Buffalo BS1061B User manual

BS1061B
Bar Stool Assembly Instructions
Max Weight Capacity 330 Lb
READ ALL INSTRUCTIONS AND WARNINGS BEFORE USING THIS PRODUCT.
This manual provides important information on proper operation & maintenance. Every effort has been
made to ensure the accuracy of this manual. These instructions are not meant to cover every possible
condition and situation that may occur. We reserve the right to change this product at any time without
prior notice.
IF THERE IS ANY QUESTION ABOUT A CONDITION BEING SAFE OR UNSAFE,
DO NOT USE THIS PRODUCT!
DO NOT RETURN THIS PRODUCT TO THE RETAILER - CONTACT CUSTOMER SERVICE.
If you experience a problem, have questions or need parts for this product, visit our website
http://www.amerihomebrand.com or call Customer Service at 1-888-287-6981, Monday-Friday,
8 AM - 4 PM Central Time, or email : [email protected]. A copy of the sales receipt is required.
KEEP THIS MANUAL, SALES RECEIPT & APPLICABLE WARRANTY FOR FUTURE
REFERENCE.
201306
Support
Cylinder (B)
Base
(D)
Seat (E)
Handle
Foot Cap
(G)
Foot
Rest
(C)
Remove Black Cap
Discard Before Assembly
ATTENTION!

ASSEMBLY INSTRUCTION
1. Use a hex wrench to attach the Base Plate
and Leg to the underside of the chair seat with
the provided hex bolts.
2A. A Black Cap protects the hydraulic
mechanism on the Support Cylinder.
2B Remove the Black Cap and discard it
before assembly. The Orange hydraulic
button will become visible.
3. Insert the Support Cylinder into the Base
Plate and Leg and press firmly.
4. Set the Foot Cap over the hole in the
Base. Insert the thicker end of the Support
Cylinder into the center hole of the Base,
and press down FIRMLY.
5. Guide the open end of the barstool assembly
over the Support Cylinder and firmly press down
on the seat.
To raise the barstool, grasp the Handle and pull upward without applying any
weight. To lower, raise the handle upward and apply weight to the seat.
DISASSEMBLY INSTRUCTIONS
Turn the stool upside down. Hit the Metal Clip
several times located in the exact center of the
bottom of the Base with a rubber mallet to
disengage the locking mechanism. The Base will
separate from the Seat Top and Support Cylinder.
To remove the Seat Top from the Support Cylinder, turn the stool upside
down, and strike the edge of the Support Cylinder several times where it
meets the support. The Support Cylinder and Base Plate and Leg will
separate with applied force.
4
5
1
2A
2B
Metal Clip
3
