Bticino Smarther X8000W User manual

1
N
L
5(2) A
HEATING
COOLING
NC
C
NO
NC
C
NO
110 - 240 V 50/60 Hz
2 W max.
X8000W
SX8000W
0 490 37
ST-00000298-
4
5
5
6
7
89101112
2 31
13
4
7
A B C
126 mm 87 mm 28,1 mm
B
A C
05/06/2018EN
Legend
1. Touch screen display
2. Temperature/humidity display
3. “Boost”mode indicator
4. Wi-Fi connection key
5. Keys for temperature setting
6. Boost mode activation
7. Reset key (keep pressed for 10”, it restores the factory settings)
8. Manual mode indicator
9. ON heating indicator
10. ON cooling indicator
11. “OFF thermostat”indicator;
7 °C temperature (antifrost) in heating function;
35 °C temperature (heat protection) in cooling function.
12. Wi-Fi connection indicator
13. Connection clamps
Front view
Rear view
The Smarther connected electronic thermostat, together with the dedicatedThermostat
App, is a device which allows you to adjust and monitor the temperature in the rooms
locally or remotely. The temperature level can be set locally for manual operation and
the Boost mode can be activated. The Boost forces the switching on of the system for
a limited time (30, 60 or 90 minutes) independent of the measured and programmed
temperature. It can also display the temperature and humidity measured.
Thanks to its Wi-Fi connection, all the programming and most of the functions are
performed simply and intuitively using the App in the home or remotely.
Smarther can be installed on the wall, using screws and dowels suitable for the
installation surface.
Description
Smarther connected thermostat
Power supply 110 – 240 Vac , 50/60Hz
Absorption 2 W max
Maximum cable section 1 x 1.5mm2
Operating temperature 5 – 40 °C
Temperature set-point 5 – 40 °C; increase of 0.5 °C
Type of activation 1BU
Pollution level 2
Rated pulse voltage 4 kV
Wireless device in compliance with 802.11b/g/n standard, frequency 2.4 – 2.4835 GHz,
transmission power < 20 dBm.
WPA/WPA2 safety protocol.
Technical data
Dimensional data

2
X8000W
SX8000W
0 490 37
ST-00000298-
1
2
3
5
4
67
8
05/06/2018EN
Installation
Smarther connected thermostat
Caution: avoid fastening the base on irregular surfaces and excessive screw tightening,
in order to prevent any base distortion that may compromise the correct installation of
the device.
The front must be tightly fixed to the base and the fastening clip should lock into place.
Once the installation has been done, wait for 2 hours before checking the read
temperature.

3
X8000W
SX8000W
0 490 37
ST-00000298- 05/06/2018EN
Smarther connected thermostat
Wiring diagrams
System only for heating with clean contact (e.g. boiler agreement)
System only for heating with load to be controlled to the network voltage (e.g. 230Vac solenoid valve)
Heating and cooling* with floor system
Heating and cooling* with different systems
C
NC
L
N
NC
NO
C
NO
TO THE HEATING SYSTEM (CLEAN CONTACT)
(ON/OFF)
110 – 240 Vac, 50/60 HZ
C
NC
L
N
NC
NO
C
NO
110 – 240 Vac, 50/60 HZ
TO THE HEATING SYSTEM
(LOAD TO BE CONTROLLED TO THE NETWORK VOLTAGE)
C
NC
L
N
NC
NO
C
NO
110 – 240 Vac, 50/60 HZ
TO THE HEATING SYSTEM
TO THE COOLING SYSTEM
C
NC
L
N
NC
NO
C
NO
110 – 240 Vac, 50/60 HZ
TO THE HEATING AND COOLING SYSTEM
WITH FLOOR SYSTEM
Heating system with Fil Pilote radiators
C
NC
L
N
NC
NO
C
NO
**
Use item
0 371 54
Fil Pilote
radiator
* The cooling function can be activated only via App.
** For the correct operation of Smarther during use with Fil Pilote radiators, the highest COMFORT temperature possible must be set on the radiator.
It is however not possible to reach a higher temperature than the COMFORT temperature set on the radiator, irrespective of the Smarter setpoint.
Switch the power supply
OFF before any work on
the system

4
X8000W
SX8000W
0 490 37
ST-00000298- 05/06/2018EN
Smarther connected thermostat
Thermostat App and technical documentation
Scan the QR code or look for“Thermostat”to download the Thermostat App in Apple Store or Google Play
Download all the technical documentation about Smarther
