ByronStatics AM66 User manual

2
Getting to know your
Retro FM/AM Radio

Getting to know your Retro FM/AM Radio
You’ll be up and running in no time
Getting to know your Retro FM/AM Radio
3
Ready? Let’s begin...
Please read these instructions carefully. They contain important information which will
help you get the best from your product and ensure safe and correct installation and
operation.
If you require any further assistance, our technical experts are happy to help. For full
details, refer to the product support section at the end of these instructions.
Fig 1.
1
Your Retro FM/AM Radio

Getting to know your Retro FM/AM Radio
You’ll be up and running in no time
Getting to know your Retro FM/AM Radio 4
1. Battery compartment, insert 4 x 1.5V
AA-size (LR6) batteries (not supplied)
2. Carry handle
3. Volume control
4. Rotary tune control
5. OFF/FM/AM rotary
control
6. Speaker
7. Telescopic aerial
8. Earphone Jack (on side)
9. Mains power socket
2
3
4 6
5
Fig 2.
1
7
8
9

Getting to know your Retro FM/AM Radio
You’ll be up and running in no time
Getting to know your Retro FM/AM Radio
5
Connection
1. Connect the mains power lead into the socket on the back of the Radio and fully
extend the radio aerial in a vertical position to obtain the maximum signal strength.
2. Plug the power lead into the mains power wall socket and switch on.
3. Turn the OFF/FM/AM rotary on the top of the radio to clockwise to turn the product
On.
Inserting the batteries (optional)
1. Before installing the batteries (not included) please ensure that the Radio is switched
off (turn the right hand rotary on the top to ‘OFF’) and is unplugged from the mains
power supply.
2. On the back of the Radio, push down the tabs to release and remove the battery
compartment cover.
3. Insert 4 x 1.5V AA-size (also known as LR-6) batteries, making sure to note the ‘+’ and
‘-‘ markings and position the batteries the correct way around.
4. Replace the battery cover, making sure it ‘clicks’ shut.
If used continuously on battery power, your Radio has an approximate battery life of 5
hours when using good quality alkaline batteries. When the battery power is low, please
switch off the Radio and replace the batteries.
Note: For battery operation please ensure that the mains power is switched off and
remove the mains power plug from the socket on the back of the Radio.
Switch on
Turn the OFF/FM/AM rotary on the top of the radio clockwise to turn the product On.
Note: Always make sure that the aerial is fully extended, to ensure the maximum signal
strength and the best possible sound quality.

Getting to know your Retro FM/AM Radio
You’ll be up and running in no time
Getting to know your Retro FM/AM Radio 6
Switch o
Turn the OFF/FM/AM rotary on the top of the radio to ‘OFF’. To completely switch off the
Radio, switch off the mains power at the wall socket.
Change the mode
Turn the OFF/FM/AM rotary on the top of the radio to ‘FM’ or ‘AM’ as required.
Adjusting the volume
Turn the rotary volume wheel on the top of the radio, anti-clockwise to decrease the
volume and clockwise to increase the volume.

This page is left intentionally blank

Using your
Retro FM/AM Radio 3

Using your Retro FM/AM Radio
Let’s get started
Using your Retro FM/AM Radio
9
Telescopic aerial
Please make sure that the aerial on the back of the Radio is fully extended before you
attempt to tune to an FM station. This will ensure that the maximum signal strength is
available when the Radio is tuning to a station. Extending the aerial also ensures the best
possible sound quality.
FM Radio mode
Check that your Radio is in FM radio mode. If you are not already in FM mode, turn the
OFF/FM/AM rotary on the top of the radio to ‘FM’.
Tuning to an FM station
In FM mode:
Use the rotary tuning dial on the front of the radio to tune to your favourite FM station.
Please use the frequencies marked on the dial as a guide.
The tuning dial will move both clockwise and anti-clockwise but does have a ‘stop’ point.
If you turn the tuning dial and reach the ‘stop’ point, please turn the dial in the opposite
direction to tune.
Note: If reception is still poor, check that the aerial is fully extended and then adjust the
tuning dial slowly, or try moving the Radio to another location.

Using your Retro FM/AM Radio
Let’s get started
Using your Retro FM/AM Radio 10
AM Radio mode
Check that your Radio is in AM radio mode. If you are not already in AM mode, turn the
OFF/FM/AM rotary on the top of the radio to ‘AM’.
Tuning to an AM station
In AM mode:
Use the rotary tuning dial on the front of the radio to tune to your favourite AM station.
Please use the frequencies marked on the dial as a guide.
The tuning dial will move both clockwise and anti-clockwise but does have a ‘stop’ point.
If you turn the tuning dial and reach the ‘stop’ point, please turn the dial in the opposite
direction to tune.
Note: If reception is still poor, check that the aerial is fully extended and then adjust the
tuning dial slowly, or try moving the Radio to another location.

Using your Retro FM/AM Radio
11
Using your Retro FM/AM Radio
Let’s get started
Use the earphone
Connect the stereo In-Ears to the Phones (8) output socket onto the appliance.
Notes:
Ensure that the 3.5mm jack of the headphone is completely inserted into the headphone
socket to accomplish optimal audio quality.
Never wear headphones while driving a car, riding a bike or during any activity that
requires awareness of the surroundings. Sound isolation could pose a safety risk to you
and the people around you
Warning !
1. Excessive sound pressure from earphones and headphones can cause hearing loss.
2. Ensure that children do not turn the volume too high.

This page is left intentionally blank

Other information 4

Other information
Helpful technical information
Other information
15
Specification
Power source:
Batteries:
Input AC 120V~/60Hz
4 x 1.5V AA size (LR6)
(Optional, not supplied)
Frequency range: FM:
AM:
88MHz to 108 MHz
520kHz to 1720 kHz
