READ AND SAVE THESE INSTRUCTIONS
WARNING
TOREDUCE THERISK OFFIRE, ELECTRICALSHOCK, ORINJURY TOPERSONS,
OBSERVETHEFOLLOWING:
1. Use thisunit onlyin themanner intendedby themanufacturer.If youhave questions,
contactthemanufacturer at theaddressor telephonenumberlisted in thewarranty.
2. Before servicing or cleaning unit, switch power off at service panel and lock service
paneltoprevent power frombeing switched onaccidentally.When the servicediscon-
nectingmeanscannotbe locked, securelyfastenaprominent warning device,suchas
atag,to theservice panel.
3. Installation workand electrical wiring must be done bya qualifiedperson(s) in accor-
dancewithall applicable codesand standards, includingfire-rated construction codes
andstandards.
4. Sufficientairisneededforpropercombustion and exhaustingofgasesthroughthe flue
(chimney)offuelburning equipment topreventbackdrafting.Follow the heatingequip-
mentmanufacturer’s guidelinesand safety standards such asthose publishedby the
National Fire ProtectionAssociation (NFPA), and theAmerican Society for Heating,
RefrigerationandAirConditioning Engineers (ASHRAE), and the local code authorities.
5. When cutting or drilling into wall or ceiling, donot damage electricalwiring and other
hiddenutilities.
6. Ducted fansmust always bevented tothe outdoors.
7. Do notuse this unitwith anysolid-statespeed controldevice.
8. Toreducethe riskof fire,use onlymetal ductwork.
9. This unitmustbe grounded.
TOREDUCETHERISKOFARANGETOPGREASEFIRE:
A. Neverleave surface units unattended at high settings.Boilovers cause smoking and
greasyspilloversthat may ignite.Heat oils slowlyon low ormediumsettings.
B. Alwaysturnhood ON whencooking at highheator whencookingflaming foods.
C. Cleanventilatingfansfrequently.Greaseshouldnotbeallowed to accumulate onfanor
filter.
D. Use proper pan size. Always use cookware appropriate for the size of the surface
element.
WARNING
TOREDUCETHERISKOF INJURYTOPERSONSINTHE EVENT OFARANGETOP
GREASEFIRE,OBSERVETHEFOLLOWING:*
1. SMOTHERFLAMESwithaclose-fittinglid,cookie sheet, ormetaltray,thenturnoffthe
burner.BECAREFULTOPREVENTBURNS.Ifthe flamesdonot go outimmediately,
EVACUATEANDCALLTHEFIREDEPARTMENT.
2. NEVERPICKUPAFLAMINGPAN-Youmaybe burned.
3. DO NOTUSEWATER, includingwetdishclothsor towels -violentsteamexplosion will
result.
4. Use anextinguisherONLYif:
A. YouknowyouhaveaClassABCextinguisherandyoualreadyknowhowtooperate
it.
B. Thefireis small andcontained in theareawhere itstarted.
C. Thefiredepartmentisbeingcalled.
D. Youcanfight the firewith yourback to anexit.
*Basedon “Kitchen FireSafetyTips”publishedbyNFPA.
!
INTENDED FOR DOMESTIC COOKING ONLY.
!

- 3 -
!
CAUTION
1. To reduce risk of fire and to properly exhaust air, be sure to duct air outside. Do
not vent exhaust air into spaces within walls or ceilings or into attics, crawl
spaces, or garages.
2. Take care when using cleaning agents or detergents.
3. Avoid using food products that produce flames under the Range Hood.
4. For general ventilating use only. Do not use to exhaust hazardous or explosive
materials and vapors.
5. To avoid motor bearing damage and noisy and/or unbalanced impellers, keep
drywall spray, construction dust, etc. off power unit.
6. Your hood motor has a thermal overload which will automatically shut off the
motor if it becomes overheated. The motor will restart when it cools down. If the
motor continues to shut off and restart, have the hood serviced.
7. For best capture of cooking impurities, the bottom of the hood should be a
minimum of 24" and a maximum of 30" above the cooking surface. See “Install
Mounting Bracket” section for mounting instructions.
8. Two installers are recommended because of the large size and weight of this
hood.
9. This product is equipped with a thermostat which may start blower automati-
cally. To reduce the risk of injury and to prevent power from being switched on
accidentally, switch power off at service panel and lock or tag service panel.
10. Use with approved cord-connection kit only.
11. Please read specification label on product for further information and require-
ments.

- 4 -
LIGHT LENS TAB
HALOGEN BULBS
This range hood requires two or four halogen
bulbs (Type JC, 12V, 20W, G4 Base).
To change bulbs:
1. Open the light lens by grasping the tab on
the lens and rotating lens downward.
2. Remove the bulb by pulling sideward (Do
notrotate). CAUTION: BULBMAYBE HOT!
3. Do not touch replacement bulb with bare
hands!Push bulb securely into lamp socket
and snap lens closed.
OPERATION
Controls
The hood is operated using the (4) push-but-
tons located at eye-level, on the front edge of
the hood.
The light switch turns the halogen lights on
and off.
The bloweron-low/ off switchturnstheblower
on to its lowest running speed. The blower
must be turned on using this switch. Turn the
blower off by pressing this switch a second time.
The blower medium speed switch changes the blower speed to medium. This
switch works only if the blower is already running at low or high speed.
The blower high speed switch changes the blower speed to high. This switch
works only if the blower is already running at low or medium speed.
The pilot lamp lights up whenever the blower is on.
Heat Sentry
TM
Your hood is equipped with a HEAT SENTRY™ thermostat. This thermostat is a
device that will turn on or speed up the blower if it senses excessive heat above
the cooking surface.
1) If blower is OFF - it turns blower ON to HIGH speed.
2) If blower is ON at a lower speed setting - it turns blower up to HIGH speed.
When the temperature level drops to normal, the blower will return to its original
setting.
WARNING
The HEAT SENTRY thermostat can start the blower even if the hood is
turned OFF. When this occurs, it is impossible to turn the blower OFF with its
switch. If you must stop the blower, do it from the main electrical panel.
0
BLOWER
ON-LOW /
OFF
SWITCH
BLOWER
MEDIUM
SPEED
LIGHT
SWITCH
PILOT
LAMP
BLOWER
HIGH
SPEED

- 5 -
FUSE REPLACEMENT
IFTHE LIGHTS FAILTO OPERATE,DISCON-
NECT THE POWER AT THE SERVICE EN-
TRANCE. CHECK THE FUSE AND RE-
PLACE IF NECESSARY.
1. Remove the filters.
2. Remove the electrical box support.
3. Remove screws from the fuse box and
open the cover.
4. Locate the fuse holder. Unscrew its cap
and remove the fuse.
5. Replace the fuse with the same size and
amperage (5 x 20mm, 4A, 125V).
6. Reinstall the fuse box cover, electrical box
support, and filters.
7. Reconnect power at the service entrance.
MAINTENANCE
Grease Filters
The grease filters should be cleaned frequently. Use a warm detergent
solution to clean filters. Filters are dishwasher safe. See “INSTALL FILTER”
section for installation and removal instructions.
Ductfree Filters
The ductfree filter should be changed every 6 months. See “INSTALL FILTER”
section for installation and removal instructions.
Hood Cleaning
Stainless steel is one of the easiest materials to keep clean. Occasional care will
help preserve its fine appearance.
Cleaning tips:
• Hot water with soap or detergent is all that is usually needed.
• Follow all cleaning by rinsing with clear water. Wipe dry with a clean, soft cloth
to avoid water marks.
• For discolorations or deposits that persist, use a non-scratching household
cleanser or stainless steel polishing powder with a little water and a soft cloth.
• For stubborn cases, use a plastic scouring pad or soft bristle brush together
with cleanser and water. Rub lightly in direction of polishing lines or "grain" of
the stainless finish.Avoid using too much pressure which may mar the surface.
•DO NOT allow deposits to remain for long periods of time.
•DO NOT use ordinary steel wool or steel brushes. Small bits of steel may
adhere to the surface causing rust.
•DO NOT allow salt solutions, disinfectants, bleaches, or cleaning compounds
to remain in contact with stainless steel for extended periods. Many of these
compounds contain chemicals which may be harmful. Rinse with water after
exposure and wipe dry with a clean cloth.
Painted surfaces should be cleaned with warm water and mild detergent only.
ELECTRICAL
BOX
SUPPORT
FUSE
FUSEBOX

- 6 -
PREPARE THE HOOD
Unpack hood and check contents.
You should receive:
1 - Hood
1 - Decorative Flue Assembly
1 - Parts Bag (B08081189) containing:
1 - Flue Mounting Bracket
2 - Mounting Brackets
8 - Mounting Screws (4.8 x 38mm Pan Head)
4 - Mounting Screws (3.9 x 9.5mm Pan Head)
4 - Mounting Screws (3.2 x 13mm Pan Head)
4 - Mounting Screws (3.2 x 13mm Pan Head - Black)
8 - Drywall Anchors
1 - Installation Instructions
1 - Warranty Card
MOUNTING
BRACKETS
FLUE MOUNTING
BRACKET
8 MOUNTING SCREWS
(4.8 x 38mm Pan Head) 8 DRYWALL
ANCHORS
DECORATIVE
FLUE 4 MOUNTING
SCREWS
(3.9x9.5mm Pan
Head)
4 MOUNTING
SCREWS (3.2x13mm
Pan Head - Black)
4 MOUNTING
SCREWS (3.2x13mm
Pan Head)

- 7 -
FRAMING BEHIND CROSS SUPPORT
INSTALL BACKSPLASH
OPTIONAL
If optional Model BSK6 series backsplash is
used,attachitto thefinishedwall. Securehood
mounting brackets to the backsplash and omit
wall framing described below.
INSTALL THE DUCTWORK
DUCTED CONFIGURATION ONLY
NOTE: To reduce the risk of fire, use only
metal ductwork.
1. Decide where the ductwork will run be-
tween the hood and the outside.
2. Astraight,short duct runwillallow the hood
to perform most efficiently.
3. Long duct runs, elbows, and transitions will
reduce the performance of the hood. Use
as few of them as possible.
4. Install a roof or wall cap. Connect 6" round
metal ductwork to cap and work back to-
wards hood location. Use duct tape to seal
the joints between ductwork sections.
INSTALL MOUNTING
BRACKETS
1. Construct wood wall framing that is flush
with interior surface of wall studs.
Make sure:
a) the framing is centered over installa-
tion location.
b) the height of the framing will allow the
mounting brackets to be secured to the
framing within the dimensions shown.
2. Afterwallsurface isfinished,secure mount-
ing brackets to framing using dimensions
shown.
CEILING
HEIGHT
8 FEET
9 FEET
HOOD DISTANCE ABOVE 36” HIGH COOK TOP (SEE NOTE BELOW)
24” 25” 26” 27” 28” 29” 30”
MOUNTING BRACKET LOCATION ABOVE 36” HIGH COOK TOP
28-1/4” 29-1/4” 30-1/4” 31-1/4” 32-1/4” 33-1/4”
10 FEET
DUCTED OR
NON DUCTED
DUCTED OR
NON DUCTED
DUCTED WITH
FEXTK23
DUCT METHOD 31”
34-1/4”
34-1/4” 35-1/4”
35-1/4”
WOOD CROSS
SUPPORT
BEHIND DRYWALL
Note: minimum hood distance above cook top must not be less than 24”.Amaximum
of 31” above cook top is highly recommended for best capture of cooking impurities.
Distances over 31” are at the installer and users discretion; and if ceiling height and
flue length permit.
DRYWALL

- 8 -
INSTALL FLUE MOUNTING
BRACKET
1. Carefully center the mounting bracket di-
rectly over the range hood location.
2. Secure the bracket assembly to the ceiling
using (2) 4.8x38mm mounting screws and
drywall anchors. Make sure the bracket is
pushed into the corner, tight against the
wall and centered over the hood.
FLUE
MOUNTING
BRACKET
PREPARE THE HOOD
DUCTED CONFIGURATION ONLY
Note: On stainless steel hoods, carefully
remove the plastic protective film from all
exterior surfaces of the hood and decora-
tive flues, prior to final installation.
1. Attach an adequate length of 6” round
metal duct to the range hood duct connec-
tor.
2. Duct tape all joints to make them secure
and air tight.
3. Carefully place the lower decorative flue
into the recessed area of the range hood
top.
4. Carefully slide the upper decorative flue
down inside the lower flue.
Note: On 8' ceilings the air vents on the upper
flue are concealed by installing the flue with
air vents down.
On 9' ceilings, air vents on the upper flue will
be exposed after installation.
6” DIAMETER
METAL DUCT
DUCT
CONNECTOR
UPPER
FLUE
LOWER
FLUE
UPPER
FLUE
VENTS
EXPOSED
LOWER
FLUE
VENTS
CONCEALED

- 9 -
PLENUM
(3) SCREWS
6” ROUND
METAL
FLEXIBLE
DUCT
DUCT
CONNECTOR
PREPARE THE HOOD
NON-DUCTED CONFIGURATION ONLY
Note: On stainless steel hoods, carefully remove the plastic protective film
from all exterior surfaces of the hood and decorative flues, prior to final instal-
lation.
Note: The following material must be purchased separately for non-ducted
recirculation installations.
• Non-Ducted Recirculation Plenum Part Number SB08089123
• 6" diameter expandable / flexible aluminum duct
• 1/16" diameter twist drill
• Recirculating filter model FILTERK3490CM (for 90 cm wide hoods) or
FILTERK3448 (for 48" wide hoods).
Caution: Use flexible metal duct. Do not use plastic or rigid metal ducting.
1. Determine length of the compressed flexible metal duct using the following
formula:
39” MINUS PLUS =
Worksheet: 39” - __________ + __________ (for 9' ceiling only) = __________
2. Remove and discard the damper
flaps from inside the hood's duct
connector.
3. Attach 6" round metal flexible duct
to the hoods 6" duct connector.
Tape all joints with duct tape.
4. Assemble the recirculation plenum
to the flexible duct.
5. Drill three 1/16" diameter equally
spaced holes though the duct and
duct connector on the recirculation
plenum.
6. Secure the duct to the plenum’s
connector with (3) sheet metal
screws. Tape all joints with
aluminum duct tape.
Distance above
cook top. 12” if ceiling height is 9-feet Compressed length of
flexible
aluminium
ductwork

- 10 -
WIRING
Note: This range hood must be properly
grounded. The unit should be installed by a
qualified electrician in accordance with all
applicable national and local electrical
codes.
1. Remove the wiring box cover. Remove a
knockout from the wiring box.
2. Feed 6" of power cable through the knock-
out opening and secure cable to the wiring
box with an appropriate connector.
3. Make electrical connections. Connect
white to white, black to black and green to
green.
4. Replace wiring box cover and screws.
Make sure that wires are not pinched be-
tween cover and box.
DUCT COLLAR
WIRING BOX
COVER
PREPARE THE HOOD (CONTINUED)
NON-DUCTED CONFIGURATION ONLY
7. Carefully place the lower flue into the
recessed area of the range hood.
8. Carefully slide the upper flue down
inside the lower flue.
9. Secure the recirculation plenum to the
upper flue with (4) flat head screws.
UPPER
FLUE
PLENUM

- 11 -
WALL
FRAMING
ADDITIONAL
MOUNTING SCREWS
RECTANGULAR CUTOUTS
MOUNTING
BRACKETS
INSTALL THE HOOD
Note: at least two people will be required to
mount the hood.
1. Raise thehood into its mounting position.
2. Align the rectangular openings on the
back of the hood with the wall-mounting
brackets. Gently lower the hood until it
securely engages the bracket.
3. Level the hood and secure with (2)
mounting screws. Use drywall anchors
provided if wall studs or framing are not
available.
4. Raise the upper flue until its holes align
with holes in the flue mounting bracket
(located on ceiling).
5. Secure the flue with (2) mounting screws.
UPPER
FLUE
FLUE
MOUNTING
BRACKET
MOUNTING
SCREWS

- 12 -
INSTALL FILTERS
DUCTED CONFIGURATION ONLY
1. ToremovetheGREASEfilter,gripthelatch
tab and pull it down. This will disengage
the filter from the hood. Tilt the filter down-
ward and remove.
2. ToinstalltheGREASEfilter,alignrearfilter
tabs with slots in the hood. Pull latch tab
down, push filter into position and release.
Make sure the filter is securely engaged
after assembly.
GREASE
FILTERS
DUCTFREE FILTER
INSTALLATION
NON DUCTED CONFIGURATION ONLY
1. Purchase a ductfree filter kit (model no.
FILTERK3490CM or FILTERK3448) from
your dealer.
2. Removethe grease filters by pushing them
back to compress the retaining springs,
thentiltfilters down and out of front groove.
3. Holding the ductfree filter on its side, insert
one of the support rods, (supplied with fil-
ters)into the upper grooveinback that runs
parallel with the front of the hood, in order
to avoid that the filter might be sucked onto
the motor.
4. Fold the filter and insert it into the front.
GROOVES
SUPPORT
ROD
DUCTFREE
FILTER SUPPORT
ROD

- 13 -
SERVICE PARTS
MODEL K29 - Parts for stainless steel models shown. For service parts for black
or white models, call Broan Customer Service.
KEY NO. PART NO. DESCRIPTION
9 B08087163 Grease Filter
14 B02300233 Motor Capacitor
19 B03295005 Terminal Box
26 B02300891 Halogen Lamp Bulb
37 B02300787 Heat Sentry
39 B03294033 Control Board Box Cover
48 B02310201 Motor
49 B03295071 Blower Wheel
53 B03202007 Rubber Washer
57 B02000756 Damper Flap
62 B08088597 Blower Mounting Cover
68 B02000295 Right Blower Housing
69 B02000296 Left Blower Housing
96 BE3245849 Ballast Support
109 BE3342578 Filter Channel - Front (48” models)
109 BE3333676 Filter Channel - Front (90cm models)
112 BE3345848 Electrical Box Support
113 B08091852 Nameplate
115 BE3335228 Wiring Box
116 BE3334252 Wiring Box Cover
118 BE3342581 Decorative Flue Bottom
119 BE3342582 Decorative Flue Top
120 B03292118 Flue Mounting Bracket
123 B03292283 Duct Connector
144 B03292287 Wire Clamp
147 BR2300135 Terminal Block
154 B03202286 Lead
166 B08086668 Control Board
208 B02300792 Transformer (48” models)
208 B02300783 Transformer (90cm models)
223 B03200351 Switch Button
229 B03201014 Lamp Lens
240 B03292301 Switch Activator
274 B03295035 Fuse Box
474 B02300719 Halogen Lamp Housing
477 B03295006 Terminal Cover
* B06002017 Blower Assembly
(Includes Key Nos. 42, 48, 49, 53, 68, 69)
* B06107659 Control Board Assembly
(Includes Key Nos. 14, 39, 144, 147, 165, 166)
* B06107657 Switch Box Assembly (48” models)
(Includes Key Nos.92,223,228,230,234,240)
998 B08081189 Hardware Package
- B02300782 Fuse
- B02300674 Fuse Holder
* Not shown assembled.

- 14 -
SERVICE PARTS
MODEL K29

- 15 -
WARRANTY
BROAN ONE YEAR LIMITED WARRANTY
Broan warrants to the original consumer purchaser of its products that such
products will be free from defects in materials or workmanship for a period of
one year from the date of original purchase. THERE ARE NO OTHER WAR-
RANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IM-
PLIEDWARRANTIESOR MERCHANTABILITYOR FITNESSFORAPARTICU-
LAR PURPOSE.
During this one-year period, Broan will, at its option, repair or replace, without
charge, any product or part which is found to be defective under normal use and
service.
THIS WARRANTY DOES NOT EXTEND TO FLUORESCENT LAMP START-
ERS, TUBES, HALOGENAND INCANDESCENDT BULBS. This warranty does
not cover (a) normal maintenance and service or (b) any products or parts
which have been subject to misuse, negligence, accident, improper mainte-
nance or repair (other than by Broan), faulty installation or installation contrary
to recommended installation instructions.
The duration of any implied warranty is limited to the one-year period as speci-
fied for the express warranty. Some states do not allow limitation on how long
an implied warranty lasts, so the above limitation may not apply to you.
BROAN’S OBLIGATION TO REPAIR OR REPLACE, AT BROAN’S OPTION,
SHALL BE THE PURCHASER’S SOLE AND EXCLUSIVE REMEDY UNDER
THIS WARRANTY. BROAN SHALLNOT BE LIABLE FOR INCIDENTAL, CON-
SEQUENTIAL OR SPECIAL DAMAGES ARISING OUT OF OR IN CONNEC-
TION WITH PRODUCT USE OR PERFORMANCE. Some states do not allow
the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other
rights, which vary from state to state. This warranty supersedes all prior warran-
ties.
To qualify for warranty service, you must (a) notify Broan at the address stated
below or telephone: [phone], (b) give the model number and part iden-
tification and (c) describe the nature of any defect in the product or part. At the
time of requesting warranty service, you must present evidence of the original
purchase date.
BEST BY BROAN, P.O. Box 140 Hartford, Wisconsin 53027

- 16 -
VEUILLEZLIRECESDIRECTIVESETLESCONSERVER
AVERTISSEMENT
OBSERVEZLESDIRECTIVESCI-DESSOUSDEMANIÈREÀRÉDUIRELESRISQUES
D'INCENDIE, DE CHOC ÉLECTRIQUE OU DE BLESSURES CORPORELLES :
1. N'utilisez cet appareil que de la manière prévue par le fabricant. Si vous avez des
questions, communiquez avec le fabricant à l'adresse ou au numéro de téléphone
indiquésdanslagarantie.
2. Avantdeprocéderàlaréparationou à l'entretien del'appareil,coupezl'alimentationdu
panneaud'entréed'électricitéetverrouillezl'interrupteurprincipalafind'empêcherquele
courantnesoit accidentellementrétabli. S'il estimpossible deverrouillerl'interrupteur
principal,fixezsolidementunmessaged'avertissement, par exempleuneétiquette,au
panneaud'entréed'électricité.
3. Laposedel'appareiletlestravauxd'électricitédoiventêtreeffectuéspardespersonnes
qualifiéesconformémentà laréglementationen vigueur, notammentlesnormes dela
constructionayanttrait à laprotection contre lesincendies.
4. Pouréviterlesrefoulements,l'apportd'airdoit être suffisantpourbrûler les gazproduits
parles appareils àcombustion et lesévacuer dans leconduit de fumée (cheminée).
Respectezlesdirectivesdufabricantdel'appareildechauffageetlesnormesdesécurité,
notammentcellespubliéesparlaNationalFireProtectionAssociation(NFPA),laAmeri-
canSocietyforHeating,lesRefrigerationand Air Conditioning Engineers(ASHRAE)et
lescodesdes autoritéslocales.
5. Veillezànepasendommagerlecâblageélectriqueoud'autreséquipementsnonapparents
lorsdela découpeoudu perçagedumur ouduplafond.
6. Lesventilateurscanalisésdoivent toujoursêtreventilés à l'airlibre.
7. N'utilisez pas de commande de régime à semi-conducteurs conjointement avec cet
appareil.
8. Pourréduirelesrisquesd'incendie, utilisez seulementdesconduitsenmétal.
9. Cetappareildoitêtre misàla terre.
POURRÉDUIRELES RISQUESD'INCENDIE CAUSÉS PARDELAGRAISSESUR LE
PLAN DE CUISSON :
A. Nelaissezjamaislesélémentsdesurfaceallumésàhautetempérature.Lesdébordements
peuventcauserdelafuméeet occasionner desécoulementsdegraisseinflammables.
L'huiledoitêtrechaufféegraduellement à basseouàmoyenne température.
B. Mettez toujours lahotteenfonction(ON) lorsdelacuissonà haute températureoulors
delacuissond'alimentsà flamber.
C. Nettoyezsouventlahotte.Ne laissez paslagraisses'accumuler sur leventilateuroule
filtre.
D. Utilisezdescasseroles dedimensionappropriée. Utiliseztoujoursune batteriedecui-
sineadaptéeàla dimensiondesélémentsde surface.
!
POUR USAGE DOMESTIQUE SEULEMENT.
!

- 17 -
AVERTISSEMENT
OBSERVEZLESCONSIGNESSUIVANTES* DE MANIÈREÀRÉDUIRELESRISQUES
DEBLESSURESCORPORELLESENCAS D'INCENDIE CAUSÉPARDELAGRAISSE
SUR LE PLAN DE CUISSON :
1. ÉTOUFFEZLESFLAMMESàl'aided'uncouvercleétanche,d'unetôleàbiscuitsoud'un
plateau en métal puis éteignez le brûleur. FAITESATTENTION DE NE PAS VOUS
BRÛLER.Silesflammesnes'éteignentpasimmédiatement,QUITTEZ LES LIEUX ET
APPELEZLESERVICEDESINCENDIES.
2. NESOULEVEZJAMAISUNECASSEROLEENFLAMMES-vouspourriezvousbrûler.
3. N'UTILISEZPASD'EAU,nideserviettes ou de lingesmouillés-uneviolente explosion
devapeurpourrait survenir.
4. Utilisez un extincteur SEULEMENT si :
A. Vous savez qu'il est de classe ABC et vous connaissez déjà son mode de
fonctionnement.
B. L'incendie n'est pastrès important etne se propagepas.
C. Vous avezdéjàtéléphoné au servicedesincendies.
D. Vous pouvezcombattrel'incendie enfaisantdos à unesortie.
* Conseils tirés de la publication de la NFPA« Kitchen Fire SafetyTips ».
!
ATTENTION
1. Pour réduire les risque d’incendie et évacuer l’air correctement, assurez-
vous qu’il est canalisé à l’extérieur. Ne pas évacuer l’air dans des espaces
enfermés par des murs ou un plafond ou dans un grenier, un vide sanitaire ou
un garage.
2. Faites attention lorsque vous utilisez des agents nettoyants ou des détergents.
3. Évitez d’utiliser des produits alimentaires pouvant produire des flammes sous
la hotte.
4. Cet appareil ne doit servir qu'à la ventilation générale. Il ne doit pas être utilisé
pour éliminer des matières ou des vapeurs dangereuses ou explosives.
5. Pour éviter d'endommager les roulements de moteur, de déséquilibrer les
pales ou de les rendre bruyantes, débarrassez l'appareil de la poussière de
plâtre, de construction, etc.
6. Le moteur de la hotte est muni d'un dispositif de protection de surcharge
électrique qui coupe automatiquement le moteur en cas de surchauffe. Il se
remet en marche lorsqu'il a refroidi. Faites réparer la hotte si le moteur con-
tinue à fonctionner par intermittence.
7. Pour mieux capter les vapeurs de cuisson, le bas de la hotte doit être au
minimum à 61 cm (24 po) et au maximum à 76 cm (30 po) de la surface de
cuisson. Pour les directives d’installation, voir la section « Installation des
brides de montage ».
8. Il est recommandé que les installateurs soient deux, compte tenu de la taille
et du poids de cette hotte.
9. Ce produit est doté d'un thermostat qui peut faire démarrer automatiquement
le ventilateur. Pour réduire les risques de blessures, coupez l'alimentation
électrique sur le panneau d'électricité et verrouillez-le ou accrochez-y une
étiquette de manière à éviter que le courant ne soit rétabli par accident.
10. À utiliser uniquement avec l’ensemble de connexion approuvé.
11. Veuillez lire l'étiquette de spécifications du produit pour obtenir plus de
renseignements, notamment sur les normes.

- 18 -
LENTILLE D'ÉCLAIRAGE ONGLET
AMPOULES HALOGÈNES
Cette hotte requiert deux ou quatre ampoules
halogènes(typeJC, 12V,20W,baseG4).
Pour remplacer les ampoules :
1.Ouvrezlalentilled’éclairageenagrippantl’onglet
eten lafaisant pivoter vers le bas.
2.Retirez l’ampoule enla tirantsur le côté(et non
en la tournant).ATTENTION : L’AMPOULE PEUT
ÊTRE BRÛLANTE !
3.Netouchezpasl’ampoulederechangeavecles
mains nues ! Enfoncez fermement l’ampoule
danssonsocleetrefermezlalentilled’éclairage.
UTILISATION
Commandes
Lahottefonctionne à l’aidede quatre (4)boutons-
poussoirs situés à hauteur des yeux, sur la face
avant.
L’interrupteur d’éclairage allume et éteint les
lampeshalogènes.
L’interrupteur de ventilateur régime lent
marche / arrêt fait démarrer le ventilateur à son
régimele pluslent. Le ventilateur doit êtremis en
marcheàl’aidedecetinterrupteur.Pourarrêterleventilateur,ilsuffitd’appuyerunedeuxième
foissurl’interrupteur.
L’interrupteur de ventilateurrégime moyen placeleventilateurenvitessemoyenne.Cet
interrupteurnefonctionnequesi le ventilateurestdéjàen marche enrégimelentouélevé.
L’interrupteur de ventilateur régime élevé place le ventilateur en haute vitesse. Cet
interrupteurnefonctionnequesileventilateurestdéjàenmarcheenrégime lent ou moyen.
Letémoin lumineux s’allume dès queleventilateur estenmarche.
Thermostat Heat Sentry
MC
Votrehotteestéquipéed'unthermostatHEATSENTRYMC.Ils'agit d'un détecteurde
chaleurquiactionne le ventilateurouen augmentelerégime en casdechaleur excessive
dégagéeparlesélémentsdecuisson.
1)EnpositionARRÊT,leventilateurestmisenMARCHEau régime MAXIMUM.
2)EnpositionMARCHEàrégimelent, le ventilateur passeaurégimeMAXIMUM.Unefois
latempératurerevenueàlanormale, le ventilateurrevientàsonréglage d'origine.
AVERTISSEMENT
Le thermostat HEAT SENTRYpeut faire démarrer le ventilateur même si la hotte
est sur ARRÊT. Lorsque cela se produit, il est impossible d’ARRÊTER le
ventilateur avec son interrupteur. Si vous devez arrêter le ventilateur, coupez le
disjoncteur du panneau d’alimentation électrique.
0
VENTILATEUR
RÉGIME LENT
MARCHE /
ARRÊT
VENTILATEUR
RÉGIME
MOYEN
INTERRUPTEUR
D'ÉCLAIRAGE
TÉMOIN
LUMINEUX
VENTILATEUR
RÉGIME
ÉLEVÉ

- 19 -
REMPLACEMENT DU FUSIBLE
SI LES LUMIÈRES NE S’ALLUMENT PAS,
COUPEZ LE COURANT AU PANNEAU
D’ALIMENTATION ÉLECTRIQUE. VÉRIFIEZ LE
FUSIBLE ET REMPLACEZ-LE, LE CAS
ÉCHÉANT.
1. Enlevezlesfiltres.
2. Retirez le support du boîtier de connexion
électrique.
3. Enlevez les vis du compartiment à fusible et
ouvrezle couvercle.
4. Repérezleporte-fusible.Dévissezsoncapuchon
etenlevezlefusible.
5. Remplacez-le par un fusible de même taille et de même intensité (5 x 20 mm, 4A, 125V).
6. Replacezlecouvercleducompartiment à fusible,lesupport du boîtierdeconnexionet
lesfiltres.
7. Rétablissezlecourantaupanneauélectrique.
ENTRETIEN
Filtres à graisse
Les filtresà graissedoiventêtrenettoyés fréquemment. Utilisezunesolutiontièdede
détergentpourlesnettoyer.Ces filtres peuventalleraulave-vaisselle.Voirla section
« INSTALLATION DES FILTRES » pour les instructions concernant leur pose et leur
démontage.
Filtre non canalisé
Lefiltre non canalisé doit être remplacé tous les 6 mois. Voir la section
« INSTALLATION DES FILTRES » pour les instructions concernant leur pose et leur
démontage.
Nettoyage de la hotte
L’acier inoxydable est l’un des matériaux les plus faciles à nettoyer. Quelques soins
contribuerontàpréserver sa belleapparence.
Conseils de nettoyage :
• Ilsuffithabituellementd’utiliserdel’eauchaudesavonneuseouadditionnéededétergent.
• Aprèsle nettoyage, rincez toujours àl’eau claire. Essuyez la surfaceavec unchiffon
propreet douxpour éviter les stries.
• Pourlesternissuresoulesdépôtstenaces,utilisez unnettoyantdomestiquenon-abrasif
ouunepoudreà polirl’acierinoxydableavec unpeud’eauet un chiffondoux.
• Pourla saletérebelle, utilisez un tampon àrécurer enplastique ouune brosseà poils
doux avec un nettoyant et de l’eau. Frottez doucement dans le sens des lignes de
polissage ou du « grain » de l’acier. Évitez de trop appuyer au risque de gâcher la
surface.
• NELAISSEZPASles dépôtss’accumulertroplongtemps.
• N’UTILISEZPASunelained’acierordinaireouunebrosse d’acier. Depetitesparticules
d’acierrisqueraientd’adhérer à lasurfaceet delafaire rouiller.
• NELAISSEZ PASunesolution saline, un désinfectant, de l’eau de javel outout autre
produitdétachantresterlongtemps encontactavecl’acier inoxydable.Bonnombrede
cesnettoyantscontiennentdesproduitspouvantenaltérerla surface. Après l’utilisation
dunettoyant, rincez lasurface àl’eau etessuyez-la avec un chiffon propre.
Nettoyezlessurfaces peintesuniquement à l’eautièdeavec undétergentdoux.
SUPPORTDU
BOÎTIERDE
CONNEXION
FUSIBLE
COMPARTIMENT
ÀFUSIBLE

- 20 -
PRÉPARATION DE LA HOTTE
Déballez la hotte et vérifiez le contenu de la boîte.
Celle-ci doit contenir les éléments suivants :
1 - Hotte
1 - Conduit décoratif de cheminée
1 - Sac de plastique (B08081189) contenant :
1 - Bride de montage du conduit décoratif
2 - Brides de montage
8 - Vis de montage (4,8 x 38 mm - à tête cylindrique)
4 - Vis de montage (3,9 x 9,5 mm - à tête cylindrique)
4 - Vis de montage (3,2 x 13 mm - à tête cylindrique)
4 - Vis de montage (3,2 x 13 mm - à tête cylindrique - noires)
8 - Chevilles d’ancrage pour cloisons sèches
1 - Directives d’installation
1 - Carte de garantie
BRIDES DE
MONTAGE
BRIDE DE MONTAGE
DU CONDUIT
DÉCORATIF
8 VIS DE MONTAGE
(4,8 x 38 mm -
à tête cylindrique)
8 CHEVILLES
D’ANCRAGE POUR
CLOISONS SÈCHES
CONDUIT
DÉCORATIF DE
CHEMINÉE
4 VIS DE MONTAGE
(3,9 x 9,5 mm - à tête
cylindrique)
4 VIS DE MONTAGE
(3,2 x 13 mm - à tête
cylindrique - noires)
4 VIS DE MONTAGE
(3,2 x 13 mm - à tête
cylindrique)
