Butler 3657024 User manual

BUTLER Assembly Instructions
SPECIALTY COMPANY
8200 SOUTH CHICAGO AVE. CHICAGO, IL 60617
Plantation Cherry Easel
3657024
ITEM DESCRIPTION QUANTITY
A
C
1
1
Top
Shelf
hardware
bolts M6 x 35mm flat washers
H1 x 1 H2 x 1 H4 x 1
hex key #4
H3 x 1
spring washer
D
E
3
1
Legs
Metal plate
page 01 of 02
B
B
B
E
C
A
B1
Bottom
D

step 1
Put the Top (A) upside down
onto a smooth surface such as carpeted floor
(the shipping box works well).
step 2
Insert the male dovetail of the Legs(C) into the female
insert nut at the bottom (B) of the Top then
insert the Bolts( H1) with Spring Washer(H3) and Flat
Washer(H2) into the female insert nut and tighten with
the Hex Key (H4)
step 3
Align the hole of the Wooden Plate(D) with the
female insert nut at the bottom of the Top then
insert the Bolt(H1) with Sping Washer(H3)
and Flat Washer(H2)into the female insertnut and,
tighten with the Hex Key (H4).
step 4
Remove the Finial by rotaring counterclockwise
the insert the post through the Shel(C) and pin
with the Bolt (H1) to the desired height.
step 5
Return back the finial by inserting the bolt and
turn clockwise until tight.
Copyright cButler Specialty Company, 05 / 19
(*) Caution : DO NOT OVERTIGHTEN.
In any correspondence regarding this product, please include the complete
Butler identification number located on the underside of the product.
We hope this product will be a useful and decorative addition to your home for
years to came.
page 02 of 02
