IMPORTANT
SAFETY
INFORMATION
AND
INSTRUCTIONS
FOR
ENGINE
SELECTION
ENGINE
INSTALLATION
ENGINE OPERATION
Keep these instructions for future
reference.
II;
Before installing
and
operating
this engine
read and
observe all
warnings,
cautions
and
instruct,ons
on
both
sides
of this
sheet,
on
the
engine,
and
in
the
operating &
maintenance instructions.
NOTE"
This sheet
of
instructions
and
safety information
is
not
meant to
cover
all
possible conditions
and situations
that
may occur.
Read
entire
Operating
&
Maintenance
lnatructions
for
this
engine AND the
instructions for
the equipment
this engine
powers.
Failure
to
follow
instructions
and safety information
could
result in
serious injur
or
death.
The safety
alert symbol
(::)is
used
to
identify safety
information
about
hazards that
can
result in
personal injury.
A signal
word
(DANGER,
WARNING,
or
CAUTION)
is
used
with
the
alert
symbol
to
indicate the likelihood
and the potential
severity
of
injury. In addition,
a
hazard
symbol
may
be used
to represent
the
type
of
hazard.
DANGER
indicates
a
hazard
which,
if
not
avoided,
will
result in death
or
serious injury.
WARNING
indicates
a
hazard which, if
not
avoided,
could result in death
or
serious
injury.
CAUTION
indicates
a
hazard
which,
if
not
avoided,
might
result
in minor
or
moderate injury.
CAUTION,
when used without the
alert symbol,
indicates
a
situation that could
result
in
damage
to
the engine.
(OVER)
FORM MS-6445-01/03

Hazard
Symbols
and Meanings
Fire
Explosion Shock
Kickback
Toxic Fumes
Hot
Surface
Moving Parts
International Symbols
and Meanings
Safety
Alert Choke
Read Operator's
Manual
Oil
Fuel
Fuel
Shutoff
On Off
Stop
WARNING
Start
and
run
engine outdoors.
Do
not start
or
run
engine
in enclosed
area, even
if
doors
or
windows
are
open.
WARNING
If
there is
natural
or
LP
gas
leakage
in
area,
do
not
start
engine.
Do
not
use
pressurized
starting
fluids
because
vapors are
flammable.
WARNING
WHEN ADDING
FUEL
Turn
engine
OFF
and let
engine cool
at
least
2
minutes before
removing
gas cap.
Fill
fuel
tank outdoors
or
in
well-ventilated
area.
Do
not
overfill fuel
tank. Fill tank
to
approximately
1/2
inch below
lowest
portion
of
fill
opening
to
allow
for fuel
expansion.
Keep
gasoline
away
from
sparks,
open
flames,
pilot
lights,
heat,
and other ignition
sources.
Check
fuel
lines,
tank,
cap,
and
fittings
frequently
for
cracks
or
leaks.
Replace if
necessary.
WHEN STARTING
ENGINE
Make
sure
spark plug, muffler,
fuel
cap
and air
cleaner
are
in
place.
Do
not
crank
engine with
spark plug
removed.
If fuel
spills,
wait until it
evaporates
before
starting
engine.
If
engine
floods,
set
choke
to
OPEN/RUN
position,
place
throttle in
FAST
and
crank until
engine
starts.
WHEN OPERATING
EQUIPMENT
Do
not
tip engine
or
equipment
at
angle which
causes
gasoline
to
spill.
Do
not
choke
carburetor
to stop
engine.
WHEN TRANSPORTING
EQUIPMENT
Transport
with
fuel
tank EMPTY
or
with fuel
shut-off
valve
OFE
WHEN STORING
GASOLINE
OR EQUIPMENT
WITH
FUEL IN
TANK
Store
away
from
furnaces,
stoves,
water
heaters
or
other
appliances that
have pilot light
or
other
ignition
source
because
they
can
ignite gasoline
vapors.
WARNING
Operate
equipment
with
guards in place.
Keep hands
and feet
away
from
rotating
parts.
Tie
up
long
hair
and
remove
jewelry.
Do
not
wear
loose-fitting
clothing,
dangling
drawstrings
or
items
that could
become
caught.
WARNING
When
starting
engine,
pull cord
slowly until
resistance
is
felt,
then pull
rapidly.
Remove
all
external equipment/engine
loads
before
staing
engine.
Direct
coupled equipment
components
such
as,
but
not
limited
to,
blades, impellors,
pulleys,
sprockets,
etc.,
must
be
securely
attached.
WARNING
Allow muffler,
engine
cylinder
and
fins
to
cool
before
touching.
Remove
accumulated
combustibles from
muffler
area
and cylinder
area.
Install
and maintain
in working
order
a
spark
arrester
before
using
equipment
on
forest-covered,
grass-covered, brush-covered
unimproved
land.
The
state
of
California
requires this
(Section
4442
of
the
California
Public Resources Code).
Other
states
may
have
similar
laws. Federal
laws
apply
on
federal
land.
WARNING
BEFORE
PERFORMING
ADJUSTMENTS
OR
RE-
PAIRS
Disconnect
spark plug
wire and keep
it
away
from
spark plug.
Disconnect
battery
at
negative
terminal (only
engines
with electric
start).
WHEN TESTING
FOR SPARK
Use
approved spark plug
tester.
Do
not
check for
spark
with spark
plug
removed.

CAUTION:
Engine
shipped from
Briggs & Stratton
without
oil. Before
starting
engine, fill
with
oil. Do
not
over-fill.
Use
a
high
quality detergent
oil classified "For Service
SG, SH,
S
J,
SL"
or
higher
such
as
Briggs
&
Stratton
30,
Part
Number
100005. Use
no
special
additives
with
recommended
oils. Do
not
mix oil
with
gasoline.
o,..
0/.
20
32 #0
60
80
100
o.
-o -_
-'IO
io o
o
40
Choose
the SAE
viscosity
grade of
oil from
this chart
that
matches
the
starting
temperature
anticipated
before
the
next
oil
change.
Air
cooled
engines
run
hotter
than
automotive
engines.
The
use
of
non-synthetic
multi-viscosity
oils (5W-30,
IOW-30, etc.)
in
temperatures
above
40
F (4
C)
will
result in higherthan
normal oil
consumption. When
using
a
multi-viscosity
oil, check
oil level
more
frequently.
Use of
SAE
30 oil below
40
F (4 C)
will
result in hard
starting
and
possible
engine
damage
due
to
inade-
quate
lubrication.
Note: Synthetic
oil
meeting
ILSAC
GF-2,
API
certification
mark and API
service
symbol (shown
at
left)
with
"SJ/CF
ENERGY CONSERVING"
or
higher,
is
an
acceptable
oil
at
all
temperatures.
Use
of
synthetic
oil does
not
alter
required
oil
change
intervals.
ADD
OIL
(Oil
capacity is
about
20
oz.
or
0.6
liter.)
1.
Place
engine
level
and clean
around oil
fil:
t)
2.
Remove
oil
filler
plug.
3.
Oil
should
be full
to
overflowing.
(
Use clean, fresh,
lead-free,
regular
gasoline
with
a
minimum of
85
octane.
Leaded
gasoline
may
be
used
if
it
is
commercially
available
and
if
unleaded
is
unavailable. Purchase
fuel
in
quantity
that
can
be
used within
30
days. See
Storage
instructions.
In
U.S.A.
leaded
gasoline
may
not
be
used.
Some
fuels,
called
oxygenated
or
reformulated
gasolines,
are
gasolines blended
with
alcohols
or
ethers.
Excessive
amounts
of
these
blends
can
damage
the fuel
system
or cause
performance
problems.
If
any
undesirable
operating
symptoms
occur,
use
gasoline
with
a
lower
percentage
of
alcohol
or
ether.
This
engine is certified
to
operate
on
gasoline. Exhaust
Emission Control
System:
EM (Engine
Modifications).
Do
not
use
gasoline
which
contains Methanol.
Do
not
mix oil
with
gasoline.
For
engine
protection,
we
recommend
using Briggs & Stratton
Fuel Stabilizer
available from
an
Authorized
Briggs & Stratton
Service
Dealer.
Check
fuel
level
Before
refueling,
allow
engine
to
cool
2
minutes.
Clean
around
fuel
fill
before
removing
cap
to
refuel.
Fill
tank
to
approximately 1/2
inch
below
lowest
portion
of
fill
opening
to
allow for fuel
expansion. Be careful
not to
overfill.
WARNING
BEFORE
STARTING
Start,
store,
and
fuel
engine
in
a
level
position.
Add fuel
and re-install fuel
cap.
Check
oil level.
STARTING
ENGINE
Move
throttle
0
to
FAST. Operate
engine
with
throttle in
FAST.
Move
choke
0
control lever
to
CHOKE.
Move
stop
switch
to
ON
(if
equipped).O
When
starting
engine,
pull
cord slowly
until
resistance
is
felt,
then
pull
rapidly.
)
Allow
engine
to
warm
up.
Adjust
Choke:
Slowly
adjust
toward RUN
position. Wait
until
engine
runs
smoothly before
each choke
adjustment.
STOPPING
WARNING
Do
not stop
engine by
moving
choke
control
to
CHOKE.
Backfire,
fire
or
engine
dam-
age
could
occur.
Move
throttle
control
to
IDLE
or
SLOW
position
O,
if
possible.
Then
move
stop
control
STOP
or
OFF
position,
if
equipped
(.

WARNING
To
prevent
accidental
starting,
remove
spark
plug wire
O
and
ground before
servicing.
We
recommend that
you see
an
authorized
Briggs
&
Stratton
Dealer for
all maintenance
and
service.
Use
only Briggs &
Stratton
parts.
WARNING
Do
not
strikethe flywheel
with
hammer
or
hard object.
If
done,
the flywheel
may
shatter
during
operation.
Do
not tamper
with
governor
spring,
links
or
other
parts
to
increase
engine
speed.
Follow
the
hourly
or
calendar
intervals,
whichever
occur
first.
More
frequent
service
is
required
when
operating in
adverse
conditions
noted below.
Change
oil
Checkoil
level
Clean
finger
guard
on
rewind
starter
Clean
around muffler
Change
oil
if
operating
under
heavy
load
or
high
ambient
temperature
Service
air cleaner
pre-cleaner,
if
equipped*
Service
air cleaner
cartridge, if
no
pre-cleaner*
Change
oil
Inspect
spark
arrester,
if
equipped
Service
air cleaner
cartridge,
if
equipped
with
pre-cleaner*
Clean
air cooling
system*
Replace
spark plug**
Clean
more
often
under
dusty
conditions,
or
when
airbome
debris
is
present
or
after
prolonged
operation
cutting
tall,
dry
grass.
In
some
areas,
Iocal
law
requires
using
a
resistor
spark
plug
to
suppress
ignition
signals.
If
this
engine
was
originally
equipped
with
resistor
spark plug,
use same
type
of
spark plug for
replacement.
CAUTION:
Used
oil is
a
hazardous
waste
product.
Dispose
of
used oil
properly. Do
not
discard
with
household
waste.
Check
with
your
local
authorities,
service
center,
or
dealer for
safe
disposal/recycling
facilities.
CHANGING
ENGINE
OIL
,
WARNING
Change
oil after first
5
hours of
operation. Change
oil
while
engine
is
warm.
Refill
with
new
oil of
recommended
SAE
viscosity
grade.
1.
Place
engine level.
2.
Disconnect
spark plug
wire
and keep
it
away
from
spark
plug.
3.
Remove
drain
plug
O
and drain
oil into
appropriate
receptacle.
4.
Reinstall
oil
drain
plug.
remove
oil fill
cap.
O
5.
Add
new
oil by filling
to
point of
overflowing.
)
6. Replace
oil fill
cap.
AIR
CLEANER
SYSTEMS
All
engines
have
an
air
cleaner
cartridge. The
cartridge
is
either flat
or
oval (see
illustrations).
In addition,
some
engines
have
a
pre-cleaner.
CAUTION:
Do
not
use
pressurized
air
or
solvents
to
clean
cartridge.
Pressurized
air
can
damage
cartridge;
solvents
will
dissolve
cartridge.
OVAL
AIR CLEANER
1.
Push
in
the
tabs
O
located
on
the sides
of
the
air
cleaner
cover,
while
pulling
cover
O
off.
2. Remove
cartridge
)
carefully
to
prevent
debris from
entering
carburetor.
3. Re-install
new
air
cleaner
assembly
in base.
E)
4.
Reassemble
cover
by
snapping
tabs back
into
place.
SQUARE
AIR
CLEANER
1. Loosen
screws
O
and
remove
cover.
2.
Remove
pre-cleaner
)
(if
equipped)
and
cartridge
)
carefully
to
prevent
debris
from
entering
carburetor.
3.
Reinstall
clean (or
new)
air
cleaner
assembly
in
base.
4.
To
service
pre-cleaner
(if
equipped),
separate
it
from
cartridge,
and
wash in liquid
detergent
and
water.
Air
dry
thoroughly.
Do
not
oil. Reinstall
dry
pre-cleaner
on
clean
cartridge.
5.
Replace
cover
and
tighten
screws.
AIR
COOLING
SYSTEM
It
is
recommended
to
clean
the
air
cooling
system
with blower
housing
removed
every
100 hours. Clean
areas
shown.
O
MUFFLER
,
WARNING
Replacement
parts
for
the
muffler
must
be the
same
and
installed
in the
same
position
as
the
original
parts,
otherwise
fire
can
occur.
If
muffler
is
equipped
with
spark
arrester
screen,
remove
screen
for
inspection.
Replace
screen
if
damaged
or
plugged
with debris.
SPARK
PLUG
Check
the
spark
plug
every
season.
Replace
the
spark plug if
upon
inspection
the
electrodes
are
burned
or worn.
Ensure
the
spark
plug is
clean.
Check
the
gap
with
a
feeler
gage
O
and
reset to
.76
mm
or
0.30
in. if
necessary.
COMBUSTION
DEPOSITS
We
recommend that after
every
100-300 hours
you
have
an
Authorized
Briggs & Stratton
Service
Dealer
remove
combus-
tion
deposits
from
the
cylinder,
cylinder
head,
top
of
piston,
and
around
valves.
FUEL SYSTEM
Replacement
parts
for fuel
system
(caps,
hoses,
tanks, filters,
etc.)
must
be the
same
as
the
original
parts
otherwise
fire
can
Occur.
CLEANING
DEBRIS
Daily
or
before
every
use,
clean
accumulated debris
from
engine.
O
Keep
linkage,
springs
and
controls clean.
O
Keep
area
around
and behind
the
muffler free
of
any
combustible
debris.
)
CAUTION:
Do
not
use
water
to
clean
engine
parts.
Water
could
contaminate
fuel
system.
Use
a
brush
or
dry
cloth.
,
WARNING
Engine
parts
should
be kept
clean
to
reduce
the
risk of
overheating
and ignition
of
accumulated
debris.
GEAR
REDUCTION
OIL
Changing
Oil
in
Gear
Reduction,
if
equipped
Change
oil in
gear
reduction
after
every
100 hours
of
operation.
1.
To
drain
oil, loosen
4
gear
case
cover
screws
O
and
drain
oil into
appropriate
receptacle.
2.
After
draining,
torque 4
screws
to
85
in-lbs.
3. To refill,
pour
SAE
30
oil into
oil fill
hole
until it
runs
out
level
check
hole.
)
4.
Replace
both
oil plugs.
)
Note:
Oil
filler
plug
has
a
vent
hole
and
must
be installed
on
top
of
gear
case
cover.

See
an
Authorized
Briggs
& Stratton Service
Dealer. Each
one
carries
a
stock of
Genuine
Briggs
& Stratton
Parts and
is
equipped with
special service
tools. Trained
mechanics
assure
expert
repair service
on
all Briggs
& Stratton
engines.
Only
dealers
advertising
as"Authorized
Briggs
& Stratton"
are
required
to meet
Briggs
& Stratton
standards.
When
you
purchase equipment
powered by
a
Briggs
& Stratton
engine,
you are
assured
of
highly
skilled, reliable
service
at
more
than
30,000
Authorized
Service
Dealers
world-
wide,
including
more
than
6,000
Master
Service
Technicians.
Look
for
these signs
wherever
Briggs
& Stratton
service is
offered.
You
find
the
nearest
Authorized
Service
Dealer in
our
dealerlocator
map
atwww.briggsandstratton.com,
orby
calling
1-800-233-3723,
or as
listed
in the
'Yellow
Pages rM' directory
under
"Engines,
Gasoline"
or
"Gasoline
Engines,"
or
"Lawn
Mowers"
or
similar
category.
Note: Walking fingers
logo
and
"Yellow
Pages"
are
registered
trademarks
in various jurisdictions.
An illustrated
shop manual includes
"Theories
of Operation,"
common
specifications
and detailed information
covering
adjustment,
tune-up
and
repair
of
Briggs
& Stratton
L-head,
single cylinder,
4
cycle engines.
Order P/N
270962
from
an
Authorized
Briggs
& Stratton
Service
Dealer
or you can
order
at
www.briggsandstratton.com.
Insist
on
Genuine
Briggs & Stratton
replacement
parts
with
our
logo
on
the box
and/or
part.
Non-original
parts
may
not
perform
as
well and
may
void
your
warranty.
Engines
stored
over
30
days need special
attention.
To
prevent
gum
from forming
in fuel
system
or
on
essential
carburetor
parts:
a) if fuel
tank
contains oxygenated
or
reformulated
gasoline
(gasoline
blended with
an
alcohol
or an
ether),
run
engine
until
it
stops
from
lack of fuel,
or
b) if fuel
tank contains
gasoline,
either
run
engine until it
stops
from
lack of fuel,
or
add
a
gasoline stabilizer
to
the
gas
in the
tank.
Note: If
stabilizer is used,
run
the engine
for
several minutes
to
circulate
the additive through
the carburetor. Then
engine and
fuel
can
be
stored.
1.
Change
oil.
2.
Remove
spark plug and
pour
about
15
ml
(1/2
oz.) of
engine
oil into cylinder. Replace
spark plug
and crank
slowly
to
distribute oil.
3.
Clean
engine
of
debris.
4.
Store
in
a
clean
and dry
area.
We
recommend
use
of
Briggs
& Stratton
Fuel
Stabilizer
available
from
an
Authorized Briggs
& Stratton
Service
Dealer.
DO NOT
store
near a
stove,
furnace
or
water
heater which
uses a
pilot light
or any
device
that
can
create
a
spark.
Partial
List of
Genuine
Briggs &
Stratton
Pads
Brig_os &
Stratton
(or equivalent)
Part
Part
No.
Oval
air cleaner
cartridge
790166
Flat air cleaner
cartridge
491588
-or-
5043
Flat air cleaner
pre-cleaner
491435
Oil
100005
-or-
100028
Fuel Filter
298090
-or-
5018
Gas
additive
5041
Resistor
spark plug
802592
Standard
spark plug
492167
Spark
plug
wrench
89838
-or-
5023
Spark
tester
19368
Oil
pump
kit
5056
(uses
standard electric drill
to
remove
oil
from
engine
quickly)

Effective
July
1,
2004
replaces all
undated Warranties and
all Warranties dated
before July
1, 2004
LIMITED WARRANTY
Briggs &
Stratton Corporation will repair
or
replace, free of charge,
any
part(s)
of the engine that is
defective in material
or
workmanship
or
both.
Transporta-
tion charges
on
parts
submitted
for repair
or
replacement
under this
warranty
must
be borne by
purchaser. This
warranty
is
effective for
the time
periods and
subject
to
the
conditions stated
below. For
warranty
service,
find
the
nearest
Authorized
Service Dealer in
our
dealer Iocator
map
at
www.10riggsandstratton.com,
or
by
calling 1-800-233-3723,
or
as
listed in the
'Yellow Pages TM'.
THERE
IS NO OTHER
EXPRESS
WARRANTY. IMPLIED
WARRANTIES,
INCLUDING THOSE OF
MERCHANTABILITY
AND
FITNESS FOR
A
PARTICU-
LAR
PURPOSE,
ARE
LIMITED
TO ONE YEAR
FROM PURCHASE,
OR TO
THE
EXTENT PERMITTED BY LAW
ANY AND ALL IMPLIED
WARRANTIES
ARE
EXCLUDED. LIABILITY
FOR INCIDENTAL
OR CONSEQUENTIAL
DAMAGES ARE
EXCLUDED TO THE EXTENT
EXCLUSION
IS
PERMITTED BY
LAW.
Some
states
or
countries do
not
allow
limitations
on
how long
an
implied
warranty
lasts,
and
some
states
or
countries
do
not
allow the
exclusion
or
limitation
of
incidental
or
consequential damages,
so
the above limitation
and exclusion
may
not
apply
to
you.
This
warranty
gives
you
specific
legal
rights
and
you
may
also have other
rights which
vary
from
state to state
and
country to country.
Briggs
& Stratton
welcomes
warranty
repair and
apologizes
to
you
for
being
inconvenienced. Any Authorized
Service
Dealer
may
perform
warranty
repairs. Most
warranty
repairs
are
han-
dled routinely, but sometimes
requests
for
warranty
service
may
not
be appropriate.
For example,
warranty
would
not
apply
engine damage
occurred because
of
misuse, lack
of routine
maintenance,
shipping, handling,
warehousing
or
improper
installation.
Similarly,
warranty
is
void the serial number
of the
engine has been removed
or
the
engine has been altered
or
modified.
If
a
customer
differs
with the
decision of the
Service
Dealer,
an
investigation will be made
to
determine whether the
warranty
applies. Ask the
Service Dealer
to
submit all supporting
facts
to
his
Distributor
or
the Factory
for
review.
If
the
Distributor
or
the
Factory
decides that the claim is
justified,
the
customer
will be
fully
reimbursed
for
those items
that
are
defective. To
avoid mis-
understanding which might
occur
between
the
customer
and
the
Dealer, listed below
are some
of the
causes
of
engine
failure
that the
warranty
does
not
cover.
Normal
wear:
Engines, like all mechanical devices, need
periodic
parts
service
and replacement
to
perform well. Warranty will
not
cover
repair
when normal
use
has exhausted
the life
of
a
part
or an
engine.
Improper
maintenance:
The
life of
an
engine depends
upon
the
conditions under which
operates,
and the
care
receives.
Some
applications, such
as
tillers,
pumps
and
rotary
mowers, are very
often
used in dusty
or
dirty conditions, which
can cause
what
appears
to
be
premature
wear.
Such
wear,
when caused by dirt, dust,
spark plug cleaning
grit,
or
other abrasive
material that has entered the
engine be-
cause
of
improper
maintenance, is
not
covered by
warranty.
This
warranty
covers
engine related
defective material
and/
or
workmanship on__qJy,
and
not
replacement
or
refund of the
equipment
to
which the engine
may
be
mounted. Nor does
the
warranty
extend
to
repairs
required
because
of:
1.
PROBLEMS CAUSED BY
PARTS
THAT ARE
NOT
ORIGINAL
BRIGGS & STRATTON
PARTS.
2.
Equipment controls
or
installations that
prevent
starting,
cause
unsatisfactory engine performance,
or
shorten
en-
gine life.
(Contact
equipment
manufacturer.)
3.
Leaking carburetors, clogged
fuel pipes, sticking valves,
or
other damage,
caused by using
contaminated
or
stale
fuel. (Use clean, fresh,
lead-free gasoline and Briggs
&
Stratton Fuel
Stabilizer,
Part No.
5041
4.
Parts which
are
scored
or
broken because
an
engine
was
operated with
insufficient
or
contaminated lubricating
oil,
or an
incorrect grade
of
lubricating
oil (check oil level daily
or
after
every
8
hours
of operation. Refill when
necessary
and change
at
recommended
intervals.)
01L GARD(R)
may
not
shut
down
running engine. Engine damage
may
occur
oil level is
not
properly
maintained. Read
Operat-
ing
&
Maintenance Instructions.
5.
Repair
or
adjustment of
associated
parts
or
assemblies
such
as
clutches, transmissions,
remote
controls,
etc.,
which
are
not
manufactured
by
Briggs
& Stratton.
6.
Damage
or
wear
to parts
caused by dirt, which entered
the engine
because of improper air cleaner
maintenance,
re-assembly,
or use
of
a
non-original air cleaner element
or
cartridge.
(At recommended
intervals, clean and re-oil
the
Oil-Foam
element
or
the
foam pre-cleaner, and
replace the
cartridge.) Read
Operating
&
Maintenance
Instructions.
7.
Parts
damaged by over-speeding,
or
overheating caused
by
grass,
debris,
or
dirt, which plugs
or
clogs the cooling
fins,
or
flywheel
area, or
damage caused by
operating the
engine
in
a
confined
area
without
sufficient ventilation.
(Clean
fins
on
the
cylinder, cylinder head and
flywheel
at
recommended intervals.) Read
Operating
&
Maintenance
Instructions.
8.
Engine
or
equipment
parts
broken by
excessive vibration
caused by
a
loose
engine mounting, loose
cutter
blades,
unbalanced blades
or
loose
or
unbalanced impellers, im-
proper
attachment
of equipment
to
engine
crankshaft,
over-speeding
or
other
abuse in operation.
9.
A bent
or
broken
crankshaft, caused by striking
a
solid ob-
ject with the
cutter
blade
of
a
rotary
lawn
mower, or
exces-
sive v-belt tightness.
10.
Routine
tune-up
or
adjustment
of the engine.
11.
Engine
or
engine
component
failure, i.e.,
combustion
chamber, valves, valve
seats,
valve guides,
or
burned
starter motor
windings, caused by the
use
of
alternate
fuels such
as,
liquified petroleum,
natural
gas,
altered
gasolines,
etc.
Warranty is
available only through
service dealers
which
have been
authorized by Briggs &
Stratton
Corporation.
your
nearest
Authorized
Service
Dealer is
listed in the
"Yel-
low
Pages of
your
telephone directory under
"Engines,
Gasoline"
or
"Gasoline
Engines,"
"Lawn
Mowers,"
or
simi-
lar
category.
Briggs &
Stratton
Engines Are Made Under
One Or
More
Of The Following Patents: Design
D-247,177
(Other
Patents Pending)
6,691,683
6,520,141 6,325,036
6,145,487 6,012,420
5,803,035 5,548,955
5,243,878
5,138,996
4,875,448
D 476,629
6,647,942
6,495,267 6,311,663
6,142,257 5,992,367 5,765,713
5,546,901
5,235,943
5,086,890 4,819,593
D 457,891
6,622,683
6,494,175 6,284,123
6,135,426 5,904,124 5,732,555
5,445,014 5,234,038
5,070,829
4,720,638
D 368,187
6,615,787
6,472,790 6,263,852
6,116,212 5,894,715
5,645,025
5,503,125 5,228,487
5,058,544
4,719,682
D 375,963
6,617,725
6,460,502 6,260,529
6,105,548 5,887,678
5,642,701
5,501,203 5,197,426
5,040,644
4,633,556
D 309,457
6,603,227 6,456,515 6,242,828 6,347,614
5,852,951 5,628352
5,497,679
5,197,425 5,009,208 4,630,498
D
372,871
6,595,897
6,382,166 6,239,709
6,082,323 5,843,345
5,619,845 5,320,795
5,197,422
4,996,956
4,522,080
D
361,771
6,595,176 6,369,532
6,237,555 6,077,063 5,823,153 5,606,948 5,301,643
5,191,864 4,977,879
4,520,288
D 356,951
6,584,964
6,356,003 6,230,678
6,064,027 5,819,513
5,606,851
5,271,363 5,188,069
4,977,877
4,512,499
D 309,457
6,557,833 6,349,688
6,213,083 6,040,767
5,813,384
5,605,130 5,269,713 5,186,142
4,971,219 4,453,507
D 308,872
6,542,074 6,347,614
6,202,616 6,014,808
5,809,958 5,497,679
5,265,700
5,150,674
4,895,119 4,430,984
D
308,871

(This
page
applicable in
the
U.S.A. and
Canada
only.)
Briggs
&
Stratton
Corporation
(B&S), the
California
Air
Resources
Board
(CARB)
and the
United
States
Environmental
Protection
Agency
(U.S. EPA)
Emission
Control
System
Warranty
Statement
(Owner's
Defect
Warranty
Rights
and
Obligations)
The
California
Air
Resources
Board
(CARB),
U.S.
EPA
and
B&S
are
pleased
to
explain
the
Emission
Control
System Warranty
on
your
small
off-road
engine
(SORE). In
California,
new
small
off-road
engines
model
year
2006
and later
must
be
designed,
built
and
equipped
to
meet
the
State's
stringent
anti-smog
standards.
Elsewhere
in
the
United
States,
new
non-road,
spark-ignition
engines
certified
for
model
year
1997
and later
must
meet
similar
standards
set
forth
by
the
U.S. EPA.
B&S
must
warrant
the
emission
con-
neglect
or
improper
maintenance
of
your
small
off-road
engine.
Your
emission
control
system
includes
parts
such
as
the
carburetor,
air
cleaner,
ignition
system,
fuel line,
muffler
and
catalytic
converter.
Also
included
may
be connectors
and other
emission
re-
lated
assemblies.
Where
a
warrantable
condition
exists,
B&S will
repair
your
small
off-road
engine
at
no
cost to
you
trol
system
on
your
engine
for
the
periods
of time
listed
below,
provided there
has
been
no
abuse,
including
diagnosis,
parts
and
labor.
Briggs
&
Stratton
Emission
Control Defects
Warranty
Coverage
Small
off-road
engines
are
warranted
relative
to
emission
control
parts
defects
for
a
period
of
two
years,
subject
to
provisions
set
forth
below.
If
any
covered
part
on
your
engine
is
defective,
the
part
will be
repaired
or
replaced
by
B&S.
Owner's
Warranty
Responsibilities
As the
small
off-road
engine
owner,
you
are
responsible
for the
performance
of the
required
main-
tenance
listed
in
your
Operating
and
Maintenance
Instructions.
B&S
recommends that
you
retain
all
your
receipts
covering
maintenance
on
your
small
off-road
engine,
but
B&S
cannot
deny
war-
ranty
solely
for
the
lack
of
receipts
or
for
your
failure
to
ensure
the
performance
of all
scheduled
maintenance.
As
the
small
off-road
engine
owner,
you
should
however
be
aware
that
B&S
may
deny
you
war-
ranty
coverage
your
small
off-road
engine
or
a
part
has
failed
due
to
abuse,
neglect,
improper
maintenance
or
unapproved
modifications.
Briggs
&
Stratton
Emission
Control
The
following
are
specific
provisions
relative
to
your
Emission
Control
Defects
Warranty
Coverage.
It is
in
nance
Instructions.
1.
Warranted Parts
Coverage
under
this warranty
extends
only
to
the
parts
listed
below
(the
emission
control
sys-
tems
parts)
to
the
extent
these
parts
were
present
on
the
engine
purchased.
a.
Fuel
Metering
System
Cold
start
enrichment system
Carburetor
and
internal
parts
Fuel Pump
Fuel line,
fuel line
fittings,
clamps
b.
Air
Induction
System
Air
cleaner
Intake
manifold
c.
Ignition
System
Spark
plug(s)
Magneto
ignition
system
d.
Catalyst
System
Catalytic
converter
Exhaust
manifold
Air
injection
system,
Pulse
valve
e.
Miscellaneous
Items
Vacuum, temperature,
position,
time
sensitive
valves
and
switches
Connectors
and
assemblies
You
are
responsible
for
presenting
your
small
off-road
engine
to
an
Authorized
B&S Service
Deal-
er
as
soon
as
a
problem
exists.
The
undisputed
warranty
repairs
should be
completed in
a
reasonable
amount
of time,
not
to
ex-
ceed
30
days.
If
you
have
any
questions
regarding
your
warranty
rights
and
responsibilities,
you
should
contact
a
B&S Service
Representative
at
1-414-259-5262.
The
emission warranty
is
a
defects
warranty.
Defects
are
judged
on
normal engine
performance.
The
warranty
is
not
related
to
an
in-use
emission
test.
Defects
Warranty
Provisions
addition
to
the
B&S engine
warranty
for
non-regulated
engines
found in
the
Operating
and
Mainte-
2.
Length
of
Coverage
B&S
warrants
to
the
initial
owner
and
each
subsequent
purchaser
that
the
Warranted Parts
shall be
free from
defects
in
materials
and
workmanship
which
caused
the
failure
of the
War-
ranted Parts
for
a
period
of
two
years
from
the
date the
engine
is
delivered
to
a
retail
purchaser.
3.
No
Charge
Repair
or
replacement
of
any
Warranted
Part
will
be
performed
at
no
charge
to
the
owner,
including
diagnostic
labor
which
leads
to
the
determination
that
a
Warranted
Part is
defective,
if the
diagnostic
work is
performed
at
an
Authorized
B&S Service
Dealer.
For
emissions
war-
ranty
service contact
your
nearest
Authorized
B&S Service
Dealer
as
listed in the
"Yellow
Pages"
under
"Engines,
Gasoline,"
"Gasoline
Engines,"
"Lawn
Mowers,"
or
similar
category.
4.
Claims
and
Coverage
Exclusions
Warranty
claims
shall be
filed in
accordance
with the
provisions
of
the
B&S Engine
Warranty
Policy.
Warranty
coverage
shall
be
excluded
for
failures
of
Warranted
Parts
which
are
not
ori-
ginal
B&S
parts
or
because
of abuse,
neglect
or
improper
maintenance
as
set
forth in
the
B&S
Engine
Warranty
Policy.
B&S
is
not
liable
to
cover
failures
of
Warranted Parts
caused by
the
use
of
add-on,
non-original,
or
modified
parts.
5.
Maintenance
Any
Warranted Part
which is
not
scheduled for
replacement
as
required maintenance
or
which
is
scheduled
only
for
regular
inspection
to
the
effect
of
"repair
or
replace
as
necessary"
shall be
warranted
as
to
defects
for the
warranty
period.
Any
Warranted Part
which is
scheduled
for
replacement
as
required
maintenance
shall be
warranted
as
to
defects
only
for the
period
of
time
up
to
the
first
scheduled
replacement
for that
part.
Any
replacement part
that
is
equivalent
in
performance
and
durability
may
be
used in
the
performance
of
any
maintenance
or
repairs.
The
owner
is
responsible
for the
performance
of all
required
maintenance,
as
defined in
the
B&S Operating
and
Maintenance
Instructions.
6.
Consequential
Coverage
Coverage
hereunder
shall
extend
to
the
failure
of
any
engine components
caused by
the
failu-
re
of
any
Warranted Part
still
under
warranty.
Look
For
Relevant
Emission
Durability
Period
and
Air
Index
Information
On
Your
Engine
Emission
Label
Engines
that
are
certified
to
meet
the
California
Air
Resources
Board
(CARB)
Tier
2
Emission
Standards
must
display
information
regarding
the
Emissions
Durability
Period
and the
Air
Index.
Briggs
&
Stratton
makes
this
information
available
to
the
consumer
on
our
emission
labels.
The
Emission
Durability
Period
describes
the
number
of hours
of
actual
running
time
for
which the
engine
is
certified
to
be
emission
compliant,
assuming
proper
maintenance
in
accordance
with the
Operating
& Maintenance
Instructions.
The
following
categories
are
used:
Moderate:
Engine
is
certified
to
be
emission
compliant
for
125
hours
of
actual
engine
running
time.
Intermediate:
Engine
is
certified
to
be
emission
compliant
for
250
hours
of
actual
engine
running
time.
Extended:
Engine
is
certified
to
be
emission
compliant
for
500
hours
of
actual
engine
running
time.
For
example,
a
typical
walk-behind
lawn
mower
is
used
20
to
25
hours
per
year.
Therefore,
the
Emission
Durability
Period
of
an
engine
with
an
intermediate
rating
would
equate
to
10
to
12
years.
The
Air
Index
is
a
calculated
number
describing
the
relative
level
of
emission
for
a
specific
engine
family. The
lower
the
Air
Index,
the
cleaner
the
engine.
This
information
is
displayed in
graphical form
on
the
emission
label.
This
is
a
generic
representation
IMPORTANT
ENGINE
INFORMATION
BRIGGS &
STRATTON
CORPORATION
of the
emission
label
typically
found
on
a
certified
engine.
FAMILYYBSXS.1451HH 274459
FOAO
ENGINES EPA P
EGS
FOR SBAL[..
GES
REF[ER
TO
OW[ER%
#,UAL
FOR
tIATEt,ACE

IMPORTANT
SAFETY
INFORMATION
AND
INSTRUCTIONS
FOR
ENGINE
SELECTION
ENGINE
INSTALLATION
ENGINE OPERATION
Keep these instructions for future
reference.
II;
Before installing
and
operating
this engine
read and
observe all
warnings,
cautions
and
instruct,ons
on
both
sides
of this
sheet,
on
the
engine,
and
in
the
operating &
maintenance instructions.
NOTE"
This sheet
of
instructions
and
safety information
is
not
meant to
cover
all
possible conditions
and situations
that
may occur.
Read
entire
Operating
&
Maintenance
lnatructions
for
this
engine AND the
instructions for
the equipment
this engine
powers.
Failure
to
follow
instructions
and safety information
could
result in
serious injur
or
death.
The safety
alert symbol
(::)is
used
to
identify safety
information
about
hazards that
can
result in
personal injury.
A signal
word
(DANGER,
WARNING,
or
CAUTION)
is
used
with
the
alert
symbol
to
indicate the likelihood
and the potential
severity
of
injury. In addition,
a
hazard
symbol
may
be used
to represent
the
type
of
hazard.
DANGER
indicates
a
hazard
which,
if
not
avoided,
will
result in death
or
serious injury.
WARNING
indicates
a
hazard which, if
not
avoided,
could result in death
or
serious
injury.
CAUTION
indicates
a
hazard
which,
if
not
avoided,
might
result
in minor
or
moderate injury.
CAUTION,
when used without the
alert symbol,
indicates
a
situation that could
result
in
damage
to
the engine.
(OVER)
FORM MS-6445-01/03

ENGINE
SELECTION
WARNING
Failure
to
select
the correct
engine could
result
in fire
or
explosion.
Some
engines
are
unique
and
designed
for
specific applications
or
types
of equipment.
If
this
engine
will be
used
to
build
new
equipment,
contact
Briggs
&
Stratton
to
ensure
that
the
engine is
appropriate
for the
intended
use.
Note: For
all
Go-karts
use
only
a
model 136200
series
engine,
which
offers
improved
safety and
performance.
Replacement
engines
should be
the
same
model
as
the original
engine,
or
be the
Briggs
&
Stratton
designated replacement
engine.
Refer
to
the
Operation &
Maintenance
Instructions
for
engine
identification
information.
Note:
For
all
Go-karts
use
only
a
model
136200
series
engine,
which
offers
improved
safety and
performance.
Do
not
use
Briggs &
Stratton engines
on
3-wheel
All-Terrain
Vehicles
(ATVs),
motor
bikes,
air
craft products,
or
vehicles
intended
for
use
in
competitive
events.
Briggs &
Stratton
does
not
approve
of
or
authorize
such
uses.
[1]
When
adding
fuel:
[2]
[3]
[4]
When
starting
engine:
[5]
[6]
When
operating
equipment:
[7]
ENGINE
INSTALLATION
Do
not
attempt
to
install
this
engine
if
you
do
not
have
the
appropriate
tools
and
knowledge
of small engine
installation
procedures.
Use
only Briggs
&
Stratton
parts.
Contact
your
Authorized
Service Dealer
for
assistance.
Do
not
modify the
engine in
any way
without
Briggs &
Stratton
factory
approval. Any
such
modification is
at
the
owner's sole
risk.
If the exhaust
system
on
the
old engine
was
supplied by
the
equipment
manufacturer,
you
must
transfer the exhaust
system
and
related
components
(original
muffler
and
related
pipes,
brackets,
clamps,
and
shields)
to
the
new
engine. All
components
must
be in
good
condition.
Install
muffler (and
muffler
de-
, WARNING
flector
if
used)
so
outlet
points
away
from
operator,
fuel
tank,
and
equipment,
and
so
muffler
heat
will
not
damage
or
deform
engine
and
components.
l
Ensure
all
fuel lines
and
fittings
WARNING
are
properly
assembled
and do
not
leak.
Replacement
parts
must
be
the
same
model
as
the
original.
WARNING
Ensure
all
wiring,
including
safety switches
and
engine
shut-off
components
are
com-
pletely
installed
and
functioning
properly.
Set engine
speed
to
equipment
manufacturer's
specification.
Refer
to
equipment
manufacturer's
manual. Do
not tamper
with
governor
springs,
or
other
parts
that
will
increase
engine
speed
above
specification.
[8]
[9]
[10]
[11]
WARNING
WARNING
WARNING
WARNING
All
engine
parts,
including
fuel
cap,
spark plug,
muffler, air
cleaner,
and
covers
and guards
for drive
components
(gears,
belts,
shafts, couplings,
etc.)
must
be
in place
before
attempt-
ing
to start
engine.
If engine
is installed
on
walk
behind lawn
mower,
all
mower
components,
including cutting
blade,
must
be
correctly
installed
before
attempting
to
start
engine.
When
working
on
the
engine
or
equipment,
remove
spark plug
wire
from spark
plug. For
electric
start,
remove
negative
wire
from
battery.
Do
not
check
for spark
with
spark
plug
removed. Use
Briggs
&
Stratton spark
tester
#19368.
ENGINE
OPERATION
WARNING
Turn
engine
off and let
engine
cool
at
least 2
minutes
before
removing
gas
cap.
Fill
fuel
tank
outdoors
or
in
well-ventilated
area.
Fill tank
to
about
inch
below lowest
portion
of
neck
to
allow
for fuel
expansion.
Keep
gasoline
away
from sparks,
open
flames, pilot
lights, heat,
and other
ignition
sources.
WARNING
Remove all
external
equipment/engine loads.
Wait until
spilled
fuel is
evaporated.
Start
engine
outdoors.
Pull cord
slowly until
resistance
is
felt,
then
pull
rapidly.
If engine
floods,
set
choke
to
OPEN/RUN, place
throttle in
FAST
and
crank until
engine
starts.
WARNING
Do
not
tip
engine
or
equipment
at
angle
which
causes
gasoline
to
spill.
Run
engine outdoors.
Do
not
run
in
enclosed
area,
even
if
doors
or
windows
are open.
Do
not
choke
carburetor
to stop
engine.
FORM
MS-6445-01/03
