FIPS Security Seal Procedures for Brocade FCX Series and Brocade FastIron SX Series 3 of 13
Publication Number: 53-1002119-01
In this document
This document contains the instructions for the application of FIPS-compliant tamper-evident security seals to
Brocade FastIron hardware devices and includes the following sections:
•FIPS security seals
•Preparing to apply FIPS security seals
•Applying seals to Brocade devices
FIPS security seals
Each seal in the Tamper Evident Seals kit (XBR-000195) measures 1.27 cm (.5 in.) by 3.18 cm (1.25 in.) and has a
unique serial number printed on it. Seals must be correctly placed on each hardware device to satisfy the
requirements for FIPS 140-2 Level 2 compliance.
The seals should be stored in a room temperature environment—between 20 and 25ºC (68 to 77ºF). Avoid applying
seals in environments where the temperature is 10ºC (50ºF) or less.
The seals have a shelf life of one year. After that period, new seals should be purchased.
NOTE
It is recommended that you follow your company’s policy for recording the seal serial numbers used and for proper
disposal of expired seals.
Once installed, if the seals are tampered with, you will be able to see the following tamper evidence:
•Appearance of a checkerboard destruct pattern
•Graphics printed within the seal can be partially visible on both the removed seal and the residue remaining on
the surface
•Residue seen under ultraviolet light
Allow the adhesive on the back of each seal at least 24 hours to cure; tamper evidence might not be visible until the
adhesive cures.
Preparing to apply FIPS security seals
The time to apply security seals varies by the number of seals required for a particular model. The application of
seals to a Brocade FastIron or NetIron can take 10 minutes or longer.
Before beginning this task, ensure that you have the proper Tamper Evident Seals Kit (part number XBR-000195)
and alcohol pads to clean the surfaces on which the seals will be affixed. Clean surfaces with alcohol and ensure
that the surfaces are dry before applying security seals.

4 of 13 FIPS Security Seal Procedures for Brocade FCX Series and Brocade FastIron SX Series
Publication Number: 53-1002119-01
Applying seals to Brocade devices
Seal placement varies by switch model. This section includes the following FIPS seal application procedures:
•Applying seals to Brocade FCX 624S-F, Brocade FCX 624S, and Brocade FCX 624S-HPOE
•Applying seals to Brocade FCX 648S and Brocade FCX 648S-HPOE devices
•Applying seals to Brocade FastIron SX 800 devices
•Applying seals to Brocade FastIron SX 1600 devices
NOTE
The figures in this document show transparent representations of the seals to show the specific openings
or fasteners that the seals are designed to cover. The actual seals are opaque.
To apply security seals, ensure that the following requirements are met:
•Carefully remove the seals from the backing and place them on the device. Do not use bare fingers to handle
the labels. Using tweezers, peel away the backing slowly and carefully to avoid contaminating or disturbing the
adhesive.
•When applying a seal to the device, use firm pressure across the surface of the entire seal to ensure maximum
adhesion.
•Allow at least 24 hours for the adhesive to fully cure. Evidence of tampering might not be apparent until the
adhesive cures.
NOTE
You should store any extra seals in a secure, temperature-controlled area.
Applying seals to Brocade FCX 624S-F, Brocade FCX 624S, and Brocade FCX 624S-HPOE
Use the figures in this section as a guide for security seal placement on the following Brocade FastIron devices:
•Brocade FCX 624S-F
•Brocade FCX 624S
•Brocade FCX 624S-HPOE
The connectors on the faceplates of your particular device might vary from the connectors shown on the figures, but
the placement of the seals will be the same. Figure 1 on page 5 and Figure 2 on page 6 display a Brocade FCX 624S
with seals as a model for the seal placement on the Brocade FCX 624S-F, Brocade FCX 624S, and Brocade FCX
624S-HPOE. Each of these devices requires the placement of 13 seals:
•Top: Affix 4 total seals to the top panel of the device. Affix two seals so that they cover the left and right
frontmost screws on the top panel of the device. Affix two seals so that they cover the two screws adjacent to the
frontmost screws on the top panel. See Figure 1 for correct seal orientation and positioning.
•Right and left sides: Affix 4 total seals to the left and right sides of the device--two seals on the right side and
two seals on the left side. Each seal should cover two holes on either side of the first vent section. See Figure 1
for correct seal orientation and positioning on the right side of the device. The orientation and placement of
seals on the left side mirrors the orientation and placement of seals on the right side of the device (visible in
Figure 1).
•Front: Affix one seal horizontally-aligned with half affixed to the front panel and half affixed to the bottom panel.
You must bend this seal to place it correctly. See Figure 1 for correct seal orientation and positioning.

FIPS Security Seal Procedures for Brocade FCX Series and Brocade FastIron SX Series 5 of 13
Publication Number: 53-1002119-01
•Rear: Affix 4 total seals to the rear panel of the device. Affix one seal from the rear panel to the bottom panel
and three seals from the rear panel to the top panel. You must bend these seals to place them correctly. See
Figure 2 on page 6 for correct seal orientation and positioning.
FIGURE 1 Front, top, and right side views of a Brocade FCX 624S device with security seals.
NOTE
The orientation and placement of seals on the left side of the device mirrors the orientation and placement of seals
on the right side of the device. Seal placement on the right side of the device is visible in Figure 1 above and Figure 2
on page 6.
9
10
1
2
3
8
5
4
6
1 to 10 = FIPS security seals
7

6 of 13 FIPS Security Seal Procedures for Brocade FCX Series and Brocade FastIron SX Series
Publication Number: 53-1002119-01
FIGURE 2 Rear, bottom, and left side views of a FCX 624S device with security seals
Applying seals to Brocade FCX 648S and Brocade FCX 648S-HPOE devices
Use the figures in this section as a guide for security seal placement on the following Brocade FastIron devices:
•Brocade FCX 648S
•Brocade FCX 648S-HPOE
The connectors on the faceplates of your particular device might vary from the connectors shown on the figures, but
the placement of the seals will be the same. Figure 3 on page 7 and Figure 4 on page 8 display a Brocade FCX 648S
with seals as a model for the seal placement on the Brocade FCX 648S and Brocade FCX 648S-HPOE. Each of these
devices requires the placement of 13 seals:
•Top: Affix 4 total seals to the top panel of the device. Affix two seals so that they cover the left and right
frontmost screws on the top panel of the device. Affix two seals so that they cover the two screws adjacent to the
frontmost screws on the top panel. See Figure 3 for correct seal orientation and positioning.
•Right and left sides: Affix 4 total seals to the left and right sides of the device--two seals on the right side and
two seals on the left side. Each seal should cover two holes on either side of the first vent section. See Figure 3
for correct seal orientation and positioning on the right side of the device. The orientation and placement of
seals on the left side mirrors the orientation and placement of seals on the right side of the device (visible in
Figure 3).
•Front: Affix one seal horizontally-aligned with half affixed to the front panel and half affixed to the bottom panel.
You must bend this seal to place it correctly. See Figure 3 for correct seal orientation and positioning.
8
11
12
13
1
3
2
11-13 FIPS security seals

FIPS Security Seal Procedures for Brocade FCX Series and Brocade FastIron SX Series 7 of 13
Publication Number: 53-1002119-01
9
10
1
2
3
8
5
4
6
1 to 10 = FIPS security seals
7
•Rear: Affix 4 total seals to the rear panel of the device. Affix one seal from the rear panel to the bottom panel
and three seals from the rear panel to the top panel. You must bend these seals to place them correctly. See
Figure 4 on page 8 for correct seal orientation and position.
FIGURE 3 Front, top, and right side views of a Brocade FCX 648S device with security seals.
NOTE
The orientation and placement of seals on the left side of the device mirrors the orientation and placement of seals
on the right side of the device. Seal placement on the right side of the device is visible in Figure 3 above and Figure 4
on page 8.

8 of 13 FIPS Security Seal Procedures for Brocade FCX Series and Brocade FastIron SX Series
Publication Number: 53-1002119-01
FIGURE 4 Rear, bottom, and left side views of a FCX 648S device with security seals
8
11
12
13
1
3
2
11-13 FIPS security seals

FIPS Security Seal Procedures for Brocade FCX Series and Brocade FastIron SX Series 9 of 13
Publication Number: 53-1002119-01
Applying seals to Brocade FastIron SX 800 devices
Use the figures in this section as a guide for security seal placement on a Brocade FastIron SX 800 device.
The connectors on the faceplates of a particular module might vary from the connectors shown on the figures, but
the placement of the seals will be the same. There is no seal placement required on the side panels or solely on the
top and bottom panels of Brocade FastIron SX 800 devices. Each Brocade FastIron SX 800 device requires the
placement of 16 seals:
•Front: Affix 15 total seals to the front panel of the device. Affix one vertically-oriented seal to the left ear of each
module installed in the left side of the chassis. As much as possible of the seal should be affixed to the module
directly above the left screw for the left side modules. Affix one vertically-oriented seal to each of the modules
installed in the right side of the chassis by affixing the seals directly under the screw to the right ear of each
module and to the chassis. Affix one seal from the upper right corner of the fan tray to the chassis. All 15 of
these seals should lie flat against the front of the device. See Figure 5 for correct seal orientation and
positioning.
FIGURE 5 Front view of a Brocade FastIron SX 800 device with security seals

10 of 13 FIPS Security Seal Procedures for Brocade FCX Series and Brocade FastIron SX Series
Publication Number: 53-1002119-01
•Rear: Affix 3 total seals to the rear panel of the device. Affix two vertically-aligned seals at the upper right and
left sides of the rear panel so that one half of the seal is affixed to the top panel of the device and the other half
is affixed to the rear panel and covering the rightmost and leftmost screws. You must bend these seals to place
them correctly. Affix one seal vertically-aligned at the lower center of the rear panel so that one half of the seal is
affixed to the bottom panel of the device and the other half of the seal is affixed to the rear panel of the device,
covering the middle screw. See Figure 6 for seal orientation and positioning.
FIGURE 6 Rear, top, and left side panel views of a Brocade FastIron SX 800 device with security seals
3 FIPS security seals
15
16
14

FIPS Security Seal Procedures for Brocade FCX Series and Brocade FastIron SX Series 11 of 13
Publication Number: 53-1002119-01
Applying seals to Brocade FastIron SX 1600 devices
Use the figures in this section as a guide for security seal placement on a Brocade FastIron SX 1600 device.
The connectors on the faceplates of a particular module might vary from the connectors shown on the figures, but
the placement of the seals will be the same. There is no seal placement required on the top panel, bottom panel, or
side panels of Brocade FastIron SX 1600 devices. Each Brocade FastIron SX 1600 device requires the placement of
24 seals:
•Front: Affix 21 total seals to the front panel of the device. Affix one horizontally-oriented seal to the upper ear of
each module installed in the top row of the chassis as shown in Figure 7 on page 12. As much as possible of the
seal should be affixed to the module to the right of the screw that secures each module to the chassis. Affix one
horizontally-oriented seal to the lower ear of each module installed in the bottom row of the chassis as shown in
Figure 7. As much as possible of the seal should be affixed to the module to the left of the screw that secures
each module to the chassis. Affix one seal from the upper left corner of the fan tray to the chassis, as shown in
Figure 7. All 21 of the seals should lie flat against the front panel of the device.

12 of 13 FIPS Security Seal Procedures for Brocade FCX Series and Brocade FastIron SX Series
Publication Number: 53-1002119-01
FIGURE 7 Front view of a Brocade FastIron SX 1600 device with security seals
12345678
910
21 20 19 18 17 16 15 14 13 12 11
1 to 21 = FIPS security seals

FIPS Security Seal Procedures for Brocade FCX Series and Brocade FastIron SX Series 13 of 13
Publication Number: 53-1002119-01
•Rear: Affix 3 total seals to the rear panel of the device. Affix two vertically-aligned seals to the right and left top
edges of the chassis so that half of the seal is affixed to the top panel and half to the rear panel or, in the case
of an ANR, to the bracket that attaches the ANR bracket to the rear panel of the chassis. Affix one seal vertically
to the center bottom edge of the rear panel so that one half of the seal is affixed to the rear panel of the device
and one half of the seal is affixed to the bottom panel. You must bend this seal to place it correctly. See Figure 8
for correct seal orientation and positioning.
FIGURE 8 Rear view of the FastIron SX 1600 device (ANR version shown) with security seals
23
22
24 3 FIPS security seals
