Instruction Manual
PUMA
Vacuum Booster
WY 8000 A
0870224356/-0002_en / Original instructions / Modifications reserved 15/12/2021

Table of Contents
2 / 29 Instruction Manual PUMA WY 8000 A_EN_en
Table of Contents
1 Safety .......................................................................................................................................3
2 Product Description ..................................................................................................................4
2.1 Operating Principle .......................................................................................................... 5
2.2 Application....................................................................................................................... 5
2.3 Standard Features ............................................................................................................ 6
2.3.1 Water Cooling.......................................................................................................6
2.3.2 Resistance Thermometer (TSA)..............................................................................6
3 Transport ..................................................................................................................................6
4 Storage .....................................................................................................................................7
5 Installation................................................................................................................................7
5.1 Installation Conditions...................................................................................................... 7
5.2 Connecting Lines / Pipes .................................................................................................. 8
5.2.1 Suction Connection ............................................................................................... 8
5.2.2 Discharge Connection ........................................................................................... 8
5.2.3 Cooling Water Connection ....................................................................................9
5.3 Filling Oil.......................................................................................................................... 10
5.4 Electrical Connection ........................................................................................................ 11
5.4.1 Machine delivered without Control Box or Variable Frequency Drive (VFD)........... 12
5.4.2 Wiring Diagram Three-Phase Motor...................................................................... 13
6 Commissioning.........................................................................................................................14
6.1 Compression Chamber Flushing ....................................................................................... 15
7 Maintenance.............................................................................................................................16
7.1 Maintenance Schedule ..................................................................................................... 17
7.2 Oil Level Inspection.......................................................................................................... 17
7.3 Oil Colour Inspection ....................................................................................................... 18
7.4 Oil Change....................................................................................................................... 18
8 Overhaul...................................................................................................................................22
9 Decommissioning.....................................................................................................................23
9.1 Dismantling and Disposal ................................................................................................. 23
10 Spare Parts................................................................................................................................23
11 Troubleshooting .......................................................................................................................24
12 Technical Data..........................................................................................................................26
13 Maximum Permissible Differential Pressures............................................................................26
14 Oil ............................................................................................................................................26
15 EU Declaration of Conformity...................................................................................................27
16 UK Declaration of Conformity ..................................................................................................29

Safety | 1
Instruction Manual PUMA WY 8000 A_EN_en 3 / 29
1 Safety
Prior to handling the machine, this instruction manual should be read and understood. If
anything needs to be clarified, please contact your Busch representative.
Read this manual carefully before use and keep for future reference.
This instruction manual remains valid as long as the customer does not change anything
on the product.
The machine is intended for industrial use. It must be handled only by technically trained
personnel.
Always wear appropriate personal protective equipment in accordance with the local
regulations.
The machine has been designed and manufactured according to state-of-the-art meth-
ods. Nevertheless, residual risks may remain. This instruction manual highlights potential
hazards where appropriate. Safety notes and warning messages are tagged with one of
the keywords DANGER, WARNING, CAUTION, NOTICE and NOTE as follows:
DANGER
... indicates an imminent dangerous situation that will result in death or serious injuries if
not prevented.
WARNING
... indicates a potentially dangerous situation that could result in death or serious injuries.
CAUTION
... indicates a potentially dangerous situation that could result in minor injuries.
NOTICE
... indicates a potentially dangerous situation that could result in damage to property.
NOTE
... indicates helpful tips and recommendations, as well as information for efficient and
trouble-free operation.

2 | Product Description
4 / 29 Instruction Manual PUMA WY 8000 A_EN_en
2 Product Description
IN
OSG
CWO 1 ODP
OFP
NP
ODP
OSG
CWI 1
OUT
BGC
BGC
TSA
MTB
OUT
EB
EB
MP
BGC
CWI 2
CWO 2
BF
MP
MP
OFP
BGC
BF Base frame BGC Barrier gas connection
CWI 1 Cooling water inlet (motor) CWI 2 Cooling water inlet (pump)
CWO 1 Cooling water outlet (motor) CWO 2 Cooling water outlet (pump)
EB Eyebolt IN Suction connection
MP Magnetic plug MTB Motor terminal box
NP Nameplate ODP Oil drain plug
OFP Oil fill plug OSG Oil sight glass
OUT Discharge connection
NOTE
Technical term.
In this instruction manual, we consider that the term ‘machine’ refers to the ‘vacuum
booster’.

Product Description | 2
Instruction Manual PUMA WY 8000 A_EN_en 5 / 29
NOTE
Illustrations
In this instruction manual the illustrations may differ from the machine appearance.
2.1 Operating Principle
The machine works on the Booster blower principle.
The two oil housings (on each side) allow the lubrication of the gears and bearings.
2.2 Application
The machine is intended for the suction of air and other dry, aggressive, toxic and non-
explosive gases.
The machine is specially designed for semiconductor applications including CVD coating,
solar, flat panel... processes. This machine is not intended for load lock application.
Conveying of other media leads to an increased thermal and/or mechanical load on the
machine and is permissible only after a consultation with Busch.
The machine is intended for the placement in a non-potentially explosive environment.
The vacuum booster is used in combination with a backing pump in vacuum system.
Permitted environmental conditions, see Technical Data [►26].
NOTICE
Start the backing pump first up to the allowed inlet pressure of the vacuum booster, see
Maximum Permissible Differential Pressures [►26] or call Busch representative.
Risk of damage to the machine!
NOTICE
Chemical compatibility of the process gases with the machine component materials.
Risk of corrosion inside the compression chamber which can reduce performance and
its lifetime!
• Check if the process gases are compatible with those following materials:
- Cast iron
- Steel
- Aluminium
- Epoxy resin
- Fluoroelastomer (FKM/FPM)
• In doubt, please contact your Busch representative.

3 | Transport
6 / 29 Instruction Manual PUMA WY 8000 A_EN_en
2.3 Standard Features
2.3.1 Water Cooling
The machine is driven by a water-cooled motor.
2.3.2 Resistance Thermometer (TSA)
The resistance thermometer monitors the oil temperature of the machine.
A warning is emitted when the oil temperature rises to 80°C.
The machine will eventually be stopped when the temperature thermometer (TSA)
reaches 90°C.
Oil TSA
T Warning T Switch off
YLC 250 B 80°C 90°C
3 Transport
WARNING
Suspended load.
Risk of severe injury!
• Do not walk, stand or work under suspended loads.
NOTICE
In case the machine is already filled with oil.
Tilting a machine that is already filled with oil can cause large quantities of oil to in-
gress into the cylinder.
• Drain the oil prior to every transport or always horizontally transport the machine.
Machine weight:
see the technical data or the
nameplate (NP)

Storage | 4
Instruction Manual PUMA WY 8000 A_EN_en 7 / 29
• Check the machine for transport damage.
If the machine is secured to a base plate:
• Remove the machine from the base plate.
4 Storage
• Seal all apertures with adhesive tape or reuse provided caps.
• Make sure that the cooling water has been completely removed, see Decommission-
ing [►23].
If the machine is to be stored for more than 3 months:
• Wrap the machine in a corrosion inhibiting film.
• Store the machine indoors, dry, dust free and if possible in original packaging
preferably at temperatures between -20 ... 55 °C.
5 Installation
5.1 Installation Conditions
NOTICE
Use of the machine outside of the permitted installation conditions.
Risk of premature failure!
Loss of efficiency!
• Take care that the installation conditions are fully complied with.
• Make sure that the environment of the machine is not potentially explosive.
• Make sure that the ambient conditions comply with the Technical Data [►26].
• Make sure to use a suitable backing pump, if necessary seek advice from your Busch
representative
• Make sure that the environmental conditions comply with the protection class of the
motor and the electrical instruments.
• Make sure that the installation space or location is vented such that sufficient cooling
of the machine is provided.
• Make sure that the oil sight glass (OSG) remains easily visible.
• Make sure that enough space remains for maintenance work.
• Make sure that the machine is placed or mounted horizontally, a maximum of 1° in
any direction is acceptable.
• Make sure that the machine is secured either from the four feet or from the discharge
flange.
• Check the oil level, see Oil Level Inspection [►17].
• Make sure that all provided covers, guards, hoods, etc. are mounted.
If the machine is installed at an altitude greater than 1000 meters above sea level:
• Contact your Busch representative, the motor should be derated or the ambient
temperature limited.

5 | Installation
8 / 29 Instruction Manual PUMA WY 8000 A_EN_en
5.2 Connecting Lines / Pipes
• Remove all protective covers before installation.
• Make sure that the connection lines cause no stress on the machine‘s connection; if
necessary use flexible joints.
• Make sure that the line size of the connection lines over the entire length is at least as
large as the connections of the machine.
In case of long connection lines it is advisable to use larger line sizes in order to avoid a
loss of efficiency. Seek advice from your Busch representative.
5.2.1 Suction Connection
WARNING
Unprotected suction connection.
Risk of severe injury!
• Do not put hand or fingers in the suction connection.
NOTICE
Ingress of foreign objects or liquids.
Risk of damage to the machine!
If the inlet gas contains dust or other foreign solid particles:
• Install a suitable filter (5micron or less) upstream from the machine.
Connection size(s):
– DN250, DIN 28404 (4 M8 screws instead of 8 screws as on standard).
Depending on the specific order, other connection dimensions may apply.
5.2.2 Discharge Connection
Connection size(s):
– DN100, DIN 28404 (4 M8 screws instead of 8 screws as on standard).
Depending on the specific order, other connection dimensions may apply.
• Make sure that the discharged gas will flow without obstruction. Do not shut off or
throttle the discharge line or use it as a pressurised air source.

Installation | 5
Instruction Manual PUMA WY 8000 A_EN_en 9 / 29
5.2.3 Cooling Water Connection
CWI 1 CWO 1
CWO 2
CWI 2
CWI 1 Cooling water inlet (motor) CWO 1 Cooling water outlet (motor)
CWI 2 Cooling water inlet (pump) CWO 2 Cooling water outlet (pump)
The cooling connections for the motor and the module must be connected in series.
• Connect the cooling water connections (CWI / CWO) to the water supply.
Connection size:
– G1/2 for the cooling water inlet and outlet on the motor (CWI 1/ CWO 1)
– Fitting Ø 10mm for the cooling water inlet and outlet on the pump (CWI 2/ CWO
2)
• Make sure that the cooling water complies with the following requirements:
Min. supply capacity l/min 4
Water pressure bar 2 ... 5
Supply temperature °C +10 ... +25
Required pressure differential across supply
and return
bar ≥ 1
• To reduce the maintenance effort and ensure a long product lifetime we recommend
the following cooling water quality:
Hardness mg/l (ppm) < 90
Properties Clean & clear
PH value 7 ... 8
Particle size µm < 200
Chloride mg/l < 100
Electrical conductivity µS/cm ≤ 100
Free chloride mg/l < 0.3
Materials in contact with the cooling water Stainless steel, copper and cast iron

5 | Installation
10 / 29 Instruction Manual PUMA WY 8000 A_EN_en
NOTE
Water hardness unit conversion.
1 mg/l (ppm) = 0.056 °dh (german degree) = 0.07 °e (english degree) = 0.1 °fH (french
degree)
5.3 Filling Oil
NOTICE
Use of an inappropriate oil.
Risk of premature failure!
Loss of efficiency!
• Only use an oil type which has previously been approved and recommended by
Busch.
For oil type and oil capacity see Technical Data [►26] and Oil [►26].
Check oil level
Oil filling at the motor side
