BZB Gear BG-ADAMO-4KND User manual

BG-ADAMO-4KND
4K UHD AUTO TRACKING HDMI 2.0/12G-SDI/USB 2.0/USB 3.0/NDI|HX3 Live
Streaming PTZ Camera with Tally Lights
User Manual

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 2

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
Table of Contents
Statement 4
Safety Precaution 4
Introduction 5
Features 5
Packing List 6
Specifications 6
Installation and Handling Caution 8
Camera Interface 8
RS-232 Interface 9
VISCA Networking 10
Mounting 10
Wall Mounting 10
Ceiling Mounting 11
Operating Instructions 12
Power on and Self-check 12
Remote 13
Remote Buttons Introduction 13
Network Connection 17
Initial Web Client Login 19
Preview 20
SD Card Recording 21
Auto-Tracking Configuration 21
Zone Tracking Setup 22
General Configuration 23
Streaming 24
Video Stream Capture 24
Live Stream Publish 25
NDI 26
Serial Port Communication and Control 27
VISCA Protocol List 27
VISCA Protocol Return Command 27
VISCA Protocol Control Commands 27
VISCA Protocol Inquiry Commands 31
Pelco-D Protocol Command List 34
Pelco-P Protocol Command List 35
Maintenance and Troubleshooting 36
Tech Support 37
Warranty 38
Mission Statement 39
Copyright 40
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 3

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
Statement
Please read these instructions carefully before connecting, operating, or configuring this
product. Please save this manual for future reference.
Safety Precaution
●To prevent damaging this product, avoid heavy pressure, strong vibration, or immersion
during transportation, storage, and installation.
●The housing of this product is made of organic materials. Do not expose to any liquid,
gas, or solids which may corrode the shell.
●Do not expose the product to rain or moisture.
●To prevent the risk of electric shock, do not open the case. Installation and maintenance
should only be carried out by qualified technicians.
●Do not use the product beyond the specified temperature, humidity, or power supply
specifications.
●Wipe the lens with a soft, dry cloth when cleaning. Wipe it gently with a mild detergent if
needed. Do not use strong or corrosive detergents to avoid scratching the lens and
affecting the image.
●This product does not contain parts that can be maintained or repaired by users.
Damage caused by dismantling the product without authorization from BZBGEAR is not
covered under the warranty policy.
●Installation and use of this product must strictly comply with local electrical safety
standards. The power supply of the product is ±12V, and the max electrical current is
2A.
●Electromagnetic fields at specific frequencies may affect the video image. This product
is Class A and may cause radio interference in household applications and appropriate
measures may be required for proper operation.
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 4

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
Introduction
The BZBGEAR BG-ADAMO-4KND is an ultra-high-definition PTZ camera that delivers 4K
resolution video at 60fps Available with either the 12x optical zoom lens with an 80.4°
wide-angle, or the 25x optical zoom lens with a 59° wide-angle. Featuring USB 2.0, USB
3.0, LAN, HDMI, and 12G-SDI video connections. The 3D noise reduction technology
combined with the low-noise CMOS sensor ensures impeccable image clarity. The
innovative auto-tracking software is intuitively designed for ease-of-use with two modes
(presenter and zone) for exceptional results.The BG-ADAMO-4KND features the latest in
NDI® technology: NDI®|HX3. With improved image quality and lower latency,
Features
●4K UHD Resolution: The SONY CMOS sensor captures images in resolutions up to
3840x1260 with a frame rate of up to 60fps.
●Interfaces / Multiple Simultaneous Streaming Outputs: With a variety of outputs
such as HDMI 2.0, 12G-SDI, USB3.0, USB 2.0, and LAN (NDI), the ADAMO can
simultaneously broadcast multiple streams to multiple outputs.
●Optical Zoom Lens: The ADAMO features either a 12X optical zoom 80.4°wide-angle
lens or 25X optical zoom 59°wide-angle lens.
●Multiple Audio/Video Compression Standards: H.264/H.265 video compression is
supported by the LAN (NDI) interface, USB 3.0 supports YUY2, and USB 2.0 supports
MJPG, H.264, YUY2, NV12, H.265. USB 3.0 supports YUY2. The A-IN supports AAC
audio compression coding.
●Advanced Auto Focusing Algorithm: The lens promptly snaps into focus with
dependable accuracy and stability.
●Low Noise and High SNR: A high SNR (Signal to Noise Ratio) image is achieved using
low noise CMOS sensors. The sophisticated 2D and 3D noise reduction technology
further reduces the noise while ensuring high image clarity, even in low light.
●Supported Network Protocol:NDI|HX3, ONVIF, GB/T28181, RTSP, RTMP.
●Control Options: RS232, RS485, LAN (NDI), or IR remote control. Protocols include
VISCA, PELCO-P/D, ONVIF, and VISCA over IP.
●Multiple Presets: Configure up to 255 presents using the Web GUI, or 10 presents via
the IR remote control.
●Two Mode Auto-Tracking Software: Presenter mode continuously tracks keeping the
subject perfectly framed. Zone mode holds the frame in predetermined zones. The
camera tracks and moves only when the subject has left one zone and entered the next,
then holds the frame in the new zone.
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 5

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
Packing List
•1 x BG-ADAMO-4KND
•1 x IR Remote Control
•1 x 12V/1.5A Power Supply
•1 x RS232 Control Cable
•1 x User Manual
Specifications
Camera Parameters
Optical Zoom
12X
f=3.85 mm～43.06 mm ±5%
25X
f=6.91 mm～214.64 mm ±5%
View Angle
Horizontal: 7.59˚（N）～ 80.4˚（W）
Vertical: 4.6˚（N）～ 50.0˚（W）
Horizontal: 1.98˚（N）～ 59˚（W）
Vertical: 1.12˚（N）～ 34.14˚（W）
Iris Value
F1.8(Wide) ～F3.56(Tele) ±5%
F1.35(Wide) ～F4.6(Tele) ±5%
Sensor
1/2.5 inch SONY CMOS sensor
1/1.8 inch SONY CMOS sensor
Effective Pixels
8.51M megapixel 16:9
Video Format
HDMI：
3840*2160P60/50/30/25/59.94/29.97;1080P60/50/ 30/25/59.94/29.97;1080I60/50/59.94;
720P60/50/59.94
SDI：
3840*2160P60/50/30/25/59.94/29.97;1080P60/50/ 30/25/59.94/29.97;1080I60/50/59.94;
720P60/50/59.94
USB 2.0:
MJPG：3840*2160/1920*1080/1280*720 /1024*768
/1024*576/800*600/720*576/720*480/704*576/640*480 /640*360 /352*288/320*240P30
H264：3840*2160/1920*1080/1280*720 /1024*768
/1024*576/800*600/720*576/720*480/704*576/640*480 /640*360 /352*288/320*240P30
H.265：1920*1080/1280*720 /1024*768 /1024*576/800*600/720*576/720*480/704*576/640*480
/640*360 /352*288/320*240P30;
YUY2：800*448 /720*480P25; 640*360 /432*240P30
NV12：800*448P25; 640*480 /640*360 /432*240P30
USB 3.0:
YUY2：1920*1080 /1280*720P60/50/30/25; 960*540 /800*600P30; 720*576P50;
720*480P60;640*480P30;
Minimum Illumination
0.5Lux (F1.8, AGC ON)
DNR
3D DNR
White Balance
Auto / Manual/ One Push/ Specified Temperature
Focus
Auto/Manual/One Push Focus
Exposure Mode
Auto/Manual/Shutter priority/Aperture priority/brightness priority
Aperture
F1.8 ～F11 CLOSE
Shutter Speed
1/25～1/10000
BLC
ON/OFF
Video Adjustment
Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 6

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
SNR
≥50dB
Interface
Product Interfaces
HDMI, 12G-SDI, LAN NDI|HX3 (supports PoE), USB 2.0, A-IN, USB 3.0, SD (FAT32), RS232-IN,
RS232-OUT, RS422 (compatible with RS485), DC12V, Power Switch
Video Compression Format
LAN Interface: H.264, H.265
USB 2.0 Interface: MJPG, H264, YUY2, NV12
USB 3.0 Interface: YUY2
Audio Input Interface
Stereo 3.5mm AUX
Audio Output Interface
HDMI, LAN, 12G-SDI, USB 2.0, USB 3.0
Audio Compression Format

AAC
Network Interface
10M/100M/1000M adaptive Ethernet port, PoE power supply, audio and video output
Network Protocols
NDI|HX3, RTSP, RTMP, ONVIF, GB/T28181; VISCA IP control protocol
Control Interface
RS232-IN, RS232-OUT, RS422 compatible with RS485, LAN
Serial Communication
Protocol
VISCA/Pelco-D/Pelco-P;
Baud Rate: 115200/38400/9600/4800/2400
USB Communication
Protocol
UVC (Video)
Power Interface
HEC3800 outlet (DC12V), PoE
Supply Adapter
AC110V~AC220V to DC12V/2.5A
Input Voltage
DC12V±10%
Input Current
<1.5A
Power Consumption
<12W
PTZ Parameters
Pan Rotation
-170°～+170°
Tilt Rotation
-30°～90°
Pan Control Speed
0.1°/s ～100°/s
Tilt Control Speed
0.1°/s ～70°/s
Preset Speed
Pan: 78.8°/s, Tilt: 31.7°/s
Preset Number
255 presets via Web GUI (10 presets using remote control)
Other Parameters
Stored Temperature
-10℃～+60℃
Storage Humidity
20%～95%
Working Temperature
-10℃～+50℃
Working Humidity
20%～80%
Dimension
220(L)mm*150.2mm(W)*177.5mm(H)
Weight
~4 Lbs
Application
Indoor
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 7

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
Installation and Handling Caution
●Do not manually rotate the camera head as it could cause mechanical failure.
●Place the camera on a stable table or horizontal surface. Installing on a slanted surface will
result in a slanted image.
●Do not place obstacles within the camera’s rotation circumference.
●For proper operation and synchronization, do not power the camera on until the cable
installation has been completed.
Camera Interface
1. Remote-control IR Indicator
7. USB 2.0
13. RS232 Control Interface (In)
2. Camera Lens
8. 12G-SDI Output
14. RS232 Control Interface (Out)
3. Tally Lights
9. HDMI Output
15. LAN/PoE
4. Mounting Hole
10. Micro SD slot
16. DC12V Power Input
5. Screw Hole for Tripod
11. Audio Input
17. Power Switch
6. USB 3.0
12. RS422/RS485 Interface
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 8

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
RS-232 INTERFACE
Camera
RS232 In
PC / Camera
Controller
RS232
Interface
RS-232 Mini-DIN 8-pin Port Definition
NO.
Port
Definition
1
DTR
Data Terminal Ready
2
DSR
Data Set Ready
3
TXD
Transmit Data
4
GND
Signal Ground
5
RXD
Receive Data
6
GND
Signal Ground
7
IR OUT
IR Commander Signal
8
NC
No Connection
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 9

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
RS-232 (BD9) Port Connections
NO.
Port
Definition
1
DCD
Definition
2
RXD
Data Carrier Detect
3
TXD
Receive Data
4
DTR
Transmit Data
5
GND
Data Terminal Ready
6
DSR
System Ground
7
RTS
Data Set Ready
8
CTS
Request to Send
VISCA Networking
Mounting
Note: Ceiling or wall mounting brackets should be mounted to a wooden or concrete wall.
Mounting to plasterboard is not recommended for safety reasons.
WALL MOUNTING
Anti-vibrate Cushion
Limited Post
1/4-20UNC Bolt
Camera
M6 Nut and Shim
M6 Swelling Bolts
Wall Mounting Bracket
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 10

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
CEILING MOUNTING
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 11

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
Operating Instructions
POWER ON AND SELF-CHECK
1. Power-on: Connect the DC12V power adaptor to the power supply socket on the back of
the camera. or connect to a PoE enabled network switch using a category cable.
2. Camera Self-check: The remote-control IR indicator and tally lights will flash when
powered on. The camera will pan-tilt to the lowest left position, then return to the HOME
position (both the horizontal and vertical positions are in the middle). The lens/zoom will
move through its complete range. Once the remote-control IR indicator and tally lights stop
flashing, the self-check has been completed.
Notes:
1. After the power-on and self-check, the camera will automatically return to the preset 0
position.
2. The factory default address for the IR remote-control is #1.
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 12

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
REMOTE
One-to-One Code Matching:
Out of the box the remote is automatically paired with the camera.
Should the camera need to be re-pair with the remote, perform the
steps below.
1. Press the "set" and " * " keys combined for 3 seconds. The
LED indicator will start flashing.
2. The camera will receive the signal and power on if not already
on.
3. The LED indicator will turn off if the code matching is
successful.
If the one-to-one code matching has failed, the LED indicator will
flash for 20 seconds and turn off. The camera will stop code
matching and go into sleep mode. Press any key to wake the camera
up and reattempt code matching.
REMOTE BUTTONS INTRODUCTION
In this manual, “press the button” means a click rather than a “press and hold”. Special
instructions will be given if pressing and holding the button for more than one second is required.
When a button-combination is required, perform the actions in sequence.
For example,【*】+【#】+【F1】means press “【*】” first, then “【#】” and press “【F1】” last.
1. Camera Remote Control Address Setting
【*】+【＃】+【F1】: Camera Address No.1
【*】+【＃】+【F2】: Camera Address No. 2
【*】+【＃】+【F3】: Camera Address No. 3
【*】+【＃】+【F4】: Camera Address No. 4
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 13

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
2. Camera Selection
Select the camera’s address to control it.
3. Pan/Tilt Control
Up: press Down: press
Left: press Right: press
Return to middle position: press 【HOME】
Press and hold the up, down, left, or right button to
pan/tilt the camera. The camera will continue to move in
the arrow direction until either the button is released or
the camera has reached its full range of motion.
4. Focus Control and Zoom
FOCUS + (near) : Press to adjust the lens focus.
FOCUS - (far) : Press to adjust the lens focus.
MANUAL : Press to enter manual focus mode.
AUTO : Press to return to auto focus mode.
ZOOM + : Press to zoom in.
ZOOM - : Press to zoom out.
5. Set and Clear Presets
Set Preset: Press the【SET PRESET】button, then press the number
buttons 0-9 to set the preset positions.
Note: 10 presets are available via remote control.
Call Preset: Press the 0-9 number buttons to call a preset
position.
Clear Preset: Press the【CLEAR PRESET】button, then press the
desired number button to clear its preset position.
BLC ON/OFF: Turn on/off the BLC.
Menu: Enter/Exit OSD menu or return to the previous menu.
Note: Pressing the【#】key three times in a row will clear all
presets.
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 14

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
6. Auto Tracking Buttons
F1: Turn off auto tracking
F2: Turn on auto tracking
F3: Switch auto tracking modes
F4: Switch auto tracking to follow a different person
7. Key Combinations
【#】+【#】+【#】: Cancel all preset positions
【*】+【#】+【3】: The menu is set to Chinese
【*】+【#】+【9】: Toggle forward and backward
【#】+【*】+ Auto : Stop demo Mode
【#】+【#】+【0】: Switch video format 4KP60
【#】+【#】+【2】: Switch video format 4KP30
【#】+【#】+【4】: Switch video format 1080P60
【#】+【#】+【6】: Switch video format 1080I60
【#】+【#】+【8】: Switch video format 1080P30
【*】+【#】+【6】: Restore factory image defaults
【*】+【#】+【4】: The menu is set to English
【*】+【#】+ Auto: Enter Demo Mode
【*】+【*】+【7】: Turn on green tally light
【*】+【*】+【8】: Turn on red tally light
【*】+【#】+ Manual: IP, username, password restore to
default
【#】+【#】+【1】: Switch video format 4KP50
【#】+【#】+【3】: Switch video format 4KP25
【#】+【#】+【5】: Switch video format 1080P50
【#】+【#】+【7】: Switch video format 1080I50
【#】+【#】+【9】: Switch video format 1080P25
【*】+【*】+【1】: Enable DHCP
【*】+【*】+【2】: Disable DHCP
【*】+【*】+【3】: Display current IP address
【*】+【*】+【4】: Reboot camera
【*】+【*】+【5】: Start recording to SD card
【*】+【*】+【6】:Stop recording to SD card
【*】+【*】+【9】: Turn off tally light
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 15

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
8. Main Menu
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 16

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
Network Connection
Connection Mode
●Direct Connection: Connect the camera directly to the computer using an ethernet cable.
●Internet Connection: Connect the camera and computer to a router or switch and access
via the local area network (LAN).
Note: Ensure power and network connections are secured to prevent video issues caused
by poor connection quality.
The computer must be on the same subnet as the camera to connect successfully. The device will
not be accessible otherwise. The camera’s default IP address is 192.168.5.163, therefore the
computer must be connected to the 192.168.5.x subnet.
●To connect to the camera, open the Local Area Connection Properties on the computer.
●For Windows 10/11 users in the Start menu type/search for “View Network Connections”
●Right-click on your connection and select “Status".
Then click “Details…” Take note of your current IPv4 Address and Default Gateway as you
will need this information later. Close the “Details” and “Status” windows.
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 17

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
●Right-click on your adapter again (Wi-Fi or Ethernet) and select “Properties”.
●Select “Internet protocol version 4 (TCP/IPv4” as shown below and click “Properties”.
For the following steps refer to the diagram below.
●Click on the bubble for “Use the following IP address”
●In the IP address field, enter a non-conflicting IP address on the same subnet as the
camera. If there is another device with the same IP address, you will not be able to
connect. In the example below uses 192.168.5.200
●In the Subnet mask field enter 255.255.255.0
●In the Default gateway field type 192.168.5.1
●Leave the DNS fields blank.
●Click “OK” to apply the settings.
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 18

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
Initial Web Client Login
●Enter 192.168.5.163 in the address bar of your internet browser and click “Enter”. Login as
the administrator (Default Username/Password: admin). Users can preview and configure
in the Web Client.
●When logged in as a normal user (Default Username/Password: user1 or user2), users can
only preview with no options for configuration.
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 19

BZBGEAR BG-ADAMO-4KND PRODUCT MANUAL
●Navigate to Configuration in the top left corner of the screen. Click “Ethernet” on the
left-hand side.
●Enter an unused IP address
on your network.
Note: You should have your specific
network information from the
“Status” and “Details” pages of your
internet connection noted above.
●In this example we will use
192.168.30.116
●Change the Subnet Mask to
255.255.255.0
●Default gateway of your network
●Click “Save”
●Reboot the Camera
●Once you have completed the camera network setup, repeat the steps on your computer
to adjust the “Internet Protocol Version 4 (TCP/IPV4) Properties.” Select the bubbles to
“Obtain an IP address automatically” and “Obtain DNS server address automatically.”
Preview
After successfully logging into the management interface, the web portal will enter the “Preview”
tab. In Preview, users can control pan/tilt, zoom, focus, video capture, sound, focus, full screen
preview, as well as set the preset position, run, delete, and other operations.
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: [phone] ·Email: [e-mail] 20
