Laser FAX/MFC
PARTS REFERENCE LIST
MODEL:
DCP-8080DN / DCP-8085DN /
MFC-8480DN / MFC-8680DN /
MFC-8880DN /MFC-8881DNHY
MFC-8890DW
Read this list thoroughly before maintenance work.
Keep this list in a convenient place for quick and easy reference at all times.
January 2009
PL-FAX160
8C5D11
Ver. P-1

NOTE FOR USING THIS PARTS REFERENCE LIST
1. In the case of ordering parts, it is necessary to mention the following items;
(1) Code
(2) Q'ty
(3) Description
(4) Symbol ( PCB No. etc )
Note: Orders without Parts Code or Tool No. can not be accepted.
< Example >
REF.NO. CODE Q’TY DESCRIPTION SYMBOL REMARK
2. Design-changed parts :
If any of the parts is changed, one of the following symbols is indicated in the REMARK column.
CHG(chg) : The parts is changed to a new parts.
ADD(add) : The parts is newly added.
DEL(del) : The parts is deleted.
Symbol in capital letters indicates the latest parts change information in the page.
3. Parts change will be informed by the Parts change information.
4. Parts are subject to change in design without prior notice.
COUNTRIES
U.S.A. ----- USA CHILE ----- CHL
CANADA ----- CAN POLAND ----- POL
GERMANY ----- GER ASIA ----- ASA
UNITED KINGDOM ----- UK GULF ----- GUL
FRANCE ----- FRA BRAZIL ----- BRA
BELGIUM ----- BEL KOREA ----- KOR
NETHERLANDS ----- NLD INDIA ----- IND
SWITZERLAND ----- CHE RUSSIA ----- RUS
AUSTRIA ----- AUS AUSTRALIA ----- ARL
ITALY ----- ITA NEW ZEALAND ----- NZ
CHINA ----- CHN PAN-NORDIC
PHILIPPINES ----- PHL (NORWAY/FINLAND/DENMARK/SWEDEN) ----- PND
TURKEY ----- TUR IBERIA (SPAIN/PORTUGAL) ----- IBR
ARGENTINA ----- ARG EEU-GENERAL ----- EEU
(1) (4)
(3)
(2)

CONTENTS
1. FRAME L & DRIVE UNIT..................................................................... 1
2. FRAME UNIT........................................................................................ 3
3. LASER UNIT ........................................................................................ 5
4. PAPER FEEDER.................................................................................. 7
5. DUPLEX ............................................................................................... 9
6. PAPER TRAY..................................................................................... 11
7. FUSER UNIT ...................................................................................... 13
8. COVERS............................................................................................. 15
9. SCANNER .......................................................................................... 17
10. ADF 1.................................................................................................. 19
11. ADF 2 ................................................................................................ 21
12. PANEL................................................................................................ 23
13. PCB .................................................................................................... 25
14. ACCESSORIES.................................................................................. 27
15. PRINTED MATERIALS ......................................................................30
16. PACKING MATERIALS......................................................................32
17. OTHERS.............................................................................................35

1. FRAME L & DRIVE UNIT
- 1 -
1-1
1-7 1-8
1-3
1-10
1-12 1-13
1-9
1-20
1-11
1-2
1-14
1-17
1-17
1-17
1-17
1-18
1-16
1-4
1-19 1-18
1-18
1-15
1-6 1-5
2
1-21
3
1
1-22
1-23
1-24
45

LIST1(FRAME L&DRIVE UNIT)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARKS
1 LS7238001 1 MAIN FRAME L UNI
T
1-1 LU7214001 1 DEVELOP JOINT
1-2 LM5047001 1 MAIN MOTOR ASSY A
L
1-3 LM5048001 1 FUSER GEAR 39 H/R DRIVE
1-4 LM5058001 1 REGISTER SOLENOID ASSY
1-5 LM5062001 1 MP SOLENOID ASS
Y
1-6 LM5067001 1 T1 SOLENOID ASS
Y
1-7 LJ9935001 1 TONER SENSOR PCB ASSY
1-8 UL9037001 1 PT SENSOR HOLDER
1-9 LJ993800
2
1 RELAY FRONT PCB ASS
Y
1-10 LJ9940001 1 FRONT COVER SW ASSY
1-11 LJ9942001 1 RELAY REAR PCB ASS
Y
1-12 LM5085001 1 NEW TONER ACTUATOR
1-13 LM5086001 1 NEW TONER ACTUATOR SPRING
1-14 LJ7403001 1 RUBBER FOOT
1-15 LJ9945001 1 CONNECTOR
1-16 LM5011001 1 EJECTOR SOLENOID
1-17 08732061
6
4 TAPTITE CUP S M3x6
1-18 08531101
6
3 TAPTITE BIND B M3x10
1-19 08531101
6
1 TAPTITE BIND B M3x10
1-20 LG4518001 1 THERMISTOR ASSY
1-21 LM5043001 1 DEV GEAR 37R JOINT DRIVE
1-22 LM5080001 1 DRIVE RELEASE LINK
1-23 LM5079001 1 DRIVE RELEASE CAM add
1-24 08721061
6
1 TAPTITE CUP B M2X6 add
2 LM5104001 1 GEAR 17 MP ROLLER DRIVE
3 LM5103001 1 GEAR 20 T1 ROLLER DRIVE
4 LM5102001 1 GEAR 17 FEED ROLLER DRIVE add
5 LM5051001 1 DX GEAR 15 TRAY DRIVE
A
DD
8C5D11/8C5D16/8C5D41/
8C5D51/8C5D56/8C5D61 DCP8080DN/DCP8085DN/MFC8480DN/ MFC8680DN/MFC8880DN/MFC8881DNHY/MFC8890DW
- 2 -

2. FRAME UNIT
- 3 -
1
2
3
4
6
5
7
8

LIST2(FRAME UNIT)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARKS
1 LV0282001 1 TONER LED PCB ASSY
2 LM4267001 1 LED HOLDER
3 LJ7403001 1 RUBBER FOOT
4 LU7141001 1 FILTER ASSY
5 LM5114001 1 FAN MOTOR 60 UNIT LV
6 LU7032001 1 FAN MOTOR 60 UNIT
7 LM6655001 1 AIR DUCT ASSY AL
8 LT0963001 1 WIRELESS PCB, MFC8890DW CHG
8C5D11/8C5D16/8C5D41/
8C5D51/8C5D56/8C5D61
DCP8080DN/DCP8085DN/MFC8480DN/
MFC8680DN/MFC8880DN/MFC8881DNHY/MFC8890DW
- 4 -

3. LASER UNIT
- 5 -
1
3
2
2
2
2
22

LIST3(LASER UNIT)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARKS
1 LU7176001 1 LASER UNIT
(
SP
)

2 08732061
6
6 TAPTITE, CUP S M3X6
3 LJ0908001 1 LASER CAUTION LABEL EXCEPT FOR CHN
3UL7931001 1 LASER CAUTION LABEL FOR CHN
8C5D11/8C5D16/8C5D41/
8C5D51/8C5D56/8C5D61
DCP8080DN/DCP8085DN/MFC8480DN/
MFC8680DN/MFC8880DN/MFC8881DNHY/MFC8890DW
- 6 -

LIST4(PAPER FEEDER)
REF No. CODE Q'T
Y
DESCRIPTIO
N
RECOMMEN
D
REMARK
S
1 LM9001001 1 PE EG SENSOR ASS
Y
2 LU7935001 1 PE ACTUATOR ASS
Y
CHG
3 LM5132001 1 EDGE ACTUATOR
4 LM5133001 1 EDGE ACTUATOR SPRIN
G
5 LU7179001 1 ROLLER HOLDER ASSY
6 LM5150001 1 REGIST ACTUATOR FRON
T
7 LM5151001 1 REGIST ACTUATOR REA
R
8 LM5152001 2 REGIST ACTUATOR SPRIN
G
9 LJ9999001 1 MP PE SENSOR ASS
Y
10 LU7184001 1 MP ROLLER HOLDER ASS
Y
11 LM5171001 1 PE ACTUATOR M
P
12 LU0027001 1 PE ACTUATOR MP B
2
13 LM6490001 1 MP SEPARATION SPRING
14 LM6752001 1 SEPARATION PAD ASSY M
P
15 LM519600
5
1 TRAY MP ASS
Y
16 LS7305001 1 MP TRAY COVER ASSY,
DCP8080DN/DCP8085DN/MFC8480DN/MFC8680D
N
16 LS7004001 1 MP TRAY COVER ASSY,
MFC8880DN/MFC8881DNHY/MFC8890D
W
16-1 LS7306001 1 BROTHER EMBLEM COVER ASSY,
DCP8080DN/DCP8085DN/MFC8480DN/MFC8680D
N
16-1 LS7283001 1 BROTHER EMBLEM COVER ASSY,
MFC8880DN/MFC8881DNHY/MFC8890D
W
17 LU7037001 1 PROCESS COVER ASSY EXCEPT FOR CHN/IND, EXCEPT
FOR MFC8881DNH
Y
17 LU7527001 1 PROCESS COVER ASSY FOR CHN, MFC8881DNH
Y
17 LU7689001 1 PROCESS COVER ASSY FOR IN
D
17-1 LM5124001 1 PROCESS COVER STOPPE
R
17-2 LU7039001 1 SUPPORT FLAP 1
17-3 087411016 1 TAPTITE CUP B M4X10
18 08531081
6
2 TAPTITE BIND B M3x
8
8C5D11/8C5D16/8C5D41/
8C5D51/8C5D56/8C5D61
DCP8080DN/DCP8085DN/MFC8480DN/
MFC8680DN/MFC8880DN/MFC8881DNHY/MFC8890DW
- 8 -

5. DUPLEX
- 9 -
1

LIST5(DUPLEX)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARKS
1 LM5209001 1 DX FEED ASSY LTR FOR US/CAN/PHL/ARG/CHL/BR
A
1 LU7503001 1 DX FEED ASSY A4 FOR GER/UK/FRA/BEL/NLD/CHE/AUS/ITA/
CHN/TUR/POL/ASA/GUL/KOR/IND/RUS/ARL/NZ/PND/IBR/EEU
8C5D11/8C5D16/8C5D41/
8C5D51/8C5D56/8C5D61 DCP8080DN/DCP8085DN/MFC8480DN/ MFC8680DN/MFC8880DN/MFC8881DNHY/MFC8890DW
- 10 -

6. PAPER TRAY
- 11 -
1
1-1
1-2
1-3
1-4
1-5

LIST6(PAPER TRAY)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARKS
1 LU7198001 1 PAPER TRAY UNIT FOR US/CAN/PHL/ARG/CHL/BRA/IND
1 LU7203001 1 PAPER TRAY UNIT FOR GER/UK/FRA/BEL/NLD/CHE/AUS/
ITA/CHN/TUR/POL/ASA/GUL/KOR/RUS/ARL/NZ/PND/IBR/EEU
1-1 LM5237001 1 SEPARATION PAD ASSY
1-2 LM5239001 1 SEPARATION PAD SPRING
1-3 LM5245001 1 GEAR 15
1-4 LM5246001 1 GEAR 21-16
1-5 LM5247001 1 LIFT GEAR 46
8C5D11/8C5D16/8C5D41/
8C5D51/8C5D56/8C5D61 DCP8080DN/DCP8085DN/MFC8480DN/ MFC8680DN/MFC8880DN/MFC8881DNHY/MFC8890DW
- 12 -

LIST7(FUSER UNIT)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARKS
1 LU7939001 1 FUSER UNIT 115V
(
SP
)
FOR US/CAN/BR
A
CHG
1 LU7941001 1 FUSER UNIT 230V (SP) FOR GER/UK/FRA/BEL/NLD/CHE/AUS/
ITA/CHN/PHL/TUR/ARG/CHL/POL/ASA/GUL/KOR/IND/RUS/ARL/NZ/
PND/IBR/EEU
CHG
1-1 LU7078001 4 PRESSURE SPRING
1-2 LU7154001 4 EJECT PINCH ROLLER M del
2 LU7164001 2 TAPTITE PAN B M4X20
8C5D11/8C5D16/8C5D41/
8C5D51/8C5D56/8C5D61 DCP8080DN/DCP8085DN/MFC8480DN/ MFC8680DN/MFC8880DN/MFC8881DNHY/MFC8890DW
- 14 -

LIST8(COVERS)
REF No. CODE Q'TY DESCRIPTION RECOMMEND SYMBO
L
REMARKS
1 LS7307001 1 JOINT COVER ASSY, GRAY(1581),
DCP8080DN/DCP8085DN
1 LS7239001 1 JOINT COVER ASSY, GRAY(1581),
MFC8480DN/MFC8680DN/MFC8880DN/MFC8881DNHY/
MFC8890DW
1-1 LU7312001 2 PAPER STACK LEVER SP ASS
Y
1-2 LU7118001 1 SUPPORT FLAP 2
2 08541121
6
9 TAPTITE, BIND B M4X12
3 LG6529001 1 SPEAKER ASS
Y
4 LG6531001 1 DRIVER PCB ASS
Y
B53K85
0
5 LF9624001 1 SIDE COVER R, GRAY
(
1736
)
6 LF9625001 1 SIDE COVER L, GRAY
(
1736
)
7 LM5273001 1
A
CCESS COVER, GRAY
(
1736
)
8 LU7046001 1 BACK COVER
9 LU7047001 1 OUTER CHUTE ASSY
10 LU7126001 1 REAR CHUTE ASSY
11 08731081
6
3 TAPTITE CUP B M3X8
12 LS7388001 1 PROCESS UNIT OP LABEL FOR US/CAN/ARG/CHL/BRA
12 LU7341001 1 PROCESS UNIT OP LABEL FOR GER/UK/FRA/BEL/NLD/CHE/
A
US/ITA/POL/RUS/PND/IBR/EEU, EXCEPT FOR MFC8881DNH
Y
12 LS7919001 1 PROCESS UNIT OP LABEL FOR CHN
12 LU7496001 1 PROCESS UNIT OP LABEL FOR
PHL/TUR/ASA/GUL/KOR/IND/ARL/NZ
12 LX2209001 1 PROCESS UNIT OP LABEL, MFC8881DNH
Y
13 LU7303001 1 FUSER CAUTION LABEL
14 LE8842001 1 EXT CAP, MFC8480DN/MFC8680DN/MFC8880DN/MFC8890DW
FOR US/CAN/CHE/CHN/PHL/TUR/POL/ARG/CHL/ASA/GUL/
BRA/KOR/IND/RUS/ARL/NZ/PND/IBR/EEU
14 UF5745000 1 MJ COVER EXT, MFC8880DN/MFC8881DNHY/MFC8890DW
FOR GER/UK/FRA/BEL/NLD/AUS/ITA
15 LT0668001 1 USB HOST PCB
8C5D11/8C5D16/8C5D41/
8C5D51/8C5D56/8C5D61 DCP8080DN/DCP8085DN/MFC8480DN/ MFC8680DN/MFC8880DN/MFC8881DNHY/MFC8890DW
- 16 -

9. SCANNER
- 17 -
1-3
1-10
1-10
1-11
1-10
1-10
1-11
1-4
1-12
1-12
1-2
1-5
1-8
1-9
1-9
1-9
1-9
1-9
22
1-7
1-6
1-8-1
1-8-3
1-8-3
1-8-2
1-1
1
1-9
1-8-3
