Broil King S18428 REV H 1004 User manual

S18428 Rev. H 10/04
RETAIN FOR FUTURE REFERENCE VEUILLEZ CONSERVER POUR REFERENCE ULTERIEURE
1-800-265-2150 [email protected]
ASSEMBLY MANUAL & PARTS LIST MANUEL DE MONTAGE & LISTE DE PIECES
REDDI-BILT BARBECUES

PARTS LIST / LISTE DES PIECES
KEY ITEM # DESCRIPTION 702-8 712-8 716-8 732-8 742-8 KEY ITEM # DESCRIPTION 702-8 712-8 716-8 732-8 742-8
1 S11425 CASTING BOTTOM 1 1 1 1 1 80 Y-11546 SCREW - 1/4:20 X 5/8 8 8 8 8 8
2 S11290 CASTING TOP 1 1 • 1 1 81 Y-11545 BOLT - 1/4:20 X 1-3/8 4 4 4 4 4
S11296 CASTING TOP • • 1 • • 82 Y-12855 BOLT - 1/4:20 X 3/8 14 14 14 14 14
3 S14018 NAMEPLATE 1 1 1 1 1 83 S21014 BOLT - 1/4:20 x 3/4 8 8 8 8 8
5 10571-6 HEAT INDICATOR 1 1 1 1 1 84 Y-12220 BUSHING 1 1 1 1 1
6 S21235 HINGE PIN 2 2 2 2 2 85 Y-11211 WASHER - LOCK 1/4 8 8 8 8 8
7 S21233 HINGE CLIP 2 2 2 2 2 86 Y-11795 NUT - 1/4 • • 8 • •
8 10222-T42 GRATE 1 1 • 1 1 87 Y-11793 NUT - 1/4 12 12 14 12 12
10222-T424 FLAV-R-WAVE • • 1 • • 88 Y-11598 NUT WING - 1/4 4 4 2 4 4
9 S12028 GRID 2 2 2 2 2 96 S21123 SCREW - 8 X 1/2 4 4 4 4 4
11 S12206 GRID RETRACTABLE 1 1 1 1 1 98 S21124 SCREW - 8 X 1/2 26 26 24 26 26
15 S10017 BURNER ASSY 1 1 1 1 1 99 Y-12646 SCREW - SHOULDER 4 4 4 4 6
17 10342-21 IGNITOR 1 1 • 1 • 101 Y-12853 WASHER - #8 • 4 4 4 4
10342-241 ROTARY IGNITOR • • 1 • 1 104 Y-12835 SCREW - 6-32 X 1/4 6 6 8 6 6
10472-K40 IGNITOR KNOB • • 1 • • 105 Y-29307 NUT – 10:24 • • • • 4
18 S15500 ELECTRODE 1 1 1 1 1 108 PB20-60 KNOB • • • • 1
21 10440-K51 CONTROL ASSY NG 1 1 1 • • 109 S21136 SCREW 8-32 X 3/8 • • 1 • 2
10440-R52 CONTROL ASSY NG • • • 1 • 110 10225-T10 GRID • • • • 1
10442-R54 CONTROL ASSY NG • • • • 1 111 10390-E10 SIDE BURNER • • • • 1
21A. S13467-132 HOSE-SIDE BURNER NG • • • • 1 113 10342-T12 ELECTRODE • • • • 1
Y-11230 COTTER PIN • • • • 1 114 10393-K40 COVER - SIDE BURNER • • • • 1
21B. 10110-91 HOSE-REAR BURNER NG • • • 1 1 115 Y-29304 SCREW 10:24 X 1/2 2 2 2 2 2
22 10111-K23 HOSE NG 1 1 1 1 1 117 10393-R50 SHELF - SIDE BURNER • • • • 1
23 10472-K36 CONTROL KNOB 2 2 • 3 4
10472-K37 CONTROL KNOB • • 2 • •
30 10086-R504 DECO PLATE • • 1 • •
S14181 DECO PLATE 1 1 • • •
S14186 DECO PLATE • • • 1 • 11300 PATIO BASE ASSY
S14187 DECO PLATE • • • • 1
31 10194-K501 CONTROL COVER 1 1 • 1 1 40 10958-K811 PATIO BASE 1
10194-R561 CONTROL COVER • • 1 • • 45 10184-K80 PATIO BASE - SUPPORT 1
35 10184-K561 SUPPORT - CASTING-LH 1 1 • 1 1 48 10958-K561 POST BASE - BRACKET 1
10184-R561 SUPPORT - CASTING-LH • • 1 • • 83 S21014 BOLT 1/4:20 X 3/4 4
36 10184-K571 SUPPORT - CASTING-RH 1 1 • 1 1 85 Y-11211 WASHER - LOCK 1/4 4
10184-R571 SUPPORT - CASTING-RH • • 1 • • 87 Y-11793 NUT 1/4-20 4
37 10184-K581 SUPPORT - SHELF - LH • 2 2 2 2 90 Y-12286 LAG BOLT - 5/16 X 4 4
38 10184-K591 SUPPORT - SHELF - RH • 2 2 2 2 92 Y-12851 WASHER - 3/8 4
39 10958-K641 BRACE - REAR 1 1 • 1 1
10958-R831 BRACE - REAR • • 1 • •
41 10958-K631 BRACE - FRONT 1 1 • 1 1 11240 POST EXTENSION ASSY
10958-K851 BRACE - FRONT • • 1 • •
42 10958-K521 POST SUPPORT 1 1 1 1 1 43 10958-K55 POST - INGROUND 1
46 10958-K531 POST 1 1 1 1 1 83 S21014 BOLT 1/4:20 X 3/4 2
47 10958-K541 POST COVER 1 1 1 1 1 86 10958-K58 POST - BRACE 1
49 10711-K541 CONDI - BIN • 1 1 1 1 87 Y-11793 NUT - HEX 1/4:20 2
50 10711-K551 SHELF - SIDE • 2 2 2 1
53 S16144-2 SHELF - BOARD - FRONT • 1 1 1 1
57 10156-K55 SHIELD 1 1 • 1 1
65 S13009 BURNER ROTISSERIE • • • 1 1
68 S21362 SPRING • • • 2 2
70 Y-11990 HEX NUT • • • 1 1
71 10696-160 REAR BURNER-ORIFICE NG • • • 1 1
74 Y-6616 BOLT 2 2 2 2 2
75 10338-145 RESIN HANDLE 2 2 2 2 2
76 10239-7 WASHER - HANDLE 2 2 2 2 2
77 S15111 GREASE CUP HOLDER 1 1 1 1 1
79 Y-11561 SCREW 1/4-20 1 1 2 1 1
OPTIONAL

22
21b
38
31
82A
98
115
98
71
110
37
36
21
68
65
98
30
23
114
108
99
10 9
51
8
81
1
50
49
96
53
70
98
15
18
17
18
6
6a
7
123
39
21a
21a
113
117
104
105
116
111
11
9
9
35
37
38
82A
79
88
80
80
4
3
98
2
87
75
5
74
13 76
98
104
98
99
101
98
104
104
98
90
92
40
83
45
87
87
87
85
85
83
85
46
84
47
98
80
77
