C.A.R.E. 2000-ADS User manual

C.A.R.E 2000
* Doctor Tested and
Recommended
* Patented Hospital
Technology
*Most complete air purifica-
tion system on the market.
*Cleans up to 1,500 sq. ft.
area.
*CSA Approved & Certi-
fied for North America &
Europe.
*Patented "Top Flow"
Design air discharge.
*5 stages of filtration
Operations Manual & C.A.R.E - ADS Instructions
"Now I can breathe the air of the
new millennium, the air my body
needs and deserves!
Thank you!"
T.E. Grissom, Solana Beach, CA
AIR DEFENSE SYSTEM

2
The Clean Air Room Environment
AIR PURIFICATION FOR THE NEXT MILLENNIUM
SAFETY GUIDELINES
The C.A.R.E. 2000-ADS is an electrical appliance and operates with 110V AC current
so it can easily be plugged into standard wall outlets. As with any electrical appliance
care must be taken when cleaning or changing the filters & UV lamps. Never move the
unit by pulling or tugging the cord as this may cause fraying and become an electrical
hazard.
SAFETY WARNINGS
 TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT EXPOSE TO RAIN OR
WATER.
 TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT USE THIS
UNIT’S FAN WITH ANY OTHER SOLID STATE SPEED CONTROL DEVICE.
 ALWAYS UNPLUG UNIT WHEN SERVICING IT.
 NEVER LOOK DIRECTLY AT THE UV LAMPS WHEN LIT.
IMPORTANT OPERATION INFORMATION
The C.A.R.E. 2000-ADS is designed for 24-hour operation to provide maximum air
cleaning of your home or office. Dust, germs, chemicals and other toxic contaminants
constantly spread throughout your air and need to be continuously removed.
The pre and post filters collect dust and need to be cleaned and replaced periodically.
Bacteria, yeasts, and mold are trapped in the HEPA filter and tend to grow. Continuous
running of the filter is necessary to dry out these organisms and keep growth to a minimum.
The Ultraviolet system will also keep any microbiologically contaminated air from passing
through, but the lamps must be replaced once a year to keep the germicidal level effective.
If for any reason the C.A.R.E. 2000-ADS is not run for a number of weeks or months,
then the HEPA filter module, in its entirety, should be changed before starting.
C.A.R.E 2000-ADS
Congratulations for purchasing the finest air purification system in the world. This
highly effective air purification system is based upon the same advanced air purification
that is recommended and used in hospitals, labs, intensive care units, medically
related facilities and by allergists and environmental doctors.
The C.A.R.E. 2000-ADS incorporates True HEPA filtration and activated carbon that
offers twice the gas reducing capability available in other filters. This unique combina-
tion of media is further enhanced by proven germicidal Ultraviolet light, and an innovative
“Topflow” air discharge system.
The C.A.R.E. 2000-ADS can transform any home or office into an odorless,
gasless, virtually germ-free environment. Purifies over 21,000 cubic feet of air per hour.

33
C.A.R.E 2000-ADS
CHOOSE A LOCATION FOR YOUR HOME OR OFFICE
The C.A.R.E. 2000-ADS air purification system is a very versatile unit and is designed for
home or office use within any room except; near sinks, showers, pools or any other water
source. For best results, place the unit at the wall across from the area where the clean air
benefits will be the greatest.
AIR FLOW PATTERN
The purified air will be directed upward toward the ceiling and will drop down around the
total room area pushing any dust, pollen, odors etc. toward the floor and these contaminants
are then drawn into the bottom of the unit.
AIR CONTROLS
Industry guidelines suggest at least 3 air
changes / hour (ACH) for adequate airborne
cleaning and allergy control. The C.A.R.E 2000-
ADS produces 350 cubic feet per minute
(CFM) in one hour. The C.A.R.E. 2000-ADS
will change 21,000 cubic feet per hour at high
speed. However, the “Topflow” featured in the
C.A.R.E 2000-ADS delivers more actual air
changes per hour than other units. The follow-
ing chart will help you determine how many air
changes your unit will provide in a given space.
AIR FLOW PATTERN
The C.A.R.E. 2000-ADS has an adjustable
speed setting. We recommend that the unit
mains in the low to medium setting
speed.For maximum number of air changes
(ACH), set the unit to high.
ezismooRegarevA
xhtdiWxhtgneL
thgieH
teeFcibuC
riAforebmuN
rePsegnahC
uoH r
'8x'61x'61teeFcibuC840,2 riA52.01
segnahC
'8x'41x'41teeFcibuC865,1 riA04.31
segnahC
'8x'21x'21teeFcibuC251,1 riA32.81
segnahC
'8x'01x'01 teeFcibuC008 riA52.62
segnahC
GREEN INDICATOR LIGHT-will remain on when the UV light is operating properly.
When the light goes out the UV lamps are not functioning.
RED INDICATOR LIGHT-Goes on when it’s time to change or clean
pre-filter or change HEPA filter. Go to the “Clean Prefilter Section” on page 5.
Order new lamps from your supplier and go to the “Change UV Lamps Section”
Dust/Dirt Fumes Air Flow
"Top Flow"
Air Discharge
C.A.R.E 2000
Fan Speed
Off
Hi Low
Medium
UV
ON
CHECK
FILTER

C.A.R.E 2000-ADS
Maintaining Your C.A.R.E. 2000
CLEANING AND CHANGING FILTERS
SAFETY WARNINGS
 BEFORE YOU ATTEMPT ANY MAINTENANCE ALWAYS UNPLUG THE UNIT.
 NEVER LOOK DIRECTLY AT THE ULTRAVIOLET LAMPS WHEN LIT.
HOW TO CLEAN YOUR PRE-FILTER
THE LIFE OF THE CARBON PRE-FILTER
The pre-filter can be vacuumed numerous times to increase the service life of of the filter.
The pre-filter can last approximately 1 to 2 years depending on the amount of dirt in the air
and the amount of use. If the red light does not go off after cleaning the pre-filter, then the
pre-filter must be changed.
WHEN THE RED INDICATOR LIGHT GOES ON
TOOLS REQUIRED: A phillips screw driver
IMPORTANT: Before opening the unit to change the pre-filter, vacuum the outside of the unit
at the bottom vents. If the red indicator light does not shut off then it is necessary to open
the unit and clean the prefilter.
1. UNPLUG THE UNIT
Remove (1) screw on each side and on the
back of the unit (3 screws total) FIG.2
The back screw on top of rear access
panel is a shipping screw and does not
need to be replaced.
2. Gently rest unit label face down.
(DO NOT REST ON WHEELS)
Remove the (2) shipping screws on the
bottom of the unit. These screws are for
shipping and do not need to be replaced
FIG.3
3. Remove (2) screws on the bottom of the
rear access panel. FIG.4 Pull off rear
access panel.
4. Use plastic handles to lift out the pre-filter/
HEPA + carbon drum filter from the inner
chamber. FIG. 5
5. Remove outer PRE-FILTER and vacuum
the pre-filter. Replace the pre-filter around
the HEPA + carbon drum filter.
Or TO REPLACE THE PRE-FILTER
Discard the old pre-filter and wrap a new
pre-filter around the HEPA +carbon drum
filter.
6. Reinstall the HEPA + carbon drum with
the pre-filter around it. Push all the way
back into the inner chamber. The seam of
the pre-filter should face you.
7. Replace rear access panel and only
replace the (2) screws at the bottom of
access panel.
STAND UNIT UPRIGHT
AND PLUG INTO WALL OUTLET,
TURN UNIT TO DESIRED SPEED.
4
FIG.2
FIG.3
FIG.4
FIG.5

C.A.R.E 2000-ADS
Maintaining Your C.A.R.E. 2000
CLEANING AND CHANGING FILTERS
THE HEPA & CARBON DRUM FILTER
FOR YOUR INFORMATION - HEPA LIFE RATING
The HEPA filter MAY last up to 5 years in some areas, The carbon filter MAY last up to 2 years.
the longevity of the HEPA or the carbon filter depends on the amount of use and the amount of
contaminants in the room air where the filter is being used. After changing the "Pre-filter" if the
red light stays on, you should change the inner HEPA drum. As the carbon media comes to the
end of its life, chemically and environmentally sensitive (MCS) people may detect contaminants
at lower levels and will have to change the filter sooner.
THE FREQUENCY GUIDELINES FOR THE CHANGE OF FILTERS
The frequency of HEPA and car-
bon filter changes will vary de-
pending the amount of contami-
nants in your indoor environment.
NOTE:
The chart to the right shows only estimates
of the life of the filters. Frequency of filter
changes may be shorter.
IF THE RED INDICATOR LIGHT REMAINS ON.
If cleaning or changing the pre-filter does not shut off the red indicator light, this signal means that
the inner HEPA filter needs to be changed. Call your distributor and order a HEPA replacement
filter.
HOW TO CHANGE THE HEPA & CARBON FILTER
1. UNPLUG THE UNIT BEFORE
SERVICING.
2. Follow steps 1 to 4 in the HOW TO
CLEAN YOUR PRE-FILTER section
(page 4)
3. Remove inner HEPA drum FIG.6
4. Place the new HEPA drum inside of
the old carbon filter; or place old HEPA
drum into new carbon filter.
5. Place complete HEPA + carbon filter
with pre-filter wrapped around filter,
into inner chamber with the open end of
HEPA facing towards the top of the
CARE unit.
6. Replace rear access panel and
replace (2) bottom screws.
SENILEDIUGYCNEUQERF
GNINAELCRETLIF-ERP 4-2OTPU
SHTNOM
RETLIFTSOP&ERP
EGNAHC RAEY2
EGNAHCRETLIFAPEHSRAEY5OTPU
RETLIFNOBRACSRAEY2OTPU
EGNAHCSPMALVURAEY1
5
IMPORTANT:
DO NOT STAND UNIT UPRIGHT UNLESS
HEPA/CARBON FILTER IS IN PLACE.
FIG.6
INNER HEPA DRUM
OUTER CARBON
FILTER

C.A.R.E 2000-ADS
Maintaining Your C.A.R.E. 2000
CLEANING AND CHANGING FILTERS
HOW TO CHANGE THE POST FILTER
NOTE:
 WHEN CHANGING THE UV BULBS IT IS RECOMMENDED TO REPLACE THE
POST FILTER UNDER THE OUT FLOW VENTS WHEN THE ACCESS PANEL
IS OPEN.
HOW TO CHANGE THE ULTRAVIOLET LAMPS
TOOLS REQUIRED:
A phillips screw driver
A cloth or glove (for New Ultraviolet Bulbs)
SAFETY WARNINGS
 UNPLUG UNIT BEFORE SERVICING.
 NEVER LOOK DIRECTLY INTO THE ULTRAVIOLET LAMPS WHEN LIT.
1. Open top access panel, FIG.7
Remove the 4 corner screws,
carefully lift access panel and gently hang
off side. BE CAREFUL NOT TO DISCON-
NECT WIRES.
2. Lift shield plate slightly FIG 8. vertically and
slide forward from middle support bar.
3. Carefully cut the black nylon shipping tie
from around the base of each Ultraviolet
lamp. BE CAREFUL NOT TO CUT THE
WHITE LAMP WIRE. FIG.9 While holding
the lamp socket with one hand, gently pull
the lamp straight out from its socket.
4. Discard the old lamps, place them in a trash
bag and throw them away.
5. DO NOT TOUCH the glass of the New
Ultraviolet lamps with your hands, as the oil
on your skin may alter the performance of
the lamps. Use a cloth or gloves.
6. Reinstall the HEPA + carbon drum with
the pre-filter around it. Push all the way
back into the inner chamber. The seam of
the pre-filter should face you.
7. Replace rear access panel and only
replace the (2) screws at the bottom of
access panel.
8. Line up top access panel with 4 holes and
replace screws with phillips screwdriver.
STAND UNIT UPRIGHT
AND PLUG INTO WALL OUTLET,
TURN UNIT TO DESIRED SPEED.
1. Peal off Post Filter
2. Place new post filter onto existing
velcro strips
6
FIG.7
FIG.8
FIG.9

C.A.R.E 2000-ADS
Technical Specification Summary
AIR PURIFICATION SYSTEM
DIMENSIONS
HEIGHT - 28 INCHES  WIDTH - 15 INCHES  DEPTH - 14 INCHES
FILTER MATERIAL
80 SQ.FT. OF TrueHEPA MEDIA RATED AT 99.97% AT 0.3 MICRONS; NON
OUT-GASSING, 10" HIGH X 13.5" DIAMETER
15 LBS. ACTIVATED CARBON MEDIA WITH A COMBINED 422 MILLION SQ.
INCHES OF TOTAL ABSORPTIVE SURFACE AREA FOR GAS AND CHEMI-
CAL REDUCTION.
PRE-FILTERS
REMOVABLE INERT CARBON IMPREGNATED SPUN POLYESTER PRE-
FILTER CAN BE WASHED OR VACUUMED TO EXTEND LIFE.
90% REDUCTION OF LARGE PARTICLES >10 MICRON TO PROTECT THE
HEPA. 48" LENGTH X 10" HEIGHT SURROUNDS HEPA CARBON FILTER.
POST FILTER
CARBON IMPREGNATED POLYESTER PAD FOR ADDITIONALABSORP-
TION. "SAFE FLOW" INDICATOR LIGHT SIGNALS YOU TO CLEAN OR
REPLACE FILTERS.
SEALING GASKETS AROUND EDGES ASSURE AIR FLOW THROUGH THE
FILTER.
ELECTRICAL
WATTAGE - 130 WATTS  HERTZ - 60 CYCLE  AMP - 1 AMP
FAN/MOTOR ASSEMBLY
350 CFM, 2500 RPM CENTRIFUGAL BACKWARD INCLINED FAN OF REIN-
FORCED POLYAMIDE IS STRONGER THAN STEEL; WITH MINIMAL VIBRA-
TION CREATING HIGH AIR FLOW WITH LOWER ELECTRICAL USAGE.
MOTOR IS A HIGH EFFICIENCY SPLIT CAPACITOR FOR CONTINOUS LONG
LIFE DUTY.
ADJUSTABLE SPEEDS TO GIVE FINELY-TUNED AIR CHANGE.
LOW NOISE AND VIBRATION DURING OPERATON.
UNIT IS CSA/NRTL CERTIFIED, A WORLD-WIDE TRADEMARK.
OVER 21,000 CUBIC FEET OF AIR CLEANED EVERY HOUR.
ULTRAVIOLET LAMPS
FOUR 9 WATT LAMPS PRODUCT GERMICIDAL DOSAGE TO KILL
BACTERIA, VIRUSES AND YEAST.
LOCATED IN AN INTERNAL CHAMBER OF POLISHED STEEL.
9,000 HOUR OPERATION CAPABILITY.
REPLACEABLE BULBS.
HOUSING CONSTRUCTION
22 GAUGE GALVANIZED STEEL WITH A POWDER PAINT COATING TO
ALLOW FOR EASY CLEANING AND DURABILITY.
UNIT OUT FLOW VIA TOP LOUVERS TO PROVIDED MAXIMUM ROOM AIR
CHANGES.
FILTER ACCESS FROM REAR DOOR OPENS WITH A SIMPLE TWIST OF 2
SCREWS.
UNIT WEIGHT: 48 POUNDS  SHIPPING WEIGHT: 53 POUNDS 7

C.A.R.E 2000-ADS
WARRANTY
AIR PURIFICATION LIMITED WARRANTY
 CWR, Environmental Products warrantees their air purification system to be free of
defects in material and workmanship under normal use for the following time from the
date of purchase.
 IF THE PRODUCT IS DEFECTIVE, CALL CWR AT 516-674-2441 OR YOUR AUTHO-
RIZED DEALER FROM WHERE YOU PURCHASED THE UNIT FOR A RETURN
AUTHORIZATION NUMBER.
 YOU MUST REGISTER THE C.A.R.E 2000 AIR PURIFICATION SYSTEM WITH CWR TO
QUALIFY FOR WARRANTY SERVICE, IF THE UNIT IS DEFECTIVE CONTACT CWR OR
YOUR AUTHORIZED DEALER, TO QUALIFY FOR WARRANTY SERVICE. AFTER
VERIFICATION OF PURCHASE DATE, CWR WILL REPAIR IT OR REPLACE IT, AT
THEIR OPTION.
 CWR ASSUMES NO LIABILITY FOR CONSEQUENTUAL DAMAGES OF ANY KIND AS A
RESULT OF THE USE OR MISUSE OF THE SYSTEM BY THE PURCHASER, HIS/HER
EMPLOYEES OR ANY OTHERS.
 THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTEES, GUARAN-
TEES, OBLIGATIONS OR LIABILITIES, EXPRESSED OR IMPLIED.
 THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE
OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE.
PLEASE FAX THIS WARRANTY OR MAIL THE ENCLOSED WARRANTY CARD.
OR REGISTER ONLINE @ www.cwrenviro.com/warranty.htm
CWR ENVIRONMENTAL PRODUCTS
100 CARNEY STREET - GLEN COVE, NY 11542
TELEPHONE: [phone]
FAX: [phone]
8
STRAPYTNARRAWREDNU
SLEEHWDNAGNISUOHSRAEY5
ROTOMDNANAFSRAEY5
:STRAPLACIRTCELE
,SLORTNOCDEEPS,SEHCTIWS,TSALLAB
SPMALNOENDNADEL
RAEY1
SPMALIGVUSYAD09
:SRETLIF
NOBRACDNAAPEH SYAD09
RAEWROESUEVSISSECXEROFDEREVOCTONSIRETLIF
SAFETY WARNINGS
 THE C.A.R.E 2000-ADS IS NOT TO BE USED IN AN OXYGEN RICH ENVIRON-
MENT. IF OXYGEN IS USED, THE C.A.R.E 2000 MUST BE AT LEAST 6 FEET
AWAY FROM OXYGEN SOURCE.
EMAN
SSERDDA
ENOHPELET
MORFESAHCRUP
ESAHCRUPFOETAD
#LAIRES
0002E.R.A.CEHTFOLENAPKCABEHTNODNUOFEBNAC#LAIRES

C.A.R.E 2000-ADS
PARTS AND ORDER FORM
TO ORDER REPLACEMENT PARTS CALL YOUR AUTHORIZED DEALER
OR CWR, ENVIRONMENTAL PRODUCTS 1-800-444--3563
9
$ 30.00
$ 89.00
$239.00
$319.00
Name:______________________________________________________________
Address:____________________________________________________________
City:__________________________State:_________________Zip:____________
Telephone:(____)____________________________________________________
E-Mail Address:_____________________________________________________
Account Number
Expiration Date:_____/_____
Cardholders Name: ________________________________________
Signature:__________________________________________________
Please allow 2-3 weeks for delivery
QTY ITEM PRICE TOTAL
CARE 2000 PRE-FILTER/POST-FILTER SET (A)
;Check Enclosed ; Money Order Enclosed
; Mastercard ;Visa ;Discover ;AmEx
;;;;;;;;;;;;;;;;
CARBON-HEPA DRUM
COMPLETE REPLACEMENT PK (A+B+C)
ULTRAVIOLET LAMPS (B) (2 PK)
Subtotal
Shp & Hdl
NYS Residents
8.5% Sales Tax
Total
A
BC
A. CARE PRE-FILTER AND POST FILTER SET
$30.00 PER SET
$8.00 SHIPPING AND HANDLING
B. ULTRAVIOLET LAMPS
$89.00 PER (2) PACK
$7.00 SHIPPING AND HANDLING
C. CARBON-HEPA DRUM
$239.00
$18.00 SHIPPING AND HANDLING
COMPLETE REPLACEMENT PARTS PACK
INCLUDES: PRE & POST FILTERS
CARBON-HEPA FILTERS
ULTRAVIOLET LAMPS
$319.00
$20.00 SHIPPING AND HANDLING
