Bronpi LOIRE-P User manual

MOD. LOIRE-P
INSTRUCTION MANUAL

Dear customer:
E G We would like to thank you for choosing one of our products. The product
you have just purchased is highly valuable and this is why we kindly invite you
to read carefully this brief manual so as you can make the most of your
equipment.
GE ERAL WAR I GS

REGULATIO S
E G To get a perfect combustion regulation, this model presents different types of
regulations and air inlets. The working process is as follow:
PRIMARY AIR REGULATIO

ARRANGEMENT AND ELEMENTS REPLACEMENT /

Loire-P
Potencia calorífica 14 kW
Rendimiento 75 %
Emisiones CO (13% O2) 0.38 %
Temperatura de humos 362 ºC
Conducto de humos (mm)
Ø 200
Carga combustible aconsejada
3.2 Kg./h
Longitud máxima de leña 65 cm
Peso 66 kg

TECH ICAL FEATURES /

EXPLODED VIEW DRAWI G /
123
5
8
9
12
17
18
21
7
22
13
24
6
4
10
11
13
14
15
16
19
20
N°
DESCRIPCION /DESCRIPTION
N°
DESCRIPCION /DESCRIPTION
1 Regulación aire primario 13 Soporte vermiculita trasera
2 Cajón cenicero 14 Soporte vermiculita lateral
3 Maneta 15 Deflector
4 Frontal 16 Rejilla
5 Cajonera 17 Collarin salida humos
6 Pata 18 Regulación aire secundario
7 Parrilla 19 Conductor aire secundario superior
8 Vermiculita lateral 20 Conductor aire secundario inferior
9 Vermiculita trasera lateral 21 Bisagra
10 Vermiculita trasera central 22 Cristal
11 Cuerpo 23 Puerta
12 Doble combustion 24 Marco

IMPORTANT
E G This product can be installed next to the walls of the room, provided that they
meet the following requirements:
•To respect a distance of about 5-10 cm. to the wall.
•To check that the wall is completely made of brick, fireproof brick
blocks, concrete, thin hollow brick, etc., and that they are covered by
a material susceptible to support high temperatures.
Therefore, in the event of the wall being made of any other material
(plasterboard, wood, non glass-ceramic, etc.) the installation engineer should
foresee an adequate isolation or leave a minimum security distance to the wall
of 80-100cm. In this case, it is compulsory to use thermal insulated pipe.

The data provided in this manual are not binding.
The company reserves the right to carry out modifications and
improvements without notice.

Please, do not hesitate to contact your dealer for further information.
