Broadrack Venus 8 / 16 User instructions

Venus 8 / 16
Combo-free KVM Switch
Quick Setting Guide
Rev 2.0

Venus 8/16 Quick Setting Guide
1
1. Application Diagram
2. Package Contents
1 x KVM Switch Unit
1 x CD-ROM (User’s Manual)
1 x Quick Setting Guide
1 x 12V DC Power Adapter
1 x Rack Mount Kit
1 x KC-1515 Daisy Chain Cable (0.9 M)
2 x KC-1501C Signal Cable (with USB Adapter) (1.8 M)
3. Local Console Installation
Connect the keyboard, mouse and monitor to the local console port. Turn on the
monitor then power on the KVM Switch by plug in the power adapter.
4. PC / Servers Installation
a. PS/2 computer –Use the signal cable with two PS/2 connectors.
b. USB computer –Use the signal cable with PS/2 connector and USB adapter.

Venus 8/16 Quick Setting Guide
2
5. Hotkey
Enter Hotkey two times [within 2 Seconds]
Command
Function
Space bar
Active OSD
↑
Previous Channel
↓
Next Channel
[1,2,…,8] bank,
[01,02,…,16] port
First digit bank number start with 1
Second and third digits port number start with “01”
PgUp
Previous bank
PgDn
Next bank
“B”
Turn on / off beeper
“S”
Auto Scan
“U”
Console Security “ON” to “OFF”
“P”
User logout / login
”R”
OSD setting back to factory default value
“L”
Turn on / off power saving
6. On Screen Display (OSD)
OSD Function Key
Esc :
Exit
Enter
Select
→/ ↑/ ←/ ↓
Move
Ins
Edit
F1
Help
F2
Last OSD screen
PgUp
Previous Bank
PgDn
Next Bank
7. Power On
Turn on local console monitor and power on by plug in the power adapter, there
will be login window at screen.
The default user name is all eight zero digits “00000000”…
The password is all eight zero digits “00000000”…
Scroll
Lock
Scroll
Lock
Space Bar
