BRYAN BOILERS RV SERIES FORCED DRAFT
KNOCKDOWN STEAM BOILERS
Form # >> 2169
Date >> 3/16/05
BOILER MODEL RV450 RV500 RV550 RV600 RV700 RV800
MBH 4,500 5,000 5,500 6,000 7,000 8,000
(KW) 1,318.5 1,465.0 1,611.5 1,758.0 2,051.0 2,344.0
MBH 3,600 4,000 4,400 4,800 5,600 6,400
(KW) 1,054.8 1,172.0 1,289.2 1,406.4 1,640.8 1,875.2
HP 108 120 131 143 167 191
(KW) 1,058 1,176 1,284 1,401 1,637 1,872
INCHES 1.50 1.50 1.50 1.50 1.50 1.50
(CM) 3.81 3.81 3.81 3.81 3.81 3.81
NUMBER OF TUBES 61 67 75 81 95 109
PRESSURE VESSEL
GAL 198 216 237 255 294 333
(L) 749.4 817.6 897.0 965.2 1,112.8 1,260.4
SQ FT 544 597 688 722 847 972
(SQ M) 50.6 55.5 63.9 67.1 78.7 90.3
LBS/HR 3,711 4,124 4,536 4,948 5,773 6,598
(KG/HR) 1,683.5 1,870.5 2,057.6 2,244.6 2,618.7 2,992.8
LBS 10,261 11,611 12,312 13,622 15,512 17,392
(KG) 4,654.5 5,266.9 5,584.5 6,178.8 7,036.2 7,889.1
LBS 8,610 9,810 10,335 11,495 13,060 14,615
(KG) 3,905.5 4,449.8 4,688.0 5,214.1 5,924.0 6,629.4
INPUT
OUTPUT*
BOILER HORSEPOWER
TUBE DIAMETER
VOLUME
HEATING SURFACE
STEAM OUTPUT*
OPERATING WEIGHT
SHIPPING WEIGHT
* Output based on nominal 80% of input. Actual combustion efficiencies will vary and are fuel dependant.
