Bryan Boilers BE Series User guide

BE Series Electric Boiler
150 psi Water Design 30 kw to 390 kw
EFFECTIVE DATE: 3-1-04
REPLACED DATE : 4-13-83
1. OPERATOR 5. POWER PANEL 9. TEMPERATURE GAUGE
2. PROBE TYPE LWCO 6. CONTROL PANEL 10. ELEMENT ACCESS
3. RELIEF VALVE 7. STEP CONTROLLER 11. DRAIN
4. AQUASTAT (HIGH LIMIT) 8. PRESSURE GAUGE 12. STRUCTURAL STEEL LEGS
WATER WATER
Vessel Dimensions Power Panel Voltage Inlet Outlet Vessel Dimensions Power Panel Voltage Inlet Outlet
length width height 208-230/3/60 380,460-575 length width height 208-230/3/60 380,460-575
KW AB C DE DEF G KW ABCDE DEFG
30 48 20 32 30 36 20 24 2 2 180 48 28 40 30 66 30 36 3 3
45 48 20 32 30 36 20 24 2 2 195 48 28 40 30 66 30 48 3 3
60 48 20 32 30 36 20 24 2 2 210 76 28 40 N/A N/A 30 48 3 3
75 48 20 32 30 36 20 24 2 2 240 76 28 40 N/A N/A 30 48 3 3
90 48 28 40 30 36 20 30 3 3 270 76 28 40 N/A N/A 30 66 3 3
105 48 28 40 30 48 30 36 3 3 300 76 28 40 N/A N/A 30 66 3 3
120 48 28 40 30 48 30 36 3 3 330 76 28 40 N/A N/A 30 66 3 3
135 48 28 40 30 66 30 36 3 3 360 76 28 40 N/A N/A 30 66 3 3
150 48 28 40 30 66 30 36 3 3 390 76 28 40 N/A N/A 30 66 3 3
165 48 28 40 30 66 30 36 3 3
