Illustrated Parts List
BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC
JEFFERSON, WISCONSIN, U.S.A.
Manual No. 197523A Revision - (12/19/2007)
Questions? Help is just a moment away!
Preguntas? La ayuda es justa un momento lejos!
Call: Generator Helpline
Llame: Línea Directa del Generador
1-800-743-4115 M-F 8-5 CT
web: www.briggsandstratton.com

6200W Portable Generator
2
EXPLODED VIEW - MAIN UNIT
Copyright © 2007 Briggs & Stratton Power Products Group, LLC. All rights reserved. No part of this material may be
reproduced or transmitted in any form by any means without the express written permission of Briggs & Stratton Power
Products Group, LLC.

6200W Portable Generator
3
EXPLODED VIEW - PARTS LIST
Item Part # Description
1 M197464GS KIT, Cradle (Includes Items 20, 31 &
55)
2 194150GS KIT, Vibration Mount, 45°
3 * NUT, M8 Flange Serrated
4 190220GS HOUSING, Engine Adapter
5 * NUT, Hex, M8-1.25
6 NSP (194080) ASSY, Alternator
7 * TPHMS, M8-1.25 x 35
8 96796GS WASHER, 8.4 x 22.2 x 3
10 190274DGS SBHCS, 3/8-16 x 7/8"
11 187365FGS HHCS, 5/16-24 x 7.44
12 * HHCS, M8 - 1.25 x 25
14 189009GS BRACKET, Muffler
15 695398 GASKET, Exhaust
16 * HHCS, M6-1.0 x 12
17 189008GS MUFFLER
18 204885GS SHCS, M8 - 1.25 x 20
19 83083GS SCREEN, Spark Arrest
20 B4986GS DECAL, Ground
21 194153GS KIT, Vibration, Mount
22 86494GS SCREW, Wing M6 - 1.0 x 16
24 194390GS SHIELD, Heat
25 191190GS CAP
26 74908GS TAPTITE, M5-0.8 x 10
27 * HHCS, 1/4 - 20 x 3/4
28 * WASHER, 1/4, Lock
29 * NUT, 1/4 - 20
30 * WASHER, Shakeproof, Ext. #10
31 196830GS DECAL, Hot Muffler
32 * NUT, 5/16 - 24
33 * WASHER, 5/16 - M8 Lock
34 195422GS COVER, RBC, Plastic w/Cap
35 791745 KIT, Fuel Hose (cut to fit)
37 B2153GS SCREW, 12-14 x 7/8 Self Drill
38 56893GS SCREW, 10-24 x 1/2 Crimptite
39 188987GS BRACKET, Switch
40 195477GS KIT, Hardware Tank Fuel (Includes
Qty 4)
41 192980GS KIT, Valve, Tank
43 77282GS SWITCH, Starter
44 194217GS ASSY., Tank, Fuel (Includes Items
41, 50, 51, 52 & 56)
Item Part # Description
I 45 B4363GS CAP, Fuel Gauge
46 B4135GS PIN, with Lanyard
47 77395GS NUT, M6 Flange Lock
48 195373GS WIRE, Ground
49 * WASHER, M6 Shakeproof
50 188333GS DECAL, Instruction, Fuel Level
51 194799GS DECAL, Danger
52 189235GS DECAL, Start Instructions
53 194034GS KIT, Handle Fold-down Hardware
54 194448GS KIT, Insulation with Clip
55 197798GS DECAL, Fuel Shut-off
56 202997GS DECAL, Warning CO
58 191757GS ASSY, Control Panel
59 * NUT, Palnut, 3/16"
60 194389GS SHIELD, Heat
68 195680GS TRAY, Battery
69 193043GS BATTERY, 12V
70 * HHCS, M6 - 1.0 x 12
71 192531GS ASM, Jack, DC
73 58359GS LUG, 5/16 #22/18 I-S
74 193347GS KIT, Battery Hardware
76 185939KGS WIRE ASM, #55
78 189302CGS WIRE ASM, #13
81 189302GGS WIRE ASM, #16
90 198669GS GRIP, Handle
91 B193200GS ASSY, Handle/Grip
900 § ENGINE
Parts Not Illustrated
MS3430 MANUAL, Engine, B&S
197523GS MANUAL, Operator’s
BB3061GS BOTTLE, Oil
43438GS PLUG, 250V, 30A
202180GS DECAL, Family, CA EVP
B4177GS CHARGER, Battery
197787GS KIT, Decals Service
* - Items without part numbers are common fasteners and
are available at your local hardware store.
§ - Contact Engine Manufacturer

6200W Portable Generator
4
EXPLODED VIEW AND PARTS LIST - CONTROL PANEL
Item Part # Description
1 195112GS KIT, Control Panel Lid
2 191450GS CONTROL PANEL, Compact
6 68759GS OUTLET, 120V, 20Amp, Duplex
7 * NUT, Palnut, 5/32
8 84198GS CAP, Circuit Breaker
9 75207AGS CIRCUIT BREAKER, 30A
10 43437GS OUTLET, 120/240 Locking, 30A
11 * NUT, Palnut, 3/16
12 * PPPHS, M3- 0.5 x 18
13 93857GS BAR, Retaining
14 188890GS COVER, Back, Control Panel
15 82308GS SCREW, Tapping, STC 3 x 18
16 22694GS HOUSING, Receptacle
17 192241GS SCREW, Tapping, 3.5 x 14
18 75207PGS CIRCUIT BREAKER, 25A
* - Items without part numbers are common fasteners and
are available at your local hardware store.

6200W Portable Generator
5
EXPLODED VIEW AND PARTS LIST - ALTERNATOR
Item Part # Description
1 186059GS ADAPTER, Mounting, Alternator
2 191876GS ROTOR
3 194006AGS STATOR
4 186060GS RBC, (with O-Ring, p/n 189197GS)
5 86308HGS HHCS, M6 - 1.0 x 140 SEMS
6 66386GS ASSEMBLY, Holder, Brush
7 66849GS TAPTITE, M5 - 0.8 x 16
8 22694GS RECEPTACLE, 6 pin
9 81917GS PIN, Roll, 4mm x 10
10 193428AGS WIRE-A, Ground
11 189769GS REGULATOR, Voltage, AVR
12 194274GS HARNESS, Wire, Power
13 65791GS BEARING

6200W Portable Generator
6
EXPLODED VIEW AND PARTS LIST - WHEEL KIT
Item Part # Description
1 196517GS WHEEL, 10"
2 191265GS E-RING, 5/8
3 191267GGS AXLE, 5/8" x 23.62"
4 * WASHER, 5/8
5 * HHCS, M8 - 1.25 x 20
6 B187101GS LEG, Support
7 87841GS VIBE MOUNT
8 * HHCS, 1/4 - 20 x 1
9 52858GS NUT, M8 - 1.25 Lock
10 192432GS NUT, 1/4 - 20 Serrated Lock
Parts Not Illustrated
187046GS SUBKIT, Hardware
* - Items without part numbers are common fasteners
and are available at your local hardware store.
