C-Dax MULTI BOOM 1018 Manual

1
MULTI BOOM 1018
INSTRUCTION LEAFLET
(Pt.No.2400-0720 Issue 7, Jan 2016)
SAFETY PRECAUTIONS
AN IMPORTANT MESSAGE FOR OWNERS & OPERATORS OF C-Dax ATTACHMENTS AND ACCESSORIES
Be warned of the dangers of loading your ATV or other vehicle in excess of its carrying capacity.
It is important to understand that any loads or attachments whether fastened to or placed on a vehicle or ATV
will alter the stability or handling characteristics of that vehicle or ATV.
Spray tanks or other equipment must be filled only to a level where the gross weight is within the load limit of
the ATV or other vehicle.
Safety is a primary concern in the design, manufacture, sale, and use of spray tanks and other equipment.
As manufacturers of spray tanks and other equipment we want to confirm to you, our customers, our concern
for safety. We take this opportunity to remind you about the simple, basic and common sense rules of safety
when using spray tanks and other equipment. Failure to follow these rules can result in severe injury or
death to operators and bystanders.
It is essential that everyone involved in the assembly, operation, transport, maintenance and storage of this
equipment be aware, concerned, prudent and properly trained in safety.
This also applies to equipment that is loaned or rented to someone who has not read the owner’s manual
and is not familiar with the operation of application equipment.
xNEVER EXCEED THE LOAD LIMIT CAPACITY OF THE ATV OR OTHER VEHICLE.
xPLEASE NOTE THAT FILLING THE SPRAY TANK OR OTHER EQUIPMENT COMPLETELY AND
OR THE ATTACHMENT OF ADDITIONAL EQUIPMENT TO THE ATV MAY EXCEED THE ATV’S
MAXIMUM LOAD CAPACITY, AND ADVERSELY AFFECT THE STABILITY OR THE ATV OR
OTHER VEHICLE.
xCARGO SHOULD BE PROPERLY DISTRIBUTED AND SECURELY ATTACHED.
xREDUCE SPEED WHEN CARRYING CARGO OR PULLING A TRAILER OR TRAILED
APPLICATION EQUIPMENT AND ALLOW GREATER DISTANCE FOR BRAKING.
xNEVER ALLOW ANYONE TO RIDE ON YOUR SPRAYER OR OTHER EQUIPMENT.
xALWAYS FOLLOW THE INSTRUCTIONS IN THE OWNER’S VEHICLE MANUAL FOR CARRYING
CARGO OR PULLING A TRAILER.
xPROPER MAINTENANCE IN LINE WITH MANUFACTURER’S RECOMMENDED MAINTENANCE
PROCEDURES IS ESSENTIAL.
xBEFORE APPLYING CHEMICALS, READ THE LABEL OF THE CHEMICAL MANUFACTURER OR
SUPPLIER FOR PERSONAL PROTECTIVE EQUIPMENT AND OPERATE AS RECOMMENDED.
xTHE SAFETY OF ALL CHEMICALS USED IN AGRICULTURE IS UNDER THE JURISDICTION OF
A GOVERNMENT AGENCY, IE N.Z. MINISTRY FOR THE ENVIRONMENT; USA
ENVIRONMENTAL PROTECTION AGENCY. FURTHER LOCAL GOVERNMENT OR STATE
LAWS MAY APPLY.

2
WARRANTY
1WARRANTY AND LIABILITY
Use of the equipment
1.1 You must satisfy yourself as to the suitability of the equipment for your intended use(s) of the
equipment.
Your relationship with the retailer
1.2 Where you consider you have a warranty claim (or any other claim) in relation to the
equipment, you must contact the retailer who sold you the equipment, not C-Dax directly.
The retailer is responsible for liaising with C-Dax in respect of your claim.
Warranty
1.3 C-Dax warrants to the original purchaser that the equipment is sold free from defects in
materials and workmanship for a period of 12 months from date of first retail sale (6 months
from date of first retail sale if the equipment is sold in the U.K.) subject to the terms set out
below.
1.4 C-Dax will at its option repair or replace the defective equipment (or part of the equipment)
or notify the retailer of the equipment to refund the purchase price for such defective
equipment to you in the event of a breach of this warranty, subject to the terms set out
below.
Liability
1.5 Except for the warranty set out in clause 1.2 above, all warranties and representations
(including those expressed or implied by law) in respect of the equipment or advice relating
to the equipment provided to you by C-Dax are excluded to the extent permitted by law.
1.6 Notwithstanding anything else in this manual, C-Dax’s maximum liability to you (in the event
that such liability exists) in respect of any breach of warranty, any matter set out in this
manual, or for defective equipment or advice relating to the equipment provided is limited at
C-Dax’s option to:
(a) repairing or replacing the equipment (or part of the equipment); or
(b) notifying the retailer of the equipment to refund the price for the equipment paid by
you.
1.7 Notwithstanding anything else in this manual, in no event will C-Dax be liable, whether in
contract, tort (including negligence) or otherwise:
(a) where you have altered or modified the equipment, misused or misapplied the
equipment, or the equipment has been subjected to any unusual, excessive or non-
recommended use, service or handling (including as set out in this manual);
(b) where the equipment is not transported, stored, handled or used in accordance with
any directions given by C-Dax (or the retailer) to you (including as set out in this
manual);
(c) where the equipment:
(i) has been subject to neglect, accident or hireage, or the damage arises from fair
wear and tear, battery damage or chemical attack;
(ii) has been built to a customer’s specifications; or

3
(iii) has been dismantled, repaired or serviced other than by an authorised service
agent of C-Dax;
(d) for loss or damage caused by any factors beyond C-Dax’s control; or
(e) for any loss of profit or revenue, or for any special, indirect, incidental or consequential
damage, loss or injury of any kind suffered by you.
1.8 Where C-Dax elects to repair or replace the equipment it will use reasonable endeavours to
do so as soon as practicable but will not be liable for any delay in doing so.
1.9 You agree that the transactions entered into between you and the retailer (and C-Dax) are for
the purposes of trade and that, having regard to all relevant circumstances of the
transactions, it is fair and reasonable that the provisions of the Consumer Guarantees Act
1993 (NZ) do not apply to those transactions to the fullest extent permitted by law.

4
DESCRIPTION
The Multiboom is a compact, lightweight, rugged spray boom suitable for spraying where
tall brush weeds or other obstacles may damage a wider boom. The boom is only 1.5
metres wide but has an effective spray width of up to 4.5 metres. The boom is divided into
five spraying sections each controlled by a shut-off valve located on each of the nozzle
bodies. The outer nozzles are mounted on swivel fittings that allow the effective spray
width to be adjusted.
Optional parts are as follows
4500-1050 Standard Mounting Brackets
1074 Where an existing Quicksmart Frame is mounted
1073 Quicksmart frame (to be used in conjunction with 1074)
INSTALLATION
All Models
Cut the delivery hose from the sprayer at a convenient point and fit the quick release valve
from the dry break kit provided to the sprayer hose.
Cut the boom delivery hose to match and fit the male quick release fitting.
Fit the remaining male QR fitting to the spray gun hose.
Secure all hose connections with the hose clamps provided.

5
CALIBRATION
4.5M Effective Width
To calibrate the Multiboom, the outer nozzles must be adjusted so that their effective
spray width is 1.5M each. This makes the effective width of the boom 4.5M.
Because the outer nozzles are covering an area three times as wide as each nozzle in the
center section, they must be selected to produce three times the flow of each center
nozzle at the same pressure.
Centre Tips (3 required) Outer Tips (2 required) Boom Flow @ 2bar
L/Min
Yellow 02 (Pt No. 5300-9800) OC06 (Pt No. 5300-3700) 5.83
Operating Shut-off Valves
Locate the red shut-off knob on the side of each nozzle body. Rotate the knob clockwise
to shut the flow off to the tip, anti-clockwise to allow fluid through the tip. The knob may
need to be pushed in towards the nozzle body in order to relocate on the thread.
DETERMINING APPLICATION RATE
Once the tip size and effective spray width have been set, measure the flow from the tips
using a measuring jug. Calculate the boom flow rate as follows; (all flows in Litres/Minute)
Boom Flow= (Centre tip flow x 3) + (Outer tip flow x 2)
Calculate the application rate as follows;
L/Ha= Boom Flow(L/Min) x 600
Effective Spray Width (Metres) x Speed (KPH)
SPARE PARTS
Part Number Description Quantity Required
1600-6000 Nozzle Cap 5
3400-5400 Nozzle Filter 5
4100-0010 8.5mm Delivery Hose By the metre as needed
5300-1900 Nozzle Body Inner 3
5300-1600 Nozzle Body Outer 2
5300-2600 Swivel Body Outer 2
5300-3700 OC-06 Brass Nozzle Tips 2
5300-9800 110WR02 Nozzle Tips 3

6
PARTS DIAGRAM

7
PARTS LIST
Item No.
QTY.
e9 part no
Description
1
5
1600-6000
Cap-Nozzle-Fan-QC-Red-Incl Gasket
2
1
1900-1300
Centre-Boom-BF1545 G2-ZP
3
1
2000-0015
Clamp-Hose-Herbi-F-Ratchet-15.0<>17.1mm-Black-Nylon
4
4
2000-2021
Clamp-Hose-Oetiker-Single Ear Stepless-20.9<>24.1mm-S/S
5
2
2840-1080
Fastener-Bolt&Nut-Hex-8.8 Grade-M10x80-ZP
6
5
3170-0006
Fastener-Nut-Nyloc-M6-ZP
7
2
3170-0010
Fastener-Nut-Nyloc-M10-ZP
8
5
3280-0634
Fastener-Self Tap-Screw-Pan-6Gx3/4"-Pozi-ZP
9
5
3290-0616
Fastener-Set Screw-Hex-8.8 Grade-M6x16-ZP
10
4
3310-6010
Fastener-Washer-Flat-M10-ZP
11
5
3400-5400
Filter-Nozzle Tip-50 Mesh-Plastic
12
1
4100-0010
Hose-Spray-Delivery-40 Bar-10mm ID-Yellow (2.5m)
13
1
4500-2200
Kit-Dry Break-8.5x10-Quick Coupler-Brass
14
2
5300-1600
Nozzle Body-DCV-3/8BSPMx22x10-Incl O'Ring-Less Cap
15
3
5300-1900
Nozzle Body-DCV-QCx22x10-W/Shut Off-Incl O'Ring-Less Cap
16
2
5300-2600
Nozzle Body-Swivel-Single-3/8BSPFxQC-Nylon
17
2
5300-3700
Nozzle Tip-Teejet-Off Centre-OC-06-Brass
18
3
5300-9800
Nozzle-Tip-Wide Range-110WR02-Single
19
2
6200-6250
Pipe-Fitting-Plug-Push In-Barbed Shank-16mm-Plastic-Black
20
1
6200-9180
Pipe-Fitting-Tee-16 Shankx10 Shankx16 Shank-Plastic
21
2
8100-1200
Spacer-ATV Boom-EWST-16x2x50LG-ZP
22
1
8840-3715
Tube-Gas-Semi Rigid-15mm ID-Yellow-Polyethylene (0.8m)
23
1
8840-3715
Tube-Gas-Semi Rigid-15mm ID-Yellow-Polyethylene (0.65M)
24
2
8900-5300
Valve-Nozzle Body-Shut Off-Incl DCV

8
INNER NOZZLE BODY PARTS
Item No.
QTY.
e9 part no e9 description
1
1
5300-1900
Nozzle Body-DCV-QCx22x10-Incl O'Ring-Less Cap
2
1
3280-0634
Fastener-Self Tap-Screw-Pan-6Gx3/4"-Pozi-ZP
3
1
3400-5400
Filter-Nozzle Tip-50 Mesh-Plastic
4
1
5300-XXXX
Nozzle-Tip-SPECIFY TYPE WHEN ORDERING
5
1
1600-6000
Cap-Nozzle-Fan-QC-Red-Incl Gasket
6
1
3700-9250
Gasket-Washer-Nozzle Tip Sealing-10x19x3.5mm-Rubber

9
OUTER NOZZLE BODY PARTS
Item No.
QTY.
e9 part no e9 description
1
1
5300-1600
Nozzle Body-DCV-3/8BSPMx22x10-Incl O'Ring-Less Cap
2
1
5300-2600
Nozzle Body-Swivel-Single-3/8BSPFxQC-Nylon
3
1
3400-5400
Filter-Nozzle Tip-50 Mesh-Plastic
4
1
1600-6000
Cap-Nozzle-Fan-QC-Red-Incl Gasket
5
1
5300-XXXX
Nozzle-Tip-SPECIFY TYPE WHEN ORDERING
6
1
8900-5300
Valve-Nozzle Body-Shut Off-Incl DCV
7
1
3280-0634
Fastener-Self Tap-Screw-Pan-6Gx3/4"-Pozi-ZP
