Buster+Punch GIRDER SHELF Operating instructions

L0217
N O T
INCLUDED
x 6x 8 x 2
x 2
x 1
BUSTERANDPUNCH.COM
GIRDER SHELF
PREPARATION AND INSTALLATION
INSTRUCTION MANUAL
DETAILS KIT
CONTENTS

x 2 x 1
1
Locate the glass rail in the position
that is desired, and use two coin
screws to fix it in place
Ensure the screws are not
cross-threaded
Use fingers only, no screw drivers
or

2
a. Hold the shelf up to the
wall, marking two points
through the top holes,
centre-distance 1094mm
Ensure that the shelf is level
before marking
b. drill two 2mm pilot holes
where the marks are
Consult this diagram
to determine the
height your shelf will
sit on the wall
Bracket mounting
screw position
276mm 260mm 280mm
17mm

3
a. Screw in two screws in the
top mounting holes on both
brackets
Do not fully tighten down
Make sure the brackets are
vertical
b. Secure brackets by adding
the remaining six screws
Ensure the brackets are
hanging vertically before
tightening screws
countersunk screw
(not supplied)
8x
2x

2x 2x
Screw together a coin
cap and a coin cap
mounting component
together, through the top
holes (one each side) in
the hanger shelf body.
Make sure the mounting
component is the correct
orientation.
4

Hang the shelf on the
brackets.
Use the coin screw
connector and slot the
shelf into the brackets.
Once the connector is in
the hole, the shelf should
drop down into the slot on
the bracket.
5

Hang the shelf on the
brackets.
Use the coin screw
connector and slot the
shelf into the brackets.
Once the connector is in
the hole, the shelf should
drop down into the slot
on the bracket.
6
2x

7
