Bukh DV29 RME User guide

009W4926-R19 29-05-2019
OWNER'S HANDBOOK
FOR
BUKH MARINE DIESEL
LIFEBOAT ENGINE
TYPE DV29 RME
BUKH A/S
Aabenraavej 13-17
DK –6340 Krusaa
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
www.bukh.dk

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 2 -
CONTENTS Page
Pictures for recognition of engine................................................. 3
Introduction, standard equipment ................................................ 4
Operating manual......................................................................... 4
Preparation for the first start......................................................... 5
Before start................................................................................... 5
Electric start.................................................................................. 5
Hand start..................................................................................... 5
After start...................................................................................... 6
Maneuvering................................................................................. 6
Stopping the engine ..................................................................... 6
Running in.................................................................................... 6
Maintenance................................................................................. 6
Belt for alternator.......................................................................... 6
Air inlet filter.................................................................................. 6
Fuel filter....................................................................................... 6
Fuel lift pump................................................................................ 7
Lubricating oil system................................................................... 7
Change of oil ............................................................................... 7
Recommended lubricating oil ...................................................... 7
Change of lubricating oil filter....................................................... 7
Cooling water system................................................................... 7
Frost precautions ......................................................................... 8
Electrical system .......................................................................... 8
Marine gear.................................................................................. 8
Starting instructions...................................................................... 8
Winter storage of the engine........................................................ 9
Hydro –and Spring Starter ........................................................10
Lubricating oil quantities.............................................................10
Instruction for Marine Diesel Fuel in cold climates.....................10
Lubricating oil for Spray pump ...................................................11
Technical data for engine and gearbox......................................12
Recommended maintenance and checklist ...............................13
Irregular operation......................................................................15
Lubricating oil chart....................................................................16
El-diagram (1 Battery system)....................................................17
El-diagram (2 Batteries system).................................................18
DV29 installation ........................................................................19
List of representatives................................................................20
General Terms of Sale and Delivery..........................................24

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 3 -
1. Lubricating oil pump
2. Bracket for control cable
3. Electric stop solenoid
4. Engine speed control lever
5. Exhaust pipe connection
6. Water cooled exhaust manifold
7. Outlet to keelcooler
8. Lifting fittings
9. Thermostat housing
10. Plug for hot-water take off
11. Alternator
12. Transmitter for cooling water alarm
13. Tension device for V-belt
14. Electric starter
15. Oil pressure switch
16. Reversible engine mountings
17. Coupling flange for propeller shaft
18. Reverse-reduction gear
19. Electric multi plug
20. Plug for draining off lubricating oil
21. Lubricating oil filter
22. Lubricating oil filling plug
23. Type plate
24. Cooling water filling plug
25. Cooling water expansion tank
26. Inlet from keelcooler
27. Dipstick for engine oil
28. Fuel lift pump
29. Fuel filter
30. Reversing lever for gear
31. Air filter
32. Bracket for reversing cable

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 4 -
INTRODUCTION
BASIC ENGINE CONFIGURATION:
The BUKH Lifeboat engine is a four-stroke marine diesel engine with direct fuel injection and the following basic
equipment:
Crankcase with oil pan, one-piece cylinder head with 2 valves per cylinder, forged crankshaft with counterweights,
balance weights, cast iron connecting rods, light metal pistons, water-cooled exhaust manifold; all necessary pipework
for exhaust, coolant, fuel and lubricating oil are fitted on engine.
A reverse/reduction gearbox with integrated thrust bearing is fitted on the engine.
All BUKH Diesel Lifeboat Engines are tested in the factory, and a test certificate according to SOLAS and ISO
regulations is issued.
If a problem with the engine should arise, we ask you to apply to one of our distributors, who will always be ready to
help you, having skilled personnel, necessary tools etc., and at the same time you will be sure that only original BUKH
spare parts are used.
Do always use original BUKH spare parts.
When ordering spare parts from the distributor please state: Engine type and serial number, description and number of
parts.
BUKH A/S
Powering Marine Safety
As BUKH A/S is always endeavouring to improve the engines, the specifications mentioned are subject to alterations
without previous notice.
Read this instruction book thoroughly before starting your new BUKH Diesel Engine.
STANDARD EQUIPMENT for DV29RME
Reverse-reduction gear
Decompression lever
Wet sump lubrication oil system
Full-flow lubrication oil filter
Automatic injection timing
Centrifugal governor
Keel cooling with thermostat
Watercooled exhaust manifold
Air inlet filter and silencer
Fuel lift pump
Electric start
Charging alternator
Operating remote panel with:
a) Charging light
b) Lub. oil pressure warning light
c) Cooling water temp. warning light
d) Push button for start
e) Electric stop or mechanical stop
f) Audible warning
Fittings for remote control
Standard set of tools
Drain pump for lub. oil
Following documentation is delivered with the engine:
1. Operating manual with sparepart katalog
2. Test certificate
3. Declaration of conformity according to SOLAS and
IMO regulations.
Flex. engine mounts (optional)
Stern gear (optional)
Raised hand start (optional)
Spring start (optional)
2 El-start (optional)
Hydro start (optional)
OPERATING MANUAL
Before the engine is put into use you are recommended to get familiar with the placing of the following components of
engine and gear:
Fuel oil filter, lub oil filter and air intake filter, fuel lift pump with handle, zincrod in the crankcase and water-separator in the
fuel pipe (if mounted).
Where is lub oil poured into engine and gear and where are the dipsticks placed? Where is fuel oil filled into the fuel tank
and where is the drain plug placed? Where is the main switch?

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 5 -
Preparation before first start
1. Pour lubricating oil through filling hole on top of valve cover.
Check that oil level is between the marks on the dipstick, placed at
the port side of the engine.
Check oil level as mentioned below:
a) remove and wipe dipstick
b) reinsert dipstick in the pipe
c) withdraw dipstick, check oil level.
2. Pour lubricating oil through dipstick hole on the top of reverse- and
reduction gear and check oil level as described in pos 1.
3. Flexible sterntube: Lubricate the stuffing box with sterntube oil (outboard).
Unscrew the filler plug and pour in oil until the bearing is full.
Important:The stuffing box shall under no circumstances be
force-lubricated.
These instructions are only valid for propeller equipment supplied by BUKH.
If other equipment is mounted, we refer to the instructions given for this.
4. We always recommend checking of oil level before start.
5. Fill the fuel tank.
6. Bleed the fuel system as below:
a) Pump with the fuel lift pump handle until fuel is free from air bubbles seen
in the hose to the fuel tank. After the pumping the pump handle must be
locked in top position.
b) Loosen fuel pipe connection on the fuel valve, if neccessary.
c) Turn the engine until fuel is free from air bubbles. Retighten the pipe
connection.
Normally it will not be necessary to bleed the fuel system before starting but
after changing the fuel filter element or carrying out any work on the fuel system
it should be bled in the following way: Loosen the bleed screw and operate the
hand priming lever on the fuel lift pump until air-free fuel discharges from screw.
Tighten bleed screw. Loosen high pressure pipe unions to injectors and turn
engine until fuel discharges from pipes. Reconnect pipes to injectors. The
engine will start in the normal way.
7. Bleed the cooling water system by removing the pressure cap. While en-
gine is idling pour water into the expansion tank until system is free of air
(loosen possible plug pos. 11 on the thermostat housing).
AFTER THE ENGINE HAS BEEN TAKEN INTO USE
Before start
1. The oil level of the engine should be checked every 14 days or every 25
hours of running as described in ”Preparation before first start”. It is not necessary
to refill oil if the level is between the two marks on the dipstick.
2. The oil level of the reduction gear should be checked every 14 days or
every 25 hours of running as described in ”Preparation before first start”.
3. The sterntube stuffing box should be lubricated every 14 days or every
25 hours of running.
4. Check the quantity of fuel in the tank.
Electric start with remote control and instrument panel
1. Switch on the main switch.
2. Put the marine gear in neutral position by means of the control handle.
3. The engine is started by putting the switch into ”RUN” position.
4. Push the ”START” button until the engine starts. The starter should not work
for more than 10-15 secs. continuously.
Hand start (optional)
1. Put the gear lever in neutral position.
2. Turn decompression lever on valve cover clockwise as far as possible.
3. Engage starting handle and crank engine as quickly as possible. Release
decompressor by turning lever anticlockwise while cranking and engine will start.
4. By hand start in cold weather you may achieve an easier start after having cranked
the engine with activated decompression lever before the starting procedure.
Never accelerate a cold engine. Let it get warm first.

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 6 -
After Start
1. When the engine has started, the RPM should be 800-1000 RPM when idling.
2. Check the oil pressure. Normally this should be 2-4.5 bar. With cold engine the RPM should be kept down so that the oil
pressure does not exceed 4.5 bar. When idling at warm engine the oil pressure must not be below 1 bar.
3. Immediately after start the oil pressure warning lamp goes out. During normal operation the lamp should stay off.
4. Make sure that the charging control lamp goes out after the engine has started.
5. Check the cooling water temperature frequently. The temperature should be in the area of 70 –95oC when engine is
warm.
Manoeuvering
1. With the control lever in central position the engine is idling, and the
marine gear is in neutral (pos. 0). When the lever is moved forward in
range 1, the marine gear is engaged to "Ahead” first, and then in range
2 the engine R.P.M. is increased. When the lever is moved from the
central position to range 3, the marine gear is engaged to "Astern”
first, and then in range 4 the engine R.P.M. is increased.
2. Only engage "Ahead” or "Astern” when the engine is idling.
3. To accelerate engine without engaging gear, operate gear release
button 5 and move control handle in either direction.
4. Increase the load gradually from idling in the course of the first 15-20
minutes shortly after the start of the engine.
Stopping the engine
1. Reduce the load gradually in the course of 15-20 minutes before stop.
2. Reduce the engine to idling and put the gear in neutral position.
3. Push the ”Stop” button (or pull the mechanical stop handle) until engine stops.
4. Move the ”Off/Run” switch to the ”Off” position.
5. Turn off the battery main switch.
Running in
To secure long life and maximum power it is recommended to run the engine for the first 25 hours at not more than 80 pct. of
the maximum output (about 3200 r.p.m.)
You should avoid slow hauling as for instance towage. After the first 25 hours it is recommended to change engine and gear
oil and to tighten up the cylinder head and to check or to possibly adjust the tension of the V-belt. Besides, it is
recommended to let an authorized service dealer go over engine and installation.
MAINTENANCE
Belt for alternator
To be adjusted every 150 hours by turning the alternator round the centres of
suspension. Tensioning should be so as to allow 8 - 10 mm deflection of the belt
under firm thumb pressure.
Air inlet filter
This is a wire gauze filter to be rinsed in petrol and cleaned by a blast of
compressed air after 300 hours' operating.
Fuel filter
A fuel filter is fitted between the fuel lift pump and the H.P. fuel pump. The filter is
a disposable one which cannot be cleaned. It should be changed every 300
operating hours or if water contamination is suspected.
Change the filter as follows:
1. Drain off the fuel from the filter by slackening drain screw A in the bottom of
the filter casing B.
2. Remove by hand or by means of a pair of tongs the filter casing and discard
it.
3. Clean the sealing surface of the filter holder C if necessary
4. Fill the new filter casing with clean fuel through the holes at the top of same.
5. Screw on the filter casing and tighten it by hand about half a turn after the
gasket fits tightly.
6. After changing the filter, bleed the fuel system as stated under ”Preparation
for first start”

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 7 -
Fuel lift pump
The fuel lift pump is a sealed type which cannot be dismantled for repair or cleaning. It is
recommended to install a water/dirt accumulating filter in the suction line to the pump.
After repairs the fuel system must be bled as described under ”Preparation for the first
start” if necessary.
Lubricating Oil System
The engine is pressure lubricated and the oil system has a built-in relief valve for
controlling the oil pressure. The oil level is checked as mentioned before.
Change of Oil
Lubricating oil should be changed for the first time after 25 hours of running, later for every 150 hours or at least once a year.
It is recommended to change the oil when engine is warm, and the procedure is as follows:
1. Remove the dipstick.
2. Insert the sump pump suction hose into the hole and pump up the oil.
3. When the sump is empty reinsert dipstick and pour fresh oil.
4. If possible, drain the oil through the plug hole at the bottom of the sump.
Recommended Lubricating Oil
Modern diesel engines demand heavy-duty oils with additives securing best operation conditions and longest life time of the
engine under various conditions. Therefore use a first class HD-oil from a recognized oil company.
Oil specifications as mentioned in ”LUBRICATION OIL CHART”.
When operating under difficult conditions, i.e. frequent cold starting,
short operation periods, greatly varying loads, use quality ”Service
CD” and also use quality "Service CD" in case the sulphur content
of fuel is higher than 1 %.
Change of Lubricating Oil Filter
Lubricating oil filter cannot be cleaned, but should be changed
every 150 hours or once a year. To change the filter proceed as
follows :
1. Unscrew filter A and discard it.
2. Clean the sealing surface of the engine B, and remove old
gasket C if any from old filter
3. Mount new filter at once under clean conditions.
4. Screw on filter until gasket fits tightly, tighten a further half turn.
5. Fill with oil until normal level is reached.
6. Start the engine and check that the filter is tight.
Cooling system (Keel cooling)
A pump circulates the freshwater in a closed system.This circulation pump is fitted on the front end of the engine.
The freshwater circulates through the cooling jackets of the engine and through the keel cooler, fitted on the bottom of the boat.
Too high cooling temperature will cause the blue lamp in the control panel to light up and the acoustic alarm to function.
1. Cirkulating pump
2. Expansion tank
3. Thermostat 75oC
4. Pressure cap
5. Keel cooling pipe 2 x ø22/ø19 copper pipe

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 8 -
Frost precautions
As protection against corrosion and to secure the cooling water freezing temperature to min. minus 15° Celsius as per
IMO/SOLAS requirement or lower if required from climate conditions, It is recommended to use a mixture of min. 30%
antifreeze liquid and 70% water and max. 50% antifreeze and 50% water.
However please also note when doing service on lifeboats that the mix of water and antifreeze can get aggressive and
start corrosion. If corrosion is found in the cooling system it can be caused by one of two conditions:
1. The anti corrosion additives in the anti freezing liquid are exhausted and have evaporated.
2. Oxidation due to incoming air causing an acid which is lowering the PH value.
Therefore and also to keep the anti freezing proporties it is recommended to change the cooling water and antifreeze every
3 years min. Please also note the details provided by your supplier of antifreeze liquid normally stated on the can.
Electrical System
The engine is equipped with a 12 volt electrical system consisting of a starter motor and an alternator, the max. charging
current of which is 50 Amp.
Electrical wiring diagram for the engine with control and instrument panels is shown later in this instruction.
The battery must never be isolated from the alternator, when the engine is running.
Warning! It is not allowed to connect additional equipment to the wiring system on the engine. Possible additional
equipment has to be connected directly to the terminals of the battery.
NOTE!
The starter must not be operated for more than 10 sec. If further operation is necessary a pause of at least half a minute
before starting attempt is repeated.
Marine Gear
The engine is equipped with a reverse-reduction gear.
The reduction is 3.06:1 for AHEAD and 2.44:1 for REVERSE.
The marine gear will need no other attendance than regular change
of oil. This to be carried out after 25 hours of operation, and then
every 500 hours or once a year.
Oil quality: "Automatic Transmission Fluid” (ATF)..
The oil change is carried out by means of the lubricating oil bilge pump.
The oil should be warm when draining.
Refill new oil to the quantity of 0.4 liters through the dipstick hole.
Check oil level on the dipstick.
Starting instructions for BUKH Diesel Engine type DV29RME
Electric start:
1. Switch on the main switch.
2. Put the gear in neutral position
3. Put the switch into ”RUN” position
4. Push the ”START” button until the engine starts
Cold Start (below minus 15oC if mounted):
Start pilot: Pull and push the pump (2) 2-3 times.
Stopping the engine: Push the ”STOP” button until the engine
stops.
After the engine has stopped: Put the switch in ”OFF” position.
Filling the pressure tank (3) (if mounted):
1. Open the cover.
2. Put the gas cylinder on top of the valve and fill up the tank
to max. marking.
Hand Start: (If mounted):
Put gear into neutral position.
Put handle into crank claw.
Lift decompression lever (1).
Cold start with hand start (below 0oC).
Start pilot: Pos 1 –2 - 3
Pull and push the pump (2) 2-3 times.
Turn the start handle as quickly as possible (clockwise), release the decompression lever, but keep on turning until the engine
starts.

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 9 -
WINTER STORAGE OF THE ENGINE
1. Carry out the following whilst the boat is still in the water:
1. Run the engine until normal working temperature is reached.
2. Drain off engine and gear oil with the oil bilge pump.
3. Fill the engine and gearbox with preservative lubricating oil of a recognized make up to the upper mark on the dipstick.
4. Fill the fuel tank with fuel preservative oil in the rate of mixture prescribed by the oil manufacturer.
5. Start the engine and let it run for about 10 minutes to be sure that the fuel mixed with preservative oil has been flushed
through the fuel system of the engine.
6. Fill the fuel tank completely with fuel. Pay no special attention to the preservative oil previously added to the fuel as this is
consumed normally and properly when service is resumed in spring.
2. On land the following procedure has to be carried out:
1. Remove the engine cooling water drain plugs, drain off the sea water from the engine and refit plugs.
2. For direct sea water cooled engines: Remove the suction hose from the cooling water pump at the bottom cock and put
the hose into a bucket with freshwater containing preservative oil in the rate of mixture prescribed by the oil manufacturer
3. The outlet hose for the cooling water which goes into the exhaust elbow may be removed and returned to the bucket via a
length of hose so that the freshwater is able to circulate. Start the engine and the freshwater containing preservative oil
will be flushed through the engine.
4. Stop the engine after 5 - 10 minutes and drain off the water. Ensure that after removing the drain plug (1 plug is placed in
the block, see page 3, pos. 17; and 1 plug in the exhaust manifold) all the water is drained off. This is done by cleaning
the drain holes with a nail, a steel wire or the like, so that any remaining water may drain out. Remove the impeller from
the cooling water pump, which will allow water in pump and pipes to be drained off. Keep the impeller separately in a dry
place during the winter.
4A. For freshwater-cooled engines: Drain the freshwater from the engine by removing the plugs as indicated for seawater
cooled engines. It is not necessary to flush this system with freshwater containing preservative oil. If the engine is to be
used in period of frost, it must be protected against frost burst with a mixture of anti-freeze solution in the freshwater
system - irrespective of the protection to the freshwater system against the risk of frost - by removing the cover of the
impeller pump and turning the engine manually or with the starter motor.
5. Remove the battery and store it separately during the winter in a dry and frost-free place. Fill up and charge the battery
before storing.
6. Remove the air filter and turn the engine manually until each inlet valve opens alternately, during which about 50 mL of
preservative oil is injected into each piston head. Turn the engine backwards and forwards manually in order to spread
the preservative oil.
7. Insert a clean, oil moistened rag (not cotton waste) into the inlet manifold.
8. Insert another clean, oil moisted rag into the exhaust elbow aperture.
9. Treat electrical connections with grease free from acid. Fill the multiple plugs with grease from the wire side.
The engine is now preserved for winter storage and can be further protected by covering of polythen sheeting, under
which a bucket of silicagel should be placed.
3. Preparation of engine before launching.
1. Remove the oil moisted rags from the inlet manifold and the aperture of the exhaust elbow.
2. Fit the cooling water pump impeller.
3. Fit cooling water drain plugs.
4. Drain the preservative lubricating oil from both engine and gearbox and fill up with fresh oil to the upper mark of the
dipstick.
5. Change the lubricating oil filter.
6. Make sure - before starting up - that the oil on the piston heads is drained off. This is checked by turning the engine
manually without operating the decompression lever.
7. Examine the stern tube stuffing box and fill up with stern tube oil.
8. Fit the battery after re-charging.
9. Lubricate all moveable parts with oil.
10. Check the anode.
11. Check that there is electrical contact at the sterntube at the internal connection to the gearbox.

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 10 -
RME-ENGINES MOUNTED WITH HYDRO- OR SPRING STARTER EQUIPMENT (service info 9201)
The above mentioned type of starting method has proved to start the lifeboat engines in a very short period of time. In cold
climates a standard multigrade lubrication oil may not be sufficient for a rapid build-up of lub. oil pressure. We recommend the
following methods to prevent problems:
1. Full synthetic low friction lub. oil with a viscosity of 5W/40 or 10W/30 (e.g. Mobil No. 1 or Castrol Syntruck).
2. Cooling water jacket heater.
3. Oil sump heater.
In view of starting time the above points also increase the electrical start performance.
LUBRICATION OIL QUANTITIES FOR DV29RME (service info 9702)
When the engine is dry, you are recommended to fill up with 3.5 litres of lubricating oil (min. 3.1 litres - max. 3.9 litres).
A dip stick with standard indications of minimum (20 mm) and maximum (32 mm) oil levels for checking of the oil quantity is
located on the side of the engine.
THESE INDICATIONS APPLY WHEN THE ENGINE IS IN HORIZONTAL POSITION!
When mounted in a lifeboat, the engine is rarely in a horizontal position. Usually, it has an aft inclination of max. 12°, which will
change the oil level on the dip stick.
The following values are intended as a guide:
Oil level when 3.5 litres of oil have been added to the engine:
Horizontal engine: Oil level on dipstick= 26 mm
Engine inclination 12° aft: Oil level on dipstick= 18 mm
Engine inclination 30° forward: Oil level on dipstick= 9 mm
Irrespective of the inclination, engine running will be trouble free if the above oil quantity has been added. If more oil than
advised is added, the crank will be running submerged in oil. Consequently, the oil will get too warm and foam, and bleeding
will be inadequate.
Oil vapour will condense and in extreme cases run out of the suction filter.
Do NOT fill the engine with more oil than indicated above.
It will not be necessary to adjust the oil quantity of freefall boats, in which the engine will
be started while the boat is still in the chute at an inclination of approx 30°.
INSTRUCTION FOR MARINE DIESEL FUEL IN COLD CLIMATES
COLD FILTER PLUGGING POINT (CFPP)
(service info 0502)
To ensure proper operation of the lifeboat engines in very cold climates, it is essential to ensure that the diesel fuel in the fuel
tank of the lifeboat is suitable to the lowest temperature possible in the area of operation of the ship.
The temperature where the fuel is no more filterable is called "CFPP" in the specifications for the particular fuel.
To improve the CFPP-point, a dilution with kerosene is recommended. A max. dilution of 40% kerosene is possible. If 50% or
more are necessary, 2-stroke lubricating oil must be added to protect the fuel injection pump and nozzles from seizure.
If no information is available onboard the ship about the particular fuel to be diluted, it is recommended to use 2-stroke
lubricating oil in ratio 0.3 ltrs. to 100 ltrs. of fuel. This is necessary due to the fact that the diesel oil might be winter-type and
already diluted from the oil company.
The reason for the necessity of 2-stroke lub. oil is that it is self-mixing with the fuel.
Note: In ship storage tanks a max. of 25% dilution is the limit, in order to ensure that min. flame point of fuel = 55°C.
For operation below -28°C use specific Arctic fuel.
EXAMPLE:
Diesel Oil without Dilution
CFPP/-18°C
90 litres diesel + 10 litres kerosene
80 litres diesel + 20 litres kerosene
70 litres diesel + 30 litres kerosene
60 litres diesel + 40 litres kerosene
50 litres diesel + 50 litres kerosene
-20°C
-22°C
-24°C
-26°C
-28°C
Specific Arctic fuel
-40°C

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 11 -
Lubricating oil for spray pump bearing housing
Checking of oil level:
Dismount the filling plug when the spray pump is in
a horizontal position.
The oil level must be just above the lower edge of
the shaft. When turning the pump shaft must carry
a little oil round.
Change the oil after 300 operating hours or every 2
years.

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 12 -
MAIN DATA DV29RME
WORKING PRINCIPLE............... .................................... .................................4-STROKE
NUMBER OF CYLINDERS......... .................................... .................................2
CYLINDER BORE/STROKE....... .................................... .................................85 mm / 85 mm
SWEPT VOLUME ....................... .................................... .................................0.964 Litres
COMPRESSION RATIO ............. .................................... .................................18,5:1
COMPRESSION PRESSURE .... at 3600 rpm................. .................................47 Bar
OUTPUT, CONTINOUS RATING at 2000 rpm ................ .................................17.3 BHP - 12.7 kW
ACCORDING TO ISO 3046 at 2400 rpm................. .................................20.9 BHP - 15.4 kW
at 3000 rpm................. .................................25.6 BHP - 18.8 kW
at 3600 rpm................. .................................29.0 BHP –21.3 kW
MAX. TORQUE........................... .................................... .................................60.8 Nm (6.2 Kpm) at 2400 rpm
MAX. AIR CONSUMPTION......... .................................... .................................1784 Litres/min
ENGINE ROTATING, LOOKING AT FLYWHEEL ........... .................................CLOCWISE
IDLING SPEED........................... .................................... .................................800 –1000 RPM
MAX INCLINATION, FORE AND AFT.............................. .................................12o
HEEL, MAX. CONTINOUS.......... .................................... .................................25o
ENGINE NET WEIGHT INCL. MARINE GEAR................ .................................223 kg
LOCATION OF ENGINE SERIAL NUMBER.................... .................................PORT SIDE
EXHAUST TEMP. MAX/NORMAL ................................... .................................600oC –580oC
VALVE TIMING AND INJECTION POINT
FLYWHEEL DIAMETER ............. .................................... .................................391 mm
INLET VALVE OPENS................ BEFORE TDC............. .................................32o(arc measure: 109 mm)
INLET VALVE CLOSES ............. AFTER BDC ............... .................................64o(arc measure: 218 mm)
EXHAUST VALVE OPENS......... BEFORE BDC ............ .................................64o(arc measure: 218 mm)
EXHAUST VALVE CLOSES ...... AFTER TDC................ .................................32o(arc measure: 109 mm)
VALVE CLEARANCES (COLD ENGINE) INLET/EXHAUST .............................0.25 / 0.30 mm
FUEL SYSTEM COMBUSTION SYSTEM....................... .................................DIRECT INJECTION
INJECTION PRESSURE............. .................................... .................................210 Bar
INJECTION TIMING.................... .................................... .................................AUTOMATIC VARIABLE
FUEL LIFT PUMP ....................... .................................... .................................CAM SHAFT DRIVEN DIAPHRAGM PUMP
STATIC PRESSURE OF FUEL LIFT PUMP.................... .................................350 mBar
FUEL FILTER.............................. .................................... .................................THROW AWAY FILTER INSERT
FUEL QUALITY GAS OIL ........... .................................... .................................BS 2869 CLASS A
LUBRICATING SYSTEM
TYPE OF LUBRICATING OIL PUMP............................... .................................ROTARY VANE PUMP
LUBRICATING OIL PRESSURE: WARM ENGINE/MINIMUM...........................2-4.5 Bar / 1 Bar
LUBRICATING OIL QUALITY..... .................................... .................................SERVICE CC or CD
LUBRICATING OIL VISCOSITY . BELOW +5oC.............. .................................SAE 10 or SAE 10W-30
BETWEEN +5oc and +25oC..........................SAE 20 or SAE 15W-40
ABOVE +25oC ............ .................................SAE 30 or SAE 15W-40
LUBRICATING OIL CONTENT INCL. FILTER................. .................................3.5 Litres
LUBRICATING OIL FILTER ....... .................................... .................................THROW AWAY FILTER INSERT
NEWAGE PRM125 MARINE GEAR
LUBRICATING OIL QUALITY..... .................................... .................................Automatic Transmission Fluid (ATF)
LUBRICATING OIL TEMPERATURE .............................. .................................50° - 95oC
LUBRICATING OIL CONTENT... .................................... .................................0.4 Litres
STERN TUBE (FLEXIBLE) LUBRICANT......................... .................................OUTBOARD GEAR OIL
COOLING WATER SYSTEM - KEELCOOLING
COOLING WATER TEMPERATURE............................... .................................70 –95oC
TYPE OF CIRCULATING PUMP/MAX. CAPACITY......... .................................CENTRIFUGAL / 135 Litres/min
COOLING WATER CONTENT INCL. KEELCOOLER..... .................................4.8 Litres
ELECTRICAL SYSTEM
BATTERY VOLTAGE/CAPACITY.................................... .................................12 Volt / 63 Ah, 500CCA
STARTER TYPE / OUTPUT ....... .................................... .................................GEAR DRIVEN, 1 kW
ALTERNATOR TYPE / OUTPUT .................................... .................................BELT DRIVEN, 700 W
STOP SOLENOID....................... .................................... .................................BOSCH
RELAY ........................................ .................................... .................................ELECTRONIC, BUILT-ON
TORQUES
CYLINDER HEAD BOLTS/BEARING TOP SECTION..... .................................118 +/- 5 Nm (12 +/- 0.5 Kpm)
CONNECTING ROD BOLTS ...... .................................... .................................69 +/- 3 Nm (7 +/- 0.3 Kpm)
FLYWHEEL/COUNTERWEIGHTS .................................. .................................81 +/- 3 Nm (8.3 +/- 0.3 Kpm)
FLEX. COUPLING ...................... .................................... .................................150 +/- 3 Nm (15.3 +/- 0.3 Kpm)
ASSEMBLY OF FUEL VALVE.... .................................... .................................59 +/- 3 Nm (6.0 +/- 0.3 Kpm)
BRACKET FOR ENGINE SUPPORTS ............................ .................................69 +/- 3 Nm (7 +/- 0.3 Kpm)
BRACKET FOR GEAR SUPPORTS................................ .................................39 +/- 3 Nm (4 +/- 0.3 Kpm)

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 13 -
RECOMMENDED MAINTENANCE AND CHECK LIST FOR BUKH LIFEBOAT ENGINES
CHECK
RECTIFY IF
NEEDED
1. Tightness of connections through hull:
W
E
E
K
L
Y
M
O
N
T
H
L
Y
Y
E
A
R
L
Y
EVERY
5
YEARS
1.1 stern tube
hull connection
change sealing
X
1.2……keel-cooling pipes
hull connection
change sealing
X
1.3……spray pump
hull connection
change sealing
X
2. Check of lubricating oil:
2.1 a engine
change oil
-
X
X
2.1.b engine
check oil level
-
X
2.2.a gearbox
change oil
-
X
2.2.b…gearbox
check oil level
-
X
2.3…...sealbox for spraypump
refill the oillevel
renew if leaking-
X
2.4……lubricating oil filter
change
-
X
3… …..Check of cooling watersystem:
3.1… ..system
system to be full
fill up
X
3.2… ..anti freeze liquid
check for minus 25°C.
refill anti freeze liquid
X
3.3… ..cooling water connections tightness
for leaks
renew if leaking
X
3.4 …..condition of rubber hoses
cracks and leaks
renew
X
3.5 …..retightened clamping bands
-
-
3.6… ..V-belt for cooling water pump
adjust or renew
-
X
3.7 …..thermostat
renew after 5 years
-
X
4… ….Check of fuel system:
4.1 ….supply line
clean water/fuel
separator and check
line bends
repair if damaged or
renew
X
4.2 ….fuel tank
drain for water
-
X
4.3 fuel filter
change
-
X
4.4 return line
check for bends &
damages
repair if damaged or
renew
X
5. Check of remote control cables:
5.1 cables
check easy operation
and stroke sufficient
adjust cables
X
6. Check of propeller shaft arrangement:
6.1 rear stern tube bearing
check clearance for
bearing insert
renew insert
X
6.2 sufficient water flow to rear stern tube bearing
check that water holes
in bearing housing are
not blocked
clean holes
X
6.3 alignment of gear flange and prop.shaft flange
alignment to be within
0.05- 0.01mm
realign the engine
X
6.4 stuffing box seals
tightness
renew all three seals
X
6.5 condition of rubber tube for stuffing box
cracks
renew
X
6.6 Out-Board gearoil.
oillevel
refill
X
6.7 propeller
check size and
condition
renew if damaged
X
7.Starting of the engine:
7.1 start with electrical start
engine start within
2 minutes
if malfunctions -the
engine must be ser-
viced by a mechanic
X
7.2 start with handstart
same
same
X
7.3 start with other optional starting system if fitted
same
same
X
7.4 starting instruction
if it is readable
change if damaged
X

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 14 -
RECOMMENDED MAINTENANCE AND CHECK LIST FOR BUKH LIFEBOAT ENGINES
CHECK
RECTIFY IF
NEEDED
W
E
E
K
L
Y
M
O
N
T
H
L
Y
Y
E
A
R
L
Y
EVERY
5
YEARS
8. Engine maintenance
8.1 valve clearance
clearance
adjust
X
8.2 electric starter
rust protection of starter
drive
spray rust protection
spray
X
9.Running with engine - check:
9.1 Idling speed to be 900-1200 RPM
900-1200 RPM
adjust RPM
X
9.2 Full speed unload / min. 3700 RPM
min. 3700 RPM
adjust RPM
X
9.3 Full speed loaded with propeller
3300-3600 RPM
adjust RPM
X
9.4 Full speed loaded with propeller and spray pump
2800-3600 RPM
adjust RPM
X
9.5 Cooling water temp. to be max. 95 degr. Celcius
max. 95°C
change termostat
X
9.6 Audible and visual alarms
check function
change senders,
lamps or switch
X
9.7 Lubricating oil pressure
min. 1.5 kg/cm² at
idling speed
adjust oil relief valve
X
9.8 Gearbox change from FW to Neutral to ASTERN
check cables
adjust
X
10. Air supply:
10.1 air inlet filter
renew
-
X
11. Bateries:
11.1 level of liquid
check, refill
renew
X
X
X
X
11.2 voltage conditon
charge
renew
X
12.Spray pump - check:
12.1 waterspray being sufficient .
waterspray- nozzles,
waterintake and pump
clean nozzles and
waterintake
connection
X
12.2 rubber hoses
cracks
renew
X
12.3 clamping bands
retightened
X

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 15 -
IRREGULAR OPERATION - CAUSES AND REMEDIES
1. Engine does not start
SYMPTOM
CAUSE
REMEDY
Insufficient or very little compression
Inlet and/or exhaust valves leaking
Grind or replace the valves, mill the seats
Inlet and/or exhaust valves sticking
Grease valve stems with 2/3 gas oil and 1/3 lub.
Oil. If necessary clean the valves.
Insufficient rocker arm clearance
Adjust to 0.25 mm inlet and 0.3 mm exhaust
when engine is cold (turn left)
Piston rings stuck in grooves or are worn
Replace piston rings
Valve springs broken or are weak
Replace springs
Insufficient or no pressure from fuel pump
Air in fuel system or nozzles sticking
Bleed or renew nozzles
Thermo start out of order
No fuel (valve leaking)
Fill up (renew thermo-start)
Electric supply out of order
Check and/or replace switch and connections.
Chech fuse
Engine does not reach normal revs
Unloaded battery or defective
Battery to be charged or renewed
Starter motor turns engine too slowly
Loose or corroded connections
Tighten or clean connections
2. The engine starts, but stops soon after
The engine starts, but stops soon after
Empty fuel tank
Refill and bleed
Air in fuel system
Bleed
Nozzle sticking
Replace nozzle
Fuel filter choked
Replace filter element. Clean the tank
3. The engine does not reach maximum output
Difficult to start
None or insufficient compression
See ”engine does not start”
The engine revs. Is reduced considerably
when loaded
Fuel supply choked up.
Air/water in fuel system
Check fuel system thoroughly
Governor incorrectly adjusted or something
in the system works sluggishly
Adjust the governor. Check governor system and
correct the error
Hot engine(smell of heat)
Insufficient cooling water supply
Stop engine. Check cooling water pump
Damaged cylinder liner or bearings
Check bearings, piston and cylinder, if
necessary replace them
4. The engine knocks
The engine runs unevenly
Air/water in fuel system
Bleed see ”engine does not start”
5. The engine smokes
Black smoke
Air inlet filter choked
Clean filter
Insufficient compression
See ”engine does not start”
Blue smoke
The lube oil passes piston and oil rings an
penetrates into combustion chamber, or
vacuum valve defective
Replace oil rings and possibly the piston rings.
Clean vacuum valve
Grey smoke
Thermostart valve is leaking
Replace
6. Excessive consumption of lubricating oil
Blue smoke
Oil- and piston rings are worn
Replace oil- and piston rings, if required
Piston and cylinder liner highly worn
Replace
Defective vacuum valve
Replace
Lub. oil leaks out of crankshaft bearings
Worn oil seal ring
Replace
7. The engine gets too warm or too cold
Cooling water temperature too high
(smell of heat)
Unsufficient cooling water supply caused
by:defective water pump, choked strainer or
a defective thermostat
Investigate pump rotor for broken wings or lost
driver screw. Clean strainer. Clean or replace
thermostat
Cooling water temperature too low
Defective thermostat
Clean or replace thermostat
8. Insufficient or no lubrication oil pressure
Oil warning lamp lights up. Oil pressure
gauge indicates abnormally low oil
pressure
Insufficient lube oil in the engine
Check and refill
Leakage in lube oil system
Tighten and refill
Relief valve sticking or spring too weak
Clean bore and valve, stretch or replace the
spring

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 16 -
LUBRICATING OIL CHART
Lubricating oil for
engine:
temp range
Auxili-
aries
OIL COMPANY
OIL TYPE
HD OIL GRADE & QUALITY
Below –15oC
Below 5oC
5oC –25oC
Above 25oC
PRM125 gear ( ATF)
Stern tube (flexible)
BP OIL
VISCO 5000
SAE 5W-40 API SJ/CF
X
BP OIL
Vanellus C4 Global
SAE 15W-40 API CF-4/CF/SG
X
X
X
BP OIL
Vanellus C3 Extra
API CF4/CE/SF
X
X
X
BP OIL
Outboard Gear Oil Universal
X
BP OIL
Energol GR-XP 150
DIN 51 517 del. 3
X
BP OIL
Energol GR-XP 220
DIN 51 517 del. 3
X
CALTEX
Havoline Fully Synthetic
SAE 5W-40 API SJ/CE
X
CALTEX
Delo 350 Multigrade
SAE 15W-40 API CF4/CJ
X
X
X
CALTEX
Outboard Gear Oil EP
SAE 90
X
CASTROL OIL
CASTROL Syntruck
SAE 5W-40 API CF
X
CASTROL OIL
CASTROL RX Super Plus
SAE 15W-40 API CH-4
X
X
X
CASTROL OIL
CASTROL Marine Gear Oil
SAE 90
X
CHEVRON
DELO 400 Synthetic
SAE 10W-30 API CD/SG + SF
X
CHEVRON
RPM HEAVY DUTY
SAE 15W-40 API CD - II
X
X
X
CHEVRON
GEAR COMPOUND EP 220
ISO VG 220
X
ELF
Elf Synthése 5W/40
SAE 5W-40 CD or CC
X
ELF
Performance 3D 15W-40
SAE 15W-40 CD or CC
X
ELF
Performance 3D 10W-30
SAE 10W-30 CD or CC
X
X
ELF
Outboard Gear Oil
SAE 85W-90
X
EXXON / ESSO
EXXMAR CM
SAE 15W-40
X
X
X
X
EXXON / ESSO
ESSOLUBE XT301
SAE 15W-40 API CG-4
X
X
X
X
EXXON / ESSO
ESSOLUBE XT301
SAE 15W-40 API CG-4 FZG11
EXXON / ESSO
SPARTAN EP220
ISO VG 220
X
EXXON / ESSO
GEAROIL GX
SAE 80W-90
X
MOBIL OIL
MOBIL 1 0W-40
SAE 0W-40 API SJ/CF/EC
X
X
X
X
MOBIL OIL
MOBIL Delvac 1 SHC
SAE 5W-40 API CE/CD
X
X
X
X
MOBIL OIL
MOBILGARD 1 SHC
API CD/CF/CF2
X
X
X
X
MOBIL OIL
MOBILGARD HSD
15W-40 API CG-4/CF-4/CF/SH
X
X
X
MOBIL OIL
MOBIL Stern Tube Lubricant
Outboard Gear Oil SAE 80-90
X
NIPPON OIL COMPANY
HIDIESEL S-3 SAVE
SAE 15W-40 CD
X
X
X
X
NIPPON OIL COMPANY
HIDIESEL S-3 SAVE
SAE 10W-30 CD
X
X
X
NIPPON OIL COMPANY
GEAR LUBE EHD
SAE 90
X
SHELL OIL
Helix Ultra
SAE 5W-40
X
SHELL OIL
Rimula X
SAE 10W-30
X
SHELL OIL
Rimula X
SAE 15W-40
X
X
SHELL OIL
Nautilus Marine Gear Oil
SAE 90
X
SHELL OIL
Spirax GX
SAE 80W-90
X
STATOIL
LazerWay 5W-40
SAE 5W-40 API SL/CF
X
STATOIL
PowerWay 15W-40
SAE 15W-40 API CF4/SJ
X
X
X
STATOIL
LoadWay EP 220
ISO VG 220
X
STATOIL
GearWay G5
SAE 80W-90
X
TEXACO
Havoline Formula 3 Synthetic
SAE 5W-40 API SJ/CF
X
TEXACO
URSA Super LA
SAE 15W-40 API CG-4
X
X
X
TEXACO
GEARTEX EP-C
SAE 80W-90 API GL-5
X
TEXACO
MEROPA 220
ISO VG 220
X
Dexron II or III
X
DIRECTIONS FOR LUBRICATION
Designation
Application Point
Capacity Incl. Filter
Engine: DV29
Change first time after 25 h and every 150 h or once a year
3.5 Litres
Newage PRM125 Gear
Change first time after 25 h and every 500 h or once a year
0.4 Litres
Oil Filter
Change every 150 h or once a year
Stern Tube (flexible)
Change every 3 years
Spray Pump
Change after 300 h or every 2 years
70 mL

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 17 -

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 18 -

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 19 -
INSTALLATION: DV29

OPERATING MANUAL FOR BUKH DV29RME LIFEBOAT ENGINES
009W4926-R19 - 20 -
