Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
󲐜󲐝󲐞󲐟󲐠www.alza.co.uk/kontakt
✆[phone]
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz

4
Thank you for using SW400,
SW750 sine wave inverter!
Connect the input battery (12 volts) of the inverter, you can provide 220V AC power
output through the AC (AC) output socket of this inverter, and reliably provide 220V AC
power output to car emergency starting equipment, civil appliances and other fields
(office equipment: computers, scanners, printers, fax machines, projectors, etc.; digital
products: cell phones, IPAD, IPHONE, IPOD, laptops, digital cameras, etc. Small power
electrical equipment: TV, water dispenser, dust collector, small electric iron, hair dryer
game machine, emergency lighting, electric shaver, etc.) Supply power; USB interface
provides DC(DC)5V SV power supply, for your mobile phone, IPAD, IPHONE, small digital
products to provide charging. At the same time, this product has a USB-C fast charging
port.
This product has reliable electronic technology, automatic safety monitoring circuit:
over-voltage protection, undervoltage protection, overload protection, short-circuit
protection, over-temperature protection, leakage protection, etc.. Not only protect the
product itself, but also protect your battery from over-discharge.
Before use, please read this manual and save it for future reference; the contents
of this manual include.
•Important safety information
•Safety features
•Panel function descriptions
•Connection instructions
•Operating instructions
•Troubleshooting
•Product specifications -Warranty and Service
Important Safety Information
Before using this product, please read the following safety instructions carefully and pay
special attention to all warnings and cautionary statements in the instruction manual.
Do not abuse or connect the appliance incorrectly may damage this product.

5
WARNINGS AND CAUTIONS
WARNING
•When the product is in use, please ensure that children are kept away from the
product. The inverter works with the same AC power as the mains, please pay
attention to the safety of electricity!
•When this product is loaded with high-power appliances, the product shell will be
hot. When using, please pay attention to the high temperature source.
•please do not use this product in flammable and explosive environment.
•the risk of electric shock: when the appliance is inserted into the AC outlet, please
ensure that your fingers do not touch the metal piece of the outlet and ensure
safe insertion.
CAUTIONS
•When the inverter AG socket is working, do not use electrical appliances that are
already charged to plug in, this will damage the product.
•Please do not cover the inverter shell, keep ventilation to avoid affecting the heat
dissipation.
OTHER SECURITY GUIDELINES
•Do not insert foreign objects into the AC output port or DC output port of this
product.
•Do not connect this product to other AC power distribution lines.
•Do not use the product for a long time in an ultra-high temperature environment.
•Do not expose the product to water, rain, snow or spray environment for use.
Security Features
The Inverter Contains The Following Protection Functions Safety Features.
This Product Includes 30a (swd400 30a*2, sw750 30a*3) Built-in Fuse
•Automatic shutdown for overload protection
•Under-voltage protection automatic shutdown
•Overvoltage protection auto shut-off
•Automatic shut-off for over temperature protection
•Load short circuit protection auto shut-off.
•Automatic shut-off for leakage protection

6
Part Description (figure 1)
FIGURE 1
FAN PANEL
SOCKET PANEL
Figure 1 Description of SW400,SW750 Inverter parts
1Ground screw
7Lithium working indication blue light
2Black negative terminal
8Error indication red light
3Fan
9Battery mode switch
4Red positive terminal
10 Power switch button
5German socket
11 In-line connection port
6Working indication green light
12 USB-A,USB-C combination port
Connection Instructions
Connect the clip cable to the 12V DC battery, check the battery type and battery voltage
match before connecting the battery.
CAUTIONS: DANGER OF REVERSE CONNECTION
•When connecting the red and black clip wire, make sure that the red is connected
to the positive terminal of the battery and the black is connected to the negative
terminal of the battery to avoid blowing the fuse by reversing the connection.
•make sure that the input cable is connected to a 12V battery, 6V batteries are not
allowed.
•connect the load that needs to be run to the AC socket or USB port, see
"Operation Guide" for details.
•Press and hold the switch for 1 second to start the inverter power.
•When the inverter is not in use, please disconnect the clip cable from both ends
of the battery to avoid static loss of battery power.

7
Operation Guide
•After long press the switch for 1 second, the socket outputs 220VAC, connect the
load to be run to AC output socket or USB port.
•If the load power exceeds the rated power, the overload protection will start and
the product will shut down automatically. Please reduce the load and connect a
load with lass than the rated power after the product restarts.
•When the battery voltage drops to 10V, the under-voltage protection function will
start and the product will automatically shut down. This can prevent the battery
from being damaged and ensure that the battery needs enough power when the
car starts.
•If the working temperature of the product exceeds the safe operating
temperature due to poor ventilation or high external temperature, the
overtemperature protection function will be activated and the product will be
automatically shut down, and it will automatically resume working when it
returns to normal temperature.
•If a defective battery charging system causes the battery voltage to rise to a
dangerous level greater than 18.5V, the overvoltage protection function will start
and the product will be automatically shut down.
CAUTION
Although this product is equipped with overvoltage protection, it may still damage the
product if the input voltage exceeds 17V.

8
Troubleshooting
PROBLEM: NO OUTPUT AND ABNORMAL POWER DISPLAY LIGHT
Possible Causes
Measures
Battery defects
Check the battery and replace it if
necessary
Loose battery clips
Check the connections
PROBLEM: OUTPUT VOLTAGE IS TOO LOW
Possible Causes
Measures
A standard average AC voltmeter
measuring the output voltage will result
in a measurement that is off by 5 to 15 V
Inverter output “pure sine wave”,
requiring measurement with a voltmeter
marked “true RMS” or with a voltmeter or
oscilloscope capable of measuring RMS
Battery voltage is too low
Charging the battery
PROBLEM: PRODUCT DOES NOT WORK
Possible Causes
Measures
Load power exceeds the continuous
output power of the product, overload
protection starts shutdown
Please use a load no greater than the
rated one
The load power is lower than the rated
power of the product, capacitive load or
inductive load too high power-on surge
caused by overload protection shutdown
The start-up surge of the load exceeds
the starting capacity of this product,
please choose a suitable 220V power
supply
The product is overheated by poor
ventilation to start the over-temperature
protection shutdown
Unplug the inverter from the output
socket, cool it for 15 minutes and remove
the shade.
Move the product to a cooler location. If
continuous operation is necessary,
reduce the load and restart
Battery feed
Recharge

9
Product specification
Specifications Are Subject To Change Without Notice
AC OUTPUT
Model
SW400
SW750
AC Output Voltage
220V/200V~25V AC
AC Continuous Output Power
400W
750W
Output overload protection power
520W Max
900W Max
AC Output Frequency
Typical values: 50 ±1Hz
Output Waveform
Pure sine wave
Fan control
Temperature 50°C or load>100W
USB-A, USB-C OUTPUT, REMOTE CONTROL FUNCTION
USB-A, USB-C port output
5V/3.1A, 9V/1.67A
Remote control board with LCD screen
Customer optional (not available by
default)
DC INPUT
Battery type
Lead acid
Lithium battery
Operating Voltage
11V-15VDC
10-16VDC
Static Current
<1.0A
Conversion efficiency (maximum)
>86%
Undervoltage Shutdown Voltage Point
10.0V±0.5VDC
9.0V±0.5VDC
Undervoltage Recovery Voltage Point
11.0V±0.5VDC
11.0V±0.5VDC
Overvoltage Shutdown Voltage Point
15.0V±0.5VDC
16.0V±0.5VDC
Overvoltage Recovery Voltage Point
14.0V±0.5VDC
15.0V±0.5VDC
LED INSTRUCTIONS
Normal Work
Green light on
Over-voltage, under-voltage, over-
temperature protection
Red light flashing
Overload protection
Red light on long
PHYSICAL PROPERTIES
Operating temperature range
0°C-50°C
Dimensions
254*143*74mm
306*143*74mm
Weight
1335g
1635g

10
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation, and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g., during transport,
cleaning by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
