Briggs & stratton 310000 vertical series User manual

Not for

Reproduction

2 BRIGGSandSTRATTON.com

Not for

Reproduction

Not for

Reproduction

This manual contains safety information to make you aware of the hazards and risks

associated with engines and how to avoid them. It also contains instructions for the proper

use and care of the engine. Because Briggs & Stratton Corporation does not necessarily

know what equipment this engine will power, it is important that you read and understand

these instructions and the instructions for the equipment. Save these original instructions

for future reference.

NOTE: The figures and illustrations in this manual are provided for reference only and may

differ from your specific model. Contact your dealer if you have questions.

For replacement parts or technical assistance, record below the engine model, type, and

code numbers along with the date of purchase. These numbers are located on your engine

(see the

Features and Controls

section).

Date of Purchase

Engine Model - Type - Trim

Engine Serial Number

Look for the 2D barcode located on some

engines. When viewed with a 2D-capable

device, the code will bring up our website

where you can access support information

for this product. Data rates apply. Some

countries may not have online support

information available.

Recycling Information

All packaging, used oil, and batteries should be recycled

according to applicable government regulations.

Operator Safety

Safety Alert Symbol and Signal Words

The safety alert symbol is used to identify safety information about hazards that can

result in personal injury. A signal word (DANGER, WARNING, or CAUTION) is used with

the alert symbol to indicate the likelihood and the potential severity of injury. In addition, a

hazard symbol may be used to represent the type of hazard.

DANGER indicates a hazard which, if not avoided, will result in death or serious

injury.

WARNING indicates a hazard which, if not avoided, could result in death or serious

injury.

CAUTION indicates a hazard which, if not avoided, could result in minor or

moderate injury.

NOTICE

indicates an situation that could result in damage to the product.

Hazard Symbols and Meanings

MeaningSymbolMeaningSymbol

Read and understand the

Operator's Manual before

operating or servicing the unit.

Safety information about

hazards that can result in

personal injury.

Explosion hazardFire hazard

MeaningSymbolMeaningSymbol

Toxic fume hazardShock hazard

Noise hazard - Ear protection

recommended for extended

use.

Hot surface hazard

Explosion hazardThrown object hazard -

Wear eye protection.

Kickback hazardFrostbite hazard

Chemical HazardAmputation hazard - moving

parts

CorrosiveThermal heat hazard

Safety Messages

WARNING

Certain components in this product and its related accessories contain chemicals

known to the State of California to cause cancer, birth defects, or other reproductive

harm. Wash hands after handling.

WARNING

The engine exhaust from this product contains chemicals known to the State of

California to cause cancer, birth defects, or other reproductive harm.

WARNING

Briggs & Stratton Engines are not designed for and are not to be used to power:

fun-karts; go-karts; children's, recreational, or sport all-terrain vehicles (ATVs);

motorbikes; hovercraft; aircraft products; or vehicles used in competitive events not

sanctioned by Briggs & Stratton. For information about competitive racing products,

see www.briggsracing.com. For use with utility and side-by-side ATVs, please contact

Briggs & Stratton Engine Application Center, 1-866-927-3349. Improper engine

application may result in serious injury or death.

NOTICE

This engine was shipped from Briggs & Stratton without oil. Before you start the engine,

make sure you add oil according to the instructions in this manual. If you start the

engine without oil, it will be damaged beyond repair and will not be covered under

warranty.

WARNING

Gaseous vapors are extremely flammable and explosive.

Fire or explosion can cause severe burns or death.

When Adding Fuel

• Fill fuel tank outdoors or in well-ventilated area.

• Check fuel lines, tank, cap, and fittings frequently for cracks or leaks. Replace if

necessary.

When Starting Engine

4 BRIGGSandSTRATTON.com

Not for

Reproduction

• Ensure that spark plug, muffler, fuel cap and air cleaner (if equipped) are in place

and secured.

• Do not crank engine with spark plug removed.

When Operating Equipment

• Never start or run the engine with the air cleaner assembly (if equipped) or the air

filter (if equipped) removed.

When Transporting Equipment

• On Natural / Liquid Petroleum (LP) Gas engines, transport with fuel cylinder empty

or valve closed, or fuel tank disconnected.

When Storing Fuel Or Equipment With Fuel In Tank

• Store away from furnaces, stoves, water heaters or other appliances that have pilot

lights or other ignition sources because they can ignite fuel vapors.

WARNING

Starting engine creates sparking.

Sparking can ignite nearby flammable gases.

Explosion and fire could result.

• If there is natural or LP gas leakage in area, do not start engine.

• Do not use pressurized starting fluids because vapors are flammable.

WARNING

POISONOUS GAS HAZARD. Engine exhaust contains carbon monoxide, a

poisonous gas that could kill you in minutes. You CANNOT see it, smell it, or

taste it. Even if you do not smell exhaust fumes, you could still be exposed to

carbon monoxide gas. If you start to feel sick, dizzy, or weak while using this

product, get to fresh air RIGHT AWAY. See a doctor. You may have carbon

monoxide poisoning.

• Operate this product ONLY outside far away from windows, doors and vents to

reduce the risk of carbon monoxide gas from accumulating and potentially being

drawn towards occupied spaces.

•Install battery-operated carbon monoxide alarms or plug-in carbon monoxide alarms

with battery back-up according to the manufacturer's instructions. Smoke alarms

cannot detect carbon monoxide gas.

• DO NOT run this product inside homes, garages, basements, crawlspaces, sheds,

or other partially-enclosed spaces even if using fans or opening doors and windows

for ventilation. Carbon monoxide can quickly build up in these spaces and can linger

for hours, even after this product has shut off.

• ALWAYS place this product downwind and point the engine exhaust away from

occupied spaces.

WARNING

Rapid retraction of starter cord (kickback) will pull hand and arm toward engine

faster than you can let go.

Broken bones, fractures, bruises or sprains could result.

• When starting engine, pull the starter cord slowly until resistance is felt and then

pull rapidly to avoid kickback.

• Remove all external equipment / engine loads before starting engine.

•Direct-coupled equipment components such as, but not limited to, blades, impellers,

pulleys, sprockets, etc., must be securely attached.

WARNING

Rotating parts can contact or entangle hands, feet, hair, clothing, or accessories.

Traumatic amputation or severe laceration can result.

• Operate equipment with guards in place.

• Keep hands and feet away from rotating parts.

• Tie up long hair and remove jewelry.

• Do not wear loose-fitting clothing, dangling drawstrings or items that could become

caught.

WARNING

Running engines produce heat. Engine parts, especially muffler, become

extremely hot.

Severe thermal burns can occur on contact.

Combustible debris, such as leaves, grass, brush, etc. can catch fire.

• Allow muffler, engine cylinder and fins to cool before touching.

• Remove accumulated debris from muffler area and cylinder area.

• It is a violation of California Public Resource Code, Section 4442, to use or operate

the engine on any forest-covered, brush-covered, or grass-covered land unless the

exhaust system is equipped with a spark arrester, as defined in Section 4442,

maintained in effective working order. Other states or federal jurisdictions may have

similar laws. Contact the original equipment manufacturer, retailer, or dealer to

obtain a spark arrester designed for the exhaust system installed on this engine.

WARNING

Unintentional sparking can result in fire or electric shock.

Unintentional start-up can result in entanglement, traumatic amputation, or

laceration.

Fire hazard

Before performing adjustments or repairs:

• Disconnect the spark plug wire and keep it away from the spark plug.

• Disconnect battery at negative terminal (only engines with electric start.)

• Use only correct tools.

• Do not tamper with governor spring, links or other parts to increase engine speed.

• Replacement parts must be of the same design and installed in the same position

as the original parts. Other parts may not perform as well, may damage the unit,

and may result in injury.

• Do not strike the flywheel with a hammer or hard object because the flywheel may

later shatter during operation.

When testing for spark:

• Use approved spark plug tester.

• Do not check for spark with spark plug removed.

WARNING

Gaseous fuels are extremely flammable and readily form explosive air-vapor

mixtures at ambient temperatures.

If you smell gas:

•Do not start the engine.

•Do not actuate any electrical switches.

•Do not use a phone in the vicinity.

• Evacuate the area.

• Contact the gas supplier or fire department.

WARNING

Wear eye protection when doing repair work.

Frostbite can result from skin / eye contact with leaking LP liquid.

• Installation, adjustment and repair work should be done by a qualified technician.

• Regularly check flexible supply line. Make sure they are in good condition. Replace

damaged or leaking components.

WARNING

Missing or inoperative "fuel lock-off" valve can cause a fire or explosion.

Not for

Reproduction

•Do not operate the equipment if the "fuel lock-off" valve is missing or inoperative.

Features and Controls

Engine Controls

Compare the illustration (Figure: 1, 2, 3) with your engine to familiarize yourself with the

location of various features and controls.

A. Engine Identification Numbers Model - Type - Code

B. Spark Plug

C. Air Cleaner

D. Dipstick

E. Oil Drain Plug

F. Muffler, Muffler Guard (if equipped), Spark Arrester (if equipped)

G. Air Intake Grille

H. Oil Filter (if equipped)

I. Electric Starter

J. LPG/NG Mixer

K. Quick Oil Drain (if equipped)

Control Symbols and Meanings

MeaningSymbolMeaningSymbol

Engine speed - SlowEngine speed - Fast

On - OffEngine speed - Stop

Operation

Oil Recommendations

Oil Capacity: See the

Specifications

section.

We recommend the use of Briggs & Stratton Warranty Certified oils for best performance.

Other high-quality detergent oils are acceptable if classified for service SF, SG, SH, SJ or

higher. Do not use special additives.

Outdoor temperatures determine the proper oil viscosity for the engine. Use the chart to

select the best viscosity for the outdoor temperature range expected.

SAE 30 - Below 40 °F (4 °C) the use of SAE 30 will result in hard starting.A

10W-30 - Above 80 °F (27 °C) the use of 10W-30 may cause increased oil

consumption. Check oil level more frequently.

Synthetic 5W-30C

5W-30D

Check Oil Level

See Figure: 4

Before adding or checking the oil

• Make sure the engine is level.

• Clean the oil fill area of any debris.

1. Remove the dipstick (A, Figure 4) and wipe with a clean cloth.

2. Install and tighten the dipstick (A, Figure 4).

3. Remove the dipstick and check the oil level. Correct oil level is at the top of the full

indicator (B, Figure 4) on the dipstick.

4. If oil level is low, slowly add oil into the engine oil fill (C, Figure 4). Do not overfill.

After adding oil, wait one minute and then recheck the oil level.

NOTE: Do not add oil at the quick oil drain , if equipped. For location, see Features and

Controls.

5. Reinstall and tighten the dipstick (A, Figure 4).

Low Oil Protection System (if equipped)

Some engines are equipped with a low oil sensor. If the oil is low, the sensor will either

activate a warning light or stop the engine. Stop the engine and follow these steps before

restarting the engine.

• Make sure the engine is level.

• Check the oil level. See the

Check Oil Level

section.

• If the oil level is low, add the proper amount of oil. Start the engine and make sure

the warning light (if equipped) is not activated.

• If the oil level is not low, do not start the engine. Contact a Briggs & Stratton

Authorized Service Dealer to have the oil problem corrected.

Fuel Recommendations

WARNING

Missing or inoperative "fuel lock-off" valve can cause a fire or explosion.

• Do not operate the equipment if the "fuel lock-off" valve is missing or inoperative.

Fuel must meet these requirements

• Use clean, dry fuel, free of moisture or any particulate material. Using fuels outside

the following recommended values may cause performance problems.

• In engines set up to run on LPG, commercial grade HD5 LPG is recommended.

Recommended fuel composition is fuel with a minimum fuel energy of 2500 BTU's/ft³

with maximum propylene content of 5% and butane and heavier gas content of 2.5%

and minimum propane content of 90%.

NG or LPG engines are certified to operate on natural or liquid propane gas. The emissions

control system for this engine is EM (Engine Modifications).

WARNING

The equipment on which this engine is mounted is equipped with an automatic safety

gas "fuel lock-off" valve. Do not operate the equipment if the "fuel lock-off" valve is

missing or inoperative

Add Fuel

WARNING

Gaseous vapors are extremely flammable and explosive.

Fire or explosion can cause severe burns or death.

When Adding Fuel

• Fill fuel tank outdoors or in well-ventilated area.

6 BRIGGSandSTRATTON.com

Not for

Reproduction

• Check fuel lines, tank, cap, and fittings frequently for cracks or leaks. Replace is

necessary.

For information on refueling natural or LP gas engines, read the operating instructions

supplied by the equipment manufacturer.

Start and Stop Engine

See Figure: 5

Start Engine

WARNING

Gaseous vapors are extremely flammable and explosive.

Fire or explosion can cause severe burns or death.

When Starting Engine

•Ensure that spark plug, muffler, and air cleaner (if equipped) are in place and secured.

• Do not crank engine with spark plug removed.

WARNING

POISONOUS GAS HAZARD. Engine exhaust contains carbon monoxide, a

poisonous gas that could kill you in minutes. You CANNOT see it, smell it, or taste

it. Even if you do not smell exhaust fumes, you could still be exposed to carbon

monoxide gas. If you start to feel sick, dizzy, or weak while using this product,

shut it off and get to fresh air RIGHT AWAY. See a doctor. You may have carbon

monoxide poisoning.

•Operate this product ONLY outside far away from windows, doors and vents to reduce

the risk of carbon monoxide gas from accumulating and potentially being drawn

towards occupied spaces.

• Install battery-operated carbon monoxide alarms or plug-in carbon monoxide alarms

with battery back-up according to the manufacturer's instructions. Smoke alarms

cannot detect carbon monoxide gas.

• DO NOT run this product inside homes, garages, basements, crawlspaces, sheds,

or other partially-enclosed spaces even if using fans or opening doors and windows

for ventilation. Carbon monoxide can quickly build up in these spaces and can linger

for hours, even after this product has shut off.

• ALWAYS place this product downwind and point the engine exhaust away from

occupied spaces.

NOTICE

This engine was shipped from Briggs & Stratton without oil. Before you start

the engine, make sure you add oil according to the instructions in this manual. If you

start the engine without oil, it will be damaged beyond repair and will not be covered

under warranty.

NOTE: Equipment may have remote controls. See the equipment manual for location and

operation of remote controls.

1. Check the engine oil. See the

Check Oil Level

section.

2. Make sure equipment drive controls, if equipped, are disengaged.

3. Move the fuel shut-off (B, Figure 5), if equipped, to the OPEN position.

4. Turn the electric start switch (A, Figure 5) to the ON or START position.

NOTICE

To extend the life of the starter, use short starting cycles (five seconds

maximum). Wait one minute between starting cycles.

NOTE: If the engine does not start after repeated attempts, contact you local dealer or go

to BRIGGSandSTRATTON.com or call 1-800-233-3723 (in USA).

Stop Engine

1. Turn the key switch (A, Figure 5) to the OFF position. Remove the key and keep in

a safe place out of the reach of children.

2. After the engine stops, move the fuel shut-off (B, Figure 5), if equipped, to the

CLOSED position.

Maintenance

NOTICE

If the engine is tipped during maintenance, the fuel tank, if mounted on

engine, must be empty and the spark plug side must be up. If the fuel tank is not empty

and if the engine is tipped in any other direction, it may be difficult to start due to oil or

gasoline contaminating the air filter and/or the spark plug.

WARNING

When performing maintenance that requires the unit to be tipped, the fuel tank, if mounted

on the engine, must be empty or fuel can leak out and result in a fire or explosion.

We recommend that you see any Briggs & Stratton Authorized Service Dealer for all

maintenance and service of the engine and engine parts.

NOTICE

All the components used to build this engine must remain in place for proper

operation.

WARNING

Unintentional sparking can result in fire or electric shock.

Unintentional start-up can result in entanglement, traumatic amputation, or

laceration.

Fire hazard

Before performing adjustments or repairs:

• Disconnect the spark plug wire and keep it away from the spark plug.

• Disconnect battery at negative terminal (only engines with electric start.)

• Use only correct tools.

• Do not tamper with governor spring, links or other parts to increase engine speed.

• Replacement parts must be of the same design and installed in the same position

as the original parts. Other parts may not perform as well, may damage the unit, and

may result in injury.

• Do not strike the flywheel with a hammer or hard object because the flywheel may

later shatter during operation.

When testing for spark:

• Use approved spark plug tester.

• Do not check for spark with spark plug removed.

Emissions Control Service

Maintenance, replacement, or repair of the emissions control devices and systems

may be performed by any off-road engine repair establishment or individual. However,

to obtain "no charge" emissions control service, the work must be performed by a factory

authorized dealer. See the Emissions Control Statements.

Maintenance Schedule

First 5 Hours

•Change oil 2

Every 8 Hours or Daily

• Check engine oil level

Every 50 Hours or Annually

•Clean air filter 1

•Clean pre-cleaner (if equipped) 1

•Change engine oil 3

•Replace oil filter (if equipped) 3

• Service exhaust system (if equipped)

Every 100 Hours or Annually

• Replace air filter

• Replace spark plugs

•Change engine oil 4

•Replace oil filter (if equipped) 4

•Service cooling system 1

•Check valve clearance 5

Annually

Not for

Reproduction

• Replace air filter

• Replace spark plugs

•Service cooling system 1

1In dusty conditions or when airborne debris is present, clean more often.

2Only engines without oil filter.

3Engines without oil filter or with standard black oil filter (see

Specifications

page

for part number).

4Engines with high-efficiency yellow or orange oil filter (see

Specifications

page

for part number).

5Not required unless engine performance problems are noted.

Service Spark Plug

See Figure: 6

Check the gap (A, Figure 6) with a wire gauge (B). If necessary, reset the gap. Install and

tighten the spark plug to the recommended torque. For gap setting or torque, see the

Specifications

section.

NOTE: In some areas, local law requires using a resistor spark plug to suppress ignition

signals. If this engine was originally equipped with a resistor spark plug, use the same type

for replacement.

Service Exhaust System

WARNING

Running engines produce heat. Engine parts, especially muffler, become extremely

hot.

Severe thermal burns can occur on contact.

Combustible debris, such as leaves, grass, brush, etc. can catch fire.

• Allow muffler, engine cylinder and fins to cool before touching.

• Remove accumulated debris from muffler area and cylinder area.

• It is a violation of California Public Resource Code, Section 4442, to use or operate

the engine on any forest-covered, brush-covered, or grass-covered land unless the

exhaust system is equipped with a spark arrester, as defined in Section 4442,

maintained in effective working order. Other states or federal jurisdictions may have

similar laws. Contact the original equipment manufacturer, retailer, or dealer to obtain

a spark arrester designed for the exhaust system installed on this engine.

Remove accumulated debris from muffler and cylinder area. Inspect the muffler for cracks,

corrosion, or other damage. Remove the deflector or the spark arrester, if equipped, and

inspect for damage or carbon blockage. If damage is found, install replacement parts before

operating.

WARNING

Replacement parts must be of the same design and installed in the same position as

the original parts. Other parts may not perform as well, may damage the unit, and may

result in injury.

Change Engine Oil

See Figure: 7, 8, 9, 10

Used oil is a hazardous waste product and must be disposed of properly. Do not discard

with household waste. Check with your local authorities, service center, or dealer for safe

disposal/recycling facilities.

Remove Oil

1. With engine off but still warm, disconnect the spark plug wire (D, Figure 7) and keep

it away from the spark plug (E).

2. Remove the dipstick (A, Figure 8).

Oil Drain Plug, if equipped

1. Remove the oil drain plug (F, Figure 9). Drain the oil into an approved container.

NOTE: Any of the oil drain plugs (G, Figure 9) may be installed in the engine.

2. After the oil has drained, install and tighten the oil drain plug (F, Figure 9).

Quick Oil Drain, if equipped

1. Disconnect the quick oil drain hose (H, Figure 10) from the side of the engine.

2. Turn and remove the oil drain cap (I, Figure 10). Carefully lower the quick oil drain

(H) into an approved container (J).

3. After the oil has drained, install the quick oil drain cap (I, Figure 10). Attach the quick

oil drain hose (H) to the side of the engine.

Change Oil Filter, if equipped

Some models are equipped with an oil filter. For replacement intervals, see the

Maintenance Schedule.

1. Drain the oil from the engine. See

Remove Oil

section.

2. Remove the oil filter (K, Figure 8) and dispose of properly.

3. Before you install the new oil filter, lightly lubricate the oil filter gasket with fresh,

clean oil.

4. Install the oil filter by hand until the gasket contacts the oil filter adapter, then tighten

the oil filter 1/2 to 3/4 turns.

5. Add oil. See

Add Oil

section.

6. Start and run the engine. As the engine warms up, check for oil leaks.

7. Stop the engine and check the oil level. Correct oil level is at the top of the full indicator

(B, Figure 8) on the dipstick.

Add Oil

• Make sure the engine is level.

• Clean the oil fill area of any debris.

• See the

Specifications

section for oil capacity.

1. Remove the dipstick (A, Figure 8) and wipe with a clean cloth.

2. Slowly pour oil into the engine oil fill (C, Figure 8). Do not overfill. After adding oil,

wait one minute and then check the oil level.

NOTE: Do not add oil at the quick oil drain (H, Figure 10), if equipped.

3. Install and tighten the dipstick (A, Figure 8).

4. Remove the dipstick and check the oil level. Correct oil level is at the top of the full

indicator (B, Figure 8) on the dipstick.

5. Reinstall and tighten the dipstick (A, Figure 8).

6. Connect the spark plug wire (D, Figure 7) to the spark plug (E).

Service Air Filter

See Figure: 11, 12

WARNING

Gaseous vapors are extremely flammable and explosive.

Fire or explosion can cause severe burns or death.

• Never start and run the engine with the air cleaner assembly (if equipped) or the air

filter (if equipped) removed.

NOTICE

Do not use pressurized air or solvents to clean the filter. Pressurized air can

damage the filter and solvents will dissolve the filter.

See the

Maintenance Schedule

for service requirements.

Various models use either a foam or a paper filter. Some models may also have an optional

pre-cleaner that can be washed and reused. Compare the illustrations in this manual with

the type installed on your engine and service as follows.

Paper Air Filter

1. Pull up on the cover handle (A, Figure 11). Rotate the cover handle toward the engine

and then remove the cover (B).

2. Remove the pre-cleaner (C, Figure 11), if equipped, and the filter (D).

3. To loosen debris, gently tap the filter (D, Figure 11) on a hard surface. If the filter is

excessively dirty, replace with a new filter.

4. Wash the pre-cleaner (C, Figure 11) in liquid detergent and water. Allow the

pre-cleaner (C) to thoroughly air dry. Do not oil the pre-cleaner.

8 BRIGGSandSTRATTON.com

Not for

Reproduction

5. Assemble the dry pre-cleaner (C, Figure 11) and the filter (D) to the engine base (E).

6. Align the tabs (F, Figure 11) on the cover (B) with the slots (G) in the blower housing.

7. Rotate the cover handle (A, Figure 11) back and push down to lock in place.

Paper Air Filter

1. Loosen the fastener(s) (A, Figure 12).

2. Remove the cover (B, Figure 12).

3. To remove the filter (C, Figure 12), lift the end of the filter and then pull the filter off

the intake (D).

4. To loosen debris, gently tap the filter (C, Figure 12) on a hard surface. If the filter is

excessively dirty, replace with a new filter.

5. Remove the pre-cleaner (E, Figure 12), if equipped, from the filter (C).

6. Wash the pre-cleaner (E, Figure 12), if equipped, in liquid detergent and water. Allow

the pre-cleaner to thoroughly air dry. Do not oil the pre-cleaner.

7. Assemble the dry pre-cleaner (E, Figure 12), if equipped, to the filter (C).

8. Install the filter (C, Figure 12) on the intake (D). Push the end of the filter down into

the engine base. Make sure filter fits securely in the engine base.

9. Install the air filter cover (B, Figure 12) and secure with fastener(s) (A).

Service Cooling System

WARNING

Running engines produce heat. Engine parts, especially muffler, become extremely

hot.

Severe thermal burns can occur on contact.

Combustible debris, such as leaves, grass, brush, etc., can catch fire.

• Allow muffler, engine cylinder and fins to cool before touching.

• Remove accumulated debris from muffler area and cylinder area.

NOTICE

Do not use water to clean the engine. Water could contaminate the fuel

system. Use a brush or dry cloth to clean the engine.

This is an air cooled engine. Dirt or debris can restrict air flow and cause the engine to

overheat, resulting in poor performance and reduced engine life.

1. Use a brush or dry cloth to remove debris from the air intake grille.

2. Keep linkage, springs and controls clean.

3. Keep the area around and behind the muffler, if equipped, free of any combustible

debris.

4. Make sure the oil cooler fins, if equipped, are free of dirt and debris.

After a period of time, debris can accumulate in the cylinder cooling fins and cause the

engine to overheat. This debris cannot be removed without partial disassembly of the

engine. Have a Briggs & Stratton Authorized Service Dealer inspect and clean the air

cooling system as recommended in the

Maintenance Schedule.

Storage

WARNING

Gaseous vapors are extremely flammable and explosive.

Fire or explosion can cause severe burns or death.

When Storing Fuel Or Equipment With Fuel In Tank

• Store away from furnaces, stoves, water heaters or other appliances that have pilot

lights or other ignition sources because they can ignite fuel vapors.

Engine Oil

While the engine is still warm, change the engine oil. See the

Change Engine Oil

section.

NOTICE

Store the engine level (normal operating position). If the engine is tipped in

any other direction, it may be difficult to start due to oil contaminating the air filter and/or

the spark plug.

Troubleshooting

For assistance, contact your local dealer or go to BRIGGSandSTRATTON.com or call

1-800-233-3723 (in USA).

Specifications

Model: 310000

30.52 ci (500 cc)Displacement

3.563 in (90,49 mm)Bore

3.062 in (77,77 mm)Stroke

46 - 48 oz (1,36 - 1,40 L)Oil Capacity

.030 in (,76 mm)Spark Plug Gap

180 lb-in (20 Nm)Spark Plug Torque

.010 - .014 in (,25 - ,36 mm)Armature Air Gap

.003 - .005 in (,08 - ,13 mm)Intake Valve Clearance

.005 - .007 in (,13 - ,18 mm)Exhaust Valve Clearance

Engine power will decrease 3.5% for each 1,000 feet (300 meters) above sea level and

1% for each 10° F (5.6° C) above 77° F (25° C). The engine will operate satisfactorily at

an angle up to 15°. Refer to the equipment operator's manual for safe allowable operating

limits on slopes.

Service Parts - Model: 310000

Part NumberService Part

790263Paper Air Filter (Figure 11)

697015Air Filter Pre-cleaner (Figure 11)

797427Paper Air Filter (Figure 12)

797704Air Filter Pre-cleaner (Figure 12)

100005Oil - SAE 30 (20 oz, 0,6 L)

100028Oil - SAE 30 (48 oz, 1,4 L)

492932, 5049Oil Filter, Standard - Black

795890Oil Filter, High Efficiency - Yellow

798576Oil Filter, High Efficiency - Orange

491055Resistor Spark Plug

5066Long Life Platinum Spark Plug

89838, 5023Spark Plug Wrench

19368Spark Tester

We recommend that you see any Briggs & Stratton Authorized Dealer for all maintenance

and service of the engine and engine parts.

Warranty

Briggs & Stratton Engine Warranty

Effective January 2016

Limited Warranty

Briggs & Stratton warrants that, during the warranty period specified below, it will repair or

replace, free of charge, any part that is defective in material or workmanship or both.

Transportation charges on product submitted for repair or replacement under this warranty

must be borne by purchaser. This warranty is effective for and is subject to the time periods

and conditions stated below. For warranty service, find the nearest Authorized Service

Dealer in our dealer locator map at BRIGGSandSTRATTON.COM. The purchaser must

contact the Authorized Service Dealer, and then make the product available to the

Authorized Service Dealer for inspection and testing.

There is no other express warranty. Implied warranties, including those of

merchantability and fitness for a particular purpose, are limited to the warranty

period listed below, or to the extent permitted by law. Liability for incidental or

consequential damages are excluded to the extent exclusion is permitted by law. Some

states or countries do not allow limitations on how long an implied warranty lasts, and

some states or countries do not allow the exclusion or limitation of incidental or

consequential damages, so the above limitation and exclusion may not apply to you. This

Not for

Reproduction

warranty gives you specific legal rights and you may also have other rights which vary

from state to state and country to country 4.

Standard Warranty Terms 1, 2

Commercial

Use

Consumer

Use

Brand / Product Name

36 months36 months

Vanguard™ 3

24 months24 monthsCommercial Turf Series™ ; Commercial Series

12 months24 monthsEngines Featuring Dura-Bore™ Cast Iron Sleeve

3 months24 monthsAll Other Briggs & Stratton Engines

1These are our standard warranty terms, but occasionally there may be additional

warranty coverage that was not determined at time of publication. For a listing of

current warranty terms for your engine, go to BRIGGSandSTRATTON.com or contact

your Briggs & Stratton Authorized Service Dealer.

2There is no warranty for engines on equipment used for prime power in place of

a utility or for standby generators used for commercial purposes. Engines used in

competitive racing or on commercial or rental tracks are not warrantied.

3Vanguard installed on standby generators: 24 months consumer use, no warranty

commercial use. Vanguard installed on utility vehicles: 24 months consumer use, 24

months commercial use. Vanguard 3-cylinder liquid cooled: see Briggs & Stratton

3/LC Engine Warranty Policy.

4In Australia - Our goods come with guarantees that cannot be excluded under the

Australian Consumer Law. You are entitled to a replacement or refund for a major

failure and for compensation for any other reasonably foreseeable loss or damage.

You are also entitled to have the goods repaired or replaced if the goods fail to be

of acceptable quality and the failure does not amount to a major failure. For warranty

service, find the nearest Authorized Service Dealer in our dealer locator map at

BRIGGSandSTRATTON.COM, or by calling 1300 274 447, or by emailing or writing

to [email protected], Briggs & Stratton Australia Pty Ltd, 1

Moorebank Avenue, Moorebank, NSW , Australia, 2170.

The warranty period begins on the original date of purchase by the first retail or commercial

consumer. "Consumer use" means personal residential household use by a retail consumer.

"Commercial use" means all other uses, including use for commercial, income producing

or rental purposes. Once an engine has experienced commercial use, it shall thereafter

be considered as a commercial use engine for purposes of this warranty.

Save your proof of purchase receipt. If you do not provide proof of the initial purchase

date at the time warranty service is requested, the manufacturing date of the product

will be used to determine the warranty period. Product registration is not required

to obtain warranty service on Briggs & Stratton products.

About Your Warranty

This limited warranty covers engine-related material and/or workmanship issues only, and

not replacement or refund of the equipment to which the engine may be mounted. Routine

maintenance, tune-ups, adjustments, or normal wear and tear are not covered under this

warranty. Similarly, warranty is not applicable if the engine has been altered or modified

or if the engine serial number has been defaced or removed. This warranty does not cover

engine damage or performance problems caused by:

1. The use of parts that are not original Briggs & Stratton parts;

2. Operating the engine with insufficient, contaminated, or an incorrect grade of

lubricating oil;

3. The use of contaminated or stale fuel, gasoline formulated with ethanol greater than

10%, or the use of alternative fuels such as liquefied petroleum or natural gas on

engines not originally designed/manufactured by Briggs & Stratton to operate on

such fuels;

4. Dirt which entered the engine because of improper air cleaner maintenance or

re-assembly;

5. Striking an object with the cutter blade of a rotary lawn mower, loose or improperly

installed blade adapters, impellers, or other crankshaft coupled devices, or excessive

v-belt tightness;

6. Associated parts or assemblies such as clutches, transmissions, equipment controls,

etc., which are not supplied by Briggs & Stratton;

7. Overheating due to grass clippings, dirt and debris, or rodent nests which plug or

clog the cooling fins or flywheel area, or by operating the engine without sufficient

ventilation;

8. Excessive vibration due to over-speeding, loose engine mounting, loose or unbalanced

cutter blades or impellers, or improper coupling of equipment components to the

crankshaft;

9. Misuse, lack of routine maintenance, shipping, handling, or warehousing of equipment,

or improper engine installation.

Warranty service is available only through Briggs & Stratton Authorized Service

Dealers. Locate your nearest Authorized Service Dealer in our dealer locator map

at BRIGGSandSTRATTON.COM or by calling 1-800-233-3723 (in USA).

80004537 (Rev.B)

Briggs & Stratton Emissions Warranty

California, U.S. EPA, and Briggs & Stratton Corporation Emissions

Control Warranty Statement for Emergency Standby Engines -

Your Warranty Rights and Obligations

General Information

The U.S. EPA, and Briggs & Stratton (B&S) are pleased to explain the emissions control

system warranty on your Model Year 2015 - 2017 and later engine / equipment. In the

U.S., new Emergency Standby Engines must be designed, built, and equipped to meet

stringent emission standards. Engines less than 25 Hp must meet requirements of 40 CFR

Part 1054. Engines greater than 25 Hp and less than 130 Hp must meet requirements of

40 CFR Part 1048. B&S must warrant the emissions control system on your engine /

equipment.

See Definition of appropriate use of Emergency Standby below.

The emission-related warranty covers all components whose failure would increase an

engine's non-evaporative emissions of any regulated pollutant referenced below.

Manufacturer's Warranty Coverage:

Briggs & Stratton warrants that the engine is free from defects in material and workmanship,

and is also designed, built, and equipped to conform to applicable regulations under Section

213 of the Clean Air Act, from the time the engine is sold, until the expiration of its warranty

period.

This warranty applies to all emission related engine components whose failure would cause

engine exhaust emissions to be out of EPA compliance. Further, this warranty also applies

to other engine components damaged due to the failure of any of these emissions related

components.

If a warrantable emissions related component on your engine is defective, the part will be

repaired or replaced by B&S at no cost to you including diagnosis, parts, and labor.

Warranty coverage period is four years from date of original purchase, and is offered to

the original purchaser and each subsequent purchaser so long as Owner's Warranty

Responsibilities are adhered to.

Owner's Warranty Responsibilities:

• Warranty claims shall be filed according to the provisions of the Briggs & Stratton

Warranty Policy.

• An engine may not be warrantable if subjected to abuse, misuse, neglect, improper

maintenance, unapproved modifications, accidents not caused by Briggs & Stratton

engines or equipment, or by acts of God.

• Only those engines used as an Emergency Stationary Engine, as defined below, are

warrantable.

• You are responsible for presenting your engine / equipment to a B&S distribution

center, servicing dealer, or other equivalent entity, as applicable, as soon as a problem

exists. The warranty repairs should be completed in a reasonable amount of time,

not to exceed 30 days. If you have any questions regarding your warranty rights and

responsibilities, you should contact B&S at 1-800-444-7774 (in USA) or

BRIGGSandSTRATTON.COM.

• If any components not scheduled for maintenance is repaired or replaced under this

warranty, the new part will be warranted only for the remaining warranty period.

•If a warrantable component scheduled for maintenance fails prior to its first scheduled

replacement, the part will be repaired or replaced by B&S at no charge to the owner.

Any such component is only warrantable until the originally scheduled maintenance

period has expired.

• Add on or modified parts that are not exempted by the EPA may not be used. The

use of any non-exempted add on or modified parts by the owner will be grounds for

disallowing a warranty claim. The manufacturer will not be liable to warrant failures

or warranted parts caused by the use of a non-exempted add on or modified part.

Emergency Stationary Engine Definition

An Emergency Stationary Engine is defined as any stationary internal combustion engine

whose operation is limited to emergency situations and required testing and maintenance.

Examples include stationary engines used to produce power for critical networks or

equipment (including power supplied to portions of a facility) when electric power from the

local utility (or the normal power source, if the facility runs on its own power production) is

interrupted, or stationary engines used to pump water in the case of fire or flood, etc.

Stationary engines used for peak shaving are not considered emergency stationary engines.

Stationary engines used to supply power to an electric grid or that supply power as part

of a financial arrangement with another entity are not considered to be emergency engines.

Emergency stationary ICE may be operated for the purpose of maintenance checks and

readiness testing, provided that the tests are recommended by Federal, State or local

government, the manufacturer, the vendor, or the insurance company associated with the

engine. Maintenance checks and readiness testing of such units is limited to 100 hours

per year. There is no time limit on the use of emergency stationary engines in emergency

situations. The owner or operator may petition the Administrator for approval of additional

hours to be used for maintenance checks and readiness testing, but a petition is not required

10 BRIGGSandSTRATTON.com

Not for

Reproduction

if the owner or operator maintains records indicating that Federal, State, or local standards

require maintenance and testing of emergency ICE beyond 100 hours per year. Emergency

stationary ICE may operate up to 50 hours per year in non-emergency situations, but those

50 hours are counted towards the 100 hours per year provided for maintenance and testing.

The 50 hours per year for non-emergency situations cannot be used for peak shaving or

to generate income for a facility to supply power to an electric grid or otherwise supply

power as part of a financial arrangement with another entity. For owners and operators of

emergency engines, any operation other than emergency operation, maintenance and

testing, and operation in non-emergency situations for 50 hours per year, as permitted

above is prohibited.

80015464 (Rev.A)

Not for

Reproduction

reservados.

Este manual contiene información de seguridad para advertirle sobre los peligros y riesgos

asociados con motores y cómo evitarlos. También contiene instrucciones para uso y

cuidado correctos del motor. Debido a que Briggs & Stratton Corporation no necesariamente

sabe para qué equipo se utilizará este motor, es importante que usted lea y comprenda

estas instrucciones y las instrucciones de su equipo. Conserve estas instrucciones

originales para consulta futura.

NOTA: Las figuras e ilustraciones en este manual son provistas solo para consulta y

pueden no ser iguales a su modelo específico. Si tiene preguntas, comuníquese con su

distribuidor.

Para piezas de repuesto o asistencia técnica, anote a continuación el modelo, tipo y

números de código del motor, junto con la fecha de compra. Estos números están ubicados

en su motor (vea la sección de

Características y Controles

Fecha de compra

Modelo del motor - Tipo - Reglaje

Número de Serie del motor

Busque el código de barras 2D que se

encuentra en algunos motores. Cuando se

ve con un dispositivo con capacidad 2D, el

código hará surgir nuestro sitio web donde

puede acceder a información de soporte para

este producto. Corresponden tarifas de datos.

Algunos países pueden no tener información

de soporte en línea disponible.

Información sobre reciclaje

El embalaje, el aceite usado y las baterías, en su totalidad,

deben reciclarse de acuerdo con las regulaciones

gubernamentales aplicables.

Seguridad del operador

Símbolo de alerta de seguridad y palabras

de señalización

El símbolo de alerta de seguridad se usa para identificar información de seguridad

sobre riesgos que pueden provocar lesiones personales. Se usa una palabra de

señalización (PELIGRO, ADVERTENCIA o ATENCIÓN) junto con el símbolo de alerta

para indicar la probabilidad y la gravedad potencial de las lesiones. Además, se puede

usar un símbolo de riesgo para representar el tipo de riesgo.

PELIGRO indica un riesgo que, si no se evita, ocasionará la muerte o lesiones

graves.

ADVERTENCIA indica un riesgo que, si no se evita, podría ocasionar la muerte

o lesiones graves.

ATENCIÓN indica un riesgo que, si no se evita, podría ocasionar lesiones menores

o moderadas.

AVISO

indica una situación que podría provocar daños al producto.

Símbolos de peligro y sus significados

SignificadoSímboloSignificadoSímbolo

Lea y entienda el Manual del

Operador antes de operar o

reparar la unidad.

Información de seguridad

sobre los riesgos que

pueden provocar lesiones

físicas.

SignificadoSímboloSignificadoSímbolo

Peligro de explosiónPeligro de incendio

Peligro de emisión de vapores

tóxicos

Peligro de descarga

Peligro de ruido: se recomienda

el uso prolongado de protección

para los oídos.

Peligro de superficie

caliente

Peligro de explosiónPeligro de caída de objetos:

utilice protección para los

ojos.

Peligro de retroceso violentoPeligro de congelación

Peligro químicoPeligro de amputación:

piezas móviles

CorrosivoPeligro de calor

Mensajes de seguridad

ADVERTENCIA

Ciertos componentes en este producto y sus accesorios correspondientes contienen

químicos que en el Estado de California se consideran generadores de cáncer, defectos

de nacimiento u otros daños para el aparato reproductor humano. Lávese las manos

después de manipular estos elementos.

ADVERTENCIA

El escape del motor de este producto contiene químicos que en el Estado de California

se consideran generadores de cáncer, defectos de nacimiento u otros daños para el

aparato reproductor humano.

ADVERTENCIA

Los motores Briggs & Stratton no están diseñados y no se deben utilizar para: kartings;

vehículos recreativos para niños o deportivos todo terreno; motos; aerodeslizadores;

productos de aeronaves o vehículos utilizados en eventos competitivos no sancionados

por Briggs & Stratton. Para obtener información sobre productos para carreras

competitivas, vaya a www.briggsracing.com. Para uso con vehículos utilitarios y todo

terreno multi personales, contáctese con el Centro de Aplicación de Motores Briggs

& Stratton al 1-866-927-3349. La aplicación inadecuada del motor puede generar

lesiones graves o la muerte.

AVISO

Este motor fue enviado desde Briggs & Stratton sin aceite. Antes de arrancar el motor,

asegúrese de agregar aceite según las instrucciones de este manual. Si arranca el

motor sin aceite, sufrirá daños irreparables que la garantía no cubrirá.

ADVERTENCIA

Los vapores gaseosos son extremadamente inflamables y explosivos.

Un incendio o una explosión pueden causar graves quemaduras o la muerte.

Cuando agregue combustible

12 BRIGGSandSTRATTON.com

Not for

Reproduction

• Llene el tanque de combustible en exteriores o en un área bien ventilada.

• Controle con frecuencia que no haya grietas o fugas en el tanque de combustible,

ni en la tapa o accesorios. Reemplace las piezas, si es necesario.

Cuando encienda el motor

• Asegúrese de que la bujía, el silenciador, la tapa del combustible y el purificador

de aire (si tiene) estén colocados de modo seguro en su lugar.

• No haga girar el motor si retiró la bujía.

Cuando opere el equipo

• Nunca encienda o haga funcionar el motor sin el conjunto del purificador de aire

(si tiene) o el filtro de aire (si tiene).

Cuando transporte el equipo

• En el caso de motores a gas natural/gas licuado de petróleo, realice el traslado

con el cilindro de combustible vacío, con la válvula cerrada o con el tanque de

combustible desconectado.

Cuando almacene el combustible o el equipo con combustible en el tanque

• Almacene a distancia de hornos, estufas, calentadores de agua u otros aparatos

que utilicen luces piloto u otras fuentes de encendido, ya que estos pueden encender

los vapores de gasolina.

ADVERTENCIA

Dar arranque al motor crea chispeo.

El chispeo puede encender los gases inflamables cercanos.

Podría ocurrir una explosión o un incendio.

• Si hay una fuga de gas natural o gas propano LP en el área, no le dé arranque al

motor.

• No use líquidos de arranque presurizados ya que los vapores son inflamables.

ADVERTENCIA

PELIGRO DE GAS TÓXICO. El escape del motor contiene monóxido de carbono,

un gas tóxico que puede matar en minutos. NO puede verlo, es inodoro e insípido.

Incluso si no huele los gases del escape, puede estar expuesto al monóxido de

carbono. Si comienza a sentirse mareado o débil cuando utiliza este producto,

apáguelo y tome aire fresco INMEDIATAMENTE. Consulte a un médico. Puede

haberse intoxicado con monóxido de carbono.

• Opere este producto SOLAMENTE al aire libre, lejos de ventanas, puertas y

ventilaciones, para reducir el riesgo de que el monóxido de carbono se acumule y

pueda circular a espacios habitados.

• Instale alarmas de monóxido de carbono con baterías o enchufe (batería de

respaldo) siguiendo las instrucciones del fabricante. Las alarmas de humo no

pueden detectar el monóxido de carbono.

• NO opere este producto dentro de hogares, garajes, sótanos, espacios reducidos,

cobertizos u otros espacios parcialmente cerrados, incluso si usa ventiladores o

deja las puertas y ventanas abiertas. El monóxido de carbono se puede acumular

rápidamente en estos espacios y puede permanecer durante horas, incluso después

de que se apaga este producto.

• SIEMPRE coloque este producto en la dirección del viento y apunte el escape del

motor lejos de espacios habitados.

ADVERTENCIA

La retracción rápida de la cuerda de arranque (retroceso violento) le halará la

mano y el brazo hacia el motor antes de que pueda soltarla.

Podrían ocasionarse roturas de huesos, fracturas, moretones o torceduras.

• Cuando arranque el motor, tire lentamente de la cuerda hasta sentir resistencia y,

a continuación, tire rápidamente de ella para evitar su retroceso.

• Remueva todas las cargas externas del equipo/motor antes de darle arranque al

motor.

• Los componentes del equipo de acoplamiento directo, como cuchillas, impulsores,

poleas, ruedas dentadas, entre otros, se deben colocar firmemente.

ADVERTENCIA

Las partes rotantes pueden tener contacto o enredar las manos, los pies, el

cabello, la ropa o los accesorios.

Puede producirse una traumática amputación o una grave laceración.

• Opere el equipo con los protectores en su lugar.

• Mantenga las manos y los pies a distancia de las partes rotantes.

• Recoja el pelo largo y quítese cualquier joya.

• No use ropa floja, tiras que cuelguen o artículos que puedan ser agarrados.

ADVERTENCIA

El funcionamiento de los motores produce calor. Las partes de los motores,

especialmente el silenciador, se calientan demasiado.

Pueden ocurrir graves quemaduras al tocarlas.

Los desechos combustibles, tales como hojas, grama, maleza, etc., pueden

prenderse fuego.

•Deje que el silenciador, el cilindro y las aletas del motor se enfríen antes de tocarlos.

•Extraiga los desechos acumulados en el área del silenciador y en el área del cilindro.

• Es una violación del Código de Recursos Públicos de California, Sección 4442,

utilizar u operar el motor en cualquier espacio con árboles, maleza o grama a menos

que el sistema de escape esté equipado con un extintor de chispas, como lo define

la Sección 4442, mantenido en correcto funcionamiento. Otros estados o

jurisdicciones federales pueden tener leyes similares. Póngase en contacto con el

vendedor, el distribuidor o el fabricante del equipo original para obtener un extintor

de chispas diseñado para el sistema de escape instalado en este motor.

ADVERTENCIA

Un chispeo involuntario puede producir un incendio o una descarga eléctrica.

Una puesta en marcha involuntaria puede causar enredos, amputaciones

traumáticas o laceraciones.

Peligro de incendio

Antes de hacer ajustes o reparaciones:

• Desconecte el cable de la bujía y manténgalo lejos de la bujía.

• Desconecte la batería en la terminal negativa (únicamente motores con arranque

eléctrico).

• Use solamente las herramientas correctas.

• No manipule el resorte del regulador, las conexiones u otras piezas para aumentar

la velocidad del motor.

• Las piezas de reemplazo deben ser del mismo diseño y deben ser instaladas en

la misma posición que las piezas originales. Otras piezas pueden no funcionar

igual de bien, pueden dañar la unidad y pueden causar lesiones.

• No golpee el volante con un martillo o un objeto duro, porque el volante más tarde

puede romperse durante la operación.

Cuando haga las pruebas de chispa:

• Use un comprobador de bujías aprobado.

• No haga las pruebas de chispa sin la bujía en su lugar.

ADVERTENCIA

Los combustibles gaseosos son extremadamente inflamables y no tardan en

formar mezclas explosivas de aire y vapor a temperatura ambiente.

Si siente olor a gas:

•No arranque el motor.

•No accione ningún interruptor eléctrico.

•No utilice ningún teléfono en el área circundante.

• Evacúe el área.

• Póngase en contacto con el proveedor de gas o con el departamento de bomberos.

Not for

Reproduction

ADVERTENCIA

Utilice protección ocular al realizar reparaciones.

El contacto de la piel o los ojos con el gas licuado de petróleo puede provocar

un efecto de congelamiento.

• Las tareas de instalación, ajuste y reparación deben estar a cargo de un técnico

calificado.

• Revise con frecuencia la línea de suministro flexible. Asegúrese de que esté en

buen estado. Reemplace los componentes que estén dañados o que presenten

fugas.

ADVERTENCIA

Si la válvula de cierre para combustible no está instalada o no funciona, puede

producirse un incendio o una explosión.

•No opere el equipo si la válvula de cierre para combustible no está instalada o no

funciona.

Características y controles

Controles del motor

Compare la ilustración (Figura: 1, 2, 3) con su motor para familiarizarse con la ubicación

de diversas características y controles.

A. Números de identificación del motor Modelo, Tipo, Código

B. Bujía

C. Filtro de aire

D. Varilla indicadora de nivel de aceite

E. Tapón para el drenaje de aceite

F. Silenciador, protector de silenciador (si tiene), supresor de chispas (si tiene)

G. Parrilla de admisión de aire

H. Filtro de aceite (si tiene)

I. Arranque eléctrico

J. Mezclador de gas licuado de petróleo (LPG)/gas natural (NG)

K. Drenaje rápido de aceite (si tiene)

Símbolos de control y sus significados

SignificadoSímboloSignificadoSímbolo

Velocidad del motor - LentaVelocidad del motor -

Rápida

Encendido - ApagadoVelocidad del motor -

Parada

Operación

Recomendaciones de Aceite

Capacidad de aceite: Consulte la sección

Especificaciones

Se recomienda el uso de aceites certificados y garantizados Briggs & Stratton para obtener

el mejor rendimiento. Otros aceites detergentes de alta calidad son aceptables si cuentan

con la clasificación de servicio SG, SH, SJ o superior. No use aditivos especiales.

Las temperaturas exteriores determinan la viscosidad adecuada del aceite para el motor.

Use la tabla para seleccionar la mejor viscosidad para el rango de temperatura exterior

esperado.

SAE 30 - El uso de SAE 30 a temperaturas inferiores a 4 °C (40 °F) provocará

dificultades en el arranque.

10W-30 -El uso de 10W-30 a temperaturas mayores a 27 °C (80 °F) puede

provocar un aumento en el consumo de aceite. Compruebe el nivel de aceite

con mayor frecuencia.

Synthetic 5W-30C

5W-30D

Verificación del nivel de aceite

Vea la figura: 4

Antes de aprovisionar con aceite o de comprobar el nivel de aceite

• Asegúrese de que el motor esté nivelado.

• Limpie todos los desechos del área de llenado de aceite.

1. Retire la varilla indicadora de nivel (A, Figura 4) y límpiela con un paño limpio.

2. Instale y ajuste la varilla indicadora de nivel (A, Figura 4).

3. Retire la varilla y verifique el nivel de aceite. El nivel de aceite debe estar en la parte

superior del indicador de lleno (B, Figura 4) de la varilla indicadora de nivel de aceite.

4. Si el nivel es bajo, agregue aceite lentamente en el llenado de aceite del motor (C,

Figura 4). No llene en exceso. Después de añadir aceite, espere un minuto y luego

vuelva a verificar el nivel de aceite.

NOTA: No agregue aceite en el drenaje rápido de aceite, si tiene. Para conocer la ubicación,

consulte la sección Características y controles.

5. Vuelva a instalar y ajuste la varilla indicadora de nivel de aceite (A, Figura 4).

Sistema de protección contra bajo nivel

de aceite (si está equipado)

Algunos motores vienen equipados con un sensor de bajo nivel de aceite. Si el nivel de

aceite está bajo, el sensor activará una luz de advertencia o detendrá el motor. Pare el

motor y siga estos pasos antes de volver a arrancarlo.

• Asegúrese de que el motor esté nivelado.

• Controle el nivel de aceite. Consulte la sección

Comprobación del nivel de aceite

• Si el nivel de aceite está bajo, agregue la cantidad adecuada de aceite. Arranque

el motor y asegúrese de que la luz de advertencia (si tiene) no esté activada.

• Si el nivel de aceite no está bajo, no arranque el motor. Para hacer corregir el

problema del aceite, póngase en contacto con un distribuidor de servicio autorizado

de Briggs & Stratton.

Recomendaciones de combustible

ADVERTENCIA

Si la válvula de cierre para combustible no está instalada o no funciona, puede

producirse un incendio o una explosión.

• No opere el equipo si la válvula de cierre para combustible no está instalada o no

funciona.

El combustible debe cumplir con los siguientes requerimientos

14 BRIGGSandSTRATTON.com

Not for

Reproduction

• Utilice combustible limpio y seco, libre de humedad y de materiales particulados. Si

se usan combustibles que no cumplen con las siguientes recomendaciones, pueden

presentarse problemas de desempeño.

•En el caso de los motores preparados para funcionar con LPG, se recomienda utilizar

LPG HD5 de grado comercial. Se recomienda que el combustible tenga una energía

mínima de 2500 BTU/ft³, con un contenido máximo de propileno del 5%, un contenido

de butano y de gases más pesados del 2,5 %, y un contenido mínimo de propano

del 90 %.

Los motores a NG o LPG cuentan con una certificación para que puedan usarse con gas

natural o con gas propano líquido. El sistema de control de emisiones que rige para este

motor es el EM (modificaciones de motores).

ADVERTENCIA

El equipo en el que está montado este motor cuenta con una válvula de cierre para

combustible a gas con activación de seguridad automática. No opere el equipo si la

válvula de cierre para combustible no está instalada o no funciona

Cómo agregar combustible

ADVERTENCIA

Los vapores gaseosos son extremadamente inflamables y explosivos.

Un incendio o una explosión pueden causar graves quemaduras o la muerte.

Cuando agregue combustible

• Llene el tanque de combustible en exteriores o en un área bien ventilada.

• Controle con frecuencia que no haya grietas o fugas en el tanque de combustible,

ni en la tapa o accesorios. Reemplace las piezas, si es necesario.

Para obtener información sobre cómo poner combustible en motores a gas natural o a

gas licuado de petróleo, lea las instrucciones de operación que ofrece el fabricante del

equipo.

Arranque y parada del motor

Vea la figura: 5

Arranque del motor

ADVERTENCIA

Los vapores gaseosos son extremadamente inflamables y explosivos.

Un incendio o una explosión pueden causar graves quemaduras o la muerte.

Cuando encienda el motor

• Asegúrese de que la bujía, el silenciador y el purificador de aire (si tiene) estén

colocados de modo seguro en su lugar.

• No haga girar el motor si retiró la bujía.

ADVERTENCIA

PELIGRO DE GAS TÓXICO. El escape del motor contiene monóxido de carbono,

un gas tóxico que puede matar en minutos. NO puede verlo, es inodoro e insípido.

Incluso si no huele los gases del escape, puede estar expuesto al monóxido de

carbono. Si comienza a sentirse mareado o débil cuando utiliza este producto,

apáguelo y tome aire fresco INMEDIATAMENTE. Consulte a un médico. Puede

haberse intoxicado con monóxido de carbono.

• Opere este producto SOLAMENTE al aire libre, lejos de ventanas, puertas y

ventilaciones, para reducir el riesgo de que el monóxido de carbono se acumule y

pueda circular a espacios habitados.

•Instale alarmas de monóxido de carbono con baterías o enchufe (batería de respaldo)

siguiendo las instrucciones del fabricante. Las alarmas de humo no pueden detectar

el monóxido de carbono.

• NO opere este producto dentro de hogares, garajes, sótanos, espacios reducidos,

cobertizos u otros espacios parcialmente cerrados, incluso si usa ventiladores o deja

las puertas y ventanas abiertas. El monóxido de carbono se puede acumular

rápidamente en estos espacios y puede permanecer durante horas, incluso después

de que se apaga este producto.

• SIEMPRE coloque este producto en la dirección del viento y apunte el escape del

motor lejos de espacios habitados.

AVISO

Este motor fue enviado desde Briggs & Stratton sin aceite. Antes de arrancar

el motor, asegúrese de agregar aceite según las instrucciones de este manual. Si

arranca el motor sin aceite, sufrirá daños irreparables que la garantía no cubrirá.

NOTA: El equipo puede tener controles remotos. Consulte el manual del equipo para

conocer la ubicación y el funcionamiento de los controles remotos.

1. Verifique el nivel de aceite en el motor. Consulte la sección

Verificación del nivel

de aceite

2. Asegúrese de que los controles de transmisión del equipo, si tiene, estén

desconectados.

3. Mueva la válvula de cierre de combustible (B, Figura 5), si tiene, a la posición abierta

(OPEN).

4. Gire el interruptor de arranque eléctrico (A, Figura 5) a la posición de encendido o

arranque (ON o START).

AVISO

Para prolongar la vida útil del arrancador, use ciclos cortos de arranque (cinco

segundos como máximo). Espere un minuto entre los ciclos de arranque.

NOTA: Si el motor no arranca después de varios intentos, póngase en contacto con su

distribuidor local o visite BRIGGSandSTRATTON.com o llame al 1-800-233-3723 (en

EE. UU.).

Parada del motor

1. Gire el interruptor de llave (A, Figura 5) a la posición de apagado (OFF). Retire la

llave y guárdela en un lugar seguro fuera del alcance de los niños.

2. Una vez que se detiene el motor, mueva la válvula de cierre de combustible (B,

Figura 5), si tiene, a la posición de cierre (CLOSED).

Mantenimiento

AVISO

Si el motor se inclina durante el mantenimiento, el tanque de combustible, si

está montado en el motor, se debe vaciar y el lado de la bujía debe estar hacia arriba.

Si el tanque de combustible no está vacío y si el motor se inclina en cualquier otra

dirección, puede resultar difícil arrancarlo debido a que el aceite o la gasolina contaminan

el filtro de aire o la bujía.

ADVERTENCIA

Al realizar trabajos de mantenimiento que requieran inclinar la unidad, el tanque de

combustible, si está montado en el motor, debe estar vacío o podría haber una fuga de

combustible y generar un incendio o una explosión.

Le recomendamos que consulte a cualquier distribuidor autorizado de Briggs & Stratton

para el mantenimiento y reparación del motor y para obtener piezas del motor.

AVISO

Todos los componentes utilizados para construir este motor deben permanecer

en su lugar para su correcto funcionamiento.

ADVERTENCIA

Un chispeo involuntario puede producir un incendio o una descarga eléctrica.

Una puesta en marcha involuntaria puede causar enredos, amputaciones

traumáticas o laceraciones.

Peligro de incendio

Antes de hacer ajustes o reparaciones:

• Desconecte el cable de la bujía y manténgalo lejos de la bujía.

• Desconecte la batería en la terminal negativa (únicamente motores con arranque

eléctrico).

• Use solamente las herramientas correctas.

• No manipule el resorte del regulador, las conexiones u otras piezas para aumentar

la velocidad del motor.

• Las piezas de repuesto deben ser del mismo diseño y deben ser instaladas en la

misma posición que las piezas originales. Otras piezas pueden no funcionar igual

de bien, pueden dañar la unidad, y pueden causar lesiones.

• No golpee el volante con un martillo o un objeto duro, porque el volante más tarde

puede romperse durante la operación.

Cuando compruebe chispa:

• Use un comprobador de bujías aprobado.

• No haga las pruebas de chispa sin la bujía en su lugar.

Not for

Reproduction

Servicio de control de emisiones

Cualquier establecimiento o individuo especializado en la reparación de motores

que no sean de automoción puede encargarse del mantenimiento, la sustitución y

la reparación de los dispositivos y sistemas de control de emisiones. Sin embargo,

para recibir el servicio de control de emisiones "sin cargo", debe realizarlo un distribuidor

autorizado por la fábrica. Ver Declaraciones de Control de Emisiones.

Plan de mantenimiento

Las primeras 5 horas

•Cambie el aceite 2

Cada 8 horas o diariamente

• Compruebe el nivel del aceite del motor

Cada 50 horas o anualmente

•Limpie el filtro de aire 1

•Limpie el pre-filtro (si tiene) 1

•Cambie el aceite del motor 3

•Reemplace el filtro de aceite (si tiene) 3

• Realice el mantenimiento del sistema de escape (si tiene).

Cada 100 horas o anualmente

• Reemplace el filtro de aire

• Sustituya las bujías

•Cambie el aceite del motor 4

•Reemplace el filtro de aceite (si tiene) 4

•Realice el mantenimiento del sistema de enfriamiento 1

•Compruebe el espacio libre de la válvula 5

Anualmente

• Reemplace el filtro de aire

• Sustituya las bujías

•Realice el mantenimiento del sistema de enfriamiento 1

1Limpie con mayor frecuencia en condiciones de mucho polvo o cuando el aire

contenga muchas partículas.

2Solo para los motores sin filtro de aceite.

3Motores sin filtro de aceite o con filtro de aceite de color negro estándar (consulte

la página de

Especificaciones

para conocer el número de parte).

4Motores con filtro de aceite de color amarillo o anaranjado de alta eficacia (consulte

la página de

Especificaciones

para conocer el número de parte).

5No se requiere a menos que se detecten problemas de desempeño en el motor.

Revisión de la bujía

Vea la figura: 6

Revise el entre-hierro (A, Figura 6) con un calibrador de alambre (B). Si es necesario,

vuelva a establecer la distancia. Instale y ajuste la bujía al par recomendado. Para el ajuste

del entre-hierro o el par de apriete, consulte la sección

Especificaciones

NOTA: En algunas áreas, las leyes locales requieren el uso de una bujía con resistencia

para suprimir las señales de encendido. Si este motor vino originalmente equipado con

una bujía con resistencia, use el mismo tipo de bujía cuando la reemplace.

Realice el mantenimiento del sistema de

escape

ADVERTENCIA

El funcionamiento de los motores produce calor. Las partes de los motores,

especialmente el silenciador, se calientan demasiado.

Pueden ocurrir graves quemaduras a causa de su contacto.

Desechos combustibles, tal como hojas, grama, maleza, etc. pueden alcanzar a

encenderse.

• Deje que el silenciador, el cilindro y las aletas del motor se enfríen antes de tocarlos.
