Bryan Boilers BE Series User manual

BE Series Electric Boiler
15# Steam Design
30 kw to 390 kw
EFFECTIVE DATE: 3-1-04
REPLACED DATE: 3-16-82
1. OPERATOR 5. POWER PANEL 9. LWCO/PUMP CONTROLLER
2. PROBE TYPE LWCO 6. CONTROL PANEL 10. ELEMENT ACCESS
3. RELIEF VALVE 7. STEP CONTROLLER 11. DRAIN
4. PRESSURETROL 8. PRESSURE GAUGE 12. STRUCTURAL STEEL LEGS
BES Series Fluid Cap. Aprox.
Vessel Dimensions Power Panel Voltage Inlet Outlet Oper. Level Ship
length width height 208-230/3/60 380-460-575/3/60 Gallons WT.
KW ABCDE DEFGWater Steam
30 48 20 32 20 24 20 24 2 2 24 13 775
45 48 20 32 20 30 20 24 2 2 24 13 775
60 48 20 32 30 36 20 24 2 2 24 13 775
75 48 20 32 30 36 20 30 2 2 24 13 850
90 48 28 40 30 36 20 30 3 3 52 32 1000
105 48 28 40 30 48 30 36 3 3 52 32 1025
120 48 28 40 30 48 30 36 3 3 52 32 1050
135 48 28 40 30 66 30 36 3 3 52 32 1300
150 48 28 40 30 66 30 36 3 3 52 32 1325
165 48 28 40 30 66 30 36 3 3 52 32 1350
180 48 28 40 30 66 30 36 3 3 52 32 1400
195 48 28 40 30 66 30 48 3 3 52 32 1450
210 76 28 40 N/A N/A 30 48 3 3 105 69 1950
240 76 28 40 N/A N/A 30 48 3 3 105 69 2000
270 76 28 40 N/A N/A 30 66 3 3 105 69 2450
300 76 28 40 N/A N/A 30 66 3 3 105 69 2500
330 76 28 40 N/A N/A 30 66 3 3 105 69 2550
360 76 28 40 N/A N/A 30 66 3 3 105 69 2600
390 76 28 40 N/A N/A 30 66 3 3 105 69 2650
