Bticino HA/HB/L4619 User manual

1
HA/HB/L4619
24/03/2016BT00056-c-
4
1
3
2
L4619
HA/HB4619
115 mm
4 mm 4 mm 10 mm
10 mm100 mm100 mm
92 mm 93 mm
70 mm
EN
1. Reset key
2. LED: if the TEST or RESET pushbutton is press for 1 second, the LED will normally
flash twice; if the battery is exhausted the LED will only flash once
3. Flooding probe
4. TEST pushbutton
Radio flooding
detector
LegendDimensional data
Power supply: Battery 3 V type CR2032
Operating temperature: 5 – 40°C
Minimum battery duration: 2 years
Radio frequency: 868 MHz
Range: 100 metres free field
(metal, concrete walls and metal plates reduce coverage)
Modulation: FSK
Technical data
Description
This device generates an alarm signal when the contacts of the corresponding sensor make
contact with water.
The signal is then processed by the alarm central unit, which activates the siren and the
Telephone communicator (if installed), for sending a telephone message.
Better protection can be ensured by installing a relay actuator within the Burglar-Alarm
system, which will order an electrovalve to shut off the main water supply in case of flooding.
Two front pushbuttons can be used to interrupt the alarm signalling and to test the operation
of the sensor.
Items HA/HB4619 and L4619 comply with the essential requirement of directive 1999/5/CE as
they meet the following standards:
- ETSI EN301 489-3
- ETSI EN300 220-3
Year of approval of the CE mark in accordance with the above directive: 2007
Conformity declaration
Flooding detector HA4619 with
front cover plate
Front view

2
24/03/2016BT00056-c-
HA/HB/L4619
Z
N
AUX
MOD
Z MODN AUX
EN
The device requires allocation of the zone it belongs to, the progressive number of the
sensors within the same zone, and the setting of the detection mode, as well as the
possible allocation of an auxiliary prealarm channel.
WARNING: The conguration operations must be performed with the battery
disconnected
Z
This congurator assigns the number of the appropriate zone to the detector.
Congurator 1 assigns zone 1 to the detector, congurator 2 assigns zone 2 and so on to a
maximum of 8 zones Congurator 9 assigns the device to the group of auxiliary devices.
N
N= 1 – 9 Progressive number in the zone
MOD
Do not congure.
AUX
The congurator in the AUX socket activates the auxiliary function of the corresponding
auxiliary channel. It therefore enables controlling auxiliary actuator devices, provided
that they have been congured using the same auxiliary channel.
Note: to complete the activations using the relay actuator type HD/HC/ HS/L/N/NT4614
and AM5794 see the appropriate technical sheet.
Pairing remote controls
1. Switch the system to“maintenance”mode.
2. Press the programming pushbutton of the radio receiver for five seconds, until the
red LED comes on.
3. Press the RESET key for 5 seconds.
4. If the pairing of the device has been performed correctly, the red LED of the radio
receiver will go off.
If this does not happen, repeat the procedure from step 3. If the LED flashes, it
means that the device memory is full.
5. To pair other devices, repeat from step 2.
6. Perform self learning of the system from the central unit.
7. Program the remote controls on the central unit.
8. Exit“maintenance”mode.
Configuration
Radio flooding
detector
Internal view
Cancelling remote controls
1. Switch the system to maintenance mode.
2. Remove the power supply from the receiver.
3. Press and hold the programming pushbutton while reconnecting the power supply
to the radio receiver.
4. After 5 seconds the LED flashes orange. If the pushbutton is released at this time,
only the remote controls are cancelled.
5. After releasing the pushbutton, the LED becomes fixed orange.When the LED goes
off, cancellation has been completed.
6. Perform self-learning of the system from the central unit and exit“maintenance”mode.
