C3 SIL Linear Series User manual

Operating Instructions
SIL Linear Series
7215870100R00
www.c3furnishings.com
! NOTE: The heater on
your fireplace may emit a
slight, harmless odor when
first used. This odor is a
normal condition caused
by initial heating of internal
heater parts and will not
occur again.
CUTOFF SWITCH
! NOTE: There is a safety
temperature cutoff switch
(cutout) inside the heater.
If the heater overheats,
the cutout will shut off the
supply power.
It can be reset by
unplugging the unit and
waiting 5 minutes before
plugging the unit back on.
CAUTION: If you need
to continuously reset the
heater, unplug the unit and
call technical service at
1-888-346-7539.
Power ON/OFF
The ON/OFF button turns the fireplace ON and OFF. When the fireplace
is OFF, pressing the ON/OFF button on the remote control or touching
the icon on the front glass will turn on the fireplace. If the ON/OFF
button is pressed again within 10 seconds it will turn OFF the fireplace.
With inactive controls, press twice to turn OFF the fireplace. The first
press on the ON/OFF button lights up the touchscreen icons and
activates the controls.
The fireplace has a built-in memory function. When the fireplace is
turned back on, the display will show the last selected function and
it will start at the last used settings (except timer). If the fireplace is
disconnected from the main power source, it will restart at the default
settings.
1
2
3
4
5
6
7
The fireplace can be operated with the multi–function IR remote
control or from the touchscreen controls on the top-right of the front
glass.
Once the fireplace is turned on the digital display and the control
icons on the front glass will illuminate. If no button or icon is pressed
within 10 seconds, the fireplace controls will deactivate by the digital
display turning off first and then the icons. To reactivate the controls
press any button on the remote or touch any icon on the front glass.
1. Power ON/OFF
2. Flame Control
3. Heat ON/OFF
4. Timer
5. Ember Bed
6. Level Selection
7. Digital Display
1
2
3
4
5
6
7
1
2
3
4
5
6
7
Touchscreen
Remote

disabled. When the heat is disabled, pressing the
Heat button will cause the ember bed to flash, but
the heater will not operate.
To enable the heater again, touch and hold the
Heat icon for 10 seconds.
! NOTE: This function cannot be set with the
remote control.
Timer ON/OFF
The Timer button is used to activate or deactivate
the sleep timer.
Pressing the Timer turns the timer on and ‘8h’
appears on the display. Pressing the Timer a
second time within 10 seconds will turn the
timer off. To set the time, use the Level Selection
control to select the desired time from the
following: 8h-1h-2h-3h-4h-5h-6h-7h.
The fireplace will shut off after the selected time
period. Switching the fireplace OFF with the
Power Button will clear any timer setting.
Ember Bed
The Ember Bed button changes the ember bed
by cycling through the seven color options:
color rotation ‘d1’ and smoldering (fluctuating
brightness) embers option ‘d9’. When the Level
Selection button is pressed while ‘d1’ is displayed,
the color rotation speed will change: ‘1‘– Low,
‘2’– Medium, ‘3’- Fast. With ‘d8’ through ‘d2’
displayed, the Level Selection button will adjust
the brightness of the ember bed from 3- High,
2-Medium, and 1-Low.
Level Selection
The Level Selection button is used to adjust
the heat setting, as well flame and ember bed
brightness, color change speed and timer setting.
See relevant section for more details.
Flame Control
This button is used to turn flames ON, to alter
the flame color and to turn flames OFF. Press the
Flame button multiple times to cycle through
7 solid color options (L8, L7, L6, L5, L4, L3, L2),
color rotation option (L1) and flames OFF.
While L8, L7…or L2 is displayed, press the Level
Selection button to change the brightness of
the flames from the available options: 3- High,
2-Medium and 1-Low.
When the color rotation is set and ‘L1’ is displayed,
pressing the Level Selection button will change
the color rotation speed. Three speed options are
available: 1-Slow, 2-Medium, 3-Fast.
Heat ON/OFF
Pressing the Heat control turns the heater ON
and OFF.
With Heat ON and set temperature displayed,
press the Level Selection button multiple times to
cycle through the 11 temperature settings:
72°F, 74°F, 76°F, 78°F, 80°F, 82°F, ON, 64°F, 66°F,
68°F, 70°F, (22°C, 23°C, 24°C, 25°C, 26°C, 27°C,
ON, 18°C, 19°C, 20°C, 21°C).
ON means the heater operates continuously.
Changing the Temperature Unit (°F °C):
With Heat ON and display showing the set
temperature, press and hold the ON/OFF icon on
the touchscreen for 5 seconds. The display will
flash 3 times and it will switch from °F to °C or °C
to °F.
! NOTE: This function cannot be set with the
remote control.
Heater Enable & Disable Function:
From the touchscreen controls touch and hold
the Heat icon for 10 seconds. The ember bed will
flash 6 times to indicate that the heater function is
1
2
3
4
5
6
7
1
2
3
4
5
6
7
1
2
3
4
5
6
7
1
2
3
4
5
6
7
1
2
3
4
5
6
7
