G20 INFINIUM
Service Manual
Created: 02 July 2015
20-Watt Class-A Tube Amplifier Head with INFINIUM
Tube Life Multiplier, MORPH EQ and Reverb
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
PCB Schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Exploded Drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

G20 INFINIUM
Specifications
- Hand-built 20-Watt Class-A amplifier driven by 2 x ECC83 and 2 x EL34 tubes
- Revolutionary INFINIUM Tube Life Multiplier technology:
- Extends the life of your amplifier’s expensive power tubes up to 20 times
- Provides incredible reliability and consistent tone over the complete lifespan of your tubes
- No need for expensive matched tube sets
- Allows you to mix and match any combination of compatible tube types and brands
- Monitors performance of the power tubes continuously and displays defective tubes to allow for easy
replacement
- Revolutionary MORPH EQ to seamlessly sweep between USA and British EQ-style tone
- Amazing classic push-pull power amp design for vintage tonal character
- High-definition reverb with dedicated Reverb control
- Heavy-duty footswitch for Channel / Reverb selection included
- Speaker-emulated output with 1 x 12 or 4 x 12 voicing option
- Impedance switch (4, 8 and 16 Ohms) to match virtually any speaker cabinet
- Effects loop with effects level switch
- Modern-style look and feel
- 3-Year Warranty Program*
- Designed and engineered by BUGERA Germany

PCB SchematicG20 INFINIUM
Page 3

PCB SchematicG20 INFINIUM
Page 4

PCB SchematicG20 INFINIUM
Page 5

PCB SchematicG20 INFINIUM
Page 6

PCB SchematicG20 INFINIUM
Page 7

PCB SchematicG20 INFINIUM
Page 8

Parts ListG20 INFINIUM
Page 9
Hi Pcb Assemblies
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC Q05-A5I00-07609 A05-A5I00-07609 PCB ASSEMBLY;P0A5I;REV:A;HAND INSERT;NO:828100
2 1.0000 PC Q05-B4001-00105 A05-B4001-00105 PCB ASSEMBLY;P0B40;PCB:1;REV:E;HI;MAIN
3 1.0000 PC Q05-B4002-00104 A05-B4002-00104 PCB ASSEMBLY;P0B40;PCB:2;REV:D;HI;REAR
Cable
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC A81-00000-56986 WIRE HARNESS;AWG:26;UL2468;2 MM;14;COMMON;PIN1
MARKING;70 MM;P1018-14P;A2006H
[P0B40:2: {1.0}(X8)]
2 1.0000 PC A81-27070-22822 WIRE HARNESS;LENGTH:270mm;ZEE;POLES:2;AWG:18;UL1015;ONE
SIDE 7mm STRIP/TINNED;PIN1 RD/OTHERS BK
3 1.0000 PC Q89-50031-04316 A89-50031-04316 FOOTSWITCH
CABLE;FS112;LENGTH:5000mm;POLES:3;COLOR:BLK;SPEC.NO:04316
4 1.0000 PC Q76-15222-06417 A76-15222-06417 CABLE;AC-
CORD;W/POLYBAG;LENGTH:152cm;AWG:18;VERSION;UL;SPEC.NO:0
6417
(UL)
5 1.0000 PC Q76-15212-03119 A76-15212-03119 CABLE;AC-CORD;W/POLYBAG;LENGTH:152cm;H05VV-F 3G
0.75MM2;VERSION;EU;SPEC.NO:03119
(EU)
6 1.0000 PC Q76-15042-05624 A76-15042-05624 CABLE;AC-CORD;W/POLYBAG;LENGTH:150cm;H05VV-
F3G0.75MM2;VERSION;UK;SPEC.NO:05624
(UK)
7 1.0000 PC Q76-00000-13573 A76-00000-13573 CABLE;AC-CORD;3;AR;1500 MM;Plug + Connector:321+730;H05VV-F
3G0.75
(AR)
8 1.0000 PC Q76-00000-05305 A76-00000-05305 CABLE;AC-CORD;3;BR;1500 MM;Plug + Connector:375+730;H05VV-F
3G0.75
(BR)
9 1.0000 PC Q76-18050-47490 A76-18050-47490 CABLE;AC-CORD;LENGTH:180cm;VERSION:SAA;PLUG:HE105
ISOLATED;SAA H05VV-F 3x0.75mm2;CONN.HP-3;SPEC.NO:47490
(SAA)
10 1.0000 PC Q76-15032-55649 A76-15032-55649 CABLE;AC-CORD;CLASS
II;W/POLYBAG;JAPAN;LENGTH:150cm;POLES:3;APPROVAL:PSE;JS15S
3 + VCTF 3x0.75mm2 + V1528
(HM, SH)

Parts ListG20 INFINIUM
Page 10
Capacitor
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 2.0000 PC CAP E;100uF;10V;PITCH:2mm5;5mm x 11mm;VERTICAL 12.7-15-
9mm
[P0B40:1: {2.0}(C85,C91)] *NOT available in DP
2 26.0000 PC CAP E;47uF;25V;PITCH:2mm5;5mm x 11mm;VERTICAL 12.7-15-9mm [P0B40:1: {17.0}(C14,C18,C22,C27,C30-C31,C59-
C60,C63,C68,C73,C79,C92-C93,C122,C155,C175)]
*NOT available in DP
3 2.0000 PC CAP E;1uF;50V;PITCH:2mm5;5mm x 11mm;VERTICAL 12.7-15-9mm [P0B40:1: {2.0}(C11,C64)] *NOT available in DP
4 1.0000 PC CAP E;2uF2;50V;PITCH:2mm5;5mm x 11mm;VERTICAL 12.7-15-9mm [P0B40:2: {1.0}(C38)] *NOT available in DP
5 1.0000 PC CAP E;4uF7;50V;PITCH:2mm5;5mm x 11mm;VERTICAL 12.7-15-9mm [P0B40:1: {1.0}(C94)] *NOT available in DP
6 7.0000 PC CAP E;10uF;50V;PITCH:2mm5;5mm x 11mm;VERTICAL 12.7-15-9mm [P0B40:1: {5.0}(C19,C65,C82,C95,C140)] *NOT available in DP
7 2.0000 PC CAP E;47uF;63V;PITCH:2mm5;6mm x 11mm;VERTICAL 12.7-15-9mm [P0B40:1: {2.0}(C153-C154)] *NOT available in DP
8 3.0000 PC CAP CER;220pF;1KV;Y5P;10%;PITCH:5mm;DISC;VERTICAL 12.7-15-
9mm
[P0B40:1: {3.0}(C99,C166,C181)] *NOT available in DP
9 2.0000 PC CAP CER;220 nF;25 V;X7R;10 %;SMD603 [P0B40:2: {2.0}(C20,C30)] *NOT available in DP
10 1.0000 PC CAP CER;0.68 uF;50 V;X7R;10%;SMD1206 [P0B40:2: {1.0}(C27)] *NOT available in DP
11 3.0000 PC CAP CER;1uF;10V;+80% /-20%;SMT603 [P0B40:1: {3.0}(C97-C98,C149)] *NOT available in DP
12 1.0000 PC CAP CER;8nF2;16V;C0G;5%;SMD805 [P0B40:1: {1.0}(C129)] *NOT available in DP
13 1.0000 PC CAP CER;150nF;25V;X7R;10%;SMT805 [P0B40:1: {1.0}(C17)] *NOT available in DP
14 2.0000 PC CAP CER;220nF;25V;X7R;10%;SMT805 [P0B40:1: {2.0}(C24,C69)] *NOT available in DP
15 1.0000 PC CAP CER;470nF;25V;X7R;10%;SMT805 [P0B40:1: {1.0}(C1)] *NOT available in DP
16 2.0000 PC CAP CER;20pF;50V;20%;SMT603 [P0B40:1: {2.0}(C117,C128)] *NOT available in DP
17 3.0000 PC CAP CER;47pF;50V;5%;COG(NPO);SMT603 [P0B40:1: {1.0}(C7)] *NOT available in DP
18 3.0000 PC CAP CER;100pF;50V;20%;SMT603 [P0B40:1: {1.0}(C21)] *NOT available in DP
19 11.0000 PC CAP CER;220pF;50V;10%;SMT603 [P0B40:1: {2.0}(C26,C75)] *NOT available in DP
20 1.0000 PC CAP CER;470pF;50V;10%;SMT603 [P0B40:2: {1.0}(C36)] *NOT available in DP
21 11.0000 PC CAP CER;1nF;50V;C0G;5%;SMT603;(MURATA
GRM1885C1H102JA01D)
[P0B40:1: {11.0}(C9,C29,C53,C58,C105,C113,C119-
C120,C131-C132,C143)]
*NOT available in DP
22 1.0000 PC CAP CER;1nF2;50V;10%;SMT603 [P0B40:2: {1.0}(C13)] *NOT available in DP
23 1.0000 PC CAP CER;1nF5;50V;C0G;2%;SMT603;(MURATA
GRM1885C1H152GA01D)
[P0B40:2: {1.0}(C21)] *NOT available in DP
24 3.0000 PC CAP CER;2nF2;50V;C0G;5%;SMT603;(MURATA
GRM1885C1H222JA01D)
[P0B40:1: {3.0}(C66-C67,C144)] *NOT available in DP
25 3.0000 PC CAP CER;3nF3;50V;X7R;10%;SMT603 [P0B40:2: {3.0}(C2,C6,C18)] *NOT available in DP
26 1.0000 PC CAP CER;3nF9;50V;10%;SMT603 [P0B40:2: {1.0}(C19)] *NOT available in DP
27 3.0000 PC CAP CER;4nF7;50V;10%;SMT603 [P0B40:1: {2.0}(C74,C76)] *NOT available in DP
28 28.0000 PC CAP CER;10nF;50V;X7R;10%;SMT603 [P0B40:1: {24.0}(C2-C6,C13,C28,C32,C49-C50,C70-
C72,C80-C81,C83,C102,C115,C123,C156,C184-
C185,C187-C188)]
*NOT available in DP
29 1.0000 PC CAP CER;33nF;50V;10%;SMT603 [P0B40:2: {1.0}(C4)] *NOT available in DP
30 4.0000 PC CAP CER;47nF;50V;10%;SMD603 [P0B40:1: {4.0}(C8,C23,C56,C96)] *NOT available in DP
31 37.0000 PC CAP CER;100nF;50V;10%;SMT603 [P0B40:1: {24.0}(C33-C48,C54-C55,C112,C124-
C127,C130)]
*NOT available in DP
32 3.0000 PC CAP CER;470pF;50V;C0G;5%;SMD805 [P0B40:1: {3.0}(C15,C62,C172)] *NOT available in DP
33 1.0000 PC CAP CER;6nF8;50V;10%;SMT805;X7R [P0B40:1: {1.0}(C12)] *NOT available in DP
34 3.0000 PC CAP CER;22nF;50V;C0G;5%;SMD805 [P0B40:1: {3.0}(C16,C20,C57)] *NOT available in DP
35 1.0000 PC CAP CER;33nF;50V;X7R;10%;SMD805 [P0B40:1: {1.0}(C111)] *NOT available in DP
36 3.0000 PC CAP CER;4nF7;50V;X7R;10%;SMD805 [P0B40:1: {3.0}(C10,C118,C152)] *NOT available in DP
37 1.0000 PC CAP CER;68nF;50V;10%;SMT805;X7R [P0B40:1: {1.0}(C116)] *NOT available in DP
38 25.0000 PC CAP CER;100nF;50V;X7R;10%;SMT805 [P0B40:1: {25.0}(C25,C61,C84,C87-C88,C90,C100-
C101,C103-C104,C108-C110,C114,C121,C136,C139,C141-
C142,C146-C147,C157,C165,C173-C174)]
*NOT available in DP

Parts ListG20 INFINIUM
Page 11
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
39 4.0000 PC CAP CER;100nF;100V;X7R;10%;SMD1206 [P0B40:1: {4.0}(C133-C134,C137-C138)] *NOT available in DP
40 1.0000 PC CAP FILM;680nF;100V;MPF;10%;PITCH:5mm;BOX;VERTICAL 12.7-15-
9mm
[P0B40:1: {1.0}(C107)] *NOT available in DP
41 1.0000 PC CAP
FILM;2uF2;100V;MPF;10%;PITCH:20mm;HEIGHT:17mm;WIDTH:23m
m;THICKNESS:9mm
[P0B40:2: {1.0}(C57)] *NOT available in DP
42 2.0000 PC CAP E;22uF;450V;20%;PITCH:5mm;13mm x 25mm;105C;VERTICAL
12.7-15-9mm
[P0B40:1: {2.0}(C182-C183)] *NOT available in DP
43 2.0000 PC CAP E;1 uF;450 V;20 %;PITCH:5 MM;RADIAL;8mm x
12mm;105C;VERTICAL 12.7-15-9mm
[P0B40:1: {2.0}(C170-C171)] *NOT available in DP
44 2.0000 PC CAP E;100 uF;450 V;20 %;PITCH:7MM5;RADIAL;18x31mm5;105C [P0B40:1: {2.0}(C160,C178)] *NOT available in DP
45 2.0000 PC CAP E;47 uF;25 V;20 %;RADIAL;5*11;2.5 MM;T&R [P0B40:1: {2.0}(C86,C89)] *NOT available in DP
46 2.0000 PC CAP E;LOW ESR;47 uF;100 V;ELECTROLYTIC;20 %;RADIAL;10*16;5
MM;105C;VERTICAL 12.7-15-9mm
[P0B40:1: {2.0}(C150-C151)] *NOT available in DP
47 4.0000 PC CAP CER;10nF;500V;PITCH:5mm;DISC;VERTICAL 12.7-15-9mm [P0B40:1: {4.0}(C162-C163,C167-C168)] *NOT available in DP
48 1.0000 PC CAP CER;10nF;1KV;20%;PITCH:10mm;DISC;PRECUT:3mm1 +/-0mm5 [P0B40:1: {1.0}(C190)] *NOT available in DP
49 1.0000 PC CAP CER;100nF;200V;X7R;10%;SMT1206 [P0B40:1: {1.0}(C180)] *NOT available in DP
50 4.0000 PC CAP FILM;22nF;400V;MPF;10%;PITCH:5mm;VERTICAL 12.7-15-9mm [P0B40:1: {4.0}(C106,C164,C169,C177)] *NOT available in DP
51 1.0000 PC CAP E;2uF2;50V;PITCH:2mm5;5mm x 11mm;VERTICAL 12.7-15-9mm [P0B40:1: {1.0}(C148)] *NOT available in DP
52 2.0000 PC CAP E;22uF;50V;PITCH:2mm5;6.3mm x 11mm;VERTICAL 12.7-15-
9mm
[P0B40:1: {2.0}(C176,C179)] *NOT available in DP
53 2.0000 PC CAP E;100uF;63V;PITCH:5mm; ;10mm x 12.5mm;VERTICAL 12.7-15-
9mm
[P0B40:1: {2.0}(C158-C159)] *NOT available in DP
54 1.0000 PC CAP E;10uF;100V;PITCH:2mm5;6mm3 x 11mm;105C;VERTICAL 12.7-
15-9mm
[P0B40:1: {1.0}(C135)] *NOT available in DP
55 1.0000 PC CAP E;4mF7;25V;PITCH:7mm5;16mm x 30mm;PRECUT:3mm2 -
0/+0mm2
[P0B40:1: {1.0}(C189)] *NOT available in DP
56 2.0000 PC CAP E;2mF2;35V;20%;PITCH:7mm5;16mm x 25mm;PRECUT:3mm2 -
0/+0mm2;105C
[P0B40:1: {2.0}(C145,C161)] *NOT available in DP
Circuit Protector
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 6.0000 PC R21-15201-52000 B21-15201-52000 FUSE CLIP;2 A;V;ZINC PLATING;250V;SERIES;520;FUSE;250 V;PLATING [P0B40:1: {6.0}(F1A-F3A,F1B-F3B)]
2 2.0000 PC R22-01513-10001 B22-01513-10001 FUSE;1A0;250V;SLOW BLOW;H-TYPE;5mm x 20mm (EU, UK, SAA, AR)
3 1.0000 PC R22-01513-10001 B22-01513-10001 FUSE;1A0;250V;SLOW BLOW;H-TYPE;5mm x 20mm [P0B40:1: {1.0}(F1)] (UL, BR, HM, SH)
4 3.0000 PC R22-01513-20001 B22-01513-20001 FUSE;2A0;250V;SLOW BLOW;H-TYPE;5mm x 20mm (UL, BR, HM, SH)
5 2.0000 PC R22-01513-20001 B22-01513-20001 FUSE;2A0;250V;SLOW BLOW;H-TYPE;5mm x 20mm [P0B40:1: {2.0}(F2-F3)] (EU, UK, SAA, AR)
Coil
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 4.0000 PC R39-00000-03394 B39-00000-03394 COIL;SMD;BEAD;SMD0805;(BLM21BD751SN1D) [P0B40:1: {4.0}(L1-L4)]

Parts ListG20 INFINIUM
Page 12
Connector
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 2.0000 PC R84-22000-06018 B84-22000-06018 CRIMP TERMINAL;PITCH:3mm96;AWG18-22;A3963TOP-2
2 14.0000 PC R84-25016-06014 B84-25016-06014 CRIMP TERMINAL;PITCH:2mm0;AWG24-30;A2008TOP-2
3 1.0000 PC R84-42050-00155 B84-42050-00155 CRIMP CONNECTOR;LUG;INNER DIA:4mm3;AWG 14-18;WIRE
MOUNT;STRAIGHT
Diode
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 6.0000 PC DIODE;BAV99;SOT23;SMD [P0B40:1: {6.0}(D1-D3,D12-D14)] *NOT available in DP
2 15.0000 PC DIODE;LL4148;LL34;TEMIC OR FC;SMD [P0B40:1: {15.0}(D4-D8,D15-D17,D19,D32-D37)] *NOT available in DP
3 9.0000 PC DIODE;GP;GS1G;400V;1A;DO-214AC;SMD [P0B40:1: {9.0}(D10,D20-D23,D26-D27,D30-D31)] *NOT available in DP
4 2.0000 PC DIODE;ZD5V6;BZX85C5V6;DO41 [P0A5I:00: {2.0}(D1-D2)] *NOT available in DP
5 1.0000 PC DIODE;ZMM04V7;SMD1206;SMD [P0B40:1: {1.0}(D9)] *NOT available in DP
6 5.0000 PC DIODE;RECTIFIER;SMD;SMA;1A;1000V;GS1MW [P0B40:1: {5.0}(D24-D25,D28-D29,D44)] *NOT available in DP
7 4.0000 PC DIODE;RECTIFIER;SR360;DO201 [P0B40:1: {4.0}(D40-D43)] *NOT available in DP
8 2.0000 PC DIODE;ES3D;DO-214AB;SMD [P0B40:1: {2.0}(D38-D39)] *NOT available in DP

Parts ListG20 INFINIUM
Page 13
Hardware
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 60.0000 PC NAIL;CROWN:2mm2;WIDTH:1mm27;THICKNESS:1mm0;LENGTH:25
mm;18-GAUGE (0.49*0.40) FINISH;GALVANIZED
*NOT available in DP
2 33.0000 PC NAIL;STAPLE;CROWN
10mm;LEGLENGTH:10mm;WIDTH:1.2mm;THICKNESS:0mm6;FINISH:
GALVANIZED
*NOT available in DP
3 1.0000 PC CABLE TIE;NYLON;4in;COLOR: *NOT available in DP
4 0.7000 G THERM-GREASE;COLOR:WHT;SPEC.NO:09286 *NOT available in DP
5 0.4000 G SCREWLOCK;SPEC.NO:01090 *NOT available in DP
6 2.0000 PC HEX.NUT;12 MM;2 MM;NICKEL;SILVER;0.75 MM *NOT available in DP
7 1.0000 PC HEX.NUT T-NUT;11.11 MM;4 MM;17 MM;NICKEL;SILVER;OCT.
NUT;7/16" x G20
*NOT available in DP
8 11.0000 PC T-NUT;INNER DIA;M4mm;W/PRONG;SURFACE:ZINC/BLACK *NOT available in DP
9 8.0000 PC T-NUT;INNER
DIA;M5mm;THICK:8mmW/PRONG;SURFACE:ZINC;COLOR:BLACK
*NOT available in DP
10 10.0000 PC HEX PIPE-NUT;THREAD-DIA;M9mm;HEIGHT:2mm;SURFACE:ZINC *NOT available in DP
11 6.0000 PC OCT. NUT;FOR
JACK;3/8in;OCTWRENCH:14.5mm;THICKNESS:3.5mm;SURFACE:NICK
EL/SILVER
*NOT available in DP
12 1.0000 PC HEX. NUT;INNER DIA:13mm;SURFACE:ZINC *NOT available in DP
13 4.0000 PC V87-00200-10103 F87-00200-10103 RUBBER BUSHING;I00172P;DST.NO:002;DPT.NO:10103;(I00172P-
RUBBER_BUSHING-REVB.dwf)
14 2.0000 PC F87-01000-12070 PAD;RUBBER;6mm*2mm5;COLOR:BLK;DWG.NO:12070;(R14-GUITAR-
RUBBERPAD-REVB.DWG)
15 16.0000 PC SCREW;A;4 MM;13 MM;PAN;ZINC;BLACK;2.84 MM;SC;A4*13mm *NOT available in DP
16 2.0000 PC SCREW;M3mm*3mm;HEAD:PAN WASHER DIA
4mm5;INSERT:PHILIPS REC.;SURFACE:BLACK/ZINC
*NOT available in DP
17 4.0000 PC SCREW;M3mm*6mm;PITCH:0mm5;HEAD:FLAT;INSERT:PHILIPS
REC.;SURFACE:BLACK/ZINC
*NOT available in DP
18 4.0000 PC SCREW;M3mm*7mm;HEAD:PAN;INSERT:PHILIPS
REC.;SURFACE:BLACK/ZINC
*NOT available in DP
19 4.0000 PC SCREW;BT3mm*8mm;HEAD:PAN;INSERT:PHILIPS
REC.;SURFACE:ZINC
*NOT available in DP
20 12.0000 PC SCREW;M03mm*08mm;HEAD:PAN SPRING WASHER;INSERT:PHILIPS
REC.;SURFACE:SILVER/ZINC
*NOT available in DP
21 2.0000 PC SCREW;M3mm*10mm;HEAD:PAN;INSERT:PHILIPS
REC.;SURFACE:BLACK/ZINC
*NOT available in DP
22 6.0000 PC SCREW;M4mm*8mm;HEAD:BINDING;INSERT:PHILIPS
REC.;SURFACE:BLACK/ZINC
*NOT available in DP
23 1.0000 PC SCREW;M4mm*8mm;HEAD:PAN;INSERT:PHILIPS
REC.;SURFACE:SILVER/ZINC
*NOT available in DP
24 11.0000 PC SCREW;M4mm*21mm;HEAD:PAN WASHER DIA
9mm;INSERT:PHILIPS REC.;SURFACE:BLACK/ZINC
*NOT available in DP
25 6.0000 PC SCREW;M4mm*30mm;HEAD:OVAL;INSERT:PHILIPS
REC.;SURFACE:BLACK/ZINC
*NOT available in DP
26 4.0000 PC SCREW;M5mm*22mm;HEAD:OVAL;INSERT:PHILIPS
REC.;SURFACE:SILVER/CHROME
*NOT available in DP
27 4.0000 PC SCREW;M5mm*23mm;HEAD:PAN;INSERT:PHILIPS
REC.;SURFACE:BLACK/ZINC
*NOT available in DP
28 1.0000 PC METAL SHIELD;P0B40-SHIELD;REVA *NOT available in DP
29 1.0000 PC SILICA GEL;MASS;30g;SPEC.NO:30QB-BB2001-4 *NOT available in DP
30 4.0000 PC CLIP-ON NUT;SQUARE STYLE;FOR M4 NUTS;PANEL
THICKNESS:0mm4 TO 0mm6;SURFACE:ZINC/SILVER;(LAN-XIN
LXJ12A)
*NOT available in DP

Parts ListG20 INFINIUM
Page 14
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
31 4.0000 PC SPRING;0.7 MM;23.5 MM;7.5 MM;NICKEL;SV;P0739-TUBE_SPRING *NOT available in DP
32 2.0000 PC SPRING;CYLINDRICAL;FS112;6mm*14mm8;CARBON STEEL;DWG.
NO:04288;(R14-FCB1010-SPRING-REVA.DWG)
*NOT available in DP
33 0.1400 M SHRINKING TUBE;INNER DIA:5mm2;SPEC.NO:16898; *NOT available in DP
34 6.0000 PC WASHER;9.7 MM;16
MM;NICKEL;WHITE;WASHER;FLAT;DIM:9.7*16*0.5mm;NIC
*NOT available in DP
35 1.0000 PC WASHER;10.9 MM;0.5 MM;18 MM;NICKEL;SILVER;PLAIN *NOT available in DP
36 6.0000 PC WASHER;PLAIN;INNER DIA:4mm;OUTER
DIA:8mm;THICKNESS:1mm;PLATING;NICKEL
*NOT available in DP
37 10.0000 PC WASHER;PLAIN;INNER DIA:9mm6;OUTER
DIA:13mm;THICKNESS;0mm5;PLATING:NICKEL
*NOT available in DP
38 4.0000 PC WASHER;PLAIN;INNER DIA:12mm3;OUTER
DIA:16mm6;THICKNESS:0mm5;SURFACE:NICKEL/SILVER
*NOT available in DP
39 7.0000 PC WASHER;SPRING;INNER DIA:4mm;OUTER
DIA:7mm;THICKNESS;1mm7
*NOT available in DP
40 1.0000 PC WASHER;SPRING;INNER DIA:14mm5;OUTER
DIA:17mm;THICKNESS:1mm5;PLATING:NICKEL
*NOT available in DP
41 1.0000 PC WASHER;EXTERNAL TEETH;INNER DIA:4mm;OUTER
DIA:7mm;THICKNESS;1mm7
*NOT available in DP
42 6.0000 PC WASHER;DONUT;INNER DIA:5mm5;OUTER
DIA:16mm;THICKNESS;2mm6;PLATING;BLACK/ZINC
*NOT available in DP
43 1.0000 PC F97-17000-04145 SHEET;FOAM;FOOTSWITCH;FS112;W/ DURABLE
ADHESIVE;DWG.NO:04145;(R14-GX112-FOAM-REVA.DWG)
44 1.0000 PC BUSHING;CABLE;FS112;NYLON;DWG.NO:04141;(R14-
CABLEBUSHING-REVA.DWG)
*NOT available in DP
Ic
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC C60-00000-79902 IC;AD/DA;MSOP;10;DAC082S085 [P0B40:1: {1.0}(IC16)]
2 1.0000 PC S60-54422-00528 C60-22422-00528 IC;AD/DA;V4220M;SSOP [P0B40:1: {1.0}(IC19)]
3 17.0000 PC C73-00000-29050 IC;OPAMP;SMD;SOP;8;BA4580RF [P0B40:1: {11.0}(IC2-IC9,IC15,IC20-IC21)]
4 1.0000 PC S73-58007-40514 C73-31007-40514 IC;OPAMP OPAMP;TL074;SOP; [P0B40:1: {1.0}(IC10)]
5 1.0000 PC S73-58007-22208 C73-58007-22208 IC;OPAMP OPAMP;TL072;SOP;BRAND:ST ONLY [P0B40:1: {1.0}(IC1)]
6 1.0000 PC S77-00000-28276 C77-00000-28276 IC;VOLT.REGULATOR;TO220;LM7905L [P0B40:1: {1.0}(IC11)]
7 1.0000 PC S77-05107-03110 C77-05107-03110 IC;VOLT.REGULATOR;7805F;FULLPACK;TO220 [P0B40:1: {1.0}(IC14)]
8 1.0000 PC S77-12107-03110 C77-12107-03110 IC;VOLT.REGULATOR;7812F;FULLPACK;TO220 [P0B40:1: {1.0}(IC13)]
9 1.0000 PC S77-12207-03110 C77-12207-03110 IC;VOLT.REGULATOR;7912F;FULLPACK;TO220 [P0B40:1: {1.0}(IC12)]
10 1.0000 PC T12-00100-02216 D12-00100-02217 IC;DIG COMM.;EUROTEC;V1000;SOIC [P0B40:1: {1.0}(IC18)]
11 1.0000 PC T22-31001-40514 D22-31001-40514 IC;LOGIC;74HC14;SOP [P0B40:1: {1.0}(IC24)]
12 1.0000 PC T22-31007-40514 D22-31007-40514 IC;LOGIC;74HC74;SOP [P0B40:1: {1.0}(IC23)]
13 1.0000 PC T24-18081-61832 D24-18081-61832 IC;MICROCONTROLLER;ATMEGA8A-AU;SMD;TQFP32
14 1.0000 PC T24-48030-02803 D24-48030-02803 IC;MICROCONTROLLER;MAX809STRG;Vth:2.93V;SOT [P0B40:1: {1.0}(IC22)]
15 1.0000 PC D33-00001-30189 IC;MICROCONTROLLER, PROGRAMMED;FIRMWARE G20 INFINIUM
V1.0
[P0B40:1: {1.0}(IC17)]

Parts ListG20 INFINIUM
Page 15
Led
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC U10-00000-47170 E10-00000-47170 LED;RED;LEN:RED;DIFFUSE;HB;3MM
ROUND;ANGLE;BASE:4.5X5.08X6
[P0B40:1: {1.0}(LD1)]
2 1.0000 PC E10-00000-79899 LED NB;3mm0 ROUND;GREEN;DIFFUSE;NORMAL
BRIGHT;ANGLE;BASE:4.5X5.08X6
[P0B40:1: {1.0}(LD2)]
3 1.0000 PC U10-51610-05431 E10-51610-05431 LED HIB;3mm ROUND;AMBER;VERTICAL;NO RING;WAVELENGTH:610
nm
[P0B40:1: {1.0}(LD3)]
4 1.0000 PC U10-53565-00588 E10-53565-00588 LED HIB;3mm ROUND;GREEN [P0A5I:00: {1.0}(LD2)]
5 3.0000 PC U12-57630-00590 E12-57630-00590 LED;3mm ROUND;RD [P0B40:2: {2.0}(LD1-LD2)]
Metal Part
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC A62-07400-18216 METAL;BOTTOM;FS112G;BLACK;DWG.NO:18216;(R14-GX-
FOOTBOTTOM-REVC.DWG )
2 1.0000 PC A63-00000-65024 METAL;P0APR;ALUMINIUM 6061;HEATSINK;EXTRUSION,
CUTTING;OXIDIZING;BLACK;AMP HEATSINK;REVA
3 1.0000 PC A63-00001-04098 METAL;HEATSINK;P0B40;MATERIAL:ALUMINIUM;P0B40-
MET_HEATSINK;REVA
4 1.0000 PC A65-00000-91172 METAL;GRILL;P0B40;MATERIAL:SPCC 1.5mm;BENDING
PUNCHING;BLACK;P0B40-MET_GRILL-REVA
5 2.0000 PC A65-00001-04087 METAL;CAP;P0B40;MATERIAL:MN65;BENDING + PUNCHING;P0B40-
MET_TUBE_CAP;REVA
6 4.0000 PC A65-00100-12275 METAL;SPRING HOLDER;P0739;DST.NO:001;DPT.NO:12275;(P0739-
SPRING_HOLDER-REVA.DWG)
7 8.0000 PC Q65-02000-04400 A65-02000-04400 METAL;CORNER;GX112;DWG.NO:04400;(R20-GX112-CORNER-
REVB.DWG)
8 2.0000 PC A65-15000-04134 METAL:SPACER;LENGTH:4mm4;HOLE
DIA:3mm5;DWG.NO:04134;(R14-FS112-SPACER-REVA.DWG)
9 1.0000 PC J02-00001-20984 METAL;CASE;P0B40;MATERIAL:SECC 1.2mm;BENDING
PUNCHING;POWDER COATING;BLACK;A001
10 1.0000 PC J02-01400-18217 METAL;COVER;P0A5I;BLACK;PRINTED;FST.NO:014;DPT.NO:18217;(GX
-FOOTPEDALCOVER-REVD.DWG)

Parts ListG20 INFINIUM
Page 16
Plastic Part
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 4.0000 PC W51-00100-14745 G51-00100-14745 PLASTIC;RUBFOOT;P0738;DST.NO:001;DPT.NO:14745;(P0738-
RUBFOOT-REVA.DWG)
2 2.0000 PC G52-00100-07083 PLASTIC;SWITCH KNOB;P0491;ABS
PA757;MOULDING;YS1284A;BLACK;SWITCH;I00168P;DST.NO:001;DP
T.NO:07083;(I00168P-SWITCH_KNOB_18MM-REVA.DWG)
3 1.0000 PC W52-00100-14962 G52-00100-14962 PLASTIC;PUSH KNOB;I00499P;BLACK
CHROME;DST.NO:001;DPT.NO:14962;(I00499P-PUSH_KNOB-REVA)
4 2.0000 PC W52-80500-09382 G52-80500-09382 KNOB;SWITCH;FOOTPEDALS;BLACK;DWG.NO:09382;(R14-GUITAR-
SWITCHKNOB1-REVA.DWG)
5 1.0000 PC W53-00000-04668 G53-00000-04668 PLASTIC;JEWEL;P0404;AMBER TRANSLUCENT
6 2.0000 PC W53-00000-12925 G53-00000-12925 PLASTIC;P0806;RUBBER 70degC;GROMMET;BLACK;12AX7;REV:C
7 1.0000 PC G53-00001-04111 PLASTIC;STRIP;P0B40;HDPE;SILVER;P0B40-PLA_STRIP;REVA
8 1.0000 PC W53-40900-05211 G53-40900-05211 LEATHER;HANDLE;P0738;BLACK LEATHER+SILVER METAL
9 10.0000 PC G58-00000-80920 PLASTIC;KNOB;P0ATD;ABS;INJECTION;PAINTING NORMAL;BLACK
CHROME;POT-KNOB
10 1.0000 PC W58-00200-09291 G58-00200-09291 PLASTIC;BUGERA LOGO;I00315P;BLACK
CHROME;DST.NO:002;DPT.NO:09291;(I00315P-BUGERA_LOGO-
REVB.DWG)
11 2.0000 PC G58-00200-11129 PLASTIC;LED
SPACER;MOULDING;BLACK;NO:8LENGTH:9MM;DST.NO:002;DPT.NO:
11129;(LED-SPACER9MM.REVB.DWG)
12 1.0000 PC W58-00300-08619 G58-00300-08619 PLASTIC;SPACER;PC;MOULDING;BLACK;3MM
VERTICAL;DST.NO:003;DPT.NO:08619;(I00129P-LED_SPACER-
REVC.DWG)
13 2.0000 PC W58-00300-11128 G58-00300-11128 PLASTIC;SPACER;P0062;MOULDING;BLACK;LED SPACER2;DI100
DSP110;DST.NO:003;DPT.NO:11128;(R14-DI100-LEDSPACER2-
REVC.DWG)
14 2.0000 PC G58-53000-25624 PLASTIC;BASE;P0089;ABS;YS1285A;BLACK;FS112 FS114
FCB1010;COLOR:BLK;DWG.NO:25624;(R14-GUITAR-SWITCHBASE1-
REVB.DWG)

Parts ListG20 INFINIUM
Page 17
Plug Socket
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC W64-14152-03710 G64-14152-03710 PLUG;PCB;PLUG;JACK PHONE;STRAIGHTPCB LUGS;MONO
6mm3;DUAL TIP/NO RING CONTACTS;NO NUT/WASHER;METAL
BUSHING;(CHUNSHENG PJ-622HA-EP)
[P0B40:2: {1.0}(X7)]
2 5.0000 PC W64-16212-00005 G64-16212-00005 PLUG;PCB;PLUG;JACK STEREO 6mm3;STRAIGHTPCB LUGS;NO
NUT/WASHER;METAL BUSHING;(CHUNSHENG PJ-632HA)
[P0B40:2: {5.0}(X2-X6)]
3 1.0000 PC W64-25272-06052 G64-25272-06052 PLUG;JACK STEREO 6mm3;ANGLED;W/O MET.RNG.;W/O NUT
ONLY;(CHUNG YEN HSJ-064-20-P)
[P0B40:1: {1.0}(X1)]
4 1.0000 PC W67-20103-01824 G67-20103-01824 PLUG;AC SOCK;W FUSE;SNAP-IN;COLOR:BLK;POLES:03;(RONG-FENG
RF-2004)
5 1.0000 PC G71-00000-03961 WAFER;V1000-14B,0.35um;LOGIC-3.3V(1P4M)
6 1.0000 PC G71-00000-90754 WAFER;POLES:9;ROWS:1;STRAIGHT;PITCH:3.96 MM;NO PIN2 AND
PIN4
[P0B40:1: {1.0}(X5)]
7 1.0000 PC W71-23114-04753 G71-23114-04753 WAFER;POLES:14;STRAIGHT;PITCH:2 mm;1 ROW;TYPE:A2006WV-14P [P0B40:1: {1.0}(X6)]
8 1.0000 PC W71-27102-04759 G71-27102-04759 WAFER;POLES:2;STRAIGHT;PITCH:3.96 mm;1 ROW;JS1120-02 [P0B40:1: {1.0}(X7)]
9 1.0000 PC W71-27104-04415 G71-27104-04415 WAFER;POLES:4;STRAIGHT;PITCH:3.96 mm;1 ROW;JS1120-04 [P0B40:2: {1.0}(X1)]
10 1.0000 PC G71-27105-04760 WAFER;POLES:5;STRAIGHT;PITCH:3.96 mm;1 ROW;JS1120-05-
S1;W/O PIN2 AND PIN4
[P0B40:1: {1.0}(X4)]
11 1.0000 PC W71-43114-06006 G71-43114-06006 PLUG;HOUSING;POLES:14;ROWS:1;STRAIGHT;PITCH:2mm;TYP:A2008
12 1.0000 PC W71-47102-05844 G71-47102-05844 PLUG;HOUSING;A3963H02;PITCH:3mm96;POLES:2;ROWS:1;UL94-
V0;STRAIGHT
13 14.0000 PC W71-80000-05663 G71-80000-05663 BD.-IN-CONN;TERMINAL;SAN-002T-0.8A
14 1.0000 PC W71-83114-05658 G71-83114-05658 BOARD-IN-CONNECTOR;POLES:14;ROWS:1;STRAIGHT;PITCH:2 mm
15 2.0000 PC G73-00001-02619 SOCKET;TUBESOCKET;POLES:8;FOR EL34 OR
6L6;CERAMIC;COLOR:WHT;W/ SOLDER LUGS;VERSION1;TUS8PC8C
[P0B40:1: {2.0}(V2-V3)]
16 2.0000 PC W73-28509-01218 G73-28509-01218 SOCKET;POLES:09;VACUUM TUBE;FOR
12AX7;CERAMIC;COLOR:WHT;W/ SOLDER
LUGS;VERSION1;TUS9PC9C
[P0B40:1: {2.0}(V1,V4)]
Power Supply
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC J60-00001-02604 TRAFO:AUDIO I/O;P0B40
2 1.0000 PC J65-00001-02606 TRAFO;EI POWER;P0B40;UL 120;VERSION:UL (UL, BR)
3 1.0000 PC J65-00001-02607 TRAFO;EI POWER;P0B40;JP 100;VERSION:JP (HM, SH)
4 1.0000 PC J65-00001-02605 TRAFO;EI POWER;P0B40;EU 230 OR 240;VERSION:EU (EU, UK, SAA, AR)
Quarz
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC X65-40471-00000 H65-40471-00000 QUARZ;RESONATOR;10MHz;HC49/S;FUNDAMENTAL [P0B40:1: {1.0}(Q1)]

Parts ListG20 INFINIUM
Page 18
Resistor
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 4.0000 PC RESISTOR;CARBON;13Kohm;5%;0W063;SMD603 [P0B40:1: {2.0}(R72,R75)] *NOT available in DP
2 1.0000 PC RESISTOR;CARBON;2ohm2;5%;0W063;SMD603 [P0B40:1: {1.0}(R89)] *NOT available in DP
3 5.0000 PC RESISTOR;CARBON;5ohm1;5%;0W063;SMD603 [P0B40:1: {5.0}(R84,R99-R100,R106-R107)] *NOT available in DP
4 1.0000 PC RESISTOR;CARBON;47ohm;5%;0W063;SMD603 [P0B40:1: {1.0}(R76)] *NOT available in DP
5 2.0000 PC RESISTOR;CARBON;100ohm;5%;0W063;SMD603 [P0B40:1: {2.0}(R2,R10)] *NOT available in DP
6 1.0000 PC RESISTOR;CARBON;120ohm;5%;0W063;SMD603 [P0B40:2: {1.0}(R37)] *NOT available in DP
7 1.0000 PC RESISTOR;CARBON;270ohm;5%;0W063;SMD603 [P0B40:2: {1.0}(R46)] *NOT available in DP
8 1.0000 PC RESISTOR;CARBON;510ohm;5%;0W063;SMD603 [P0B40:1: {1.0}(R27)] *NOT available in DP
9 1.0000 PC RESISTOR;CARBON;560ohm;5%;0W063;SMD603 [P0B40:1: {1.0}(R52)] *NOT available in DP
10 1.0000 PC RESISTOR;CARBON;620ohm;5%;0W063;SMD603 [P0B40:1: {1.0}(R42)] *NOT available in DP
11 2.0000 PC RESISTOR;CARBON;680ohm;5%;0W063;SMD603 [P0B40:1: {2.0}(R145,R155)] *NOT available in DP
12 2.0000 PC RESISTOR;CARBON;820ohm;5%;0W063;SMD603 [P0B40:1: {2.0}(R24,R91)] *NOT available in DP
13 7.0000 PC RESISTOR;CARBON;1Kohm;5%;0W063;SMD603 [P0B40:1: {5.0}(R20,R23,R58,R66,R157)] *NOT available in DP
14 7.0000 PC RESISTOR;CARBON;2Kohm;5%;0W063;SMD603 [P0B40:1: {7.0}(R36-R40,R50,R74)] *NOT available in DP
15 4.0000 PC RESISTOR;CARBON;2Kohm2;5%;0W063;SMD603 [P0B40:1: {4.0}(R41,R216-R217,R228)] *NOT available in DP
16 7.0000 PC RESISTOR;CARBON;2Kohm7;5%;0W063;SMD603 [P0B40:1: {6.0}(R73,R85,R108,R149,R185-R186)] *NOT available in DP
17 5.0000 PC RESISTOR;CARBON;3Kohm3;5%;0W063;SMD603 [P0B40:1: {2.0}(R54,R180)] *NOT available in DP
18 16.0000 PC RESISTOR;CARBON;4Kohm7;5%;0W063;SMD603 [P0B40:1: {16.0}(R4-R7,R9,R11-
R12,R14,R32,R53,R55,R57,R63,R77,R90,R179)]
*NOT available in DP
19 2.0000 PC RESISTOR;CARBON;5Kohm1;5%;0W063;SMD603 [P0B40:1: {2.0}(R1,R34)] *NOT available in DP
20 3.0000 PC RESISTOR;CARBON;5Kohm6;5%;0W063;SMD603 [P0B40:1: {3.0}(R64-R65,R207)] *NOT available in DP
21 1.0000 PC RESISTOR;CARBON;6Kohm2;5%;0W063;SMD603 [P0B40:2: {1.0}(R23)] *NOT available in DP
22 3.0000 PC RESISTOR;CARBON;6Kohm8;5%;0W063;SMD603 [P0B40:1: {3.0}(R17-R18,R31)] *NOT available in DP
23 1.0000 PC RESISTOR;CARBON;7Kohm5;5%;0W063;SMD603 [P0B40:1: {1.0}(R60)] *NOT available in DP
24 1.0000 PC RESISTOR;CARBON;8Kohm2;5%;0W063;SMD603 [P0B40:2: {1.0}(R29)] *NOT available in DP
25 4.0000 PC RESISTOR;CARBON;9Kohm1;5%;0W063;SMD603 [P0B40:1: {1.0}(R44)] *NOT available in DP
26 29.0000 PC RESISTOR;CARBON;10Kohm;5%;0W063;SMD603 [P0B40:1: {20.0}(R19,R22,R35,R61,R69-
R70,R88,R98,R105,R112,R118,R121,R160,R172,R182,R188
-R189,R198,R204,R206)]
*NOT available in DP
27 4.0000 PC RESISTOR;CARBON;12Kohm;5%;0W063;SMD603 [P0B40:2: {4.0}(R12,R24,R35-R36)] *NOT available in DP
28 1.0000 PC RESISTOR;CARBON;14Kohm;1%;0W063;SMD603 [P0B40:1: {1.0}(R21)] *NOT available in DP
29 2.0000 PC RESISTOR;CARBON;15Kohm;5%;0W063;SMD603 [P0B40:1: {2.0}(R68,R187)] *NOT available in DP
30 1.0000 PC RESISTOR;CARBON;18Kohm;5%;0W063;SMD603 [P0B40:1: {1.0}(R168)] *NOT available in DP
31 1.0000 PC RESISTOR;CARBON;20Kohm;5%;0W063;SMD603 [P0B40:1: {1.0}(R30)] *NOT available in DP
32 5.0000 PC RESISTOR;CARBON;22Kohm;5%;0W063;SMD603 [P0B40:1: {3.0}(R15,R29,R130)] *NOT available in DP
33 2.0000 PC RESISTOR;CARBON;27Kohm;5%;0W063;SMD603 [P0B40:1: {2.0}(R56,R166)] *NOT available in DP
34 6.0000 PC RESISTOR;CARBON;33Kohm;5%;0W063;SMD603 [P0B40:1: {6.0}(R48,R51,R59,R126-R127,R167)] *NOT available in DP
35 2.0000 PC RESISTOR;CARBON;39Kohm;5%;0W063;SMD603 [P0B40:2: {2.0}(R30,R41)] *NOT available in DP
36 12.0000 PC RESISTOR;CARBON;47Kohm;5%;0W063;SMD603 [P0B40:1:
{10.0}(R13,R16,R28,R62,R181,R203,R205,R227,R229-
R230)]
*NOT available in DP
37 2.0000 PC RESISTOR;CARBON;68Kohm;5%;0W063;SMD603 [P0B40:2: {2.0}(R33-R34)] *NOT available in DP
38 1.0000 PC RESISTOR;CARBON;82Kohm;5%;0W063;SMD603 [P0B40:1: {1.0}(R33)] *NOT available in DP
39 12.0000 PC RESISTOR;CARBON;100Kohm;5%;0W063;SMD603 [P0B40:1: {8.0}(R25,R49,R92,R95,R113,R122,R146,R161)] *NOT available in DP
40 4.0000 PC RESISTOR;CARBON;120Kohm;5%;0W063;SMD603 [P0B40:1: {4.0}(R26,R67,R71,R184)] *NOT available in DP
41 2.0000 PC RESISTOR;CARBON;220Kohm;5%;0W063;SMD603 [P0B40:1: {2.0}(R97,R163)] *NOT available in DP
42 3.0000 PC RESISTOR;CARBON;330Kohm;5%;0W063;SMD603 [P0B40:1: {3.0}(R8,R170-R171)] *NOT available in DP

Parts ListG20 INFINIUM
Page 19
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
43 2.0000 PC RESISTOR;CARBON;470Kohm;5%;0W063;SMD603 [P0B40:1: {2.0}(R114,R169)] *NOT available in DP
44 2.0000 PC RESISTOR;CARBON;820Kohm;5%;0W063;SMD603 [P0B40:1: {2.0}(R115,R162)] *NOT available in DP
45 4.0000 PC RESISTOR;CARBON;1Mohm;5%;0W063;SMD603 [P0B40:1: {4.0}(R3,R129,R200,R221)] *NOT available in DP
46 2.0000 PC RESISTOR;METAL;200ohm;1%;0W063;SMD603 [P0B40:1: {2.0}(R101,R103)] *NOT available in DP
47 2.0000 PC RESISTOR;METAL;360ohm;1%;0W063;SMD603 [P0B40:1: {2.0}(R117,R133)] *NOT available in DP
48 2.0000 PC RESISTOR;METAL;1Kohm2;1%;0W063;SMD603 [P0B40:1: {2.0}(R124,R132)] *NOT available in DP
49 4.0000 PC RESISTOR;METAL;2Kohm2;1%;0W063;SMD603 [P0B40:1: {4.0}(R116,R123,R131,R140)] *NOT available in DP
50 2.0000 PC RESISTOR;METAL;3Kohm9;1%;0W063;SMD603 [P0B40:1: {2.0}(R125,R141)] *NOT available in DP
51 4.0000 PC RESISTOR;METAL;4Kohm7;1%;0W063;SMD603 [P0B40:2: {4.0}(R19,R27,R38-R39)] *NOT available in DP
52 2.0000 PC RESISTOR;METAL;7Kohm50;1%;0W063;SMD603 [P0B40:1: {2.0}(R102,R110)] *NOT available in DP
53 2.0000 PC RESISTOR;METAL;8Kohm06;1%;0W063;SMD603 [P0B40:1: {2.0}(R109,R111)] *NOT available in DP
54 1.0000 PC RESISTOR;METAL;8Kohm45;1%;0W063;SMD603 [P0B40:1: {1.0}(R43)] *NOT available in DP
55 3.0000 PC RESISTOR;METAL;10Kohm;1%;0W063;SMD603 [P0B40:1: {3.0}(R86-R87,R156)] *NOT available in DP
56 4.0000 PC RESISTOR;METAL;20Kohm;1%;0W063;SMD603 [P0B40:1: {4.0}(R93-R94,R119-R120)] *NOT available in DP
57 2.0000 PC RESISTOR;METAL;22Kohm;1%;0W063;SMD603 [P0B40:1: {2.0}(R151-R152)] *NOT available in DP
58 2.0000 PC RESISTOR;METAL;470Kohm;1%;0W063;SMD603 [P0B40:1: {2.0}(R135-R136)] *NOT available in DP
59 7.0000 PC RESISTOR;CARBON;100ohm;5%;0W1;SMD805 [P0B40:1: {3.0}(R83,R191,R195)] *NOT available in DP
60 2.0000 PC RESISTOR;CARBON;510ohm;5%;0W1;SMD805 [P0B40:1: {2.0}(R192,R196)] *NOT available in DP
61 1.0000 PC RESISTOR;CARBON;820ohm;5%;0W1;SMD805 [P0B40:1: {1.0}(R233)] *NOT available in DP
62 5.0000 PC RESISTOR;CARBON;1Kohm;5%;0W1;SMD805 [P0B40:1: {5.0}(R144,R150,R153-R154,R164)] *NOT available in DP
63 2.0000 PC RESISTOR;CARBON;1Kohm5;5%;0W1;SMD805 [P0B40:1: {2.0}(R176,R224)] *NOT available in DP
64 2.0000 PC RESISTOR;CARBON;1Kohm6;5%;0W1;SMD805 [P0B40:1: {2.0}(R147-R148)] *NOT available in DP
65 4.0000 PC RESISTOR;CARBON;2Kohm2;5%;0W1;SMD805 [P0B40:1: {4.0}(R209-R211,R215)] *NOT available in DP
66 1.0000 PC RESISTOR;CARBON;6Kohm8;5%;0W1;SMD805 [P0B40:1: {1.0}(R219)] *NOT available in DP
67 2.0000 PC RESISTOR;CARBON;10Kohm;5%;0W1;SMD805 [P0B40:1: {2.0}(R128,R212)] *NOT available in DP
68 2.0000 PC RESISTOR;CARBON;11Kohm;5%;0W1;SMD805 [P0B40:1: {2.0}(R158-R159)] *NOT available in DP
69 1.0000 PC RESISTOR;CARBON;20Kohm;5%;0W1;SMD805 [P0B40:1: {1.0}(R173)] *NOT available in DP
70 4.0000 PC RESISTOR;CARBON;47Kohm;5%;0W1;SMD805 [P0B40:1: {4.0}(R134,R137,R142-R143)] *NOT available in DP
71 1.0000 PC RESISTOR;CARBON;100Kohm;5%;0W1;SMD805 [P0B40:1: {1.0}(R213)] *NOT available in DP
72 3.0000 PC RESISTOR;CARBON;220Kohm;5%;0W1;SMD805 [P0B40:1: {3.0}(R190,R197,R220)] *NOT available in DP
73 3.0000 PC RESISTOR;CARBON;330Kohm;5%;0W1;SMD805 [P0B40:1: {3.0}(R45-R47)] *NOT available in DP
74 2.0000 PC RESISTOR;CARBON;470Kohm;5%;0W1;SMD805 [P0B40:1: {2.0}(R139,R165)] *NOT available in DP
75 2.0000 PC RESISTOR;CARBON;1Mohm;5%;0W1;SMD805 [P0B40:1: {2.0}(R138,R218)] *NOT available in DP
76 1.0000 PC RESISTOR;CARBON;100ohm;5%;0W25;SMD1206 [P0B40:1: {1.0}(R231)] *NOT available in DP
77 2.0000 PC RESISTOR;CARBON;10Kohm;5%;0W25;SMD1206 [P0B40:1: {2.0}(R225-R226)] *NOT available in DP
78 2.0000 PC RESISTOR;METAL;2ohm2;1%;0W25;SMD1206 [P0B40:1: {2.0}(R201-R202)] *NOT available in DP
79 2.0000 PC RESISTOR;SMT;12Kohm7;1%;METAL;0W25;SMD1206 [P0B40:1: {2.0}(R193-R194)] *NOT available in DP
80 2.0000 PC RESISTOR;SMD;METAL;300Kohm;1%;0W25;SMD1206 [P0B40:1: {2.0}(R177-R178)] *NOT available in DP
81 1.0000 PC Y04-12000-03091 I04-12000-03091 THERMISTOR;NTC;20ohm;+/- 20%;4A;DIA:;PITCH:7mm5;(THINKING
SCK-20200MSY)
82 1.0000 PC RESISTOR;METAL;5.6 kohm;2W;5%;METAL OXIDE FILM;MOF;F-TYPE [P0B40:1: {1.0}(R234)] *NOT available in DP
83 1.0000 PC RESISTOR;CARBON;220Kohm;5%;0W5;LEAD WIRE [P0B40:1: {1.0}(R104)] *NOT available in DP
84 3.0000 PC RESISTOR;METAL;100Kohm;1%;0W5;LEAD WIRE;HORIZONTAL 52-
6mm
[P0B40:1: {3.0}(R199,R208,R232)] *NOT available in DP
85 2.0000 PC RESISTOR;METAL;47Kohm;5%;2W;LEAD WIRE;F-TYPE [P0B40:1: {2.0}(R222-R223)] *NOT available in DP
86 1.0000 PC RESISTOR;CEMENT;3Kohm3;5%;2W;LEAD
WIRE;RADIAL;PITCH:5mm;PRECUT:3mm1+/-0mm5
[P0B40:1: {1.0}(R237)] *NOT available in DP
87 3.0000 PC RESISTOR;CEMENT;220ohm;5%;5W;LEAD
WIRE;RADIAL;PITCH:5mm;PRECUT:3mm1+/-0mm5
[P0B40:1: {3.0}(R174-R175,R214)] *NOT available in DP

Parts ListG20 INFINIUM
Page 20
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
88 2.0000 PC RESISTOR;CEMENT;1Kohm50;5%;5W;LEAD
WIRE;RADIAL;PITCH:5mm;PRECUT:3mm1+/-0mm5
[P0B40:1: {2.0}(R235-R236)] *NOT available in DP
Potentiometer
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 2.0000 PC I03-00000-91676 POTENTIOMETER;20 kohm;0.050W;TAPER:15A;20 %;MONO;F-
SHAFT:15MM;ANGLED;NO NUT AND WASHER;80-
150GF;HHTORQUE;SOUNDWELL
[P0B40:1: {2.0}(VR1,VR4)]
2 2.0000 PC I03-00000-91679 POTENTIOMETER;2 kohm;TAPER:1B;20 %;MONO;F-
SHAFT:15MM;ANGLED;NO NUT AND WASHER;80-
150GF;HHTORQUE;SOUNDWELL
[P0B40:1: {2.0}(VR6-VR7)]
3 1.0000 PC I03-00000-91680 POTENTIOMETER;50 kohm;0.050W;TAPER:15C;20 %;STEREO;F-
SHAFT:15MM;ANGLED;NO NUT AND WASHER;80-
150GF;HHTORQUE;SOUNDWELL
[P0B40:1: {1.0}(VR8)]
4 2.0000 PC Y03-00001-02592 I03-00001-02592 POTENTIOMETER;20 kohm;TAPER:1B;20 %;MONO;W/O CC;BULK;F-
SHAFT:15MM;ANGLED;80-150GF;HHTORQUE;NO NUT AND WASHER
;SOUNDWELL
[P0B40:1: {2.0}(VR9-VR10)]
5 1.0000 PC I03-00001-02593 POTENTIOMETER;50 kohm;TAPER:3B;20 %;MONO;W/O CC;BULK;F-
SHAFT:15MM;ANGLED;80-150GF;HHTORQUE;NO NUT AND
WASHER;SOUNDWELL
[P0B40:1: {1.0}(VR2)]
6 1.0000 PC I03-00001-07557 POTENTIOMETER;100 kohm;TAPER:15A;20 %;MONO;F-
SHAFT:15MM;ANGLED;W/O CC;80-150GF;HHT;SW;NO NUT AND
WASHER
[P0B40:1: {1.0}(VR5)]
7 1.0000 PC I03-00001-07560 POTENTIOMETER;250 kohm;TAPER:15A;20 %;MONO;F-
SHAFT:15MM;ANGLED;W/O CC;80-150GF;HHT;SW;NO NUT AND
WASHER
[P0B40:1: {1.0}(VR3)]
Switch
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 2.0000 PC Y77-03422-02778 I77-03422-02778 SWITCH;RADIAL;2P2T;PCB VERSION;LOCKING;NONSHORT;RAD2P [P0B40:2: {2.0}(SW1-SW2)]
2 1.0000 PC Y82-00822-04267 I82-00822-04267 SWITCH;PUSH;2P2T;PCB VERSION COMAX PB-22D01-F
NS;NONLOCKING;NONSHORT
[P0B40:1: {1.0}(SW1)]
3 1.0000 PC Y86-00323-04226 I86-00323-04226 SWITCH;SLIDE;POLES:2;TOGGLES:3;LOCKING;SHORTING;PCB
VERSION;DONGGUAN WEILI SS-23H49-G6
[P0B40:2: {1.0}(SW3)]
4 2.0000 PC Y87-43811-03768 I87-43811-03768 SWITCH;TACTILE;POLES:1;HEIGHT:4mm3;PCB
VERSION;NONLOCK;NONSHORT
[P0A5I:00: {2.0}(SW1-SW2)]
5 2.0000 PC Y90-02211-03087 I90-02211-03087 SWITCH;TOGGLE;TOGGLES:1;POLE:1;LOCKING; NONSHORT; SOLDER
LUG;/ARCO C3900BAAAB)
Transistor
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC TRANSISTOR;2SC3326B;SOT [P0B40:1: {1.0}(T2)] *NOT available in DP
2 2.0000 PC TRANSISTOR;FET;600V;SPP04N60C3;TO220 [P0B40:1: {2.0}(T18-T19)] *NOT available in DP
3 2.0000 PC TRANSISTOR;BC846B;SOT;SMD [P0B40:1: {2.0}(T13,T16)] *NOT available in DP
4 4.0000 PC TRANSISTOR;BC856B;SOT;SMD [P0B40:1: {4.0}(T10,T14-T15,T17)] *NOT available in DP
5 2.0000 PC TRANSISTOR;MBTA92;SOT [P0B40:1: {2.0}(T8-T9)] *NOT available in DP
6 6.0000 PC TRANSISTOR;MMBFJ175;SOT23 [P0B40:1: {6.0}(T1,T3-T6,T12)] *NOT available in DP
