BWINE F7GB2 User manual
14+
for age
v1.0
Quick Start Guide
Copyright ©2021 Bwine All Rights Reserved. 1
(Not included in package)
Download App
1
Charge the Batteries
Bwine Drone App
Bwine Drone
15W
Bwine Drone
Download on the
App Store
Download for
Android
Copyright ©2021 Bwine All Rights Reserved.2
2
Copyright ©2021 Bwine All Rights Reserved. 3
Unfold the handle
Unfold the antenna
3
1
2
3
Height≥65ft
4
Select an Open Flight
Copyright ©2021 Bwine All Rights Reserved.
4
5
Copyright ©2021 Bwine All Rights Reserved. 5
( About 40 seconds )
The DI sounds of the transmitter
stop and signal sign on the screen
lights, paring completed.
The light on the back of the drone
turns from red to green.
Pair the Transmitter with the Aircraft
Short-press 2 times to power
on the transmitter.
2
Press and hold the button until
the aircraft plays startup sound.
1
6
Calibrate the Compass
Connect to Wi-Fi
Copyright ©2021 Bwine All Rights Reserved.
6
Connect the mobile device to the aircraft's Wi-Fi and enter the App operation page.
Please refer to user manual (page 34) for more details.
Bwine-F7-GB2-******-BRG
Rotate the aircraft horizontally 360°.
( About 1-2 turns )
Push joysticks to 1 & 11 o'clock position.
Rotate the aircraft vertically 360°.
( About 1-2 turns )
Tap "CONTROLS" icon
7
Copyright ©2021 Bwine All Rights Reserved. 7
Calibrate the Gyroscope
Push joysticks to 11 & 1 o'clock position.
( About 2 seconds )
A level ground
Gimbal Self-inspection
Put on a level surface.
( About 20 seconds )
Copyright ©2021 Bwine All Rights Reserved.
8
Take off
Push up the left stick.
Start the Motors
Push joysticks to 5 & 7 o'clock position.
( About 2 seconds )
Tips: 1. The searching time depends on the flight environment.
2. If unsuccessful, the motors can't be started.
Search for GPS Automatically
GPS ≥3 bars Flash turns to solid light
D 0ft H 0ft DS 0ft/s VS 0ft/s
Ready to fly
Copyright ©2021 Bwine All Rights Reserved. 9
Search “Bwine F7 Quick Start”
on YouTube for First Flight
NEW TO FLYING DRONES?
Scan QR Code for More
Tech and Video Support
Check the Flight Guide in the App
CONTACT US FOR MORE TECH SUPPORT
Printed in China.
Common Problems and Solutions
The gyroscope is not calibrated
Question Reason Solutions
The motors cannot be started
GPS signal is unstable. Flying
near buildings and in
obstructed places
The aircraft isn't placed
correctly when it takes off
The Transmitter signal is
interfered or the aircraft
exceeds the range of remote
control
Compass interference
The side with the camera should be
forward and the tail of aircraft towards the
operator before it takes off
Please fly the aircraft outdoors without
interference, and ensure that it is within a
controllable range
Please manually land the aircraft in time
and calibrate the compass. Please make
sure to fly away from the buildings, trees,
power lines, and signal towers
Replace the propellers with new ones
Push joystick on the left into 1 O'clock
position and the joystick on the right into 11
O'clock position at the same time
The flying direction of the
aircraft is opposite to or
inconsistent with the remote
control joystick when flying
Out of control, spinning around
on its own, abnormal sound
Can't enter the compass
calibration program
Need to calibrate compass
each time
Aircraft falls suddenly Please don't use it in non-emergency
situations to avoid unnecessary losses
Emergency stop function
is used
The propellers become
deformed and incomplete
The position of the joysticks
isn't right
To reduce the situation of out
of control, improve its
stability and make it return
more accurate
Calibrating it follows the user manual or
APP commands
Please fly the aircraft in an open area
free of obstacles within the circle of
radius 32.81 ft (10 meters)
Turn on the aircraft in an open area with
strong GPS signal
The aircraft has low battery. Please
charge the battery in time
The compass is not calibrated. Please refer
to the "Calibration Before Flight" section
of the user manual
Push the left and right joysticks simultane-
ously to 5 o'clock and 7 o'clock for 2
seconds
Weak GPS signal
The red light stays on
The pink light stays on
The left and right joystick
are in place
Please fly the aircraft above 9.84ft(3
meters)
Place the aircraft on a horizontal surface
and conduct gyroscope/horizontal
calibration. Please refer to the "Calibration
Before Flight" section of the user manual
Unstable flight
Flying too low, affected by
aircraft airflow
The propellers become
deformed and incomplete Replace the propellers with new ones
Copyright ©2021 Bwine All Rights Reserved.
10
Copyright ©2021 Bwine All Rights Reserved. 11
Gimbal doesn't work
The gimbal hits the grass
when the aircraft takes off
from the grass
Put the aircraft on the aircraft landing pad
or cardboard to avoid hitting obstacles
The gimbal of aircraft is
interfered by man-made
external forces, or the aircraft
is picked up during the
calibration process of gimbal
It takes about 40 seconds for gimbal
self-checking and don't touch it during
calibration
The aircraft enters compass
calibrations program
The gimbal doesn't work during calibration.
Please place the aircraft on a level ground
when calibrating and the gimal will
calibrate automatically
Phone performance freezes
Question Reason Solutions
The phone is not connected to
Wi-Fi
The phone version is too low
Wrong app downloaded
Connect your mobile device to the Wi-Fi :
Bwine-F7-GB2-******
Android 6.0 and above, IOS 10.02 and
above
Set the Wi-Fi correctly
Turn the phone to airplane mode
Download the correct APP
When connecting to the
aircraft’ s WiFi, the network is
not set or set incorrectly
It's intercepted by mobile
phone plug-in
VPN switch is turned on
Turn off the intercept function and modify
permissions
Turn off the VPN switch
App does not display the
interface
Video isn't clear
Video freezes, image
transmission distance is short
APP crash or its functions are
abnormal
Phone cannot connect to Wi-Fi
Give us your mobile phone version model
and we will give you a corresponding
solution
The phone version is old and
not compatible with the APP
It is the first time to connect
your phone to the Wi-Fi
Try connecting a few more times or restart
the phone
Please insert an SD card into the camera
and save the video on it
Move the joysticks slowly
Adjust the frame rate and pixel on the APP
Point the Transmitter and the mobile
device at the flying direction of the aircraft
to maintain the trongest signal connection
Fly the aircraft in an unobstructed open
area free of buildings, high-voltage wires
and signal towers
Saved it on APP. The video
resolution is only 1280*720P
when saved on APP
The joysticks are moved too
fast when controlling the
aircraft
The aircraft is out of Wi-Fi
range
WiFi image transmission signal
interference
Fly the aircraft within the range of the
Wi-Fi
The transmitter and the
mobile phone are not pointed
at the direction of the aircraft
Close unused apps running in the
background to maintain the best
performance of the phone
The remote control antennas
aren't unfolded
Unfold the antenna and mobile phone
holder and make the antennas aim at the
flying direction of the aircraft
Copyright ©2021 Bwine All Rights Reserved.12
Turn on the aircraft and remote control and
it takes about 40 seconds for the aircraft
to connect to the remote control. And then
you can find the Wi-Fi name in the list
The WiFi name is not displayed
in the list
GPS signal is weak
Unable to return home, drifting
and flying away
The phone is a single band
phone
WiFi has not been activated
Use the dual band devices that support
both 2.4 GHz and 5 GHz/5.8 GHz
Wait for about 30 seconds after turning on
the aircraft and keep refreshing the Wi-Fi
list while the Wi-Fi is activated
The aircraft doesn't pair with
the remote control
Turning on the aircraft indoors
GPS signals cannot be found
indoors.Please search for GPS signals in
an open place outdoors
Please stay away from obstacles for more
than 32.81 feet(10 meters), and search for
GPS signals in an open area
Please don't turn off GPS suddenly during
outdoor flight. Switch back to GPS mode
in time
Under the tree, next to the
building, in an obstructed place
GPS signal was turned off
during the flight
It takes too long for the
aircraft to pair with the remote
control
Cannot charge battery/Cannot
fully charge battery
Short battery life
The product has slight marks
Please wait for about 40 seconds patiently
Please use the original factory charging
cable to charge
Flying in windy weather will accelerate
power loss
Please use a charger with 5V/3A to charge
it
Use a mobile USB charger that ensures
constant stable voltage output(5V) and
amperage output(2-3A)
It takes about 40 seconds for
the aircraft to connect to the
remote control
Using inferior charger or
charging on the computer with
unstable voltage output
Using inferior charging cables
Flying in windy weather
The battery is not fully
charged
In low temperatures, the chemical reaction
of the lithium battery is slowed down and
the energy cannot be fully released
In order to give you the best experience, we
tested functions of all aircraft before
shipping. Therefore, it is inevitable that
there will be slight traces. However, it can
be guaranteed that all aircraft are 100%
brand new
Flying in cold weather
We tested all aircraft before
shipping
Question Reason Solutions
