Cable Innovations DLPS-15D Manual

Cable Innovations,Inc.
4665 Hwy 332 Suite C
Hoschton,GA 30548
770-962-5146
www.Cableinnovations.com
INSTALLATION AND INFORMATION
SHEET FOR DLPS-15D
GENERAL INFORMATION:
1. This surge protector is for outdoor use.
2. The DLPS-15D is to be used with 75 ohm coaxial cable such as Series 59 and Series 6.
3. This is a dual directional protector, so either connector can be the service port and the other
connector would be the customer port.
4. DLPS-15D conforms to surge fusing guidelines outlined under UL-497C and ANSI/NFP70
National Electrical Code, Article 830 and is rated as a low power device as defined in Table
830-4.
5. The DC breakdown rating is 135 volts.
6. The normal operating parameters of the DLPS-15D are as follows:
Operating voltage: 60 and 90 volts
current: less than 1 Amp
wattage: 90 watts
LIMITED WARRANTY
Cable Innovations, Inc warrants its products to be free from defects in material and workmanship for a period of two (2) years. If a
product proves to be defective in material or workmanship during the warranty period, Cable Innovations, Inc will, at its sole option,
repair or replace the product. Please call 1-800-952-5146 8:00 AM to 5:00 PM EST Monday thru Friday for warranty information.
There are no warranties, expressed or implied, which extends beyond the description contained herein.
DWG# 1015D000 REV C

INSTALLATION INSTRUCTION
FOR DLPS-15D
INSTALLATION:
* New Installation:
1. Mount the DLPS-15D to the structure using the two 1/4” Hex head screws provided,
with the two F connectors facing down (see figure 1). This will help keep the water
out of the cable connectors.
2. It is very important that the DLPS-15D is connected to a substantial ground system
preferably the power service grounding electrode system. The ground wire should be
#10 copper or #8 aluminum. Run the ground wire to the electrode (rod) in as straight a
line as possible. If bends are needed make the bend radius not less than 4”. Insert the
wire under the grounding screw of the unit, and make sure that the wire is tightly
secured under the screw.
3. Connect the cable to the DLPS-15D making sure to have drip loops, see figure 1.
* Existing Installation:
1. Remove the cables from the grounding block and remove the grounding block from
the installation. Use the new installation instructions from this point on.
FIGURE 1
DWG# 1015D000 REV B
DWG# 1015D00 REV C
CABLE INNOVATIONS
BRKDWN VOLTAGE 135V
DLPS-15D
PATENT # 5216569
R
L
U
75O SIGNAL
CIRCUIT PROTECTOR
LISTED 6P12
MHZ
5-1000
Grounding Electrode Rod
#10 Copper or #8 Aluminum
Grounding Wire
