CT-VGA/HD-CONV-V2
User Manual

CT-VGA/HD-CONV-V2 Manual
2
Table of Contents
1.0 Introduction........................................................................................................................... 2
2.0 Specications ....................................................................................................................... 2
3.0 Package Contents ................................................................................................................ 3
4.0 Connection Diagram............................................................................................................. 3
5.0 Warranty ............................................................................................................................4-5
1.0 Introduction
The CT-VGA/HD-CONV-V2 is a high-denition VGA to HDMI video converter. Easily input your
analog PC RGBHV and analog audio signals and convert to digital HDMI signal. It allows you
to connect the VGA (HD-15 connector) output from the PC to the digital HDMI input of the latest
HD ready plasma, LCD, LED or DLP monitor. Its high bandwidth capability supports a wide
range of PC and HDTV resolutions.
1.1 Features
• Plug and play
• No power supply required
• HDMI 1.3 compliant
• VGA input supports up to 1920 x1080@60Hz
• Small form factor for tight spaces
• Perfect for devices with no HDMI output available
2.0 Specications
Specifications
Input Port 1 x VGA, 1 x 3.5mm Audio Jack
Output Port 1 x HDMI
Input/Output Resolution
640 x 480@60/72/75/85Hz, 800 x 600@60/72/75/85Hz, 1024 x 768@60/70/75/85Hz,
1152 x 864@75Hz, 1280 x 720@60Hz, 1280 x 768@60Hz, 1280 x 800@60Hz, 1280 x
960@60Hz, 1280 x 1024@60Hz, 1360 x 768@60Hz, 1400 x 1050@60Hz,
1440 x 900@60Hz, 1680 x 1050@60Hz, 1600 x 1200@60Hz, 1920 x 1080@60Hz
Dimensions 2.59" x 2.16" x 0.78" (66 x 55 x 20mm)
Weight 0.088 lbs (40 g)
Warranty 1 year - Can be extended to 3 years

CT-VGA/HD-CONV-V2 Manual
3
3.0 Package Content
Before attempting to use this unit, please check the packaging and make sure the following
items are contained in the shipping carton:
1. 1 x Main unit (VGA to HDMI Converter)
2. 1 x USB cable
3. 1 x User Manual
4.0 Connection Diagram
Laptop
PC
HD TV
HDMI Projector
HDMI
VGA

CT-VGA/HD-CONV-V2 Manual
4
5.0 CableTronix 1-Year Limited Warranty
CABLETRONIX. (the “Company”) warrants to the Original Purchaser that the item purchased is
free from defects in workmanship or material under normal use. This warranty starts on the date
of shipment of the hardware to the Original Purchaser.
During the warranty period, the Company agrees to repair or replace, at its sole option, without
charge to Original Purchaser, any defective component. To obtain service, the Original Purchas-
er must return the item to the Company properly packaged for shipping. All defective products
must be returned to the Company within thirty (30) days of failure. Products must be returned
with a description of the failure and Return Merchandise Authorization (RMA) number supplied
by the Company. To receive a RMA number and a return shipping address on where to deliver
the hardware, call 610-429-1821. The shipping, and insurance charges incurred in shipping to
the Company will be paid by Original Purchaser, and all risk for the hardware shall remain with
the Original Purchaser until such time as Company takes receipt of the hardware. Upon re-
ceipt, the Company will promptly repair or replace the defective unit, and then return said unit to
Original Purchaser, shipping prepaid. The Company may use reconditioned or like-new parts or
units, at its sole option, when repairing any hardware. Repaired products shall carry the same
amount of outstanding warranty as from original purchase. Any claim under the warranty must
include dated proof of purchase or invoice. In any event, the Company’s liability for defective
hardware is limited to repairing or replacing the hardware.
his warranty is contingent upon proper use of the hardware by Original Purchaser and does
not cover: if damage is due to Acts of God (including re, ood, earthquake, storm, hurricane or
other natural disaster), accident, unusual physical, electrical, or electromechanical stress, mod-
ications, neglect, misuse, operation with media not approved by the Company, tampering with
or altering of the hardware, riot, war, invasion, act of foreign enemies, hostilities (regardless of
whether war is declared), civil war, rebellion, revolution, insurrection, military or usurped power
or conscation, terrorist activities, nationalization, government sanction, blockage, embargo,
labor dispute, strike, lockout or interruption or failure of electricity, air conditioning, or humidity
control, Internet, network, or telephone service.
The warranties given herein, together with any implied warranties covering the hardware,
including any warranties of merchantability or tness for a particular purpose, are limited in
duration to one year from the date of shipment to the Original Purchaser. Jurisdictions vary with
regard to the enforceability of warranty limitations, and you should check the laws of your local
jurisdiction to nd out whether the above limitation applies to you.

CT-VGA/HD-CONV-V2 Manual
5
The Company shall not be liable to you for loss of data, loss of prots, lost savings, special, inci-
dental, consequential, indirect, or other similar damages arising from breach of warranty, breach
of contract, negligence, or other legal action even if the Company or its agent has been ad-
vised of the possibility of such damages, or for any claim brought against your by another party.
Jurisdictions vary with regard to the enforceability of provisions excluding or limiting liability for
incidental or consequential damages. You should check the laws of your local jurisdiction to nd
out whether the above exclusion applies to you.
This warranty allocates risks of product failure between Original Purchaser and the Company.
The Company’s hardware pricing reects this allocation of risk and the limitations of liability
contained in this warranty. The warranty set forth above is in lieu of all other express warran-
ties, whether oral or written. The agents, employees, distributors, and dealers of the Company
are not authorized to make modication to this warranty, or additional warranties binding on
the Company. Accordingly, additional statements such as dealer advertising or presentations,
whether oral or written, do not constitute warranties by the Company and should not be relied
upon.
This warranty gives you specic legal rights. You may also have other rights which vary from
one jurisdiction to another.
