Unit Objectives
Unit 1 installation
Given a realistic scenario depicting a new site install, the learner will be able to install and setup the trifecta coffee
brewer for customer turnover without error.
Given a new trifecta, all the necessary tools and safety equipment, the learner will be able to install
the brewer without error.
The learner will be able to verify that the site requirements have been met.
The learner will be able to locate and document the serial number.
The learner will be able to hook up the water supply.
The learner will be able to hook up the electrical supply.
The learner will be able to power on the brewer.
The learner will be able to perform initial setup.

trifecta™ Training Manual
4
Installation
Site Requirements
Space
• trifecta dimensions are 23” H x 12” W x 12” D
• Weight 35 lbs
Plumbing
• 1/4malearetting
• Dedicated water supply with shut-off
• Connected to cold water supply
• Water pressure 20-90psi, 50psi if regulator is needed
Electrical
• 120VAC, 2 wire plus ground
• Dedicated 15Amp circuit breaker
• Receptacle within 5 feet of the brewer
Location of the Serial Number
The serial number is located on the data plate which is located on the
inside of the brewer. The serial number half tag can be found underneath
the switch panel.
Water Supply Installation
Step 1: Flush water lines.
Step 2: Securely attach 1/4” water supply line to the elbow.
Step 3: Secure the water supply line and power cord under the retainer strap in any of the three locations as needed.
Step 4: Turn on the water supply.
1
2
3
Water Line and Power Cord Entrance Locations
Data Plate/Serial Number
Serial Number

Bunn-O-Matic Corporation
5
Electrical Install
Step 1: Use a voltmeter to verify the correct voltage supply.
Step2:Thebrewermustbedisconnectedorunpluggeduntilspeciedintheinitialsetupsection.
Optional Drain Hook-up
Step 1: Remove the drip tray and the chrome plug from the base.
Step 2: Drill out the auxiliary outlet on the drip tray with a 1/2” drill bit.
Step 3: Secure a 5/8” hose to the drip tray; routing it through the
opening in the base assembly.
Step 4: Connect the hose to the drain line as needed.
Step 5: Install the drip tray.
Initial Setup
Step 1: Install the check valve.
Step 2: Install the clear brew chamber, brew cup and then lock into position.
Step 3: Place an empty container under the brew chamber.
Step 4: Connect the brewer to the power source.
Step5:Pressthebrewstartswitchandallowthewatertoowintothebrewtank.Someexcesswaterwillowinto
the receiving container.
Step6:Waitapproximatelyveminutesforthewaterinthetanktoheattothepropertemperature.Thedisplaywill
read “HEATING” until the tank reaches it’s operating temperature. Some water will drip from the brew
chamber during this time; this is due to expansion and should not occur thereafter. Any excess water in the
brew chamber will be purged automatically at the end of the initial setup.
Step7:Watervolumesandowsettingshavebeenpresetatfactorydefault.Refertothe“AdjustingBrewing
Parameters” section of the “Installation & Operating Guide” if the parameters need to be adjusted.
Step 8: If the instruction in this section was followed correctly, the brewer is now ready for use.
Brew Chamber
Brew Cup
Check Valve

Unit Objectives
Unit 2 setup
Given a realistic scenario depicting a new site install, the learner will be able to install and setup the trifecta coffee
brewer for customer turnover without error.
Given an installed trifecta, all the necessary tools and safety equipment, the learner will be able to
setup the brewer for initial operation.
The learner will be able operate the switch controls.
The learner will be able to enter the programming menus.
  Thelearnerwillbeabletoperformtheow-ratecalibrationofthebrewwater.
The learner will be able to adjust the brewing parameters and perform a brew process.
The learner will be able to adjust optional program menu settings.

Bunn-O-Matic Corporation
7
Setup
User Interface
The switch decal adheres to the front housing over the electronic switch and LCD (Liquid Crystal
Display) board. The mechanical switches are mounted directly onto the electronic board with a
buttonmountedonthestemforproductactuation.Theswitchdecaloverlaybuttonsareidentied
by symbols for button recognition. The user interface allows the user to program the brewer for a
product recipe, start brew process and to perform a rinse after the brew process.
Levels of Programming
Level 1 Access
Press and hold both arrows approximately 3 seconds until the
display screen reads “RECIPE CHANGES” “ENABLED - LOCKED”.
Level 2 Access
Press and hold both arrows approximately 10 seconds until the
display screen reads “ PAUSE % BEFORE BUBB”.
Programming Lockout Switch
The switch is used to prevent access to both levels of the programming menus.
Program Lock Position
When trying to access either level of the programming menus, a message will display reading
“MEMORY IS LOCKED CONSTANT CHANGE IS NOT POSSIBLE”.
Set Position
You are able to access the programming menus in level 1 or level 2.
Rinse
Press this button to
rinse the brew chamber
after each brew cycle.
(-)/NO
Program/Select
Brew Start
Press again to cancel.
(+)/YES
Operating Controls

trifecta™ Training Manual
8
How to Access the Programming Lockout Switch
Step 1: Before accessing the lockout switch, disconnect the brewer from the power source.
Step 2: Remove the drip tray.
Step 3: Remove the two screws located behind the drip tray and lower the backsplash panel as far as it will go.
Step 4: Push the top down to clear the brew chamber support arm and then pull the top of the panel out before
completely removing the panel.
Step 5: The programming lockout switch is located on the top right of the main control board.
Programming Menus
The programming menus for the trifecta™ are divided into two levels. Level 1 allows for brewing adjustments,
supporting services and diagnostic functions. Level 2 contains menus for advanced parameter settings and factory setup
menus that are used in development of the trifecta™. Generally, level 2 factory default values will require no adjustment.
Level 1 Optional Adjustment Menus
    Bydefault,“ENABLED”willbeashingtoindicatethatthebrewingparametersmaybe 
accessed and changed. Selecting “LOCKED” will prevent changes to the brewing
parameters.
This screen allows the user to modify or change a recipe’s name.
This screen allows the user to add additional names to the default list.
This screen allows the user to delete a recipe name from the default list.
This screen allows the user to access and change the language setting.
Selecting “METRIC” will allow the user to change the units for measurement from
Fahrenheit to Celsius; ounces to milliliters; etc. “ENGLISH” is the default setting.
When enabled, this will allow different temperatures for recipes and will disable the
“BREW LOCKOUT” screen. The default setting is “DISABLED”.

Bunn-O-Matic Corporation
9
Selecting “YES” will only allow brewing at or above the “READY DEGREES” screen. The
default of this option is set to “YES”.
The screen allows the user to set the minimum temperature allowable to start a brew
cycle. The set temperature on this screen is how many degrees under the tank target
temperature that the brewer can begin a brew cycle. Range of 2° to 20° below the tank
target temperature.
The amount of press time during auxiliary rinse mode. Enabling this option will allow
the user to set the seconds for rinse time. Range
This screen allows the user to adjust the rinse time.
This screen allows the user to adjust the amount of press out time during the primary
rinse mode.
Primary rinse mode. “OFF” is equal to push and hold. Numbers represent seconds and
the brewer will continue to rinse when the button is released.
This screen allows the user to adjust the amount of pressure used to exit water from
the brew chamber during the primary rinse mode.
This screen will track and display the total number of brew cycles completed. This screen
cannot be reset.
This screen will track and display the total number of brew cycles completed. This screen
can be reset.
This screen allows the user to program a phone number of a factory authorized service
department. This phone number will be displayed if the brewer should encounter a fault
code.
This screen allows testing of load components and switches. It should only be used by
trained technicians.
This screen will allow the user to reset all brew settings, calibrations, temperature
adjustments, coffee names and recipes to the factory presets.
Level 2 Optional Adjustment Menus
Note: These menus are generally used for developmental purposes only. While some of the menus can be adjusted
intheeventofcoffeenotmixingproperly,othersarenottobeadjustedatallintheeld.
Brew Water Calibration

trifecta™ Training Manual
10
These menus are used to set up the initial mixing of the coffee grounds
and can be adjusted in the event of coffee not mixing properly.
Do Not Adjust: Factory Setup Menus
The adjustable time on this screen effects how soon the brewer will go from full power
heating to a reduced power triac control at the end of a brew cycle. Changing this setting
will slow the recovery time and reduce the expansion of water.
    Theturbulencepowerduringtheinitialmixofcoffee.Thisistherstintervalwhentheair
    comeson.ThisadjustmentmenucorrespondswiththerstfourmenusinLevel2.
This adjustment menu is the power level of the turbulence when the brewer is in the off
time during a brew cycle.
The time that the turbulence pump is on right before a dispense. This adjustment menu
is used to help clear the brew screen and aid the initial press-out. It also can work in con
junction with items 11 and 12 to begin the pressure build up in the chamber to speed up
the press-out sequence.
This screen allows the time to be adjusted for reduced air power level during the end of a
press-out sequence.
This screen allows the time to be adjusted for reduced air power during the end of a
press-out sequence. This is intended for reducing the amount of splatter at the end of a
brew cycle.
This adjustment menu is used to minimize the delay between an end of brew and press-
out sequence. This will cause the pressure to build up in the chamber during the end of
the brew. This menu screen works in conjunction with items 8 and 12.
This screen allows the amount of pressure build up in the chamber to be adjusted during
the end of a brew cycle.

Bunn-O-Matic Corporation
11
After the initial setup, it is recommended to perform a brew water calibration before making any recipe adjustments
and starting a brew process. The purpose is to ensure that the brew volume or portion dispense is accurate upon
anishedbrew.Therecipebrewvolumeisadjustableandiscalculatedfromtheowcountsproducedfromthe
owmeter.Thedefaultcalibrationvalueis10ouncesduringthecalibrationroutine.Oncetheactualowamountis
captured,measuredandenteredintoprogramming,thebrewerwillautomaticallyadjusttheowcountnumber(ow
meter) to achieve a 10 ounce dispense.
How to Calibrate Water Flow
Step 1: Install the water supply and power to the brewer.
Step 2: Verify that the brew chamber is installed and locked into position.
Step 3: Gain access into programming and scroll to “SERVICE TOOLS” menu.
Step 4: Under “SERVICE TOOLS”, scroll through until the display screen reads “CALIBRATE FLOW” and select this
option.
Step 5: Place a graduated measuring cup that can hold at least 10 ounces of water under the coffee outlet.
Step 6: Follow the instruction on the display.
Step7:Allowthecalibrateowroutinetodispenseallofthewaterfromthebrewchamberintothegraduated
measuring cup.
Step 8: Record the ounces of water that dispensed into the graduated measuring cup.
Step 9: Enter the number of ounces recorded into the “ENTER OZ. 10.0” menu using plus and minus switches, then
 pressdonewhennished.
Adjusting Brewing Parameters
Tosetupspecicparametersforaparticularrecipe,verifythattherecipenameiscurrentlydisplayed.Thenpress
“SELECT”andthedisplayscreenwilltaketheusertotherstadjustmentoption.Ifthespecicbrewingparameters
need to be adjusted after selecting the coffee name, then you will need to scroll through all of the recipe parameter
menus and adjust them accordingly to your recipe.
This screen allows the user to adjust the desired brew volume. Range: 2 -16 oz.
This screen allows the user to adjust the seconds for the pre-wet of ambient water on top
of the coffee grounds. Range: 0 - 1.0 sec.
This screen allows the user to adjust the percentage of overall brew volume during the
pre- infusion stage. Range: OFF/ 1-100%.
This screen allows the user to adjust the timed delay after pre-infusion, when the
remaining water is introduced and the brewing process continues. Range: 1-25 sec.
This screen allows the user to adjust the seconds of extraction time that starts after the
total brew water is added to the brew chamber. Range: 20-250 sec.
This screen allows the user to adjust how long the turbulence air ON time is.
Range: OFF/ 1-25 sec.
This screen allows the user to adjust how long the turbulence air off time is.
Range: OFF/ 1-20 sec.

trifecta™ Training Manual
12
This screen allows the user to adjust the force of the air pump during turbulence.
Range: 1-14
    Thisscreenallowstheusertoadjusttheforceofthepress-outairpumpduringnish.
Range: 1-7
    Thisscreenallowstheusertoadjustthelengthofthepress-outtimeduringnish.
Range: 20-70 sec.
This screen allows the user to adjust the temperature of the tank. Range: 165°F - 205°F.
(74°C - 96°C)
trifecta™ Brewing Process
The trifecta™ offers the barista the opportunity to create an individual experience while producing a unique, deep,
ampliedcoffeebeveragebyutilizingtheparametersinthreephases.Usinganairinfusionprocess,thebrewer
heightens the quality of coffee. This unique process allows the barista to develop a distinct single cup of coffee with
theavorproletoelevatethecoffeeexperience.
Wetting Phase
The saturation of the coffee grounds can be controlled to get the percentage of water and pause appropriate for that
coffee.
The pre-wet of ambient water on top of the coffee grounds.
The percent of overall brew volume during pre-infusion.
The timed delay after pre-infusion and before the remaining water is introduced.
Extraction
By utilizing air infusion technology, air will be injected into the pressurized chamber to agitate the coffee grounds.
Thiswillresultinauniformextractiontocreateacomplexfullavoredbeverage.
The amount of time for extraction to start after the total brew water is added to the brew
chamber.
The amount time that the air pump is on during turbulence.
The amount of time that the air pump is off during turbulence.
The amount of force that the air pump generates during turbulence.

Bunn-O-Matic Corporation
13
Hydrolysis
Theairwillpressthecoffeeproductthroughametalscreentolteroutcoffeegrounds,whilepreservingcoffeeoils
and aromatics for a deep bodied and unique coffee experience.
    Theforceofthepress-outairpumpduringnish.
    Thelengthofthepress-outtimeduringnish.
How to Load Ground Coffee and Start the Brewing Process
Load Ground Coffee in the Brew Cup
Step 1: Lift the handle all the way up.
Step 2: Remove the brew cup assembly.
Step 3: Fill the brew cup with a desired amount of ground coffee.
Step 4: Place the brew cup under the brew chamber.
Step 5: Place the cup on the drip tray.
Step 6: Lower the handle to secure it over the top of the brew chamber.
Start the Brewing Process
Note: Before the user starts this process, the brewing parameters must be set. See “Adjusting Brew Parameters”.
Step 1: Scroll through the recipes using the arrow buttons.
Step 2: Press the “select” button to choose your recipe.
Step 3: Press the brew button. To cancel the brew cycle, press the brew button once more.
Step4:Whenbrewinghasnished,place an empty cup on the drip tray and then press rinse.
Step 5: Remove the brew cup assembly and empty out the wet coffee grounds.
Step 6: Rinse the brew cup thoroughly and place it back under the brew chamber.

Unit Objectives
Unit 3 Machine coMposition
Given a realistic scenario in which the learner has access to the internal components, the learner will understand the
composition and functions of the trifecta coffee brewer.
Given a realistic scenario requiring the learner to access the internal components of the trifecta, the learner
will be able to remove the top cover, front panel, brew chamber and arm cup support.
Given a module of the brewer, the learner will be able to identify major components and describe their
functions.
The learner will be able to explain how the components work in relation to the module.
The learner will be able to explain how the modules work in relation to the brewer.

Bunn-O-Matic Corporation
15
Machine Composition
Exterior Overview
The Enclosure
The majority of the service work done to the trifecta™ will require the service technician to access the inside of the
brewer. The components that make up the enclosure are the top cover, cup support and front panel. Once the en-
closure is removed, there will be access to the hot water tank, CBA and other electrical components. Depending on
the repair, the technician may have to remove one or all of these panels. In order to work safely, the power should
be disconnected prior to removal of any body panel. Once the panels and drip tray are removed, the power can be
reconnected in order to troubleshoot the machine.
Removing the Front Panel
Removingthefrontpanelwillgiveyouaccesstothemaincontrolboard,ventvalve,owmeter,hotwatertankand
drain line.
Step 1: Disconnect the power source.
Step 2: Remove the drip tray.
Step 3: Remove the two screws located behind the drip tray and lower
the front cover as far as it will go.
Step 4: Push the top down to clear the brew chamber support arm, then
pull the top of the cover out before completely removing the cover.
Removing the Top Cover
Removing the top cover will give you access to the dual inlet valve, turbulent air pump, press out air pump, LED,
sprayhead assembly, and the display or switch board.
Step 1: Disconnect the power source.
Step 2: Remove the 2 slotted screws next to each LED from under the trunk frame.
Step 3: Lift up on the top cover.
Note:Thetopcovermaybettedtightly.
Top Cover
Trunk
Base
Front Panel
Cup Support
Drip Tray

trifecta™ Training Manual
16
Upper Component Mounting
Parts Review
Upper Component Mounting Assembly
Dual Inlet Valve - Left Valve
Theleftvalveisthebrewwaterorknowastheinlettothebrewtank.Thewaterisrestrictedbyaowwasherwithin
the valve on the left side only.
Dual Inlet Valve - Right Valve
Therightvalveistherinsewaterforthebrewchamber.Thewaterisnotrestrictedbyaowwasherandtravelstothe
brewchamber’stoptting.
Press Out Air Pump (Left)
The pump is know as the coffee press out. The air vent valve will close; the air pump will turn on and create pressure
above the coffee to press out into the receiving cup.
Turbulent Air Pump (Right)
The pump is used to create the turbulence or rolling of the coffee particles within the brew chamber.
Display/Switch Board
The user interface allows the user to program or adjust the brewer for product recipes and begin the brew process
andnishwitharinseprocess.Anoverlayisusedwiththedescriptionofthebuttons.
Sprayhead
Parts Review
Dual Inlet Valve
Press Out Air Pump
Turbulent Air Pump
Display/Switch Board
Bezel
Switch Decal
Brew Chamber
Vent Line
Rinse Line
Sprayhead/Rinse Cone
Brew Chamber Switch

Bunn-O-Matic Corporation
17
Sprayhead Assembly
Brew Chamber Vent Line
The brew chamber top is vented through a normally open vent line which is interrupted by a vent valve when
activated for coffee press out.
Rinse Line
The rinse line directs cold water to the left rinse outlet hole above the rinse cone.
Sprayhead/Rinse Cone
Therinseconedeectsthecoldwaterevenlytoachieveauniformrinseowaroundthebrewchamber’sinnerwall.
Brew Chamber Switch
The switch is used to display a reminder message after a brew or used as a brew lockout. The message will read
“Check Brew Chamber” or “Brew Chamber Not In Place”.
Lower Component Mounting
Parts Review
Lower Component Assembly
Thermistor
A thermally sensitive resistor that will monitor the tank temperature and change resistance when subjected to a
corresponding change in temperature.
Tank
A vessel or container used with a non-serviceable heating element and will supply hot water for the coffee brewing
process. The approximate capacity is 20 ounces.
Limit Thermostat
A safety device made up of contacts on a bimetallic arm, which bends when heated, causing the contact points to
open. The device acts as a safety protection in the event of a tank over heating.
Flow Meter
Avolumetricmeterusingapaddlewheelwithmagnets.Thewheelrotateswhenwaterowsthroughthemeter
generatingapulsesignalforeveryamountofmilliliterspassingthrough.Theowmeterisusedas a dry plug in
preventionandusedastheprimarycomponentfordeterminingtheamountofbrewwater,alsoreferredtoasaow
count.
Thermister
Vent Valve
Tank
Limit Thermostat
Flow Meter
Control Board

trifecta™ Training Manual
18
Control Board
The control board is a single component that contains all of the programming software, interprets all of the data it re-
ceivesfromthesensorsandactivatescomponentstofulllthosedemands.Thecontrolboardrespondstotheusers
input through the switch or display board that activates and controls all of the necessary processes to deliver a single
cup of hot coffee.
Vent Valve
The vent valve is a normally open air valve that keeps the brew chamber vented and will close to allow pressurization
of the brew chamber for coffee press out.
Brew Chamber
Part Review
Brew Chamber Assembly
Brew Chamber
The clear brew chamber is captured by arm supports while loading the brew cup into position on the cup platform to
seal the top and bottom brew chamber rim. This is the area in which the coffee is extracted through enhanced
turbulence and coffee press out.
Grounds Cup and Brew Screen
Thegroundscupcanholdbetween12to40gramsofgroundcoffeeandcontainsthebrewscreenthatltersthecof-
fee grounds from entering a receiving container during press out.
Check Valve
The check valve is positioned in the center on the cup support and aligned to the water or air inlet hole. An o-ring
around the check valve’s body is used to seal off around its circumference. During the coffee press-out phase, coffee
will push the center poppet open in order for the coffee to dispense into a receiving container.
The brew and dispense system consists of:
• Inlet Valve • Flow Meter • Tank Assembly • Cup Platform
• Check Valve • Vent Valve • Press-out Air Pump • Turbulent Air Pump
• Brew Cup • Brew Chamber • Brew Chamber Top with
Micro Switch
Brew Chamber
Brew Screen
Grounds Cup
Check Valve
Assembly

Bunn-O-Matic Corporation
19
Brew and Dispense Sequence
Thebrewtankisinitiallylleduponstartupandmonitoredbytheowcountsfromtheow
meter.Oncethetankhasmetitsowcountnumber,thebrewtankwillbeginheating.Atthis
point, the incoming recipe brew water will displace the recipe hot water. Water in the brew
tank will maintain a certain level when commanded by the brew switch.
Once you depress the brew start button, a series of recipe brew events can take place dur-
ing the brew process depending upon how the selected coffee parameter menus are set.
Pre-wetting of the coffee grounds (ambient water), pre-infusion (percentage of overall brew
volume),llpause(delayafterpre-infusionbeforeremainingbrewwaterisintroducedand
brew turbulence intervals associated with the brew time menu setting).
The turbulence is the newest technology used to enhance the roll of the coffee grounds in
the brew chamber during the coffee extraction. Once all the recipe parameters have timed
out, the brewer will begin pressing out the coffee in the brew chamber using an air pump.
The air vent valve will close, shutting off the vent to the brew chamber and the press out
air pump will turn on for the amount of time set in the recipe parameter setting. The coffee
exits out through the center of the stream guide/check valve by pressure created within the
brewchamberthatpushesthecheckvalveopen.Thecoffeeowsoverthestreamguide
and into the receiving coffee cup.
Rinse Sequence
After a brew is complete, remove the receiving container from the drip tray and place an empty container onto the
driptrayunderthebrewchamber.Youwillpresstherinsebuttononthecontrolpanelidentiedbythewatersymbol
at the top. The purpose of the rinse before removing the brew chamber assembly is to rinse the brew chamber wall
of any remaining coffee grounds and into the brew cup.
The brew chamber is ready to be disengaged from the brew cup by lifting up on the top handle and rotating the
brew top upwards. Remove the brew cup from the cup support base and empty the coffee grounds from the cup.
Thoroughly rinse the brew cup and screen in preparation for the next brew process.

Unit Objectives
Unit 4 preventive Maintenance
Given a realistic scenario depicting a trifecta coffee brewer requiring a preventive maintenance, the learner will be
able to identify which elements of a component need to be serviced without error.
Given a trifecta brewer, all the necessary tools and safety equipment, the learner will be able to identify the
components that need to be serviced for each PM cycle.
Based on the cycle count the learner will be able to locate in the PM section of the manual the
appropriate PM procedures.
The learner will be able to use the manual to match the part and cycle count to the correct procedure.
