  9. Brugg Pipesystems CASAFLEX UNO User manual

Brugg Pipesystems CASAFLEX UNO User manual

10.04.2017 www.brugg.com Tel. +49 (0)5031 170-0
- Technische Änderungen vorbehalten - Subject to technical change -
CASAFLEX-Fernwärmeleitung
CASAFLEX District Heating Pipe
Montageanleitung CASAFLEX UNO Anschlussverbindung „MINI“
DN 20 – DN 40 (PN 16)
Instruction manual CASAFLEX UNO Connection unit “MINI”
DN 20 – DN 40 (PN 16)
1
2.22.32.1
DE
1 Druckring
2 Schiebehülse, komplett
2.1 Schiebehülse
2.2 Graphitdichtung
2.3 Sprengring, DIN 5417
3 Anschlussstück
DE
Verpackungs-
einheit
EN
Packing unit
EN
1 Pressure ring
2 Slide-on sleeve, complete
2.1 Slide-on sleeve
2.2 Graphite sealing
2.3 Snap ring, DIN 5417
3 Connection piece
2 3
Art. Nr. 1061613
Nut für Sprengring
Groove for snap ring
2.3 1
2.22.1
3
10.04.2017 www.brugg.com Tel. +49 (0)5031 170-0
CASAFLEX MINI 2
- Technische Änderungen vorbehalten - Subject to technical change -
Montageanleitung / Instruction manual
Sicherheitshinweise / Saftey Instructions
CASAFLEX
DE Lesen Sie diese Montageanleitung aufmerksam, bevor Sie mit dem Arbeiten beginnen.
EN Read these installation instructions carefully before starting work.
DE Wichtige Hinweise für die sichere und korrekte Handhabung dieses Produkts!
Unfallverhütungsvorschriften beachten!
EN Important information on how to handle this product safely and correctly!
Attention! Be careful to observe all safety regulations!
x
x = 50 mm
DE Verlegung und Montage von CASAFLEX Rohren
EN Laying and installation of CASAFLEX pipes
Spannbänder
xing ribbons
1.
DE Verlegung (Skizze)
Spannbänder nacheinander von außen nach innen
durchtrennen und Ring im Graben (oder neben
dem Graben) abrollen.
EN Laying the pipe (sketch)
Cut the xing ribbons one after the other from the
outside inwards and roll the pipe out into the trench
(or next to the trench).
10.04.2017 www.brugg.com Tel. +49 (0)5031 170-0
CASAFLEX MINI 3
- Technische Änderungen vorbehalten - Subject to technical change -
Montageanleitung / Instruction manual
1.
DE Benötigte Werkzeuge
2.
DE Montagewerkzeug zum Verpressen
a geteilter Flansch
b Flansch
c Sechskantschrauben M8
d Unterlegscheiben
EN Tools needed
EN Installation set for compression connection
a Split ange
b Flange
c Allen screws M8
d Washers
a
b
c
e
d
f
g
q
h
i
j
kl
mn
o
p
DE Übersicht Werkzeuge
EN Tools at a glance
c
a b
d
a Heißluftfön
b Sicherheitsmesser
c Marker
d Steckschlüssel
½" – SW13
e Umschaltknarre ½"
f Seitenschneider
g Pinsel
h Gliedermaßstab
i Schraubendreher
j Edelstahl-Drahtbürste
k Klebeband
l Gratpaste
m Handsteckschlüssel SW7
n Halbrundfeile
o Bügelsäge
p Schutzhandschuh
q Schmirgelleinen
a Hot-air blower
b Safety knife
c Marker
d Socket wrench
½" – SW13
e Ratchet brace ½"
f Side cutter
g Brush
h Folding rule
i Screwdriver
j Stainless steel wire brush
k Adhesive tape
l Graphite paste
m Manual socket wrench
SW7
n Half-round le
o Bow saw
p Protective gloves
q Emery cloth
10.04.2017 www.brugg.com Tel. +49 (0)5031 170-0
CASAFLEX MINI 4
- Technische Änderungen vorbehalten - Subject to technical change -
Montageanleitung / Instruction manual
6.
DE Mantel mit Schraubendreher anheben
und mit der Hand entfernen.
EN Lift the jacket using the screwdriver and
remove it by hand.
5.
DE Mantel mit Sicherheitsmesser längs einschneiden.
EN Cut into the jacket in a longitudinal direction using
the safety knife.
DE Rohrvorbereitung für
CASAFLEX-Anschlussverbindung „MINI“
EN Preparing the pipe for the
CASAFLEX connecting piece “MINI”
4.
DE Mantel maximal 10 mm (Sägeblatthöhe) tief rund-
herum ansägen – Streckgitter mit durchtrennen!
Achtung! Überwachungsader nicht ansägen.
EN Saw around the circumference of the jacket to a
maximum depth of 10 mm (saw blade depth) –
cut through the expanding mesh as well!
Attention! Take care not to cut the monitoring leads.
3.
DE Mantel 150 mm vom Ende rundherum markieren.
EN Mark off a line around the circumference of the
pipe jacket 150 mm from the end.
10.04.2017 www.brugg.com Tel. +49 (0)5031 170-0
CASAFLEX MINI 5
- Technische Änderungen vorbehalten - Subject to technical change -
Montageanleitung / Instruction manual
8.
DE Streckgitter mit Schraubendreher
abhebeln und entfernen.
EN Lever off the expanding mesh using the
screwdriver and remove it.
7.
DE Schaum im Bereich der Überlappung des
Streckgitters (gegenüber den Überwachungs-
adern) entfernen.
EN Remove the foam from the expanding mesh
where it overlaps (opposite the monitoring leads).
10.
DE Anzeichnen 80 mm Rohrlänge.
EN Mark off 80 mm of the pipe length.
9.
DE Freilegen und xieren der Überwachungsadern
am Außenmantel. Kunststoff-Beilauf am Mantel
abschneiden.
EN Expose and secure the monitoring leads to the
outer jacket. Cut the plastic core off at the outer
jacket.
80 mm
10.04.2017 www.brugg.com Tel. +49 (0)5031 170-0
CASAFLEX MINI 6
- Technische Änderungen vorbehalten - Subject to technical change -
Montageanleitung / Instruction manual
12.
DE Schaum vom verbliebenen Rohr bis zum
Außenmantel entfernen.
Wellrohr nicht beschädigen!
EN Remove the foam from the remaining pipe as
far as the outer jacket.
Take care not to damage the corrugated pipe!
11.
DE Absägen der Rohrlänge.
EN Saw off the pipe length.
13.
DE Rohr von innen mit Heißluftfön anwärmen –
keine Anlauffarben!
Rohrende mit Edelstahl-Drahtbürste metallisch
blank säubern und entstauben.
Achtung: Rohroberäche ist Dichtäche!
EN Warm up the pipe from inside using the hot-air
blower – take care there is no discolouration!
Clean pipe end to the are surface with stainless
steel brush and remove all dust.
Attention: pipe surface = seal surface!
10.04.2017 www.brugg.com Tel. +49 (0)5031 170-0
CASAFLEX MINI 7
- Technische Änderungen vorbehalten - Subject to technical change -
Montageanleitung / Instruction manual
16.
DE Wellrohrende mit Halbrundfeile sauber entgraten.
Späne mit Pinsel entfernen.
Das Rohr außen und innen nicht beschädigen!
EN Remove any burs from the corrugated pipe end
using a half-round le until it is quite clean.
Remove llings using a brush.
Take care not to damage the pipe inside or outside!
15.
DE Flansch (b) am Druckring (1) gegenhalten! Well-
rohr am Flansch entlang gerade absägen.
Achtung! Druckring (1) nach Sägevorgang
weiter aufschrauben!
EN Hold the ange (b) tight in position against the
pressure ring (1). Saw the corrugated pipe off in a
straight line along the ange.
Attention! Screw the pressure ring (1) further on
after sawing is completed.
1
14.
DE Druckring (1) soweit auf das Wellrohr aufdrehen,
dass Maß L mit Flansch (b) eingestellt ist.
Maß L einhalten:
DN 20, DN 25 und DN 32 = 55 mm
DN 40 = 60 mm
EN Screw the pressure ring (1) onto the corrugated
pipe until it is adjusted to the measurement L
with the ange (b).
Keep to the measurement L:
DN 20, DN 25 and DN 32 = 55 mm
DN 40 = 60 mm
L
1
b
b
17.
DE Anschlussstück (3) bis zum Anschlag in
das Wellrohr schrauben.
EN Screw the connection piece (3) into the
corrugated pipe as far as is will go.
3
DE Montage der
CASAFLEX-Anschlussverbindung „MINI“
EN Installing the
CASAFLEX connecting unit “MINI”
10.04.2017 www.brugg.com Tel. +49 (0)5031 170-0
CASAFLEX MINI 8
- Technische Änderungen vorbehalten - Subject to technical change -
Montageanleitung / Instruction manual
18.
DE Druckring (1) mit Hilfe der Schiebehülse (2)
einstellen.
EN Adjust the pressure ring (1) with the help of the
slide-on sleeve (2).
19.
DE Schiebehülse (2) an der Kerbe anhalten und
Druckring (1) bis zur Schiebehülse (2) zurück-
schrauben – siehe Abb. 18.
Wichtig: genau arbeiten! Einstellung prüfen!
EN Hold the slide-on sleeve (2) on the notch and
screw the pressure ring (1) back to the slide-on
sleeve (2) – see Fig. 18.
Important: Work precisely! Check the setting
carefuly!
1
2
20.
DE Position des Druckringes (1) für weitere
Montage bis an den Schaum markieren.
EN Mark the position of the pressure ring (1)
up to the foam for the further installation.
1
21.
DE Schiebehülse (2) bis zum Anschlag aufschieben.
Achtung: Teil (1) darf sich während der Montage
nicht verdrehen.
EN Push on the slide-on sleeve (2) as far as it will go.
Attention: Component (1) must not be allowed to
twist during installation.
2
1
Markierung / Marking
1
2
1
2
Kerbe
Notch
Kerbe
Notch
Kerbe
Notch
10.04.2017 www.brugg.com Tel. +49 (0)5031 170-0
CASAFLEX MINI 9
- Technische Änderungen vorbehalten - Subject to technical change -
Montageanleitung / Instruction manual
25.
DE Schrauben (c) setzen.
EN Place all screws (c) in position.
24.
DE Schmiermittel (z.B. Graphit-/Kupferpaste)
auf das Gewinde und unter den Kopf der
Schraube (c) aufbringen.
EN Lubricate the screws on the thread and
under the screw heads (c) (e.g. with
graphite or copper paste).
26.
DE Alle Schrauben von Hand einschrauben.
Achtung: Beim Anziehen der Schrauben den Druck-
ring (1) nicht verdrehen; Markierung beachten!
EN Screw in all the screws by hand.
Attention: when tightening the screws take care not
twist the pressure ring (1); Observe the marking!
23.
DE Montagewerkzeug montieren:
Rundansch (b) vorn auf das Anschlussstück (3) und
geteilten Rundansch (a) hinter den Druckring (1)
auf das Wellrohr aufsetzen.
EN Assembling the installation set:
Push the round ange (b) over the connection piece
(3) and the split ange (a) onto the corrugated pipe
from the front behind the pressure ring (1).
1
a
c
c
3
b
kein Spalt
no gap
1
10.04.2017 www.brugg.com Tel. +49 (0)5031 170-0
CASAFLEX MINI 10
- Technische Änderungen vorbehalten - Subject to technical change -
Montageanleitung / Instruction manual
29.
Typ/Type Länge/Length
DN 20 L1ca. 95 mm
DN 25 L1ca. 100 mm
DN 32 L1ca. 105 mm
DN 40 L1ca. 110 mm
DE Fertige Anschlussverbindung.
Achtung: Druckring (1) zeigt maximal 0.5mm aus
der Schiebehülse (2).
EN The nished connection tting.
Attention: the pressure ring (1) may not protrude
more than 0.5 mm from the slide-on sleeve (2).
30.
DE Fertiger Anschluss beim Einbau von Muffen
im Erdreich. Beim Schweißanschluss die
Schweißnahtvorbereitung beachten
(Entfetten und Schleifen der Oberäche).
EN Connection in the soil when installing sleeves.
Observe the weld seam preparation when
welding. Attention! Degreasing and sanding the
surface.
28.
DE Montageansche bis zum Anschlag festziehen.
Danach Verpresswerkzeug demontieren.
EN Screw the mounting anges of the installation
set tight as far as they will go. Then dismantle
the compression set.
2
Druckring (1) max. 0.5 mm vorstehend
Pressure ring (1) max. 0.5 mm protruding
27.
DE Zum Verpressen die Schraubverbinder nachein-
ander gleichmäßig in mehreren Runden anziehen.
Achtung: Markierung beachten!
EN To press in the connection, tighten the connecting
srews uniformly one after the other in several
rounds. Attention: observe the marking!
1
ca. L1
10.04.2017 www.brugg.com Tel. +49 (0)5031 170-0
CASAFLEX MINI 11
- Technische Änderungen vorbehalten - Subject to technical change -
Montageanleitung / Instruction manual
31.
DE Verpackungseinheit
a 3 x Schrumpfschlauch klar, auf 130 mm Länge schneiden
b 3 x Schrumpfschlauch klar, auf 80 mm Länge schneiden
c 1 x Schrumpfschlauch schwarz, ca. 60 mm Länge
d 3 x Quetschverbinder
e 3-adriges Teonkabel
f 1 x Schrumpfschlauch schwarz, groß, ca. 120 mm Länge
EN Packing unit
a 3 x shrink sleeves, transparent, cut to 130 mm length
b 3 x shrink sleeves, transparent, cut to 80 mm length
c 1 x shrink sleeve, black, c. 60 mm length
d 3 x crimp connectors
e 3-wire Teon cable
f 1 x shrink sleeve, black, large, c. 120 mm length
33.
DE Auf die 150 mm langen Überwachungsadern drei
130 mm lange Schrumpfschläuche klar (a) bis an den
Schaum schieben und schrumpfen. Maße einhalten!
EN Push three 130 mm long transparent shrink sleeves onto
the 150 mm long monitoring leads (a) as far as the foam
and shrink on. Observe the dimensions scrupulously!
32.
DE Vom Außenmantel des Teonkabels 30 mm entfernen.
Ummantelung der drei Adern nicht beschädigen!
Einzeladern 8 mm abisolieren.
EN Strip off 30 mm of the outer jacket of the teon cable.
Do not injure the single wires! Strip off 8 mm of the
individual wires insulation.
34.
DE Auf die geschrumpften Schrumpfschläuche (a) drei 80 mm
lange Schrumpfschläuche klar (b) bis an den Schaum
schieben – nicht schrumpfen!
EN Push three 80 mm long transparent shrink sleeves (b)
onto the shrunk shrink sleeves (a) up as far as the foam –
do not shrink on!
DE Überwachungsadern verbinden
EN Connecting the monitoring leads
a
ab
a b c ed f
10.04.2017 www.brugg.com Tel. +49 (0)5031 170-0
CASAFLEX MINI 12
- Technische Änderungen vorbehalten - Subject to technical change -
Montageanleitung / Instruction manual
35.
DE Überwachungsadern 8 mm abisolieren. Einen 60 mm
langen Schrumpfschlauch schwarz (c) auf die grüne Über-
wachungsader schieben.
EN Strip off 8 mm of the monitoring lead insulation.
Push one 60 mm long shrink sleeve, black (c) onto the
green monitoring lead.
37.
DE Die Einzeladern des Teonkabels (e) mit Quetschverbinder
(d) farblich gleich an die Überwachungsadern anschließen.
Schrumpfschlauch schwarz (c) und zwei Schrumpfschläu-
che klar (b) mittig über die Quetschverbinder (d) und
schrumpfen.
EN Connect the individual wires of the Teon cable (e) with
the crimp connector (d) to the monitoring leads of the
same colour. Push the shrink sleeve, black (c) and two
shrink sleeves, transparent (b) up to the middle of the
crimp connectors (d) and shrink on.
36.
DE Quetschverbinder (d) setzen.
EN Position the crimp connector (d).
38.
DE Dritten Schrumpfschlauch klar (b) über den schwarzen
Schrumpfschlauch schieben und schrumpfen.
EN Push the third shrink sleeve, transparent (b) over the black
shrink sleeve and shrink on.
c
d
d
b
e
c
b
10.04.2017 www.brugg.com Tel. +49 (0)5031 170-0
CASAFLEX MINI 13
- Technische Änderungen vorbehalten - Subject to technical change -
Montageanleitung / Instruction manual
40.
DE g Geteilte Schutzkappe
h Spannring klein
i Spannring groß
EN g Split protective cap
h Small clamping ring
i Large clamping ring
41.
DE Die Bohrungen in der Schutzkappe (g) müssen oben
und unten positioniert sein. Überwachungsadern mit
Verbindungen lose in der Kappe positionieren und das
Teonkabel (e) herausführen. Anschlag in der Schutzab-
deckung (g) gegen die Schiebehülse (2) schieben.
EN The through holes in the protective cap (g) must be cor-
rectly positioned above and below. Position the monitoring
leads loosely in the protective cap and lead out the Teon
cable (e). Push the limit stop of the protective cap (g) up
against the slide-on sleeve (2).
2
42.
DE Schutzkappe (g) gerade aneinandersetzen.
Spannringe (h, i) so setzen, dass die Schrauben
90° versetzt zum Spalt und gegenüberliegend
positioniert sind.
EN Place the halves of the protective cap (g) together
taking care to align them straight. Place the
clamping rings (h, i) so that the screws are offset
at 90° to crack on opposite sides.
DE Montage der
CASAFLEX-Schutzabdeckung
EN Installing the
CASAFLEX protective cap
g
g
g
h
i
39.
DE Schrumpschlauch schwarz, groß (f) über das Teon-
kabel (e) schieben und min. 20 mm auf dem Teon-
kabel (e) überlappend schrumpfen.
Achtung: Die Quetschverbinder müssen vorher
einzeln abgeschrumpft sein – siehe Bild 37.
EN Push the shrink sleeve, black, large (f) over the
Teon cable (e) and shrink till it overlaps at least
20 mm onto the Teon cable (e).
Attention: the crimp connectors must be individually
shrunk beforehand – see Fig. 37.
f
e
g
hi
e

Other manuals for CASAFLEX UNO

1

Popular Heating System manuals by other brands

Viessmann VITODENS operating instructions

Viessmann

Viessmann VITODENS operating instructions

Salda RIS EKO 3.0 400 PE 0.9 MOUNTING AND INSTALLATION INSTRUCTION

Salda

Salda RIS EKO 3.0 400 PE 0.9 MOUNTING AND INSTALLATION INSTRUCTION

Girafus V-15 manual

Girafus

Girafus V-15 manual

Amana APG 16 M Series installation instructions

Amana

Amana APG 16 M Series installation instructions

flowair OXeN user manual

flowair

flowair OXeN user manual

Hitachi UTOPIA R32 Series Installation & operation manual

Hitachi

Hitachi UTOPIA R32 Series Installation & operation manual

Laars NEOTHERM NTH User information

Laars

Laars NEOTHERM NTH User information

SolutionAir elicent REC-Duo 100 instruction manual

SolutionAir

SolutionAir elicent REC-Duo 100 instruction manual

Salda RIS 400HW 3.0 Technical data

Salda

Salda RIS 400HW 3.0 Technical data

Truma Combi E operating instructions

Truma

Truma Combi E operating instructions

EBECO T-18 installation instructions

EBECO

EBECO T-18 installation instructions

ALLTEC ExoTHERM manual

ALLTEC

ALLTEC ExoTHERM manual

Energotech EnergoCassette ENC 300 Fitting instructions

Energotech

Energotech EnergoCassette ENC 300 Fitting instructions

ubbink Ubiflux Vigor W225 installation instructions

ubbink

ubbink Ubiflux Vigor W225 installation instructions

Lampoassa VMI 6-17 Instructions for use, installation and maintenance

Lampoassa

Lampoassa VMI 6-17 Instructions for use, installation and maintenance

TM SURETHERM 30X quick start

TM

TM SURETHERM 30X quick start

Julabo F38-ME operating manual

Julabo

Julabo F38-ME operating manual

Hotstart OXM Installation & operation manual

Hotstart

Hotstart OXM Installation & operation manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
