to the bread. Cook for
about 4 minutes until crispy and golden.
PIZZA POCKETS - Makes 2
4 slices of bread
40g mozzarella cheese
2 tbsp pizza topping
Pizzatoppingideas:
Sliced olives, nely chopped mixed peppers, chillies, pepperoni, tuna, cooked shredded
chicken, cooked sliced mushrooms, sliced tomatoes etc.
To make, assemble your sandwiches, spreading the pizza topping on the bottom of the
bread, then add the mozzarella and your chosen toppings. Cook for approx 4 minutes
until crispy and golden. Serve with a rocket and parmesan salad drizzled with olive oil and
balsamic vinegar.
recipes

8
STEAK PASTIES - Makes 2
Ready rolled shortcrust pastry or a small
quantity of homemade shortcrust pastry
2 tbsp tinned stewed steak
Melted butter
1. Dust your work surface with our and roll out half of the shortcrust pastry, this should
be large enough for 2 sandwich plates. Repeat again so that you have 4 squares.
You can remove the top plate from your sandwich toaster and use it as a template
(rather than pressing the plate onto the pastry).
2. Place some of the steak lling in the centre of each of the pastry triangles (don’t
overll). Place the remaining pastry triangles over the pastie and seal all the edges.
3. If removed, ret the sandwich plate and switch on, allow the machine to heat. Brush
the plates sparingly with some vegetable oil or butter if you prefer.
4. Carefully place each pasty onto the bottom plate and close and latch the lid.
5. Cook for 6–7 minutes until golden brown and piping hot.
6. Switch off your sandwich toaster and carefully remove the pasties. Allow the pasties
to cool for a few minutes. Remember that the lling inside will be very hot!
OMELETTE - Serves 2
3 medium eggs
Pinch sea salt
Freshly ground black pepper
Melted butter or oil
1. Beat together the egg and seasoning.
2. Brush the top and bottom cooking plates with a little melted butter.
3. Carefully pour in the egg dividing it between the two lower plates.
4. Close the lid and cook for 1½ minutes
5. Open the lid and using a silicone spatula, carefully lift the omelettes out. Eat them hot
with some Caesar salad or a salad of your choice.
Why not try adding a teaspoon of grated mature cheese and a pinch of chives to the egg
for a cheesy omelette alternative.
recipes

9
LOW TEMPERATURE COOKING
CAKE BITES - Makes 4 triangles
50g softened butter
50g castor sugar
1 medium egg
50g self-raising our
Vanilla extract (optional)
1. Using a hand mixer, cream together the butter and sugar until light and uffy. Add a
few drops of vanilla (if using) and mix well.
2. Add the egg and beat until smooth. Fold in the our.
3. Preheat your sandwich toaster.
4. Add a heaped tablespoon of the mixture into each ‘triangle’ and close the lid.
5. Cook for 3–4 minutes until golden brown.
6. Dust with castor sugar and serve warm, with ice cream and fruit.
CHOCOLATE, HAZELNUT AND BRIE - Makes 2
4 slices of brioche bread
1 tbsp chopped toasted hazelnuts
60g Brie, sliced
1 tbsp dark chocolate, chopped
Honey (optional)
Brioche (although smaller than supermarket bread) will seal and toast beautifully.
1. Butter one side of each bread slice. Place two slices on the bottom plate.
2. Assemble by placing the cheese on the bottom slices of brioche. Scatter over the
nuts and chocolate and drizzle with a little honey if desired.
3. Top with the other two slices of brioche and cook for 3–4 minutes. The rich brioche
will toast quickly.
4. Remove from your sandwich maker using care because they will be extremely hot.
FRUITY FLAPJACK BITES - Makes 4
You will need to use baking parchment for this recipe.
100g oats
25g mixed seeds
(pumpkin and sesame seeds work well)
50g dried fruit
50g butter
1 tbsp syrup
50g brown sugar
1. Place the oats, seeds and dried fruit into a suitable mixing bowl. Melt the butter, syrup
and brown sugar together, either in a microwave or in a heatproof bowl over a pan of
water.
2. Combine all the ingredients, mixing well to coat all of the oats.
3. Preheat your sandwich toaster.
4. Place a rectangular piece of non-stick baking parchment over the bottom plate. This
needs to be slightly larger than the plate.
5. Divide the apjack mixture equally between the plates, close the lid and cook for 6–7
minutes.
6. Once cooked and golden, carefully remove the paper and apjacks and allow to cool
on a wire rack for about 1 hour. Peel off the baking parchment when cool.
recipes

10
recipes
COCONUT AND HONEY FLAPJACK BITES - Makes 4
You will need to use baking parchment for this recipe.
100g oats
30g mixed seeds
50g dried fruit
50g brown sugar
50g coconut oil
1 tbsp honey
50g brown sugar
1. Place the oats, seeds, dried fruit and brown sugar into a suitable mixing bowl. Melt
the coconut oil either in a microwave or in a heatproof bowl over a pan of water.
2. Combine all the ingredients together, adding the honey and mixing well to coat all of
the oats.
3. Preheat your sandwich toaster.
4. Place a rectangular piece of non-stick baking parchment over the bottom plate. This
needs to be slightly larger than the plate.
5. Divide the apjack mixture equally between the plates, close the lid and cook for 6–7
minutes.
6. Once cooked and golden, carefully remove the paper and apjacks and allow to cool
on a wire rack for approx 1 hour.
7. Peel off the baking parchment when cool.
TRIPLE CHOCOLATE SPONGE BITES
75g softened butter
75g castor sugar
1 large egg
60g self-raising our
30g cocoa powder
25g white chocolate chips
25g milk chocolate chips
Splash of milk
1. Place the softened butter and castor sugar into a suitable mixing bowl and cream
together until light and uffy. Add the egg and whisk well.
2. Fold in the our and cocoa powder. Add a splash of milk and the chocolate chips, mix
lightly to combine.
3. Preheat your sandwich toaster.
4. Place a large tbsp of the mixture into each hot mould, close the lid and cook for 6–7
minutes until cooked through.
5. Remove carefully with a silicone spatula and allow to cool.
Delicious eaten slightly warm and dusted with icing sugar.

11
care and cleaning
Unplugandswitchoffyoursandwichtoasterandallowittofullycooldown
beforecleaningit.Donotimmersethemainbody,cordsetorpluginwateror
liquidofanykind.
Neverusesteelwool,scouringpads,abrasivecleanersormetallicutensilstoclean
yoursandwichtoaster.
1. Wipe the cooking plates with an absorbent paper or soft damp cloth.
2. Clean the outside of your sandwich toaster with a soft damp cloth which has been
wrung almost dry in warm soapy water. The cover can be polished with a soft dry
cloth.
3. Press the cooking plate release buttons and remove the plates from your sandwich
toaster. Immerse the plates in warm, soapy water. Rinse with clean water. Wipe dry
with a soft cloth. To avoid oxide forming on the uncoated surfaces of the plate, insert
the plate back into your sandwich toaster and heat for one minute with the lid closed.
Note: We recommend that you wash the cooking plates by hand only, in order to
preserve the DuraCeramic™ coating.

12
Thisappliancemustbeearthed.
This appliance is tted with either a moulded or rewirable BS1363, 13 amp plug. The fuse
should be rated at 13 amps and be ASTA approved to BS1362.
If the fuse in a moulded plug needs to be changed, the fuse cover must be retted. The
appliance must not be used without the fuse cover tted.
If the plug is unsuitable, it should be dismantled and removed from the supply cord
and an appropriate plug tted as detailed below. If you remove the plug it must not be
connected to a 13 amp socket and the plug must be disposed of immediately.
The wires of the mains lead are coloured in accordance with the following code:
GREEN/YELLOW = EARTH BLUE = NEUTRAL BROWN = LIVE
The wire which is coloured GREEN/YELLOW must be connected to the terminal in
your plug which is marked with an E or by the earth symbol ( ) or coloured GREEN or
GREEN /YELLOW.
The wire which is coloured BLUE must be connected to the terminal in your plug which is
marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal in your plug which
is marked with the letter L or coloured RED.
If any other plug is used, a 13 amp fuse must be tted either in the plug or adaptor or at
the distributor board.
connection to the mains supply
Blue
(Neutral)
Brown
(Live)
13A Fuse
Green/Yellow
(Earth)
Plug should be ASTA approved to BS1363
Fuse should be ASTA approved to BS1362
Ensure that the outer sheath of
the cable is firmly held by the cord grip

13
after sales service
These appliances are built to the very highest of standards. There are no user serviceable
parts. Follow these steps if the unit fails to operate:
1. Check the instructions have been followed correctly.
2. Check that the fuse has not blown.
3. Check that the mains supply is functional.
If the appliance will still not operate, return the appliance to the place it was purchased for
a replacement. To return the appliance to the Customer Service Department, follow the
steps below:
1. Pack it carefully (preferably in the original carton). Ensure the unit is clean.
2. Enclose your name and address and quote the model number (located on the rating
label) on all correspondence.
3. Give the reason why you are returning it.
4. If within the guarantee period, state when and where it was purchased and include
proof of purchase (e.g. till receipt).
5. Send it to our Customer Service Department at the address below:
CustomerServiceDepartment
JardenConsumerSolutions(Europe)Limited
MiddletonRoad,Royton,Oldham
OL25LN,UK.
Telephone:01616216900Fax:01616260391
e-mail:[email protected]
Replacementparts
For additional or replacement parts, please visit www.breville.co.uk or call us
on 01616216900.
Troubleshooting
For troubleshooting and FAQs visit www.breville.co.uk/faqs
TurnonyourCreativity™
Let Breville®help you turn on your creativity with a gateway to a world of food and drinks
without limits. You don’t have to travel far – just to your computer, tablet or mobile - where
you will discover our FREE website with top tips and recipes to inspire your imagination.
Join us now atwww.turnonyourcreativity.com
®

14
guarantee
Please keep your receipt as this will be required for any claims under this guarantee.
This appliance is guaranteed for 1 year after your purchase as described in this
document.
During this guaranteed period, if in the unlikely event the appliance no longer functions
due to a design or manufacturing fault, please take it back to the place of purchase, with
your till receipt and a copy of this guarantee.
The rights and benets under this guarantee are additional to your statutory rights, which
are not affected by this guarantee. Only Jarden Consumer Solutions (Europe) Limited
(“JCS (Europe)”) has the right to change these terms.
JCS (Europe) undertakes within the guarantee period to repair or replace the appliance,
or any part of appliance found to be not working properly free of charge provided that:
• you promptly notify the place of purchase or JCS (Europe) of the problem; and
• the appliance has not been altered in any way or subjected to damage, misuse,
abuse, repair or alteration by a person other than a person authorised by JCS
(Europe).
Faults that occur through, improper use, damage, abuse, use with incorrect voltage, acts
of nature, events beyond the control of JCS (Europe), repair or alteration by a person
other than a person authorised by JCS (Europe) or failure to follow instructions for use
are not covered by this guarantee. Additionally, normal wear and tear, including, but not
limited to, minor discoloration and scratches are not covered by this guarantee.
The rights under this guarantee shall only apply to the original purchaser and shall not
extend to commercial or communal use.
If your appliance includes a country-specic guarantee or warranty insert please refer
to the terms and conditions of such guarantee or warranty in place of this guarantee or
contact your local authorized dealer for more information.
Waste electrical products should not be disposed of with Household waste. Please
recycle where facilities exist. E-mail us at [email protected] for further
recycling and WEEE information.
Jarden Consumer Solutions (Europe) Limited
5400 Lakeside
Cheadle Royal Business Park
Cheadle
SK8 3GQ
UK
