Brocade DCX-4S Backbone QuickStart
Guide
53-1001192-01 New document. November 2008
Brocade DCX-4S Backbone QuickStart
Guide
53-1001192-02 Updated for EMI
certification.
December 2008
Brocade DCX-4S Backbone QuickStart
Guide
53-1001192-03 Corrected IPaddrset
command.
November 2009

Brocade DCX-4S QuickStart Guide 3 of 20
Publication Number: 53-1001192-03
In this guide
•Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
•Safety notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
•Brocade DCX-4S, port side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
•Brocade DCX-4S, nonport side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
•Time and items required for installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
•Site planning and safety guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
•Items included with the Brocade DCX-4S . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
•Unpacking and installing the Brocade DCX-4S. . . . . . . . . . . . . . . . . . . . . . . 10
•Providing power to the Brocade DCX-4S. . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
•Managing cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
•Installing ICL cables (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
•Establishing a serial connection and logging on to Brocade DCX-4S . . . . . 15
•Configuring IP addresses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
•Establishing an Ethernet connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
•Customizing a switch name. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
•Setting the Domain ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
•Verifying the PID mode and connecting to the fabric. . . . . . . . . . . . . . . . . . 19
•Enabling software licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
•Backing up the configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Introduction
This guide provides instructions for unpacking, installing, and setting up a Brocade DCX-4S Backbone as a
standalone unit quickly. Note the following additional documentation:
•For detailed installation and configuration instructions, refer to the Brocade DCX-4S Backbone Hardware
Reference Manual.
•For rack-specific installation instructions, refer to the appropriate rack mount or mid-mount installation
procedures.
The Brocade DCX-4S can be installed in the following ways:
•As a standalone unit on a flat surface.
•In a chassis with the DCX-4S Port Side Exhaust Kit (provided) in a Brocade-qualified rack.
•In a 19-in. Electronic Industries Association (EIA) cabinet, using a Brocade DCX-4S Rack Mount Kit (either a
27-31 in. or 18-34 in. kit depending on rack used).
•In a mid-mount telecommunications (Telco) rack, using the Brocade DCX-4S Mid-Mount Rack Kit available from
your Brocade DCX supplier (optional).
The basic configuration steps required to set up the Brocade DCX-4S Backbone are listed in this guide. Additional
configuration information is provided in the Brocade DCX-4S Backbone Hardware Reference Manual and the Fabric
OS Administrator’s Guide.

4 of 20 Brocade DCX-4S QuickStart Guide
Publication Number: 53-1001192-03
ATTENTION
In order to comply with EMI certification, the door of the DCX-4S must be installed and EMI plugs must be inserted in
the ICL cable sockets of the core switch blades if ICL cables are not used.
Safety notices
NOTE
Translated safety notices are in the Brocade Product Safety Notices publication, which is on the CD-ROM that
accompanies this product.
When using this product, observe the danger, caution, and attention notices in this manual. The notices are
accompanied by symbols that represent the severity of the safety condition.
The danger and caution notices are listed in numerical order based on their IDs, which are displayed in parentheses,
for example (D004), at the end of each notice. Use this ID to locate the translations of these danger and caution
notices in the Brocade Product Safety Notices.
Danger notices
A danger notice calls attention to a situation that is potentially lethal or extremely hazardous to people. A
lightning bolt symbol accompanies a danger notice to represent a dangerous electrical condition. Read and
comply with the following danger notice before installing or servicing this device.
DANGER
Use the supplied power cords. Ensure the facility power receptacle is the correct type, supplies the
required voltage, and is properly grounded. (D004)
Caution notices
A caution notice calls attention to a situation that is potentially hazardous to people because of some existing
condition. Read and comply with the following caution notice before installing or servicing this device.
CAUTION
Use safe lifting practices when moving the product. (C015)
Brocade DCX-4S, port side
NOTE
Airflow in the Brocade DCX-4S is from the nonport side to the left side of the chassis (viewed from the port side) and
out the exhaust vent. If you use the Port Side Exhaust Kit the air vents on the port side of the chassis (see Figure 2.
Figure 1 displays a sample configuration of the port side of the Brocade DCX-4S.

Brocade DCX-4S QuickStart Guide 5 of 20
Publication Number: 53-1001192-03
FIGURE 1 Port side of the Brocade DCX-4S (sample configuration)
1 FC8-48 port blade (example, 4x) 3 Control processor blade (CP8) (2x)
2 Core switch blade (CR4S-8) (2x) 4 Exhaust vent

6 of 20 Brocade DCX-4S QuickStart Guide
Publication Number: 53-1001192-03
FIGURE 2 Port side of the Brocade DCX-4S with the port side exhaust kit installed (sample configuration)
Brocade DCX-4S, nonport side
Figure 3 displays a sample configuration of the nonport side view of the Brocade DCX-4S.

Brocade DCX-4S QuickStart Guide 7 of 20
Publication Number: 53-1001192-03
FIGURE 3 Nonport side of the Brocade DCX-4S (sample configuration)
Time and items required for installation
This document describes how to set up the Brocade DCX-4S as a standalone unit. For rack-mount installation
instructions, refer to the appropriate manual as described in Table 1.
Table 1 describes the main installation and setup tasks and the estimated time required for each, based on a fully
populated Brocade DCX-4S (192 Fibre Channel ports). Configurations with fewer ports require less time. These time
estimates assume a prepared installation site and appropriate power and network connectivity.
1 WWN card bezel (logo plate) 2 Power supply (2x)
3Blowerassembly(2x)
TABLE 1 Installation tasks, time, and items required
Installation task Time estimate Items required
Site preparation and unpacking Brocade
DCX-4S.
30 minutes 1/2-in. socket wrench (to remove pallet bolts).
#2 Phillips screwdriver.
(for cable management comb).
Pallet jack.
Hydraulic lift or assisted lift, able to rise to a
minimum of 55 in. (140 cm), with a minimum
capacity of 113 kg (250 lb). The Brocade
DCX-4S weighs 68 kg (150 lb) with four FC8-48
port cards installed (192 ports).

8 of 20 Brocade DCX-4S QuickStart Guide
Publication Number: 53-1001192-03
Site planning and safety guidelines
NOTE
Read the safety notices before installation (“Safety notices”).
The following steps are required to ensure correct installation and operation.
1. Provide a space that is 9 rack units (9U) high, 61.19 cm (24.09 in.) deep, and 43.74 cm (17.22 in.) wide. 1U is
equal to 4.45 cm (1.75 in.). If you do not use the provided port side exhaust kit, the space needs to be only 8
rack units (8U) high.
The Brocade DCX-4S can be installed facing either direction in a cabinet, if serviceability and cooling
requirements are met.
2. Ensure that dedicated electrical branch circuits with the following characteristics are available:
•200 – 240 VAC, 50–60 Hz (two branch circuits)
•Two cables for the 200 - 240 VAC service
•Power supply standards are met
•Protected by a circuit breaker in accordance with local electrical codes
•Supply circuit, line fusing, and wire size adequate to the electrical rating on the chassis nameplate
•Location close to the chassis and easily accessible
•Grounded outlets installed by a licensed electrician and compatible with the power cords
ATTENTION
To maximize fault tolerance, connect each power cord to a separate power source.
3. Plan for cable management before installing the chassis.
Installing the rack mount kit or
port side exhaust kit.
30 minutes Refer to the one of the Brocade DCX-4S rack
mount kit installation procedures or to the
Brocade DCX-4S Mid-Mount (Telco) Rack Kit
Installation Procedure or to the Brocade Port
Side Exhaust Kit Installation Procedure.
Mounting and securing Brocade DCX-4S in
rack.
15 minutes
Installing power cables and powering on
the Brocade DCX-4S.
10 minutes Power cables.
Establishing serial connection, logging on
to Brocade DCX-4S, and configuring IP
addresses.
20 minutes Serial cable (provided in the accessory kit).
Workstation computer with a serial port or
terminal server port and a terminal emulator
application (such as HyperTerminal).
Ethernet IP addresses for the switch.
Installing an Ethernet cable, opening a
Telnet session, and configuring the
Brocade DCX-4S domain ID, date and time,
and additional system parameters. Verify
and back up configuration.
20 minutes Ethernet cable for Telnet access.
Refer to the Fabric OS Administrator’s Guide.
Installing SFPs. Attaching and managing
fiber optic cables.
15 minutes SFP optical transceivers. Fiber optic cables
and cable ties.
TABLE 1 Installation tasks, time, and items required (Continued)
Installation task Time estimate Items required

Brocade DCX-4S QuickStart Guide 9 of 20
Publication Number: 53-1001192-03
Cables can be managed in a variety of ways, such as by routing cables below the chassis, along either the port
or the nonport side of the chassis, through cable channels on the sides of the cabinet, or by using patch panels.
4. Ensure that the following is available for configuration of the Brocade DCX-4S:
•Workstation with an installed terminal emulator, such as HyperTerminal
•Serial cable (provided)
•Three Ethernet cables
•Access to an FTP server for backing up the switch configuration or collecting supportsave output data
(optional)
•A Brocade USB stick for collecting supportsave output data (optional)
•SFPs and compatible cables
NOTE
For information about the SFP transceivers that are qualified for the Brocade Encryption Switch, go to
http://www.brocade.com/products/interop_and_compatibility.jsp.
5. Ensure that the air intake vents have a minimum of 2 inches of airspace.
6. Ensure that the air temperature on the air intake side is less than 40 degrees Celsius (104 degrees Fahrenheit)
during operation.
CAUTION
UUse safe lifting practices when moving the product. (C015)
NOTE
A fully populated Brocade DCX-4S (eight FC8-48 port cards, 384 ports) weighs approximately 104 kg (228 lbs) and
requires a hydraulic or assisted lift to install it.
Items included with the Brocade DCX-4S
The Brocade DCX-4S ships with the following:
•Brocade DCX-4S chassis, populated with:
•Control processor blades (CP8)
•Core switch blades (CR4S-8)
•Port blades, application blades, and encryption blades (included based on customer specification)
•Blade slot filler panels (for slots not filled by blades)
•Port side exhaust kit
•WWN cards
•WWN bezel (logo plate)
•Power supplies
•Power supply filler panel (included if there is only one power supply)
•Blower assemblies
•Vertical cable management fingers
•Chassis door

10 of 20 Brocade DCX-4S QuickStart Guide
Publication Number: 53-1001192-03
•Accessory kit containing the following items:
•Brocade DCX-4S Backbone QuickStart Guide
•Brocade Documentation CD (contains documents related to the Brocade DCX-4S)
•ESD grounding strap
•RS-232 serial cable. The RS-232 cable has an adapter at one end that can be removed to provide an
RJ-45-style connector.
•Brocade DCX-4S rack mount kit with instructions
Order the optical transceivers (SFP and XFP) from Brocade. The Brocade DCX-4S supports SWL, LWL, and ELWL
transceivers.
NOTE
For information about the SFP and XFP transceivers that are qualified for the Brocade DCX-4S, go to
http://www.brocade.com/products/interop_and_compatibility.jsp.
Unpacking and installing the Brocade DCX-4S
CAUTION
Use safe lifting practices when moving the product. (C015)
NOTE
A fully populated Brocade DCX-4S (four FC8-48 port cards, 192 ports) weighs approximately 68 kg (150 lbs) and
requires a hydraulic or assisted lift to install it.
1. Unpack and install the Brocade DCX-4S.
a. Cut the bands that encircle the packaging.
b. Remove the lid and the kits and foam from the top of the chassis.
c. Lift the cardboard box off the chassis and remove the plastic bag from around the chassis.
Save the packing materials for use when returning the old chassis.
d. Leave the chassis on top of the plastic shipping tray if the chassis must be transported to the installation
location.
NOTE
The Brocade DCX-4S packaging does not incorporate a wood pallet and pallet brackets. The chassis sits on top
of a plastic shipping tray.
2. Use a pallet jack or other assisted lift to transport the new chassis to the installation area. Doorways must be
wider than 36 in. (91 cm) to accommodate the chassis.
3. Remove the Brocade DCX-4S port side exhaust kit, accessory kit, packing foam, and antistatic plastic from the
chassis and set aside.
4. Remove the chassis door from the Brocade DCX-4S.
5. Remove the vertical cable management fingers.
6. Use a lift to raise the chassis to the correct level. If installing the chassis in a cabinet, follow the instructions
provided by the port side exhaust kit installation procedure or the appropriate rack kit installation procedure.

Brocade DCX-4S QuickStart Guide 11 of 20
Publication Number: 53-1001192-03
7. If applicable, lock the wheels of the lift.
8. Gently slide the chassis onto the final installation surface, ensuring that it remains supported during the
transfer.
9. Ensure the chassis can be oriented so that the nonport side has access to intake air (cool).
10. Reinstall the vertical cable management fingers.
11. If ICL cables are not being used, ensure that EMI plugs are inserted in the ICL cable sockets in the core switch
blades.
12. Reinstall the chassis door. The door must be installed to meet EMI compliance.
Providing power to the Brocade DCX-4S
DANGER
Use the supplied power cords. Ensure the facility power receptacle is the correct type, supplies the
required voltage, and is properly grounded. (D004)
1. Connect the two AC power cords to each of the two power supplies.
2. Connect the power cords to a power source with a voltage of 200 to 240 VAC, 47 to 63 Hz.
3. Turn the AC power switches on the power supplies to ON. The AC power switches light green when switched on
and power is supplied.
4. The Brocade DCX-4S performs a power-on self-test (POST) each time it is powered on. POST takes approximately
ten minutes and is complete when the indicator light activity displays the operational state.
You can bypass POST by using the fastBoot command. You can also disable POST for successive reboots on the
Brocade DCX-4S using the diagDisablePost command.
ATTENTION
Do not connect the switch to the network until the IP addresses are configured.
Managing cables
ATTENTION
The minimum bend radius for a 50 micron cable is 2 in. under full tensile load and 1.2 in. with no tensile load.
Cables can be organized and managed in a variety of ways: for example, using cable channels on the port or nonport
sides of the cabinet or patch panels to minimize cable management. With the horizontal orientation of the blades in
the DCX-4S, a pair of vertical cable management finger assemblies (Figure 4) have been provided to keep the cables
from hanging down in front of other blades.
Following is a list of recommendations:
•Leave at least 1 m (3.28 ft) of slack for each port cable. This provides room to remove and replace the
Brocade DCX-4S, allows for inadvertent movement of the rack, and helps prevent the cables from being
bent to less than the minimum bend radius.

12 of 20 Brocade DCX-4S QuickStart Guide
Publication Number: 53-1001192-03
•If ISL Trunking is in use, group the cables by trunking group. The ports are color-coded to indicate which
ports can be used in the same ISL Trunking group: eight ports marked with solid black ovals alternate with
eight ports marked with oval outlines.
•For easier maintenance, label the fiber optic cables and record the devices to which they are connected.
•Route the cables to both the left and right sides of the DCX-4S through the cable management fingers.
•Keep LEDs visible by routing port cables and other cables away from the LEDs.
FIGURE 4 Vertical cable management finger assemblies
Installing ICL cables (optional)
NOTE
ICL ports can be used only with an ICL license. After the addition or removal of a license, the license enforcement is
performed on the ICL ports only when the portdisable and portenable commands are issued on the ports. An ICL
license must be installed on both Brocade Backbones forming the ICL connection. The backbones can be either two
Brocade DCX-4S units or one DCX-4S and one Brocade DCX.
Follow this procedure to install the inter-chassis link (ICL) cables. Refer to the Fabric OS Administrator’s Guide for the
configuration procedure and requirements.
Figure 5 shows an ICL cable. The ICL cables (2 meters long) and the ICL connectors are color-coded and labeled for
ease of installation.Figure 6 and Figure 7 show the acceptable cabling configurations for the inter-chassis link (ICL)
feature. Connect the ICL cables in one of the configurations shown.
ATTENTION
To prevent the latch mechanism from wear, use the color-coded (green) latch-release tab for cable removal. Pull the
tab to disengage the retention latch before cable removal.

Brocade DCX-4S QuickStart Guide 13 of 20
Publication Number: 53-1001192-03
ATTENTION
Since the blades in the DCX-4S are installed horizontally, the usual top-to-bottom orientation becomes a left-to-right
orientation.
Connect the cables from the left (top) connectors (ICL 1) of the CR4S-8 blades in the first chassis to the right (bottom)
connectors (ICL 0) of the CR4S-8 blades in the second chassis.
Similarly, connect the cables from the right (bottom) connectors (ICL 0) of the CR4S-8 blades in the first chassis to
the left (top) connectors (ICL 1) of the CR4S-8 blades in the second chassis.
NOTE
The cables can cross between the slot 3 CR4S-8 blade on the first chassis and the slot 6 CR4S-8 blade on the second
chassis as long as the left-to-right (top-to-bottom) rule is followed.
FIGURE 5 Inter-chassis link (ICL) cable
ICL 1
ICL 0

14 of 20 Brocade DCX-4S QuickStart Guide
Publication Number: 53-1001192-03
FIGURE 6 ICL cable connections – between two DCX-4S chassis
1 Chassis 1 5 ICL connector (ICL 1)
2 Core switch blades (CR4S-8) 6 ICL connector (ICL 0)
3 Control processor blades (CP8) 7 ICL cables
4Portblades 8Chassis2
12
5
6
34
7
8

Brocade DCX-4S QuickStart Guide 15 of 20
Publication Number: 53-1001192-03
FIGURE 7 ICL cable connections between a DCX-4S and a DCX
Establishing a serial connection and logging on to Brocade DCX-4S
Follow these steps to connect a serial cable.
1. Verify that the Brocade DCX-4S is powered on and that POST is complete by ensuring that all power LED
indicators on the port, control processor, and core switch blades display a steady green light.
2. Remove the shipping cap from the CONSOLE port on the active CP. Use the serial cable provided with the
Brocade DCX-4S to connect the CONSOLE port on the active CP to a computer workstation. The active CP blade
is indicated by an illuminated (blue) LED.
ATTENTION
The CONSOLE port is intended primarily for the initial setting of the IP address and for service purposes.
1 Chassis 1 (DCX-4S) 5 ICL connector (ICL 1)
2 Core switch blades (CR8) 6 ICL connector (ICL 0)
3 Control processor blades (CP8) 7 ICL cables
4Portblades 8Chassis2(DCX)
12
5
6
34
7
8

16 of 20 Brocade DCX-4S QuickStart Guide
Publication Number: 53-1001192-03
3. Access the Brocade DCX-4S using a terminal emulator application (such as HyperTerminal in a Windows
environment or tip in a Linux environment).
4. Disable any serial communication programs running on the workstation (such as synchronization programs).
5. Open a terminal emulator application (such as HyperTerminal on a PC, or term, tip, or kermit in a UNIX
environment), and configure the application as follows:
•In a Windows environment:
•In a UNIX environment, enter the following string at the prompt:
tip /dev/ttyb -9600
If ttyb is already in use, use ttya instead and enter the following string at the prompt:
tip /dev/ttya -9600
6. When the terminal emulator application stops reporting information, press Enter. You receive the following login
prompt:
CP0 Console Login:
7. Log in to the Brocade DCX-4S as admin, using the default password: password. You are prompted to change the
default passwords at initial login.
swDir login: admin
Password:
Please change your passwords now.
Use Control-C to exit or press 'Enter' key to proceed.
Password was not changed. Will prompt again at next login
until password is changed.
swDir:admin>
NOTE
Passwords can be 8 to 40 characters long. They must begin with an alphabetic character. They can include
numeric characters, the dot (.), and the underscore (_). Passwords are case-sensitive, and they are not
displayed when you enter them on the command line.
Configuring IP addresses
The Brocade DCX-4S requires three IP addresses, which are configured using the ipAddrSet command. IP addresses
are required for both CP blades (CP0 and CP1) and for the single logical switch (shown as SWITCH under the
ipAddrShow command) in the Brocade DCX-4S.
Parameter Value
Bits per second 9600
Databits 8
Parity None
Stop bits 1
Flow control None

Brocade DCX-4S QuickStart Guide 17 of 20
Publication Number: 53-1001192-03
NOTE
The default IP addresses and host names for the Brocade DCX-4S are:
– 10.77.77.75 / CP0 (the CP blade in slot 4 at the time of configuration)
– 10.77.77.74 / CP1 (the CP blade in slot 5 at the time of configuration)
ATTENTION
Resetting an IP address while the Brocade DCX-4S has active IP traffic or has management and monitoring tools
running, such as DCFM, Fabric Watch, and SNMP, can cause traffic to be interrupted or stopped.
1. Log in to the active CP as admin using the serial cable connection.
2. Set up the Brocade DCX-4S IP address by entering the ipaddrset -chassis command:
swDir:admin> ipAddrSet -chassis
Enter the information at the prompts. Specify the -chassis IP address. The -sw 0 IP address is no longer valid on
this chassis.
NOTE
The addresses 10.0.0.0 through 10.0.0.255 are reserved and used internally by the Brocade DCX-4S. External
IPs must not use these addresses.
3. Set up the CP0 IP address by entering the ipaddrset -cp 0 command:
swDir:admin> ipAddrSet -cp 0
Enter the information at the prompts.
4. Set up the CP1 IP address by entering the ipaddrset -cp 1 command:
swDir:admin> ipAddrSet -cp 1
Enter the information at the prompts.
This is a sample IP configuration:
swDir:admin> ipaddrset -chassis
Ethernet IP Address [0.0.0.0]: 123.123.123.120
Ethernet Subnetmask [0.0.0.0]: 123.123.123.123
Fibre Channel IP Address [0.0.0.0]:
Fibre Channel Subnetmask [0.0.0.0]:
Issuing gratuitous ARP...Done.
Committing configuration...Done.
swDir:admin> ipaddrset -cp 0
Host Name [cp0]:
Ethernet IP Address [10.77.77.75]: 123.123.123.121
Ethernet Subnetmask [0.0.0.0]: 123.123.123.123
Gateway IP Address [0.0.0.0]: 123.123.123.124
IP address is being changed...Done.
Committing configuration...Done.
swDir:admin> ipaddrset -cp 1
Host Name [cp1]:
Ethernet IP Address [10.77.77.74]: 123.123.123.122
Ethernet Subnetmask [0.0.0.0]: 123.123.123.123
Gateway IP Address [0.0.0.0]: 123.123.123.124
IP address of remote CP is being changed...Done.
Committing configuration...Done.

18 of 20 Brocade DCX-4S QuickStart Guide
Publication Number: 53-1001192-03
swDir:admin> reboot
5. Type reboot to reboot the Brocade DCX-4S.
6. You can use the serial port to monitor error messages through the serial connection. If the serial port is no
longer required, use the logout command to log out of the serial console, remove the serial cable, and replace
the plug in the serial port.
Establishing an Ethernet connection
NOTE
Connecting the CP blades to a private network/VLAN is recommended.
After using a serial connection to configure the IP addresses for the Brocade DCX-4S, you can connect the active CP
blade to the local area network (LAN).
By establishing an Ethernet connection, you can complete the Brocade DCX-4S configuration using either a serial
session, Telnet, or a management application such as Web Tools or DCFM. To create an Ethernet connection to the
Brocade DCX-4S, follow these steps.
1. Remove the shipping plug from the Ethernet port on the active CP blade.
2. Insert one end of an Ethernet cable into the Ethernet port.
3. Connect the other end to an Ethernet 10/100/1000 BaseT LAN.
The Brocade DCX-4S can be accessed through a remote connection using any of the management tools, such as
Telnet, Web Tools, or DCFM.
4. To complete any additional Brocade DCX-4S configuration procedures through a Telnet session, log in to the
Brocade DCX-4S by Telnet, using the admin login. The default password is password.
Customizing a switch name
The switch name of the Brocade DCX-4S can be up to 15 characters long; it can include alpha, numeric, and
underscore characters; and must begin with an alpha character.
NOTE
Changing the name causes a domain address format RSCN to be issued.
1. Type switchName followed by the new name in quotes.
swDir:admin> switchName "swModularSwitch5"
Committing configuration...
Done.
swModularSwitch5:admin>
2. Record the new name for reference.

Brocade DCX-4S QuickStart Guide 19 of 20
Publication Number: 53-1001192-03
Setting the Domain ID
Each switch in the fabric must have a unique domain ID. The domain ID can be manually set through the configure
command or can be automatically set. The default domain ID for the Brocade DCX-4S is “1”. Use the fabricShow
command to view the already assigned domain IDs.
1. Enter switchDisable to disable the Brocade DCX-4S.
2. Enter configure.
3. Enter yat the “Fabric parameters” prompt:
Fabric parameters (yes, y, no, n): [no] y
4. Enter a unique domain ID:
Domain: (1.239) [1] 3
5. Complete the remaining prompts or press Ctrl+D to accept the settings and exit.
6. Enter switchEnable to re-enable the Brocade DCX-4S.
Verifying the PID mode and connecting to the fabric
Before connecting the Brocade DCX-4S to the fabric, verify that the port identifier (PID) mode on the Brocade DCX-4S
matches the other switches in the fabric. This parameter must be identical for all switches in the fabric.
Perform the following steps to connect the Brocade DCX-4S to the fabric.
1. Add SFP optical transceivers (or XFP optical transceivers with FC10-6 port card installed) and cables to the Fibre
Channel ports.
The ports are color-coded to indicate which can be used in the same port group for trunking (trunking port
groups can be up to 8 ports). The ports and cables used in trunking groups must meet specific requirements.
Refer to the Fabric OS Administrator’s Guide for information about configuring trunking.
2. Position one of the optical transceivers so that the key is oriented correctly to the port. Insert the transceiver into
the port until it is firmly seated and the latching mechanism clicks.
Transceivers are keyed so that they can only be inserted with the correct orientation. If a transceiver does not
slide in easily, ensure that it is correctly oriented.
3. Position a cable so that the key (the ridge on one side of the cable connector) is aligned with the slot in the
transceiver. Insert the cable into the transceiver until the latching mechanism clicks.
Cables are keyed so that they can be inserted in only one way. If a cable does not slide in easily, ensure that it is
correctly oriented.
4. Repeat step 1 through step 3 for the remaining ports.
5. Organize the cables using the vertical cable management fingers.
6. Verify Brocade DCX-4S and port status using the switchShow command.
7. Verify fabric connectivity using the fabricShow command.

20 of 20 Brocade DCX-4S QuickStart Guide
Publication Number: 53-1001192-03
Enabling software licenses
Depending on the vendor agreement, certain licenses are factory installed on the Brocade DCX-4S. To determine
which licenses are enabled, use the licenseShow command.
swDir:admin> licenseshow
AAbbccDDeeFFeeGG:
Web license
Zoning license
Extended Fabric license
Fabric Watch license
Performance Monitor license
Trunking license
Security license
In this example, the license key is AAbbccDDeeFFeeGG. Keep a copy of the license key for reference.
The 64-bit chassis ID is required to obtain and activate licenses for the Brocade DCX-4S. The chassis ID is available
through the licenseIdShow command. The licenseShow and licenseIdShow commands must be entered on the
active CP blade. Refer to the Fabric OS Administrator’s Guide for more information.
Backing up the configuration
Save all key configuration data for the Brocade DCX-4S, including license key information, and upload it to a host for
reference. Routine backups of the configuration are recommended to ensure the current configuration is available.
1. Log on to the switch by Telnet, using the admin account.
2. After zoning configurations and other changes are complete, back up the configuration by typing configUpload
at the prompt. This command uploads the Brocade DCX-4S configuration to the server so that it is available for
downloading to a replacement Brocade DCX-4S.
3. Run the following commands to save the configuration to a file on a secure host.
•configShow
•ipaddrShow
•licenseShow
•switchShow
Alternatively, you can save the configuration file to a Brocade USB.
Keep copies of key data such as passwords, license keys, and IP addresses in a secure location.
NOTE
Passwords are not saved in the configuration file, and are not uploaded during a configUpload.
