BullFrog SPA-562 User manual

HOT TUB
Model SPA-562
OPERATING INSTRUCTION
1

1. I、Illustration to buttons
Fig.1：Control Panel
“
MIN
”Frequency up- searching / Minute “ ” On-off/Setting confirm
“
HOUR
” Frequency own- searching/ Hour “ ” Ra io or CD Switch/ On-off
“
+
” Volume up/ Set switch “ ” Blower On-off/ or Switch℉ ℃
“
-
” Volume own/ Open “ ” Spa Light On-off
“
MEM
” Ra io channel Memory/ Lock “ ”Surfing pump 1 On-off
“
SET
” Ra io channel rea / Close “ ” Surfing pump 2 On-off
“ ” Lasting Circulation Cleaning On-off “ ”Surfing pump +circulaltion pump 3 On-off/Set
Circulation Cleaning Time
“ ” Heating On-off / Set Pre-heating “ ” Set Temperature
Note：
.The functions liste with bule letters only works on the con ition of on-off
Chart 1
II、Function Summary
2

1、Max. with 6 KW heating system, pre-heating seting, water temperature isplaying an setting
2、Max. with 2 pcs surfing pumps,1 pc circultion pump, an one pc air blower.
3、Spa light an ozone setting
4、CD au io-input / Display of ra io frequency,it can be preserve 10 channels
5、Volume isplay an 87 volume a justing
6、Circulation cleaning/ time set circulation cleaning
7、24 hours isplay an setting
8、Memory preserve once power off
9、Fahrenheit & Celsius can be mutually switche
10、Antifreezing functions
11、Keys with backlight
12、Lock settingl
13、Three-phase or single-phase available,can be choose 110-120VAC or 220-240VAC
14、Choice with offering a AC for circumscribing DVD or TV
15、Choice of power controlle
III、Operation
Fig.3:：Normal Temperature Display Fig.4：Senor on/short circuit Display
1、When you first turn on the spa, the backlight control panel is im an LCD shows current time an
temperature. If spa happen with the short circuit the panel will isplay co e “E1”. When the ra io frequency is
isplaye “----” it in icates that the spa is in “power off” mo e, an pre-heating an circulation cleaning function
are in off status.
2、Lock memory Mode：
It is an optional function. Key boar will be locke by pressing “
MEM
” once when panel is in off
mo e. Pressing continuous twice of “
MEM
” to unlock the panel, the wor “LOCKED”will isappear.
3、Time djusting：
In the status of “Power off” an unworking of pre-heating an circulation cleaning.
Pressing “
MIN
”or“
HOUR
” to start time a justing. When Minute an Hour flashing, you can
a just your esire time.
It will be a e one hour when pressing “
HOUR
” each time an the hours can be a juste continually
3

when pressing “
HOUR
” without stopping. The hour a justment range is 00-23.
It will a one minute when pressing “
MIN
” each time an the minutes coul be a juste continually
when pressing “
MIN
” without stopping. The minute a justment range is 00~59
The system will quit the time-setting status automatically after 6 secon s without pressing any buttons
4、Pre- circulation-cleaning Setting：
The isplay will show clearly whether circulation clearning is work or not. See following Fig 5-6：
AM
AM
Fig.5：Circulation-cleaning off Fig.6：Circulation-cleaning on
Pre- circulation-cleaning Setting should be under the power off status. just turn on
the spa , LCD will display “---”
1）、Press“ ” to start Circulation-cleaning setting mo e, LCD showes “ ” an it is flashing.You can
set the pre-circulation time simultaneously(refer to chart 2 an illustration 2). Press “ ” again to turn
off the circulation cleaning,an the “ ” will isappear.
2)、Press“ ”（minutes）an “ ”（hours）to a just the time.
It will a 1 hour when pressing “
HOUR
” each time an the hours coul be a e continually when
pressing “
HOUR
” without stopping. The a justment range is 00-23.
It will a 1 minute when pressing “
MIN
” each time an the minutes coul be a e continually
when pressing “
MIN
” without stopping. The a justment range is 00~59.
4

3)、Press“ ” to set lasting time of circulation.
It will be a e 5 minutes by pressing “ ” an 1 hour by pressing“ ”each time。The maximum
working time is 19 hours an 55 minutes.
4)、Finally Press “ ” to confirme all settings .
Notice: The system will be exit automatically by pressing key of “ ”
1） Pre-circulation setting be turn off
2）
starting time of circulation
3） Lasting time of circulation
4）
Finished
Chart 2
***Notice***
1 ll the setting of Circulation-cleaning must be set on Power OFF status
2 Circulation PUMP and OZONE are not working while setting the circulation
cleaning.
5

5、Preheating Setting (if required)：
The isplay will show clearly whether preheating work or not. See following Fig 7-8：
：
ON
OFF
Fig.7：Pre-heating On 图8：Pre-heating Off
Pre- heating setting should be under the power off status. just turn on the spa ,
LCD will display “---”
1） 、Press“ ” to start Pre-heating setting mo e, LCD flashes of “ON” , You can set the pre-heating time
simultaneously (refer to chart an illustration 3). Press“ ”to turn off the pre-heating ,an the “
” will isappear on panel.
2)、Press“ ”（minutes）an “ ”（hours）to a just the time.
It will be a e 1 hour when pressing “
HOUR
” each time an hours coul be a e continually when
pressing the “
HOUR
” without stopping. The a justment of hours is 00-23
It will be a e 1 minute when pressing “
MIN
” each time an minutes coul be a e continually
when pressing the “
MIN
” without stopping. The a justment range is 00~59
3)、Press“ ” to set lasting time of circulation.
It will be a e minutes by pressing “ ” an 1 hour by pressing“ ”each time。The maximum
working time is 19 hours an 55 minutes.
4)、Press “ ” again to set the water temperature(please refer to Chart 3 an illustrate 4). Press “ ”
button to change the temperature. The range of temperature setting is: 15~40℃。
5)、Press “ ” to confirm all settings.
6

Notice: The system will be exit automatically by pressing key of “ ”
1） Pre-heating setting is turn off
2） Starting time of pre-heating
3） Lasting time of circulation
4） Preset temperature
5）
Finished
Chart 3
***Notice***
1、ll setting of preheating must be in Power OFF mode, just turn on the spa，the
LCD will display “---”
2、Please note that it shows "on" or "off" on the LCD. "on" means preheating is
turned on mode. when the time reaches your desired time, heater will work. If panel
shows "off", means that heater not be set.
3、Circulation PUMP and HE TER not working while setting preheating.
6、bout Pre-heating
When the time reaches your esire time, LCD shows “ON” an the tub is fille with water, heater works.
circulation pump works simultaneously. The count own time will be shown on the LCD screen, till the preset
time finishe .
7

The preheating will be turne off automatically once the preset time is finishe .
Or Pressing the “ ” key can stop preheating.
***Notice***
i. When setting temperature is lower than or equal with current water
temperature ，Even preheating is on status, the circulation PUMP and
HE TER are not working。
ii. When the HE TER is a “I” type frame，The power of circulation PUMP must
reach 1HP 。Otherwise the heater don’t work due to not enough water
pressure to drive pressure switch.
iii. If above two condiction still not make the heater work, Please short the line
of water pressure switch。
7、Circulation-cleaning：
As the current time is as same as the preseting time, the preset is “on” too an the tub is fille with water,
the circulation cleaning will start, the circulation pump works at the same.. The LCD shows the count own time.
All the surfing pumps an blower will work for 30 secon s at every 30 minutes. The Ozonier works at every 15
minutes.
The circulation cleaning will be turne off automatically once the count own time is finishe or By pressing
the “ ” key to turn off irectly.
8、Operation to Power ON/ OFF
Pressing the key “ ” in “power-off” status to enter the “power-on” status. To pressing the in
the status of “power-on” to enter the “power-off” status. The LCD screen shows the on or off.See following
Fig.9-10
AM
OFF
AM
OFF
Fig.9：Power Turn OFF Status Fig.10：Power Turn ON Status
9、Temperature setting：
In the status of “Power-on” an “HEATER” is working.It will a 1 centigra e by press “ ” each
time ，the temperature will be a e continually till reach 40 centigra e(106 Fahrenheit ) by press “ ”
without stop.Press “ ” again ，an the temperature is show 15 (59 Fahrenheit)℃。The range of
a justment is：15~40 (59~1℃06 Fahrenheit)。
10、Operation Radio & CD：
8

AM
PUMP3
Fig.11：Ra io frequency is 105.2 MHZ，Save the present frequency to channel 3 (Save channel)
or Exchange the frequency form channel 3 to the present (Searching channel)
I、“ ” key is the ON/OFF key of ra io an CD。an it is only available in the status of power on.
The first pressing “ ” is turning on the ra io，the secon pressing “ ” will turn off the ra io an turn
on the CD at the same time，an the thir pressing“ ” ，will turn off the ra io an CD simultaneously.
Ⅱ、LCD will show present frequency an volume of the ra io after turning on the ra io。
Ⅲ、In the working of ra io， The volumle of the present ra io frequency can be change by pressing “
MIN
”an “
HOUR
”
Ⅳ、Pressing the key “
SET
” will take out the memorize ra io frequency ，Pressing the key “
SET
” continually will take out the memorize ra io frequency from channels will be save at present
channel by pressing this key continually。If none of the channel， LCD will isplay “---”。
Ⅴ、Press the key “
MEM
” coul memorize the present ra io frequency ， Pressing the key “
MEM
” continually will memorize the present ra io frequency in ifferent channel 。 The channel of max is
10，Name of channel is 0-9。
Ⅵ、The volume can be change by pressing key “
SET
VOL+
”an “
OPEN
”
11、Operation of Pump：
The Button , operates pump 1 ；The Button
PUMP2
operates pump 2 ；The button
PUMP3
operates pump 3，Also the pump 3 is the circulation pump。When pump 3 is turne on the LCD
will show “ ”， whether the heating an circulation is on or off. The LCD will show when pump3 is off
an the heating, inclu ing pre-heating an circulation is about to start
12、Operation of lasting circulation cleaning：
Press the key “ ” at any time to turn on or off the lasting circulation cleaning, work mo e is like the
preset circulation cleaning. The surfing pumps an blower work for 30 secon s at every 30 minutes. Ozonizer
works for 15 minutes at every 105 minutes,an repeat in this program .
Ozonater only work un er the circulation cleaning works.
IMPORT NT: Please ensure that the ozone function is not in use whilst bathing in the spa
9

During the lasting circulation cleaning,press” ” key can stop the heating ,but start again the heating.
13、Operation of spa lights：
Press the “ ” key to turn ON/OFF of the the LED lights an the Fiber optic lights.
14、Setting the constant Temperature Settings：
1）、Pressing the “ ” button will start the constant temperature heating.
2）With the setting above, the circulation pump will work automatically.
3）、If the tem perature is set at 35 , when the water tem perature reaches or excee s 36, the heater℃ ℃
will be turne off automatically an the circulation pump will stop after 5 secon s. When the water temperature
reaches or lower than 34 , the heater will start up℃ again.
4）、In the case of an error the LCD shows ”E1” or “FF”. If this happens, the thermostatic heating sytem
will NOT be available, the heater oesn’t work.
15、Operating the ir Blower：
Press“ ” controls the blower
16、Fahrenheit & Celsius Temperature shift：
In the status of“Power off” pressing the key “ ” can change the mo e of Fahrenheit & Celsius egree
17、When there is no water in the spa. ll surfing pumps, and heating system can not
start up. However the corresponding signals will flash on the LCD.
18、Prevent freezing function:
This function is only available while the spa is on normal power supply.The heater & circulation pump will work
automatically once the water temperature is at below 5 , when the water tem perature is reach at 10, heating℃ ℃
will stop.
IV、Electric parameters
1、Performance index：
Rate voltage： 220V/50Hz Maximum working current：60 A/220V－240V～
Voltage-resistance：1250V/1 minute without penetration。 Isolative resistance：》200MΩ
Water resistance gra e：IPX5 Electric shock resistance：first gra e
(2) Output loading index
Heater： AC220V/3KW Water pump： AC220V/3HP×2
water pump：AC220V/1HP×1
Air pump：AC220V/700W×1
Spa light： AC12V/5W Ozone： AC12V/15W
Ra io： 1) Frequency Range： FM： 87.0~108.0MHz
2) Maximum Output Power： 10W
3) Speaker：8Ω amp proof speaker
10

5.Warning Information
a. Means for isconnection must be incorporate in the fixe wiring in accor ance with the wiring rules.
b. If the supply cor is amage , it must be replace by the manufacturer, its service agent or similarly
qualifie persons in or er to avoi a hazar .
c. This appliance is not inten e for use by persons (inclu ing chil ren) with re uce physical, sensory or
mental capabilities, or lack of experience an knowle ge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
. Chil ren shoul be supervise to ensure that they o not play with the appliance.
e. Details concerning cleaning an other maintenance
f. Maintenance of water purity, especially PH values an chlorine concentrations.
g. Cleaning an isinfection
h. Use an installation of a cover.
i. Disposal of water
j. Precautions to avoi amage ue to water freezing
k. Precautions to avoi amage when the appliance is left empty for exten e perio .
2.2 Sub-clause 7
The installation instruction shall state the substance of the following:
- Earthe appliances must be permanently connecte to fixe wiring;
- The appliance shoul be supplie through a resi ual current evice (RCD) having a rate resi ual
operating current not excee ing 30 mA.
- The floor has to be capable of supporting the expecte loa .
- An a equate rainage system has to be provi e to eal with overflow water.
- Details of how to follow the wiring rules, for example, specifying that parts are installe in the correct zone
an that equipotential bon ing is carrie out.
W R
NING
1、DANGER ：RISK OF ELECTRIC SHOCK ，Connect only to a circuit protecte by a
Groun Fault Circuit lnterrupter.
2、Groun ing is require . The unit shoul be installe by a qualifie service representative an
groun .
3、FOR YOUR SAFETY-This pro uct shoul be installe by a professional service
technician,qualifie in hy rotherapy bath installation.
4、lt’s prohibite to cover the instrument with something while opeating.
5、when using at the first time ,Be sure there is water in heater pipe before staring.
6、parts containing live parts, except parts upplie with safety extra-low voltage not Excee ing
12V,must be inaccessible to person in the bath；
8、earthe appliances must be permanently connecte to fixe wiring；
9、the appliance shoul be supplie through a resi ual current evice (RCD)having a rate
resi ual operating current not excee ing 30 mA.
10、If the mains cor of this appliance is amage ,It must only bereplace by our service
representative,As special tools an /or parts are require
11

Solutions of ault
Phenomenon Reason Ho to Solve the problem
No power supply 1. The electric leakage switch was
breaked off
2. The use be break off
1. Check and eliminate the malfunction,
restart the spa
2. Please change fuse
No display on control
panel
1. The plug which connected with the
panel loose or disconnected
2. The Panel happened with malfunction
1. to connect the plug of the control
panel and the main box
2. Change a new control panel
LED light not work 1. Power of the light be break off
2. use be break off
3. light be burn
1. To check if cable of the light is well
connected with main box or not
2. Change a fuse
3. Change a new lampwick
Ozone not work 1. Ozonater burn
2. use be break off
3. Cable of the ozonater be cut off
1. Change a new ozonater
2. change a fuse
3. check if the cable of the main power
is connected with the main box or
not.
Displaied “E1”” ” in
control panel
1. temperature detector be cut off or
shortcirculate
2. plug of the temperature detector be
nundated by water
1. Connect the temperature detector
2.Change a new temperature detector
being incapable of
activate water pump,and
water pump icon
flashing
1.water not achieve the appointed level
2. water detector not connect well
1. To add more water to make it up to
the water detector
2. To re-connect the line of water
detector
Heater not work, and
heating icon on panel
flashing
1. setting water temperature lower then
the water temperature
1. set the temperature degrees higher
than the water in tub
temperature(between 15 and 43 °C。
Leakage 1. silicon plaster not good
2. PVC plaster not good
3. Blow out of the water pipe
1. To remove the jets then re-install one
2. To plaster once again
Change water pipe
12

13

14

15
