Bruno Sohnle RONDA 4210.B User manual

O
perating
g
uide
Certificate and Operating Guides for Watches
with the Following Movements:
rOnda 4210.B
rOnda 4220.B
rOnda 5020.B
rOnda 5040.B
rOnda 5040.C
rOnda 5050.C
rOnda 7003.L
rOnda 7004.n
rOnda 7004.p
rOnda 8040.B
rOnda 8040.n

C
ertifiCate
We congratulate you on your Bruno Söhnle timepiece and are sure you
will derive much satisfaction and pleasure from it. Bruno Söhnle watches
are made and tested by our qualified craftsmen in Glashütte/Saxony, a
town with a long history of watchmaking.
With this quality passport we guarantee the flawless operation of your
Bruno Söhnle watch. Any defects that may occur are covered by our
24-month warranty from the date of purchase.
Bruno Söhnle GmbH
Uhrenatelier Glashütte
Dresdner Straße 14 01768 Glashütte/Saxony Germany
Fon [phone] Fax [phone]
e-mail: [e-mail]
www.brunosoehnle.de
Bruno Söhnle

Q
uaLity in
p
reCisiOn
Visible quality
All watches made by Bruno Söhnle bear the Glashütte mark of origin;
guaranteeing proven German quality. The centrepiece of every Bruno
Söhnle watch is a Swiss Ronda quartz clock, which is finished in Glashütte.
The quartz clock ensures complete accuracy, can control a numerical or
retrograde calendar, and can simultaneously run a second time zone.
Slim stainless steel casing
We exclusively use stainless steel and high-quality, skin-friendly surgical
steel (316L) for the casing. The casing is characterised by its hardness,
the high level of comfort it offers wearers, and its low nickel content.
One further special feature of Bruno Söhnle watches is that some models
in our collection are provided with a slim-line casing, which offers a snug,
superbly flat fit around the wearer’s wrist.
Sapphire glass – Highly resistant to scratches
Sapphire glass is the strongest type of glass used in watches. The high
level of light penetration means that the face always appears as if in
bright light, which in turn results in clearly improved readability.
Furthermore, sapphire glass is highly resistant to scratches, meaning
that even the most delicate parts of your watch are always protected. All
sapphire glass is non-reflective on the interior surface.

Q
uaLity in
p
reCisiOn
Crown and casing partially (crown) screwed in place and waterproof
Improved waterproofing and increased shock resistance – these are the
requirements for a watch that is to be used day in, day out. Bruno Söhnle
watches ensure these features with their screwed in crowns. A screw
thread is used to fasten the crown tightly to the casing, and in some models
even the bottom of the casing is screwed down, rather than consisting of
a spring lid, thus making it considerably more watertight.
Watchstrap links screwed together and sturdy
Some models in the collection see the links on the watchstraps screwed
together.
Watchstraps with closing clasps
Bruno Söhnle watches are characterised by their classic design and their
high functionality. The clasps use hinges to fasten both straps together.
Putting the watch on and taking it off is far easier as the watchstrap does
not fully open. This also has the advantage of protecting the watchstrap
and thus giving it a longer lifespan.

Q
uaLity in
p
reCisiOn
The casing finish
Bruno Söhnle watches are classics - they should stay with you for a
long time. This longevity is ensured by both the watch mechanism and
by the stainless steel or titanium casing, which is manufactured with the
greatest precision. If you choose a gold-plated watch you can be certain
that your Bruno Söhnle will keep its gold brilliance virtually forever. The
highest quality gold plating, with 10 microns (23 ct. gold), and the PVD
coating both represent the highest level of quality and a natural gold shine.
Chronographs: Make time stand still
With the Bruno Söhnle chronograph you can stop time.These chronographs
feature two extra buttons alongside the normal time display. Pressing
these buttons activates the stopwatch function so you can stop time.
A separate hand system is used to display the stopwatch.
GMT - For life in two time zones
Watches that can display a second time zone are especially popular with
regular flyers. And with our ‘Milano’ watches you will know both the local
time and the time in the place that you have just left, whether that be home
or somewhere else in the world. Set your 'Milano’ watch once and it will
always keep you informed of the correct time, wherever you are in the world.

g
uarantee
Bruno Söhnle offers a 24-month warranty against faulty materials or work-
manship. This product has been manufactured and tested using the most
advanced methods. The technology and materials used in manufacture
are of the highest quality. Should a fault in manufacture or materials occur
within the warranty period, it will be rectified free of charge by your BS
dealer or the manufacturer. The extent of the indemnity is limited to the
manufacturing cost of this model. The warranty excludes all claims for
compensation, replacement or refund.
Excluded from the warranty are defects arising from improper treatment
or tampering by third parties. Also excluded are breakage of the glass,
spring pins or crown or damage caused by accidents and normal wear
and tear. Straps, bracelets, spring pins and batteries are not covered
by the warranty.
In order to provide proof of the warranty claim, please enclose the com-
pleted certificate of sale with the watch. The certificate of sale will be
recognised only if it has been properly completed by the specialist dealer.
The watch and document are dispatched at the sender’s risk.

g
uarantee
Water resistant to 3 bar:
This Bruno Söhnle watch has been tested to the stated atmospheric pres-
sure of 3 bar. These watches are protected against surface contact with
water. Avoid immersing in water and heavy perspiration.This level of water
resistance is not recommended for swimming or other water sports.
Water resistant to 5 bar:
This Bruno Söhnle watch has been tested to the stated atmospheric
pressure of 5 bar. The glass and seals withstand this pressure. This watch
may be worn for swimming. Have your dealer check the glass, crown and
seals once a year and after every battery replacement in order to ensure
lasting water resistance.
Water resistant to 10 bar:
These watches have been tested up to an atmospheric pressure of 10 bar
and are the ideal partner for all types of water sports (excluding diving)
thanks to the thickness of the glass and the seals. In the case of intensive
use or intense perspiration it is very important to have a check carried out
annually to ensure lasting water resistance. Also let the watch be checked
after each battery change to make sure that all elements which contribute
to water resistance are still in good condition.

g
uarantee
Water resistant to 20 bar:
These watches have been tested up to an atmospheric pressure of
20 bar and are the ideal partner for all types of water sports thanks to
the thickness of the crystal and the seals. In the case of intensive use
or intense perspiration it is very important to have a check carried out
annually to guarantee permanent water resistance. Also let the watch be
checked after each battery, to confirm that all elements which contribute
to the water resistance are still in good condition.

Description of Display and Operating Elements
17
Date Indicator
Second Hand
Hour Hand
Minute Hand
Crown
Small
Minute Hand
Small
Hour Hand Push Button
Display Elements
Control Elements
O
perating
g
uide
fOr MOveMent 4210.B
Attention!
Please remember that your watch may be
fitted with a screw-down crown or rather
with a screw-held button.

Setting the Time
1Pull crown into Position III
(hands stop moving)
2Turn crown until the current
time is displayed as 07:45
3Push crown into Position I*
Note
* To display the time to the
exact second, pull out the
crown 1 the moment the
second hand is in the 60
position. Once the hours and
minutes have been set, push
the crown back to Position I
at precisely the zero second
of the minute 3.
17
Crown
17

I II III
Second Hand

I II III
Crown
O
perating
g
uide
fOr MOveMent 4210.B

Rapid Date Setting
1Pull crown into Position II.
(hands continue moving)
2Turn crown until the current
date (here the 7th) appears.
3Push crown back into
Position I.
Note
When setting the date during the
date changeover phase (21:00 to
24:00) it is necessary to set it for
the next day.
Performing the rapid date change
too quickly can result in an erro-
neous setting.
Switching the date from 01 to 31
(Crown Position II) restores the
synchronisation.
31
Crown
07

I II

I II
Crown
O
perating
g
uide
fOr MOveMent 4210.B

Setting the Date
and Time after Changing
the Battery
Example:
– Date and time on watch:
17th / 01:25
– Current date and time:
21st / 19:30
1Pull crown into Position II.
(hands continue moving)
2Turn crown until the date
before the current date (20)
is displayed.
17
Crown
20

I II

I II
O
perating
g
uide
fOr MOveMent 4210.B

3Pull crown into Position III*.
(hands stop moving)
4Turn crown until the current
date (21) is displayed.
5Continue turning crown**
until the current time of 19:30
is set.
6Push crown back into
Position I.
Notes
*To set the time to the exact
second see instructions in
Setting the Time section
** Observe 24-hour rhythm
20
Crown
21


I II

I II III
III

O
perating
g
uide
fOr MOveMent 4210.B

Setting the Second Time
Zone
The small dial is used to display
the time in a freely selectable
second time zone.
1To activate: Press push
button for at least 2 seconds.
When the small minute hand
advances by 1 minute, the
mode is active.
2Each short push:
(less than 1 sec.) advances
the time by a minute.
Each moderate pushes:
(1–2 sec.) advances the time
by an hour.
A long push:
(longer than 2 sec.) advances
the time zone continually until
the push button is released.
Note
If the push button is not touched
for 10 seconds, the setting mode
is deactivated. To reactivate
see 1.
20

Second
Time Zone
O
perating
g
uide
fOr MOveMent 4210.B

Description of Display and Operating Elements













O
perating
g
uide
fOr MOveMent 4220.B
Attention!
Please remember that your watch may be
fitted with a screw-down crown or rather
with a screw-held button.

Setting the Time
1Pull crown into Position III
(hands stop moving)
2Turn crown until the current
time is displayed as 07:45
3Push crown into Position I*
Note
* To display the time to the
exact second, pull out the
crown 1 the moment the
second hand is in the 60
position. Once the hours and
minutes have been set, push
the crown back to Position I
at precisely the zero second
of the minute 3.




 


 

O
perating
g
uide
fOr MOveMent 4220.B

Rapid Date Setting
1Pull crown into Position II.
(hands continue moving)
2Turn crown until the current
date (here the 7th) appears.
3Push crown back into
Position I.
Note
When setting the date during the
date changeover phase (21:00 to
24:00) it is necessary to set it for
the next day.
Performing the rapid date change
too quickly can result in an erro-
neous setting.
Switching the date from 01 to 31
(Crown Position II) restores the
synchronisation.








O
perating
g
uide
fOr MOveMent 4220.B

Setting the Date
and Time after Changing
the Battery
Example:
– Date and time on watch:
17th / 01:25
– Current date and time:
21st / 19:30
1Pull crown into Position II.
(hands continue moving)
2Turn crown until the date
before the current date (20)
is displayed.








O
perating
g
uide
fOr MOveMent 4220.B

3Pull crown into Position III*.
(hands stop moving)
4Turn crown until the current
date (21) is displayed.
5Continue turning crown**
until the current time of 19:30
is set.
6Push crown back into
Position I.
Notes
*To set the time to the exact
second see instructions in
Setting the Time section
** Observe 24-hour rhythm





 




O
perating
g
uide
fOr MOveMent 4220.B
