Eclipse®5 with autoSAT®
User Manual (English)

2 - ENG PN 21182453 C | User Manual
Eclipse 5
User Controls & System Status Indicators
Internal Symbols
External Power Indicator
Power Cartridge (battery) Status
Gauge
Power Cartridge Symbol
AAmperes
02Oxygen Output
Recycle Symbol
FAA Approved Symbol: The U.S.
Federal Aviation Administration
(FAA) has approved this device for
use on-board commercial aircraft.
Flow Setting Indicator
Pulse Mode Operation
Device operating normally; power
button
Increase Flow Setting
Decrease Flow Setting
ISO 7000; Graphical symbols for use on
equipment—Index and synopsis
Storage temperature limitation range
is -4°F to 140°F (-20°C to 60°C).
Reg. # 0632
Portable humidity range is 15 to 95%.
Base humidity range is 30 to 75%.
Reg. # 2620
Atmospheric pressure limitation. Reg.
# 2621
Operator’s manual; operating instruc-
tions. Reg. # 1641
Name and address of manufacturer.
Reg. # 3082
Date of manufacturer. Reg. # 2497
Catalog Number. Reg. # 2493
Serial Number. Reg. # 2498
This way up. Reg. # 0623
Fragile, handle with care. Reg. #
0621
Keep away from rain, keep dry. Reg.
# 0626
Stacking limit by number. Reg. # 2403
ISO 7010: Graphical symbols—Safety colors
and safety signs—Registered safety signs
The instruction manual must be read.
Reg. # M002
Keep away from open ame, re,
sparks. Open ignition source and
smoking prohibited. Reg. # P003
Do not smoke near unit or while
operating unit. Reg. # P002
Council Directive 93/42/EEC; concerning
medical devices
Authorized representative in the
European Community
This device complies with the
requirements of Directive 93/42/EEC
concerning medical devices. It bears
the CE marking as shown.
IEC 60417
Class II Equipment, Double Insulat-
ed Reg. # 5172
Alternating Current Reg. # 5032
Direct Current Reg. # 5031
Type BF applied part (degree of
protection against electric shock).
Reg. # 5333
CSA Certification
Certied for both the U.S. and Cana-
dian markets, to the applicable U.S.
and Canadian standards.
FCC Notice
21 CFR 801.15: Code of Federal Regulations
Title 21
Federal law restricts this device to
sale by or on the order of a physician.

PN 2118245 C | User Manual 3 - ENG
Eclipse 5
Council Directive 2012/19/EU: waste electrical
and electronic equipment (WEEE)
WEEE
IEC 60601-1: Medical electrical equipment Part
1 General requirements for basic safety and
essential performance
Drip Proof Equipment - IP22: The
Eclipse 5 and the AC power supply
provide protection against the harmful
effects of ingress of liquids (IP22 per
IEC 60529)
IEC 60601-1-8
Low Priority Technical Alarm
FCC NOTICE:
This device may contain CYBLE-022001-00, in-
cluding the antenna 2450AT18B100 from Johnson
Technology, complies with par 15 of the FCC rules.
The device meets the requirements for modular
transmitter approval as detailed in FCC public No-
tice DA00-1407. Transmitter operation is subject to
the following two conditions (1) This device may
not cause harmful interference, and (2) This device
must accept any interference received, including
interference that may cause undesired operation.
This product may be covered by one or more pat-
ents, US and international. Please visit our website
below for the listing of applicable patents. Pat.:
patents.gtls.io.
Aircraft Use:
CAIRE conrms that this machine meets the Fed-
eral Aviation Administration (FAA) requirements
(RTCA/DO-160, section 21, category M) for all
phases of air travel.
Wireless Technology
Technology used Bluetooth
Connection types SSP, iAP2, GATT
Frequency 2402 to 2480 MHz
Max RF power output +4 dBm
Operating range 10m (Class 2)
It is recommended that the machine is at a
minimum distance of 0.43” (1.1 cm) from the body
during operation. Not applicable to masks, air
tubing, or accessories.
What is the Oxygen
Concentrator
The air we breathe contains approximately 21%
oxygen, 78% nitrogen, and 1% other gasses. In
the Eclipse 5, room air is drawn into the machine
through the air intakes. It then passes through an
adsorbent material called molecular sieve. This
material separates the oxygen from the nitrogen and
allows only the oxygen to pass through. The result
is a ow of high-concentration oxygen delivered to
the user.
The Eclipse 5 combines advanced oxygen con-
centrator and oxygen conserving technologies to
create a portable device that allows for maximum
portability and ambulation. The advanced pulse
ow delivery quickly senses when the user breathes
in and delivers a pulse of oxygen at the beginning
of each inhalation. Pulse ow delivery is ideal for
activities and time away from home. It conserves
oxygen and extends battery life as opposed to con-
tinuous ow. The Eclipse 5 is lightweight enough
to be carried via handle or cart. It can be operated
on AC, DC (vehicle) or battery power.
The Essential Performance of the Eclipse 5 is to
provide oxygen concentrations between 82% to
96% at the prescribed ow setting. If Essential
Performance cannot be attained the Eclipse 5 Low
Priority Technical Alert will be activated. If the
Eclipse 5 is exposed to an extreme electromagnetic
disturbance the device may shut down without
activating the alert.
The Eclipse Oxygen System is intended for the
administration of supplemental oxygen to the
patient continuously in the end user’s home or for
their portable needs outside the home and can also
be used in institutions such as nursing homes or
sub-acute care facilities. The device is not intended
for life support nor does it provide any patient
monitoring capabilities. The instruction manual of
the device recommends an alternate source of sup-
plemental oxygen in the event of o power outage,
alarm condition or mechanical failure.
The device is used by COPD patients or those with
diminished breathing capacity. The device is pre-
scribed to the patient. Typically the device is sold
to a provider that is trained to operate and service
the Eclipse 5. The provider trains the user. Those
devices purchased through Chart website receive
setup instructions and the User Manual that denes
setup and usage instructions.

4 - ENG PN 21182453 C | User Manual
Eclipse 5
Quick Start Guide
1 Unpack Your Eclipse 5 2 Getting to Know Your Eclipse 5
Review all Warnings, Cautions and additional de-
vice information in the rest of this manual. Become
familiar with the key features of the Eclipse 5 and
the User Control Panel.
Eclipse 5
AC Power Supply
DC Power Supply
Universal Cart
Power Cartridge (battery)
FRONT
Control Panel Handle
Oxygen
Outlet Port
FAA
Approval
Icon
Rating Label &
Serial Number
Location
BACK
Power Cartridge
Latch
Exhaust Vent
Power
Cartridge
(Battery)
Cart
Attachment
Location
Air Inlet
Filter
Service Port
(Not for
Patient Use)

PN 2118245 C | User Manual 5 - ENG
Eclipse 5
ON/OFF Button (Green) Indicator
Press and hold the “ON/OFF” button for two (2)
seconds to power ON your Eclipse 5. A brief audi-
ble and visual power on self-test will occur. Verify
that all the indicators are illuminated and the buzz-
er sounds. Press and hold the “ON/OFF” button for
two (2) seconds to power OFF your Eclipse 5.
When the Eclipse 5 is plugged in properly, a green
indicator on the AC Power Supply will light and
the External Power Indicator, will appear on the
user control panel.
Install the Battery: Slide the battery into the empty
compartment until it locks into position and is ush
with the back of the device.
When the battery is properly installed and the
Eclipse 5 is ON, the Power Cartridge Status Gauge
will appear.
3 Powering on the Eclipse 5
To connect to AC power source: Insert the AC
Power Supply cord securely into the External Power
Receptacle on the right side of the device. If your
power supply has three pins, plug the AC power
cord into a grounded AC outlet. If your power
supply has a two pin plug, plug the AC cord into a
grounded or non-grounded AC outlet.
The Eclipse 5 User Control Panel displays important
operating information.
ON/OFF Button (Green) Indicator: This
button powers the device ON or OFF.
The Green Indicator is illuminated
when the device is ON and functioning
properly.
Increase or Decrease Flow Setting
Buttons: Use these buttons to set the
flow to your prescribed setting.
Delivery Mode Button and Indicator:
The button toggles between Contin-
uous Flow and Pulse Dose Mode. The
Pulse Dose Mode activates autoSAT
Technology and allows a significant
increase in the operating time while
powered by the battery. When the Pulse
Dose Mode is activated, the green Pulse
Dose Mode Indicator illuminates and a
pulse of oxygen is delivered with each
inspiratory effort.
Low Priority Technical Alarm: When
illuminated, this indicates a low priority
awareness condition. Continue to use
your system and refer to the trouble
shooting table for the proper response,
or contact your Home Care Provider.
Flow Setting Indicator: This is the main
focus on your control panel. Your home
care provider will correctly set your
prescribed flow for the Continuous
Flow Mode (LPM) and/or your Pulse
Dose Mode (mL) settings. Each time
you power the device ON, the previous
mode and/or setting has been saved
and will be used at start-up.
Power Cartridge (battery) Status Gauge:
This indicator displays the charge re-
maining in the battery. Each of the five
horizontal gray bars represents approxi-
mately 20% of the total battery charge.
When the battery is being charged,
the charge indicator bars will blink in
a waterfall-type fashion. If the battery
is not installed, or if it is improperly
installed, the Power Cartridge (battery)
Status Gauge will not be illuminated or
will flash on and off.
External Power Indicator: When the
Eclipse 5 is properly plugged in and
is using the AC or DC Power Supply,
this indicator will appear on the User
Control Panel.
Buzzer: An audible alarm (or buzzer) alerts you to the
operating condition of the device, either a warning or
failure, and confirms a valid key press.
Step 1 Step 2

6 - ENG PN 21182453 C | User Manual
Eclipse 5
Your unit is equipped with an Air Inlet Filter (extra
lter provided). Check daily and clean once a week.
Connect the oxygen supply
tubing to the oxygen outlet and
connect the oxygen cannula
per the instructions provided
with the cannula, or per the
instructions from your home
care provider.
Breathe normally through the nasal cannula.
When operating on battery power, utilizing the
Pulse Dose Mode will achieve longer dura-
tion-of-use.
7 Universal Cart Operation
Align the locater holes on the bottom of the device
to the tabs on the Universal Cart. Align the large
threaded screw to the insert at the back of the
Eclipse 5. Then hand-tighten the knob on the cart
until the Universal Cart is tightly secured to the
device. Depress the push-button on the telescoping
Universal Cart handle to adjust the height of the
handle.
6 Begin Using the Eclipse 5
Air Inlet Filter
Pulse Dose Mode Display
4 Select Flow Delivery Mode
Flow Mode Button and Indicator
Press the Flow Mode button to select your desired
ow mode. Pressing this button repeatedly will
toggle you back and forth between continuous
ow and pulse dose modes. In Continuous Flow
Mode the oxygen is provided at a constant ow rate
between 0.5 and 3.0 LPM. In Pulse Dose Mode, ox-
ygen is supplied in a bolus at the beginning of each
inspiration, providing a selectable range of settings
1-9 with bolus sizes 16-192 mL. Pulse Dose can be
adjusted for sensitivity and breath bolus delivery.
Flow settings in both modes should be prescribed
for you by your physician.
5 Adjust Flow Setting to Prescribed
Level
Increase or Decrease Flow Setting
Button
Using the + or - buttons, adjust the setting to the
prescription supplied by your physician.
Continuous Flow Mode Display
WARNING: IT IS VERY IMPORTANT TO
SELECT ONLY THE PRESCRIBED LEVEL OF
OXYGEN. DO NOT CHANGE THE FLOW SE-
LECTION UNLESS YOU HAVE BEEN DIRECT-
ED TO DO SO BY A LICENSED CLINICIAN.
THE PORTABLE OXYGEN CONCENTRATOR
MAY BE USED DURING SLEEP UNDER
THE RECOMMENDATION OF A QUALIFIED
CLINICIAN. YOUR DELIVERY SETTINGS
SHOULD BE PERIODICALLY REASSESSED
FOR EFFECTIVENESS OF THERAPY.
Contact your equipment provider for available
training options. If you do not know your provider,
contact CAIRE.
Note: For assistance, if needed, in setting up, or
maintaining the Eclipse 5, or to report unexpect-
ed operation or events, contact CAIRE or CAIRE
Representative.

PN 2118245 C | User Manual 7 - ENG
Eclipse 5
Important!
Safety Instructions are defined as follows:
WARNING: IMPORTANT SAFETY
INFORMATION FOR HAZARDS THAT
MIGHT CAUSE SERIOUS INJURY.
CAUTION: Important information for
preventing damage to the Eclipse 5.
Note: Information needing special attention.
Indications for Use
WARNING: IT IS VERY IMPORTANT
TO SELECT ONLY THE PRESCRIBED
LEVEL OF OXYGEN. DO NOT CHANGE
THE FLOW SELECTION UNLESS YOU
HAVE BEEN DIRECTED TO DO SO BY A
LICENSED CLINICIAN. THE PORTABLE
OXYGEN CONCENTRATOR MAY BE
USED DURING SLEEP UNDER THE
RECOMMENDATION OF A QUALIFIED
CLINICIAN.
WARNING: TO ENSURE RECEIVING THE
THERAPEUTIC AMOUNT OF OXYGEN DELIVERY
ACCORDING TO YOUR MEDICAL CONDITION,
ECLIPSE 5 MUST BE USED ONLY AFTER ONE OR
MORE SETTINGS HAVE BEEN INDIVIDUALLY
DETERMINED OR PRESCRIBED FOR YOU AT YOUR
SPECIFIC ACTIVITY LEVELS. ECLIPSE 5 MUST BE
USED WITH THE SPECIFIC COMBINATION OR
PARTS AND ACCESSORIES THAT ARE IN LINE
WITH THE SPECIFICATION OF THE CONCENTRA-
TOR MANUFACTURER AND THAT WERE USED
WHILE YOUR SETTINGS WERE DETERMINED.
WARNING: FEDERAL (USA) LAW RESTRICTS THIS
DEVICE TO SALE OR RENTAL BY ORDER OF A
PHYSICIAN OR OTHER LICENSED HEALTH CARE
PROVIDER.
WARNING: THIS UNIT IS NOT TO BE USED FOR
LIFE SUPPORT. GERIATRIC, PEDIATRIC, OR ANY
OTHER PATIENT UNABLE TO COMMUNICATE
DISCOMFORT CAN REQUIRE ADDITIONAL
MONITORING AND/OR A DISTRIBUTED ALARM
SYSTEM TO CONVEY THE INFORMATION ABOUT
THE DISCOMFORT AND OR THE MEDICAL
URGENCY TO THE RESPONSIBLE CARE GIVER TO
AVOID HARM. PATIENTS WITH HEARING AND/OR
SIGHT IMPAIRMENT(S) MAY NEED ASSISTANCE
WITH MONITORING ALARMS.
Contraindications for Use
WARNING: IN CERTAIN CIRCUM-
STANCES, THE USE OF NON-PRE-
SCRIBED OXYGEN CAN BE HAZARD-
OUS. THIS DEVICE SHOULD ONLY
BE USED WHEN PRESCRIBED BY A
PHYSICIAN.
WARNING: NOT FOR USE IN THE PRESENCE OF
FLAMMABLE ANESTHETICS.
WARNING: AS WITH ANY ELECTRICALLY
POWERED DEVICE, THE USER MAY EXPERIENCE
PERIODS OF NON-OPERATION AS A RESULT OF
ELECTRICAL POWER INTERRUPTION, OR THE
NEED TO HAVE THE ECLIPSE 5 SERVICED BY A
QUALIFIED TECHNICIAN. THE ECLIPSE 5 IS NOT
APPROPRIATE FOR ANY PATIENT WHO WOULD
EXPERIENCE ADVERSE HEALTH CONSEQUENCES
AS THE RESULT OF SUCH TEMPORARY INTER-
RUPTION.
Safety Guidelines
WARNING: NO MODIFICATION OF
THIS EQUIPMENT IS PERMITTED
WARNING: THE MANUFACTURER RECOMMENDS
AN ALTERNATE SOURCE OF SUPPLEMENTAL
OXYGEN IN THE EVENT OF A POWER OUTAGE,
ALARM CONDITION, OR MECHANICAL FAILURE.
CONSULT YOUR PHYSICIAN OR EQUIPMENT
PROVIDER FOR THE TYPE OF RESERVE SYSTEM
REQUIRED.
WARNING: THIS DEVICE SUPPLIES HIGH-CON-
CENTRATION OXYGEN THAT PROMOTES RAPID
BURNING. DO NOT ALLOW SMOKING OR OPEN
FLAMES WITHIN TWO (2) METERS OF (1) THIS
DEVICE, OR (2) ANY OXYGEN-CARRYING ACCES-
SORY. FAILURE TO OBSERVE THIS WARNING CAN
RESULT IN SEVERE FIRE, PROPERTY DAMAGE,
AND/OR CAUSE PHYSICAL INJURY OR DEATH.
WARNING: DO NOT OPERATE UNIT IN A RE-
STRICTED OR CONFINED SPACE (I.E., A SMALL
CASE OR HANDBAG) WHERE VENTILATION CAN
BE LIMITED. THIS CAN CAUSE THE OXYGEN
CONCENTRATOR TO OVERHEAT AND IMPAIR
PERFORMANCE.

8 - ENG PN 21182453 C | User Manual
Eclipse 5
WARNING: THE CONCENTRATOR
SHOULD BE LOCATED AS TO AVOID
SMOKE, POLLUTANTS OR FUMES.
WARNING: THE USE OF SOME OXYGEN ADMIN-
ISTRATING ACCESSORIES NOT SPECIFIED FOR
THIS OXYGEN CONCENTRATOR MAY IMPAIR ITS
PERFORMANCE. RECOMMENDED ACCESSORIES
ARE REFERENCED WITHIN THIS MANUAL.
WARNING: IF THE OXYGEN CONCENTRATOR
HAS BEEN DROPPED, DAMAGED OR EXPOSED
TO WATER PLEASE CONTACT YOUR HOME CARE
PROVIDER FOR INSPECTION OR POSSIBLE RE-
PAIR OF THE DEVICE. DO NOT USE THE OXYGEN
CONCENTRATOR IF IT HAS A DAMAGED POWER
CORD OR PLUG.
WARNING: PROPERLY SECURED, BELT OR OTHER-
WISE RESTRAIN THE OXYGEN CONCENTRATOR
WHEN IN A VEHICLE DURING TRANSPORT TO
PREVENT DAMAGE OR INJURY.
WARNING: DO NOT ALLOW EITHER THE AIR
INTAKE OR THE AIR OUTLET VENTS TO BECOME
BLOCKED. DO NOT DROP OR INSERT ANY
OBJECTS INTO ANY OPENINGS ON THE DEVICE.
THIS CAN CAUSE THE OXYGEN CONCENTRATOR
TO OVERHEAT AND IMPAIR PERFORMANCE.
WARNING: DO NOT OVERFILL THE OPTIONAL
HUMIDIFIER. FILL THE OPTIONAL HUMIDIFIER
WITH WATER ONLY TO THE LEVEL SHOWN BY
THE MANUFACTURER OF THE HUMIDIFIER.
WARNING: DO NOT OPERATE THE ECLIPSE
5 AND AMBULATE WHILE A HUMIDIFIER IS
ATTACHED. REMOVE THE HUMIDIFIER BOTTLE
BEFORE WALKING. DO NOT LAY THE ECLIPSE
5 DOWN WHILE ATTACHED TO A HUMIDIFIER
BOTTLE.
WARNING: THE US DEPARTMENT OF TRANS-
PORTATION (DOT) AND UNITED NATIONS (UN)
REGULATIONS REQUIRE THE REMOVAL OF THE
BATTERY FROM THE DEVICE FOR ALL INTERNA-
TIONAL AIRLINE TRAVEL WHEN THE OXYGEN
CONCENTRATOR IS CHECKED AS LUGGAGE.
WHEN SHIPPING THE OXYGEN CONCENTRATOR,
THE BATTERY MUST ALSO BE REMOVED FROM
THE DEVICE AND PACKAGED PROPERLY.
WARNING: DO NOT OPERATE THIS EQUIPMENT
WITHOUT FIRST READING AND UNDERSTAND-
ING THIS MANUAL. IF YOU ARE UNABLE TO
UNDERSTAND THE WARNINGS AND INSTRUC-
TIONS, CONTACT YOUR EQUIPMENT PROVIDER
BEFORE ATTEMPTING TO USE THIS EQUIPMENT;
OTHERWISE, INJURY OR DAMAGE MAY RESULT.
WARNING: IF YOU FEEL DISCOMFORT OR ARE
EXPERIENCING A MEDICAL EMERGENCY, SEEK
MEDICAL ASSISTANCE IMMEDIATELY.
WARNING: OPERATING THE OXYGEN CON-
CENTRATOR OUTSIDE OF THE OPERATIONAL
TEMPERATURE SPECIFICATIONS CAN LIMIT THE
CONCENTRATOR’S ABILITY TO MEET OXYGEN
CONCENTRATION SPECIFICATION. REFER TO THE
SPECIFICATION SECTION OF THIS MANUAL FOR
TEMPERATURE LIMITS.
WARNING: USE NO OIL, GREASE, OR PETRO-
LEUM-BASED OR OTHER FLAMMABLE PROD-
UCTS WITH THE OXYGEN-CARRYING ACCESSO-
RIES OR THE OXYGEN CONCENTRATOR. ONLY
WATER BASED, OXYGEN COMPATIBLE LOTIONS
OR SALVES SHOULD BE USED. OXYGEN ACCEL-
ERATES THE COMBUSTION OF FLAMMABLE
SUBSTANCES.
WARNING: THE INCORRECT USE OF THE BAT-
TERY CAN CAUSE THE BATTERY TO GET HOT,
IGNITE, AND MAY CAUSE SERIOUS INJURY. BE
SURE NOT TO PIERCE, STRIKE, STEP ON, DROP
THE BATTERY, OR OTHERWISE SUBJECT THE
BATTERY TO STRONG IMPACTS OR SHOCKS.
THE USE OF A DAMAGED BATTERY MAY CAUSE
PERSONAL INJURY.
WARNING: THE OXYGEN CONCENTRATOR
SHOULD NOT BE USED ADJACENT TO OR
STACKED WITH OTHER EQUIPMENT. IF ADJACENT
OR STACKED USE IS UNAVOIDABLE, THE DEVICE
SHOULD BE OBSERVED TO VERIFY NORMAL
OPERATION.
WARNING: USE OF ACCESSORIES, TRANSDUCERS
AND CABLES OTHER THAN THOSE SPECIFIED
OR PROVIDED BY THE MANUFACTURER OF THIS
EQUIPMENT COULD RESULT IN INCREASED
ELECTROMAGNETIC EMISSIONS OR DECREASED
ELECTROMAGNETIC IMMUNITY OF THIS EQUIP-
MENT AND RESULT IN IMPROPER OPERATION.

PN 2118245 C | User Manual 9 - ENG
Eclipse 5
WARNING: THE CONCENTRATOR
SHOULD BE LOCATED AS TO AVOID
SMOKE, POLLUTANTS OR FUMES.
WARNING: THE USE OF SOME OXYGEN ADMIN-
ISTRATING ACCESSORIES NOT SPECIFIED FOR
THIS OXYGEN CONCENTRATOR MAY IMPAIR ITS
PERFORMANCE. RECOMMENDED ACCESSORIES
ARE REFERENCED WITHIN THIS MANUAL.
WARNING: IF THE OXYGEN CONCENTRATOR
HAS BEEN DROPPED, DAMAGED OR EXPOSED
TO WATER PLEASE CONTACT YOUR HOME CARE
PROVIDER FOR INSPECTION OR POSSIBLE RE-
PAIR OF THE DEVICE. DO NOT USE THE OXYGEN
CONCENTRATOR IF IT HAS A DAMAGED POWER
CORD OR PLUG.
WARNING: USE ONLY SPARE PARTS RECOM-
MENDED BY THE MANUFACTURER TO ENSURE
PROPER FUNCTION AND TO AVOID THE RISK OF
FIRE AND BURNS.
WARNING: DO NOT LUBRICATE FITTINGS,
CONNECTIONS, TUBING OR OTHER ACCESSORIES
OF THE OXYGEN CONCENTRATOR TO AVOID THE
RISK OF FIRE AND BURNS.
WARNING: PROPERLY SECURED, BELT OR OTHER-
WISE RESTRAIN THE OXYGEN CONCENTRATOR
WHEN IN A VEHICLE DURING TRANSPORT TO
PREVENT DAMAGE OR INJURY.
WARNING: DO NOT ALLOW EITHER THE AIR
INTAKE OR THE AIR OUTLET VENTS TO BECOME
BLOCKED. DO NOT DROP OR INSERT ANY
OBJECTS INTO ANY OPENINGS ON THE DEVICE.
THIS CAN CAUSE THE OXYGEN CONCENTRATOR
TO OVERHEAT AND IMPAIR PERFORMANCE.
WARNING: DO NOT OVERFILL THE OPTIONAL
HUMIDIFIER. FILL THE OPTIONAL HUMIDIFIER
WITH WATER ONLY TO THE LEVEL SHOWN BY
THE MANUFACTURER OF THE HUMIDIFIER.
WARNING: DO NOT OPERATE THE ECLIPSE
5 AND AMBULATE WHILE A HUMIDIFIER IS
ATTACHED. REMOVE THE HUMIDIFIER BOTTLE
BEFORE WALKING. DO NOT LAY THE ECLIPSE
5 DOWN WHILE ATTACHED TO A HUMIDIFIER
BOTTLE.
WARNING: THE US DEPARTMENT OF TRANS-
PORTATION (DOT) AND UNITED NATIONS (UN)
REGULATIONS REQUIRE THE REMOVAL OF THE
BATTERY FROM THE DEVICE FOR ALL INTERNA-
TIONAL AIRLINE TRAVEL WHEN THE OXYGEN
CONCENTRATOR IS CHECKED AS LUGGAGE.
WHEN SHIPPING THE OXYGEN CONCENTRATOR,
THE BATTERY MUST ALSO BE REMOVED FROM
THE DEVICE AND PACKAGED PROPERLY.
WARNING: DO NOT OPERATE THIS EQUIPMENT
WITHOUT FIRST READING AND UNDERSTAND-
ING THIS MANUAL. IF YOU ARE UNABLE TO
UNDERSTAND THE WARNINGS AND INSTRUC-
TIONS, CONTACT YOUR EQUIPMENT PROVIDER
BEFORE ATTEMPTING TO USE THIS EQUIPMENT;
OTHERWISE, INJURY OR DAMAGE MAY RESULT.
WARNING: IF YOU FEEL DISCOMFORT OR ARE
EXPERIENCING A MEDICAL EMERGENCY, SEEK
MEDICAL ASSISTANCE IMMEDIATELY.
WARNING: OPERATING THE OXYGEN CON-
CENTRATOR OUTSIDE OF THE OPERATIONAL
TEMPERATURE SPECIFICATIONS CAN LIMIT THE
CONCENTRATOR’S ABILITY TO MEET OXYGEN
CONCENTRATION SPECIFICATION. REFER TO THE
SPECIFICATION SECTION OF THIS MANUAL FOR
TEMPERATURE LIMITS.
WARNING: USE NO OIL, GREASE, OR PETRO-
LEUM-BASED OR OTHER FLAMMABLE PROD-
UCTS WITH THE OXYGEN-CARRYING ACCESSO-
RIES OR THE OXYGEN CONCENTRATOR. ONLY
WATER BASED, OXYGEN COMPATIBLE LOTIONS
OR SALVES SHOULD BE USED. OXYGEN ACCEL-
ERATES THE COMBUSTION OF FLAMMABLE
SUBSTANCES.
WARNING: THE INCORRECT USE OF THE BAT-
TERY CAN CAUSE THE BATTERY TO GET HOT,
IGNITE, AND MAY CAUSE SERIOUS INJURY. BE
SURE NOT TO PIERCE, STRIKE, STEP ON, DROP
THE BATTERY, OR OTHERWISE SUBJECT THE
BATTERY TO STRONG IMPACTS OR SHOCKS.
THE USE OF A DAMAGED BATTERY MAY CAUSE
PERSONAL INJURY.
WARNING: DO NOT ATTEMPT ANY
MAINTENANCE OTHER THAN THE POS-
SIBLE SOLUTIONS LISTED WITHIN THIS
MANUAL. DO NOT REMOVE COVERS,
ONLY YOUR EQUIPMENT PROVIDER
OR A QUALIFIED SERVICE TECHNICIAN
SHOULD REMOVE THE COVERS OR
SERVICE THIS DEVICE.

10 - ENG PN 21182453 C | User Manual
Eclipse 5
WARNING: ONLY ACCESSORIES RECOMMENDED
BY THE MANUFACTURER. USE OF ANY OTHER
MAY BE HAZARDOUS, CAUSE SERIOUS DAMAGE
TO YOUR OXYGEN CONCENTRATOR AND WILL
VOID THE WARRANTY .
WARNING: THE MANUFACTURER REC-
OMMENDS AN ALTERNATE SOURCE
OF SUPPLEMENTAL OXYGEN IN THE
EVENT OF A POWER OUTAGE, ALARM
CONDITION, OR MECHANICAL FAIL-
URE. CONSULT YOUR PHYSICIAN OR
EQUIPMENT PROVIDER FOR THE TYPE
OF RESERVE SYSTEM REQUIRED.
WARNING: DO NOT ALLOW EITHER THE AIR
INTAKE OR THE AIR OUTLET VENTS TO BECOME
BLOCKED. DO NOT DROP OR INSERT ANY
OBJECTS INTO ANY OPENINGS ON THE DEVICE.
THIS CAN CAUSE THE OXYGEN CONCENTRATOR
TO OVERHEAT AND IMPAIR PERFORMANCE.
WARNING: SMOKING WHILE USING
OXYGEN IS THE NUMBER ONE CAUSE
OF FIRE INJURIES AND RELATED
DEATHS. YOU MUST FOLLOW THESE
SAFETY WARNINGS:
WARNING: DO NOT ALLOW SMOKING, CANDLES,
OR OPEN FLAMES IN THE SAME ROOM WITH
THE DEVICE OR THE OXYGEN-CARRYING ACCES-
SORIES.
WARNING: SMOKING WHILE WEARING AN
OXYGEN CANNULA MAY CAUSE FACIAL BURNS
AND POSSIBLY DEATH.
WARNING: IF YOU SMOKE, THESE 3 STEPS
MAY SAVE YOUR LIFE: TURN OFF THE OXYGEN
CONCENTRATOR, TAKE OFF THE CANNULA,
AND LEAVE THE ROOM WHERE THIS DEVICE
IS LOCATED. IF UNABLE TO LEAVE THE ROOM,
YOU MUST WAIT 10 MINUTES AFTER YOU HAVE
TURNED THE OXYGEN CONCENTRATOR OFF
BEFORE SMOKING.
WARNING: “NO SMOKING – OXYGEN IN USE”
SIGNS MUST BE PROMINENTLY DISPLAYED
IN THE HOME, OR WHERE OXYGEN IS IN USE.
PATIENTS AND THEIR CAREGIVERS MUST BE IN-
FORMED ABOUT THE DANGERS OF SMOKING IN
THE PRESENCE OF, OR WHILE USING, MEDICAL
OXYGEN.
WARNING: DO NOT USE YOUR OXYGEN CON-
CENTRATOR IN THE PRESENCE OF FLAMMABLE
GASES. THIS CAN RESULT IN RAPID BURNING
CAUSING PROPERTY DAMAGE, BODILY INJURIES
OR DEATH.
WARNING: REMOVING THE CANNULA AND
PUTTING IT ON CLOTHING, BEDDING, SOFAS,
OR OTHER CUSHION MATERIAL WILL CAUSE A
FLASH FIRE WHEN EXPOSED TO A CIGARETTE,
HEAT SOURCE, OR FLAME.
WARNING: DO NOT LEAVE A NASAL CANNULA
ON OR UNDER CLOTHING, BED COVERINGS OR
CHAIR CUSHIONS. IF THE UNIT IS TURNED ON
BUT NOT IN USE, THE OXYGEN WILL MAKE THE
MATERIAL FLAMMABLE. SET THE I/0 POWER
SWITCH TO THE 0 (OFF) POSITION WHEN THE
OXYGEN CONCENTRATOR IS NOT IN USE.
WARNING: PATIENT OR OTHERS MAY BE ENTAN-
GLED IN CANNULA OR OTHER TUBING CAUSING
ASPHYXIATION.
WARNING: DO NOT BLOCK ACCESS TO THE AC
POWER CORD, IN THE EVENT OF AN
EMERGENCY.
WARNING: ACCESSORIES MAY
CONTAIN PHTHALATES. CHILDREN,
PREGNANT OR NURSING WOMEN
SHOULD NOT USE ACCESSORIES THAT
CONTAIN PHTHALATES.
CAUTION: Always disconnect AC
power supply from the wall before
disconnection the AC power supply
from the oxygen concentrator.

PN 2118245 C | User Manual 11 - ENG
Eclipse 5
CAUTION: Always place oxygen supply tubing
and power cords in a manner that prevents a
trip hazard.
CAUTION: When using the Oxygen Concen-
trator in an automobile, boat, or on other DC
sources with the DC power supply, make sure
that the vehicle is started and running before
connecting the Oxygen Concentrator. If the DC
power supply does not illuminate and requires
resetting, disconnect the DC power supply from
the DC outlet, restart your vehicle, and then
reconnect your DC power supply into the DC
outlet. Failure to follow these instructions can
result in the power supply not supplying power
to the Oxygen Concentrator.
CAUTION: When the automobile in which you
are using the Oxygen Concentrator unit is
turned off, disconnect and remove the device
from the automobile. Do not store the Oxygen
Concentrator in a very hot or cold automobile
or in other similar, high-or low-temperature
environments.
CAUTION: In the event of an alarm or
you observe the Oxygen Concentrator
is not working properly; consult the
Troubleshooting section in this manu-
al. If you cannot resolve the problem,
consult your Equipment Provider.
CAUTION: To prevent a void warranty,
follow all manufacturers’ instructions.
Note: Portable and mobile RF communications
equipment can effect medical electrical equipment.

12 - ENG PN 21182453 C | User Manual
Eclipse 5
Recommended Operating Environments
For proper use of the device, the following chart
provides important information concerning the
recommended operating environments, or operating
conditions.
Specifications
Operating
Temperature
50º F to 104º F (10º C to 40º C)
Operating
Humidity
10% - 95% at an 82.4° F (28° C)
dew point
Transport/Stor-
age
Temperature
-4º F to 140º F (-20º C to 60º C)
Humidity: Up to 95% Non-Con-
densing
Electrical Use no extension cords. Use no
electrical outlets controlled by a
switch.
Altitude 0 – 13,123 feet (0 - 4,000
meters)
Placement DO NOT block the air inlet (top
back cover) or the exhaust vent
(back bottom left). Place device
a minimum of 3 inches (7.5
cm) away from walls, draperies,
furniture, etc.
Environment Must be smoke, pollutant, and
fume free.
Operating Time 24-hours a day when connected
to an external AC or DC power
source.
Oxygen
Concentration
90%+5.5%/-3% @ sea level
Dimensions 19.3 high x 12.3 wide x 7.1 deep
(inches), 49.0 height x 31.2 wide
x 18.0 deep (CM)
Weight Eclipse 15 lbs., Battery 3.4 lbs.
Power AC Power (100-240 VAC, 50-60
Hz; DC Power (12V nominal);
Battery (Quantity (2) 95 W-Hr
battery packs each containing
7.92 gm of lithium content)
Nominal
Battery
Recharge Time
1.8 to 5.0 hrs recharge time to
achieve 80% capacity (dependent
upon the flow)
Alarms/Alerts Loss of power, Low Battery, Low
Therapeutic O2 Output, O2 flow
outside normal limits. No Inspi-
ration detected in Pulse Dose
Mode, Unit Malfunction
O2
Concentration
Indicator
Green Light=Normal
Yellow=Caution <85%
Outlet
Pressure
Nominal: 7.0 psig
Maximum: 14.0 psig
Sound Level 48 dBA at 3.0 LPM Continuous
Flow Mode; 40 dBA at 3.0 Pulse
Dose Setting; 59 dBA while
alarming
Applied Part Cannula
The expected service life is a minimum of ve years.
WARNING: USE OF THIS DEVICE AT AN
ALTITUDE ABOVE 13,123 FEET (4,000
METERS) OR OUTSIDE TEMPERATURE
OF 50º F TO 104º F (10º C TO 40º C) OR
A RELATIVE HUMIDITY ABOVE 95% IS
EXPECTED TO ADVERSELY AFFECT THE
FLOWRATE AND THE PERCENTAGE OF
OXYGEN AND CONSEQUENTLY THE
QUALITY OF THE THERAPY.
Note: If the Oxygen Concentrator has been stored
for and extended period of time outside its normal
operating temperature range, the unit should be
allowed to return to normal operating temperature
before use. The recommended time is 3 hours.
Available Settings
The Eclipse 5, including the cannula and other
accessories, are specied for use at the following
specic ows.
Continuous Flow Settings
in LPM
Pulse Dose Setting Bolus
Size (mL)
0.5 -
1.0 16
1.5 24
2.0 32
2.5 40
3.0 48
-56
- 64
- 72
- 80
- 88
- 96
- 128
- 160
- 192
Minimum oxygen concentration (82%).

PN 2118245 C | User Manual 13 - ENG
Eclipse 5
Operating Instructions
Before Operating
This users manual serves as your reference to help
you operate and maintain the device. If you have
any questions or concerns please call your home
care provider.
Important! DO NOT attempt to operate the Eclipse
5 without rst reading the Safety Guidelines section
of this manual. Please follow all of the operating
instructions. Please observe all Warnings on the
device and in the Users Manual. In order to reduce
the risk of re, personal injury and serious damage
to the Eclipse 5, please observe all of the safety
precautions.
WARNING: CLEAN THE CABINET, CON-
TROL PANEL, AND POWER CORD ONLY
WITH A MILD HOUSEHOLD CLEANER
APPLIED WITH A DAMP (NOT WET)
CLOTH OR SPONGE, AND THEN WIPE
ALL SURFACES DRY. DO NOT ALLOW
ANY LIQUID TO GET INSIDE THE DE-
VICE. PAY SPECIAL ATTENTION TO THE
OXYGEN OUTLET FOR THE CANNULA
CONNECTION TO MAKE SURE IT
REMAINS FREE OF DUST, WATER, AND
PARTICLES.
CAUTION: Do not allow either the
air intake or the air outlet vents to
become blocked. This can cause the
Oxygen Concentrator to overheat and
impair performance. Do not operate
the Oxygen Concentrator without
the air intake filter in place. If a
second filter is provided, insert the
“replacement” filter before you clean
the dirty filter. Clean the dirty filter in
a warm soap and water solution then
dry thoroughly prior to use.
Proper Placement of the Eclipse 5
Select a location for the device that avoids the
intake of smoke, fumes and pollutants. Correct
placement of the device should allow intake of air
through the air inlet lter at the top rear of the cabi-
net and allow exhaust air to freely leave the exhaust
vent at the bottom left of the device.
Place the device such that the alarms can be heard.
Position the oxygen supply tubing in such a way
that it does not kink or occlude.
WARNING: DO NOT USE YOUR
OXYGEN CONCENTRATOR IN THE
PRESENCE OF FLAMMABLE GASES.
THIS CAN RESULT IN RAPID BURNING
CAUSING PROPERTY DAMAGE, BODILY
INJURIES OR DEATH. USE NO OIL,
GREASE, OR PETROLEUM-BASED OR
OTHER FLAMMABLE PRODUCTS WITH
THE OXYGEN-CARRYING ACCESSO-
RIES OR THE OXYGEN CONCENTRA-
TOR. ONLY WATER BASED, OXYGEN
COMPATIBLE LOTIONS OR SALVES
SHOULD BE USED. OXYGEN ACCELER-
ATES THE COMBUSTION OF FLAMMA-
BLE SUBSTANCES.
WARNING: THIS DEVICE SUPPLIES HIGH-CON-
CENTRATION OXYGEN THAT PROMOTES RAPID
BURNING. DO NOT ALLOW SMOKING OR OPEN
FLAMES WITHIN THE SAME ROOM OF (1) THIS
DEVICE, OR (2) ANY OXYGEN-CARRYING ACCES-
SORY. FAILURE TO OBSERVE THIS WARNING CAN
RESULT IN SEVERE FIRE, PROPERTY DAMAGE,
AND/OR CAUSE PHYSICAL INJURY OR DEATH.
Note: When the automobile in which you are using
the Oxygen Concentrator unit is turned off, discon-
nect and remove the device from the automobile.
Do not store the Oxygen Concentrator in a very
hot or cold automobile or in other similar, high-or
low-temperature environments. DO NOT leave the
Oxygen Concentrator or the Power Supply plugged
into the vehicle if the ignition is in the off position.
Doing so may drain the vehicle’s battery.
CAUTION: Do not operate unit in a
restricted or confined space (i.e., a
small case or handbag) where venti-
lation can be limited. This can cause
the Oxygen Concentrator to overheat
and impair performance. Do not allow
either the air intake or the air outlet
vents to become blocked. This can
cause the Oxygen Concentrator to
overheat and impair performance.

14 - ENG PN 21182453 C | User Manual
Eclipse 5
Powering on your Eclipse 5
The device is capable of being
operated directly from three (3)
different power sources:
• AC Power Supply with
NEMA Power Cord
• DC Power Supply
• Rechargeable Power
Cartridge (Battery)
General
Charging
Information
The Eclipse
5 charges the
battery while
using AC power and when the battery temperature
is within safe charging temperature. When external
power is disconnected, the device will automat-
ically switch over to the battery if the battery is
installed and charged. When external power is
restored by plugging into an AC outlet, the device
will accept power from the external power source
and replenish the battery. It is not mandatory
for the battery to be installed for the Eclipse 5 to
operate.
Proper connection of the AC or DC Power Supply
requires aligning the power plug with the recessed
external power receptacle of the device. The
recessed external power receptacle is located on
the right side of the device when facing the Control
Panel. Push the power plug into the recessed
receptacle.
WARNING: THE ECLIPSE BATTERY
CARTRIDGE AND DC POWER SUPPLY
MUST BE PERIODICALLY CHECKED.
WHEN AC POWER IS NOT AVAILABLE
THESE ALTERNATE POWER SOURCES
MAY BE USED.
AC Two-Pin Power Supply
Item# 20852326
AC POWER SUPPLY WITH TWO PINS
The Eclipse 5 includes a universal AC Power
Supply for use at home or wherever standard AC
power is available. To connect to an AC power
source, be sure the AC Power Supply cord is
securely inserted into the recessed power receptacle
on the side of the device and that the cord from the
AC Power Supply is plugged into an AC outlet.
When the Eclipse 5 is plugged in properly, a green
indicator on the AC Power Supply will light and the
External Power Indicator, will appear on the
user control panel.
Note: Use only electrical voltage specified on the
specification label affixed to the device.
CAUTION: Use only accessories rec-
ommended by the manufacturer. Use
of any other may be hazardous, cause
serious damage to your oxygen con-
centrator and will void the warranty.
CAUTION: Do not use extension cords with
this unit or connect too many plugs into the
same electrical outlet. The use of extension
cords could adversely affect the performance
of the device. Too many plugs into one outlet
can result in an overload to the electrical panel
causing the breaker/fuse to activate or fire if
the breaker or fuse fails to operate.
CAUTION: Use of cables and adapters other
than those specified, with the exception of
cables and adapters sold by the manufacturer
of the medical electrical equipment as replace-
ment parts for internal components, may result
in increased emissions of decreased immunity
of the Oxygen Concentrator.
Step 1 Step 2

PN 2118245 C | User Manual 15 - ENG
Eclipse 5
DC Power Supply
Item# 5942-SEQ
DC POWER SUPPLY
A DC Power Supply allows the system to operate
from DC outlets, such as those found in motor
vehicles.
1. Start your vehicle.
2. Insert the DC cord into the recessed power
receptacle on the side of the device.
3. Insert the DC Power Supply plug into the
DC power outlet in your motor vehicle.
4. Start the unit on the lowest ow setting
and slowly increase the ow setting to the
prescribed ow rate. (Starting the unit at a
setting of 3 LPM on DC power can cause a
temporary overload of the power supply).
When the device is properly connected and
receiving power from the DC power source,a
green indicator light on the Power Supply and the
External Power Indicator on the control panel
will illuminate.
Eclipse 5 DC Supply Connection
When the Eclipse 5 is connected to the DC supply
in a vehicle, the following applies:
• The Eclipse 5 is able to run at all continuous ow
settings up to 3.0LPM and all pulse ow settings
up to 9.0 (192 mL) while being operated with
the DC supply in a car.*
• The Eclipse 5 is able to charge the battery while
on DC Supply in a car while running on con-
tinuous ow at 2LPM or less, and at all pulse
settings.*
• If the Eclipse 5 battery is being charged, the
battery symbol will waterfall. If the Eclipse 5
battery is not charging, the battery symbol will
be displayed solid.
*Capabilities of the unit on DC power are depen-
dent on the vehicle electrical system. Some
features or ow settings may not be available
depending on the power available from the
vehicle’s DC power outlet.
WARNING: DO NOT ALLOW EITHER
THE AIR INTAKE OR THE AIR OUTLET
VENTS TO BECOME BLOCKED. THIS
CAN CAUSE THE OXYGEN CONCEN-
TRATOR TO OVERHEAT AND IMPAIR
PERFORMANCE.
WARNING: IF THE VEHICLE’S DC POWER SOURCE
DROPS BELOW 11.5 VOLTS, THE ECLIPSE 5 WILL
REVERT TO THE BATTERY OPERATION (IF THE
BATTERY IS PRESENT AND CHARGED). (THE EX-
TERNAL POWER INDICATOR MAY REMAIN ON.)
CAUTION: The DC Power Supply is
designed for 12VDC minimum (150
Watt) vehicle electrical systems. Do
not attempt to operate with 6V, 24V,
or other vehicle electrical system. De-
vice performance may be impacted by
operating on a 120 Watt DC system.
Note: While operating the device from a DC power
supply, the Battery may not charge if the DC power
source does not supply sufficient power. The Eclipse
will dedicate power to running the device first. Any
leftover power is used to supply a trickle charge to
the battery.
Note: To ensure that the device is utilizing the DC
power, check that the External Power Indicator is
illuminated. If a beep is heard, this could indicate
a loss of external power. Check if the green Battery
Power Verification LED is on or off. If the battery
is removed on DC power, it will ensure no loss of
charge while the unit is running. If the indicator is
not illuminated, the battery is powering the device.
Settings Available When Operating on DC for
Eclipse 5
Flow Setting
(LPM) Continuous Bolus Size (mL) Pulse
0.5 Yes - -
1.0 Yes 16 Yes
1.5 Yes 24 Yes
2.0 Yes 32 Yes
2.5 Yes 40 Yes
3.0 Yes 48 Yes
- - 56 Yes
- - 64 Yes
- - 72 Yes
- - 80 Yes
- - 88 Yes
- - 96 Yes
- - 128 Yes
- - 160 Yes
- - 192 Yes
WARNING: ACTUAL PERFORMANCE OF
THE ECLIPSE 5 MAY VARY DEPENDING
UPON USAGE CONDITIONS OF THE
MOTOR VEHICLE AND THE PERFOR-
MANCE SPECIFICATIONS OR CONDI-
TION OF ITS ELECTRICAL SYSTEM.

16 - ENG PN 21182453 C | User Manual
Eclipse 5
Rechargeable Power Cartridge (Battery)
The Eclipse 5 can be powered by the rechargeable
Power Cartridge (Battery), which is supplied with
the device.
Installing the Battery: Align the Battery so that it
will slide into the empty Power Compartment. Push
the Battery into the empty Power Compartment
until it locks (clicks) into position and is ush with
the back of the device. When the Battery is properly
installed and the Eclipse 5 is ON, the Battery Status
Gauge will appear on the Control Panel. (If you DO
NOT have a Battery installed, the Power Cartridge
Status Gauge will not illuminate). The unit will still
operate on external power.
To remove the Battery, pull down on the black re-
lease lever. While holding DOWN the release lever,
pull the Battery away from the Eclipse 5.
Battery Operating Times: The duration-of-use of
the Battery is displayed at the top of the Control
Panel. A variety of factors, such as ow setting,
Pulse or Continuous Flow Mode, and breath rate
will impact the operating time. The table Typical
New Power Cartridge Operating Times provides
operating time estimates for the Eclipse 5 using a
new, fully charged Battery based on ow settings
and operating conditions as indicated.
Rechargeable Power
Cartridge (Battery)
Item#7082-SEQ
WARNING: FOR OXYGEN CONCEN-
TRATORS EQUIPPED WITH BATTERIES:
STORE IN A COOL AND DRY LOCATION
TO HELP ENSURE THE LONGEVITY OF
YOUR BATTERY. STORING YOUR OXY-
GEN CONCENTRATOR FOR EXTENDED
PERIODS OF TIME AT HIGH TEMPERA-
TURES OR WITH A FULLY CHARGED OR
COMPLETELY DISCHARGED BATTERY
CAN DEGRADE ITS OVERALL BATTERY
LIFE. DO NOT ATTEMPT TO OPEN THE
BATTERY; THERE ARE NO SERVICEABLE
PARTS INSIDE THE BATTERY. KEEP
BATTERIES AWAY FROM CHILDREN.
Initial Battery Charging
The new Battery supplied with your Eclipse 5 is not
fully charged when it is shipped from the factory.
Before using your Eclipse 5 for the rst time, you
must rst fully charge the Battery.
With the AC Power Supply plugged in, and the
Battery correctly installed in the Power Compart-
ment of the device, allow the Battery to completely
charge. The Battery is fully charged when the Pow-
er Cartridge Status Gauge, on the Control Panel, is
no longer cascading.
The initial battery charge can occur with the
Eclipse either on or off and connected to AC or
DC power. The Eclipse can be used while either
discharging or recharging the Battery. It may take
between 2 and 5 hours, dependent upon the ow
setting, to achieve 80% capacity from a fully
discharged Battery. The battery will also recharge
when the Eclipse is plugged into AC or DC power
and turned off.
CAUTION: When the automobile in
which you are using the Oxygen Con-
centrator unit is turned off, discon-
nect and remove the device from the
automobile. Do not store the Oxygen
Concentrator in a very hot or cold
automobile or in other similar, high-or
low-temperature environments. DO
NOT leave the Oxygen Concentrator
or the Power Supply plugged into
the vehicle if the ignition is in the
OFF position. Doing so may drain the
vehicle’s battery.
CAUTION: Only use the Manufacturer’s provided
batteries. For proper battery disposal, contact
your Equipment Provider or your local govern-
ment agency for disposal requirements.

PN 2118245 C | User Manual 17 - ENG
Eclipse 5
* Batteries are recyclable. *
In the event of an AC or DC power interruption,
the Eclipse 5 will beep and automatically switch to
Battery operation, as long as the Battery is present
and charged. When AC power is restored, the
Eclipse 5 will beep and the Battery will auto-
matically start recharging, if not fully charged or
too warm. If the Battery is not present, or fully
discharged, during an AC power interruption, the
Eclipse 5 will shut down and alarm. The Battery is
fully discharged when the Power Cartridge Status
Gauge on the control panel is no longer illumi-
nated. The device will display a yellow light and
sound a beep for 120 seconds. The yellow light will
remain on and the beep will repeat after 20 seconds
until the device completely shuts down.
Note: Press and hold the Eclipse 5 ON/OFF button
for a minimum of 5 seconds, to silence the Loss
of Power alarm. Connecting the Eclipse 5 to an
external AC power supply for 2 minutes will also
eliminate this alarm.
Typical New Power Cartridge Operating Times
Continuous
Flow
Battery
Duration
Pulse
Setting
Battery
Duration
(12 BPM)
0.5 LPM 4.4 hours - -
1.0 LPM 3.7 hours 16mL–1.0 5.4 hours
2.0 LPM 2.0 hours 32mL–2.0 5.1 hours
3.0 LPM 1.3 hours 48mL–3.0 4.9 hours
64mL–4.0 4.0 hours
80mL–5.0 3.7 hours
96mL–6.0 3.5 hours
128mL–7 2.5 hours
160mL–8 2.0 hours
192mL–9 1.7 hours
Note: Operating the Oxygen Concentrator outside
of its normal operating temperature range can
affect performance and decrease battery run time
and/or increase battery charge time. (Refer to the
Specifications section in this manual.) You will
achieve longer operating time on the Battery if you
operate your Eclipse 5 in the Pulse Mode (Physician
approved mode).
Typical Battery Recharge Time
The typical time to recharge your Battery to
achieve 80% capacity from a fully discharged
Battery is between 2 and 5 hours, depending upon
the device ow setting. When the battery is fully
charged, the battery gauge will cease cascading.
The battery can be charged in the unit when the
Eclipse 5 is turned off and plugged in.
If the Battery becomes too warm during discharg-
ing, recharging will not begin until the Battery suf-
ciently cools. Removing the Battery and allowing
it to cool may expedite this cooling process.
When operating the Eclipse 5 on DC power, the
battery will recharge while the unit is running at
2.0LPM or less if sufcient power is available.
Typical Power Cartridge Operating Times at 80%
Charge
Continuous
Flow
Battery
Duration
(12 BPM)
Pulse
Setting
Battery
Duration
(12 BPM)
0.5 LPM 4.0 hours 16mL–1.0 3.0 hours
1.0 LPM 3.5 hours 24mL–1.5 3.0 hours
1.5 LPM 2.5 hours 32mL–2.0 3.0 hours
2.0 LPM 2.0 hours 40mL–2.5 3.0 hours
2.5 LPM 1.5 hours 48mL–3.0 3.0 hours
3.0 LPM 1.3 hours 56mL–3.5 3.0 hours
64mL–4.0 3.0 hours
72mL–4.5 3.0 hours
80mL–5.0 2.5 hours
88mL–5.5 2.5 hours
96mL–6.0 2.5 hours
128mL–7.0 2.0 hours
160mL–8.0 1.5 hours
192mL–9.0 1.5 hours

18 - ENG PN 21182453 C | User Manual
Eclipse 5
Step 3: Connect the Oxygen Supply
Tubing or Nasal Cannula to the Oxygen
Outlet
Replace the cannula and oxygen supply tubing
regularly, as recommended by your home care
provider. Consult your home care provider for can-
nula and supply tubing cleaning and replacement
information.
Note: Ensure the cannula is fully inserted and
secure. This ensures that the Oxygen Concentrator
can properly detect inspiration for oxygen delivery.
During inhalation, you should hear or feel oxygen
flow to the prongs of the nasal cannula. The proper
placement and positioning of the prongs of the
nasal cannula in your nose is critical to the amount
of oxygen delivered to the respiratory system of the
end user.
Step 4: Select the Flow Mode
Press the Flow Mode button to select the desired
mode. Pressing this button repeatedly will toggle
you back and forth between Pulse Dose Mode and
Continuous Flow Mode. The proper mode and
proper setting should be prescribed for you by your
physician.
Continuous Flow Mode Operation:
When operating in the Continuous Flow Mode, a
continuous supply of oxygen measured in liters per
minute (LPM) will ow through your tubing and
nasal cannula.
Pulse Dose Mode Operation:
When operating in Pulse Mode, a bolus of oxygen,
measured in milliliters (mL), is delivered upon
inspiration. DO NOT use a humidier in the Pulse
Dose Mode.
To ensure proper saturations, secure a prescription
for pulse dose from your physician with con-
sideration to your needs at rest, during exercise,
and when traveling at altitude. Contact your care
provider for prescription and boarding forms.
When operating in pulse dose mode, the Eclipse
5 supplies a continuous ow of oxygen if a breath
is not detected. The device will continually check
for an inspiratory effort every 15 seconds. Once
an inspiration is detected, the device reverts to
measured bolus delivery. To exit Pulse Dose Mode
and engage Continuous Flow Mode, push the ow
mode button.
First Time Eclipse 5 Operation
Step 1: Positioning Your Eclipse 5 for
Use
Place the Eclipse 5 in a well-ven-
tilated, well lit area. Be sure the
air inlet and exhaust vents are not
obstructed.
Position the Eclipse 5 so that all
audible and visual indicators or
alarms can be easily seen and
heard.
Be sure the air inlet lter is in
place before operating your
Eclipse 5. If the air inlet lter is missing, contact
your home care provider. If the air inlet lter is
dirty, wash with warm soapy water, rinse with clear
water and allow it to dry before placing the air inlet
lter back in the device. If necessary, replace it with
a new, clean air inlet lter.
Plug the device into an appropriate AC Power out-
let, a DC Power source, or be sure there is a fully
charged Battery installed.
Step 2: Power ON the Device and
Allow it to Warm-Up
Press and hold the “ON/OFF” Button for two
(2) seconds to power ON your Eclipse 5. A brief
audible and visual power-on self-test will occur.
Verify that all the power verication indicators are
illuminated and that a buzzer sounds to indicate the
device is operating properly.
The Eclipse 5 has an oxygen concentration status
indicator (OCSI) built in to the device. The OCSI
continually monitors the oxygen output of the
device and incorporates a green light (normal),
yellow light (alert), and a buzzer. These indicators
will all illuminate during the power-on self-test at
start-up. After initially powering ON the device,
please allow up to ve (5) minutes for the device to
reach its performance specications. When only the
green indicator light is illuminated, the device has
reached its performance specications.
Exhaust Vent
Air Inlet Filter

PN 2118245 C | User Manual 19 - ENG
Eclipse 5
Pulse Dose Mode and autoSat Features
Your Eclipse 5 has a feature, called autoSAT®that
delivers a consistent-sized bolus of oxygen up to
40 breaths per minute (see Max Breath Rate table
below). As your breath rate increases, ie. during
ambulation, the autoSAT feature servo-controls
the device, delivering the set bolus size. autoSAT
Technology is proprietary to CAIRE and is utilized
during Pulse Mode only.
Max Breath Rate
Pulse
Dose
Setting
Bolus
Size
(±
15%)
mL
AC Power
Supply &
Power
Cartridge
(Battery)
DC Power
Supply
Max Breath
Rate
Max Breath
Rate
1.0 16 40 40
2.0 32 40 40
3.0 48 40 40
4.0 64 40 31
5.0 80 37 25
6.0 96 31 20
7 128 23 15
8 160 18 12
9 192 15 10
Note: Bolus volume decreases as breath rate
exceeds published range.
Note: The pulse dose setting number (1-9) is not
equal to LPM.
WARNING: PULSE DOSE MODE
SETTINGS MUST BE DETERMINED
FOR EACH PATIENT INDIVIDUALLY
FOR THEIR NEEDS AT REST, DURING
EXERCISE AND WHEN TRAVELING.
WARNING: THE ECLIPSE 5 MAY NOT BE ABLE TO
DETECT ALL INSPIRATORY EFFORTS IN PULSE
MODE. IF THE ECLIPSE 5 DOES NOT RESPOND TO
YOUR INSPIRATION EFFORTS, ASK YOUR HOME
CARE PROVIDER TO CHECK THE SENSITIVITY
SETTING.
Bolus Volume (+/- 15%)
Note: To Equipment Provider: The following oxygen
administration accessories are recommended for
use with the Oxygen Concentrator:
• Nasal Cannula with 7 feet (2.1 m) of tubing: PN
5408-SEQ
• For any additional recommended accessories,
please see the Accessories Catalog (PN ML-
LOX0010) available on www.CAIREmedical.com.
A firebreak is required for use with any cannula.
• CAIRE offers the OxySafe™. This is intended to be
used in conjunction with the oxygen concentrator.
The OxySafe™ is a thermal fuse to stop the flow of
gas in the event that the downstream cannula or
oxygen tubing is ignited and burns to the OxySafe.
It is placed in-line with the nasal cannula or oxygen
tubing between the patient and the oxygen outlet
of the Eclipse 5.
For proper use of the OxySafe, always refer to the
manufacturer’s instructions (included with each
OxySafe kit).
CAIRE offers an OxySafe™ kit that includes a
cannula headpiece, OxySafe™, and 7’ tubing: PN
206773184.
Step 5: Adjust the Flow Setting to
the Prescribed Level
Using the Flow Setting Buttons, adjust the ow
setting to the prescribed setting supplied by your
physician.
WARNING: IT IS VERY IMPORTANT
TO SELECT ONLY THE PRESCRIBED
LEVEL OF OXYGEN. DO NOT CHANGE
THE FLOW SELECTION UNLESS YOU
HAVE BEEN DIRECTED TO DO SO BY A
LICENSED CLINICIAN.
Step 6: Begin Using Your Eclipse 5
Breathe normally through the nasal cannula.
Step 7: Universal Cart Operation
The Universal Cart is designed for use on pedestri-
an-type surfaces.
Align the locater holes on the bottom of the device
to the tabs on the Universal Cart.
Align the large threaded screw
to the insert at the back of the
Eclipse 5. Then hand-tighten
the knob on the cart until the
Universal Cart is tightly secured

20 - ENG PN 21182453 C | User Manual
Eclipse 5
User Troubleshooting Table
Do Not Ignore Alarms
WARNING: THE MANUFACTURER RECOMMENDS AN ALTERNATE SOURCE OF SUPPLEMEN-
TAL OXYGEN IN THE EVENT OF A POWER OUTAGE, ALARM CONDITION, OR MECHANICAL
FAILURE. CONSULT YOUR PHYSICIAN OR EQUIPMENT PROVIDER FOR THE TYPE OF RESERVE
SYSTEM REQUIRED.
Yellow Light
Symptom Possible Cause Your Action
The yellow light is
on solid. There is no
audible alarm.
The Eclipse 5 has de-
tected a problem with
the connection to the
power cartridge.
1) Remove power cartridge and re-install to ensure that it is
secure in the concentrator.
2) If possible, install a separate power cartridge in the Eclipse
5.
3) If this problem persists, contact healthcare provider.
The yellow light is
on. Battery symbol is
flashing on LCD.
The Eclipse 5 power
cartridge may be
warm.
1) Re-attach the Eclipse 5 to external power or install a
fully-charged power cartridge in the Eclipse 5. Allow warm
power cartridge to cool outside the concentrator for 30
minutes.
2) Re-charge the power cartridge using AC power
3) Replace the power cartridge if another is available.
4) If the condition persists, contact your healthcare provider.
The yellow light is
on. Battery symbol is
flashing on LCD.
The Eclipse 5 power
cartridge voltage may
be low.
1) Plug Eclipse 5 into AC power supply and recharge or replace
power cartridge with fully charged power cartridge.
The yellow light is on.
The green light is off.
The Eclipse 5 may
have detected a flow
restriction causing
low or blocked flow.
1) Clean and replace cabinet inlet filter
2) Ensure that the cannula is not kinked or blocked. If used
with a humidifier bottle, ensure that it is filled properly and
not creating a blockage.
3) Ensure that the Eclipse 5 has proper ventilation. It needs to
be at least 3 inches from any surface to ensure the vents are
not blocked.
4) If the problem persists, switch to an alternate source of
oxygen and contact healthcare provider for assistance.
to the device.
Depress the push-button on the
Universal Cart handle to adjust
the height of the handle.
Step 8: Power Off the Device
Press and hold the “ON/OFF” Button for two (2)
seconds to power OFF your Eclipse 5.
Store the Eclipse 5 in a cool and dry location for a
period no longer than 1 month. The Eclipse 5 must
run for a minimum of 2 hours per month to ensure
proper function of the unit.
Note: DO NOT operate the Eclipse 5 and ambulate
while a humidifier is attached. Remove the humidi-
fier bottle before walking. DO NOT lay the Eclipse 5
down while attached to a humidifier bottle.
