Buster+Punch HANGER SHELF User manual

L0218
N O T
INCLUDED
x 4
x 4
x 2
x 8
x 2
x 2
x 2
x 1
x 1
BUSTERANDPUNCH.COM
HANGER SHELF
PREPARATION AND INSTALLATION
INSTRUCTION MANUAL
DETAILS KIT
CONTENTS

1114MM
1
MARK TWO POINTS,
CENTRE-DISTANCE 1114MM
ENSURE THAT HOLES ARE LEVEL
DRILL TWO 2MM PILOT HOLES
WHERE THE MARKS ARE
B
A
CONSULT THIS DIAGRAM TO DETERMINE THE HEIGHT YOUR SHELF WILL SIT ON THE WALL
BRACKET MOUNTING SCREW POSITION
2
SCREW IN TWO SCREWS IN
THE TOP MOUNTING HOLES
ON BOTH BRACKETS
DO NOT FULLY TIGHTEN DOWN
MAKE SURE THE BRACKETS
ARE PERFECTLY STRAIGHT
SECURE BRACKETS BY ADDING
THE REMAINING SIX SCREWS
ENSURE THE BRACKETS ARE
HANGING STRAIGHT BEFORE
TIGHTENING SCREWS
A
B
276mm 260mm
17mm
344mm

3SCREW A COIN CAP AND A COIN SCREW
MOUNTING COMPONENT TOGETHER,
THROUGH THE TOP HOLES (ONE EACH SIDE)
IN THE HANGER SHELF BODY
MAKE SURE
THE MOUNTING
COMPONENT IS
THE CORRECT
ORIENTATION

4HANG THE SHELF ON THE BRACKETS
USE THE COIN SCREW CONNECTOR AND
SLOT THE SHELF INTO THE BRACKETS
ONCE THE CONNECTOR IS IN THE HOLE,
THE SHELF SHOULD DROP DOWN INTO
THE SLOT ON THE BRACKET

5SCREW IN THE REMAINING TWO COIN SCREW
INTO THE BOTTOM HOLES
CHECK ALL FOUR SCREWS TO MAKE SURE THEY
ARE ALL TIGHT
ENSURE THE SCREWS ARE NOT CROSS-THREADED
6ASSEMBLE THE PAN RAIL TO THE SHELF USING THE TWO
CONNECTING BOLTS SUPPLIED, THREADING THE BOLTS
INTO THE PAN RAIL
USE A 3MM ALLEN KEY BOLT TO TIGHTEN THEM
NOT INCLUDED

8SCREW IN THE FOUR GRUB SCREWS TO THE
HOLES ON THE BACK OF THE GUARD RAIL,
ENSURING THEY ARE TIGHT.
ONCE GRUB SCREWS ARE TIGHT, TIGHTEN THE TWO
M5 X 10 MM COUNTERSUNK BOLTS FOR THE GUARD
RAIL ON THE BOTTOM OF THE SHELF
ASSEMBLE THE
GUARD RAIL ON TO
THE SHELF, LOCATING
THE PAN RAIL
CONNECTING BOLTS
LOOSELY SCREW
IN THE TWO
M5 X 10 MM
COUNTERSUNK
BOLTS USING A
5MM ALLEN KEY
(NOT INCLUDED).
7
A
B
