Cabletron Systems Netlink FRX4000 Operating manual

0DLQWHQDQFH
*XLGH
Document number
09-41-06-114-03 The Complete Networking Solution TM

iii
Notice
Cabletron Systems reserves theright to make changes in specifications and
other information contained in this document without prior notice. The
readershould in all cases consult Cabletron Systems to determine whether
any such changes have been made.
Thehardware, firmware, and/orsoftwaredescribed in this manualis subject
to change without notice.
IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR
ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL
DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO
LOST PROFITS) ARISING OUTOF OR RELATED TO THISMANUAL
OR THE INFORMATION CONTAINED IN IT, EVEN IF CABLETRON
SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR SHOULD HAVE
KNOWN, THE POSSIBILITY OF SUCH DAMAGES.
Copyright 1997, 1998 by Cabletron Systems, Inc. All rights reserved.
Printed in the UnitedStates ofAmerica.OrderNumber: FRX4-MNT-DOC.
Also see third-party software copyrights in theNetlink
FRX4000/FRX6000 User Guide.
Netlink is a trademark of Cabletron Systems, Inc. All other product desig-
nations are the property of their respective owners.
Statements of Compliance
United States (FCC)
Theequipmentprovided byCabletron Systems,Inc.anddocumented in this
manual has been tested and found to comply with the limits for a Class A
digital device, pursuant toPart 15of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment.
Thisequipmentgenerates,uses, and canradiateradio frequencyenergy and,
if not installed and used in accordance with the installation manual, may
cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in
which casethe userwill berequired to, at his/herown expense, takethe nec-
essary measures to eliminate the interference.

iv FRX4000 Maintenance Guide, Rev 03
To ensurecompliancewith theClassA FCClimits,useonly shielded cables
with this equipment. Any cableinstalled above a ceiling or below a floor
must be of amaterial and construction approved by UL for that application.
Canada
This digital apparatus does not exceed the Class A limits for radio noise
emissions from digital apparatus set out in the Radio InterferenceRegula-
tions of the Canadian Department of Communications.
Le present appareil numerique n'emet pas de bruits radioelectriques
depassant les limits applicables aux appareils numeriques de laclass Apre-
scrites dans le Reglement surlebrouillageradioelectrique edicte parle min-
istere des Communications du Canada.
About This Manual
This manual is intended for use by field service personnel either directly
employed by orcontracted by Cabletron Systems,Inc.Themanualprovides
information that will aid in troubleshooting and maintaining an FRX4000.
You should also have a Netlink FRX4000/FRX6000 User Guide for ref-
erence.
Some of the operations described in this manual can lead to
damage to the hardware and/or software if not performed
correctly. This manual should be used only byqualified
service personnel.
Revision History
Rev Date Reason for Update
01 December 1996 Initial release (included FRX6000)
02 April 1997 Separate FRX4000 and FRX6000manuals
03 March 1998 Release 4.0
Terminology and Conventions
This typeface represents general text. This typeface represents computer
input and output.
In on-screen versions of the manual, items in blue are links to other places
inthe manual.

v
This symbol points to an informational noterelating to the text,
table, or figure that immediately precedes orfollows it.
This symbol and text identifies a cautionary note, the
content ofwhich is more criticalto heed than an informa-
tional note.
This symbol and text identifies a warning, intended to
prevent either injury to the user or major damage to
hardware, software, or system operation.
References to these keyboard keys appear in the manual and/or on the
screen:
"[N]"—is a reference to a key on yourkeyboard (where “N” is thekey).
"Enter"—means that you should type in the information,then press the
[Enter] key.
"Type"—is similar to "Enter", except that the word “[Enter]” follows
the information to be typed (e.g., "type n [Enter]").
"Press"—means press (hit, strike)the key once. Pressing the[Enter]
key afterwards is not necessary.
"[Ctrl]"—followed by oneortwo otherkey designations,mustbe struck
simultaneously with the other keys shown.
If a statement ends with a reference to a key—for example, “....then press
[Enter].”—the period is not part ofthe data to beentered.Ifa period should
be entered, it will be shown as "[.]." The same applies to all other punctu-
ation.
Wheninstructedto, for example, “press[A],[B] from the Main Menu,” this
meanspress[A], then [B], not [A] comma [B].
Screen displaysare provided to show thegeneral appearance of
actual screens. Theyareonly examples—they do not neces-
sarily represent an operational system.
Related Documents
The Netlink FRX4000/FRX6000 User Guide is shipped with every
FRX6000, and is an option with FRX4000. Copies of this and other
Cabletron documents can be ordered from Cabletron Systems or your local
distributor of Cabletron products.

vi FRX4000 Maintenance Guide, Rev 03

v
Table of Contents
Chapter 1— Product Overview
LAN Interfaces ..............................................................1-2
Operator Interfaces ........................................................1-2
Chapter 2—Diagnostic Procedures
Reviewing Boot Messages .............................................2-4
BootMessages ...........................................................2-5
Chapter 3—Testing & ReplacingComponents
Removing theChassis Cover .........................................3-3
Testing Component Voltages .........................................3-4
Replacing Memory Modules .........................................3-5
Adding or Replacing an Expansion Card ......................3-6
Adding or Replacing a DSU/CSUCard ......................3-11
Appendix A—Configuration Drawings
I/O Cables .....................................................................A-2
Cables for WAN Ports 0 and 1 .................................A-2
Cables for WAN Ports 2 and 3 .................................A-3
Cables for WAN Ports 4–7 .......................................A-7
Auxiliary Console Cables ...........................................A-10
Appendix B—Installing Software
Backing Up and Restoring Files ................................... B-1
Backing Up and Restoring a Database...................... B-1
Backing Up and Restoring Local Files ..................... B-3
RemoteFileTransfer ....................................................B-7
RemoteSoftware Update .............................................. B-8
Index

vi FRX6000 Maintenance Guide, Rev 03
List of Figures
1-1 I/O Ports on theFRX4000...............................................1-1
2-1 Port Status Display.......................................................... 2-2
2-2 Main Menu......................................................................2-3
3-1 FRX4000, Front View..................................................... 3-1
3-2 FRX4000, Rear View...................................................... 3-1
3-3 FRX4000, Interior View.................................................. 3-2
3-4 FRX4000, Bottom View.................................................. 3-3
3-5 Removing theFRX4000 Cover.......................................3-4
3-6 SIMM.............................................................................. 3-5
3-7 Expansion and Connector Cards ..................................... 3-7
3-8 FRX4000 Motherboard ...................................................3-8
3-9 Connector Card Mounting Post.......................................3-9
3-10 Installing a Connector Card............................................. 3-9
3-11 Installing an Expansion Card ........................................ 3-10
3-12 Connector Card Mounting Post..................................... 3-11
3-13 Installing a DSU/CSU Card .......................................... 3-12
A-1 I/O Ports on theFRX4000.............................................. A-1
A-2 RS-232 Cables for Ports 0, 1..........................................A-2
A-3 RS-232 Cables for Ports 2, 3..........................................A-3
A-4 V.35 Cables for Ports 2, 3 .............................................. A-4
A-5 RS-449 Cables for Ports 2, 3..........................................A-5
A-6 X.21 Cables for Ports 2, 3 .............................................. A-6
A-7 RS-232 Cables for Ports 4–7.......................................... A-7
A-8 V.35 Cables for Ports 4–7 ..............................................A-8
A-9 X.21 Cables for Ports 4–7 ..............................................A-9
A-10 Auxiliary Console Cable, FRX4000 to PC .................. A-10
A-11 Console Cable Converter,FRX4000 to Terminal........ A-10
A-12 Auxiliary Console Cable, FRX4000 to Modem........... A-11
List of Tables
B-1 Database Files..................................................................B-4

Chapter 1
Product Overview
The NetlinkTM FRX4000 is used to provide concentration and access
to remote devices. Each FRX4000 supports up to eight serial inter-
faces. (The FRX6000 isgenerally used where more than eight serial
interfaces are required.) The FRX4000 provides local and remote
switching, and (on devices with video interfaces) features an intu-
itive, menu-based management structure that allows complete local
and remote control of other Cabletron frame relay devices in the
family ofFRX4000,FRX6000, SmartSwitch 1800, and 9W004.
Detailed product descriptions can be found in the Netlink FRX4000/
FRX6000 User Guide.
AbasicFRX4000 containsfour serialports forconnection toa frame
relay or X.25network,user devices, and/or other Cabletron frame
relay devices (FRX4000, FRX6000, SmartSwitch 1800, 9W004).
Each FRX4000 also contains one LANinterface, either Ethernet or
Token Ring. An optional serial expansion card offers four more
WAN ports.
Figure 1-1 I/O Ports on theFRX4000
The main board on the FRX4000 supports four serial
ports. If the CSU/DSU port is used, WAN port 1 is dis-
abled.
I/Ocables are available for WAN ports 0–7 in several configura-
tions, described in Appendix A.
Ports 4–7are on optional
expansion module
Optional
CSU/DSU port
LAN port
WAN 0 WAN 1 WAN 2 WAN 3
WAN 4 WAN 5 WAN 6 WAN 7

1-2 FRX4000MaintenanceGuide,Rev 03
LAN Interfaces
The Ethernet model of FRX4000 contains an Ethernet interface, pro-
videdin RJ-45 (fortwistedpair) and15-pin“D” (AUI, for Thicknet)
configurations. The Ethernet cable and, if AUI, the tranceiver, must
be provided by the customer.
The Token Ring model of FRX4000 contains a Token Ring
interface, provided in RJ-45 (for unshielded twisted pair) and 9-pin
“D” (for shielded twisted pair) configurations. A Token Ring cable,
Cabletron number FRX-TR-CAB, is available.
Operator Interfaces
The FRX4000 doesnot require anyoperator intervention for normal
operation. However, a keyboard and video device are necessary for
initial configuration, and can be helpful later for monitoring.
Each FRX4000 is shipped with cables that allow connection to an
ASCII terminal by any of three methods: direct connection to ter-
minal, connection to terminal via modems, or direct connection to
PC running terminal emulation software.
A keyboard and video device can also be connected via one of these
methods:
●ASCII terminal/keyboard (or PC with terminal emulation
software) connected to an async PAD portin the local
FRX4000.
●ASCII terminal/keyboard (or PC with terminal emulation
software) connected to an async PAD portin a remote
Cabletron frame relay device (FRX4000, FRX6000,Smart-
Switch1800,9W004),through anetwork,into anX.25portin
the local node.
●Keyboard and videodeviceon aremoteCabletron framerelay
device.

Product Overview 1-3
Remote monitoring and configuration of any FRX6000
with IP and SNMP configured can be performed via
Cabletron’s Spectrum network management platform, or
via a Hewlett Packard® workstation with HP OpenView
and Netlink OmniView.
An async terminal’s keyboard must have [F1]–[F10] function keys as
well as [PgUp] and [PgDn] keys.
Standard PC keyboard function keys are represented as follows on a
VT100. (^[ is[Esc], and the followingcharacteris anuppercase letter
O.)
Standard VT100
Keyboard Keypad Maps to:
[F1] [PF1] ^[0P
[F2] [PF2] ^[0Q
[F3] [PF3] ^[0R
[F4] [PF4] ^[0S
[F5] [5] ^[0u
[F6] [6] ^[0v
[F7] [7] ^[0w
[F9] [,] (comma) ^[0l
[F10] [.] (period) ^[0n
[PgUp] [Up Arrow] ^[0A
[PgDn] [Down Arrow] ^[0B

Chapter 2
Diagnostic Procedures
All of the procedures in this chapter require an attached
video device.
Once an FRX4000 is operational, much diagnostic information is
availablethrough menu-leveloperations (described in the Netlink
FRX4000/FRX6000 User Guide). However, some problems might
arise that do not readily identify themselves through system error
messagesorobviouschangesin operation. Thischapter describesthe
procedures for verifying correct configuration and operation of an
FRX4000. It also provides some guidelines for pursuinga solution if
there is aproblem.
When an FRX4000 is switched on, the following should occur:
●The fan(s) and the power light on the front panel will come on.
●As the software is loaded, messages will be displayed.
If there are problems during boot-up, error messages will be dis-
played, and the process will continue after the message has been dis-
played for a short time (so watch the screen carefully).
Once the software has correctly loaded, a screen similar to the fol-
lowing will be displayed.

2-2 FRX4000MaintenanceGuide,Rev 03
Figure 2-1 Port Status Display
From this screen, you should be able to log into the Main Menu
(Figure 2-2), which is the starting point for most configuration and
operation procedures.
Rmtid=local
Port Status Display (Page 1)
P Type PPS Conn# State P Type PPS Conn# State
0 FR 62 4 Operational 1 FR 127 12 Operational
2 SNA 112 7 Operational 3 SNA 60 6 Operational
4 SNA 110 3 Operational 5 SNA 87 5 Operational
6 ASY 0 0 Link_disable 7 X25 88 4 Operational
F1:Login

Diagnostic Procedures 2-3
Figure2-2 Main Menu
It can probably be asssumed that if you are reading this chapter, the
node did not boot correctly as described. The remainder of this
chapterdescribes steps foridentifying and fixing someproblems.
Certain problems may beeasy to track down; for example:
●If there seems to be no power at all, check to make sure the
powercord issecurely connected atbothends and thatthere is
power (of the appropriatevoltage) at the receptacle.
●If the screen messages are obvious, take the appropriate
action.
●If there is an obvious problem with one or more hardware
components, go to Chapter 3.
Ifthe problem isunclear, review the remainder ofthismanual.If nec-
essary, contact Cabletron Systems Technical Support, at:
Phone: [phone]
FAX: [phone]
E-mail: [e-mail]
Rmtid=local
Software Version n.n
M A I N M E N U
A Configuration
B Operation
C S tatus Displays
D Events
E Statistics
F Reports
Option:

2-4 FRX4000MaintenanceGuide,Rev 03
Reviewing Boot Messages
Asan FRX4000boots, screeninformationverifies configuration file
format, and displays any errors. This data is displayed only until the
FRX4000 software is running; however, it is saved in a file named
BOOTRPT.TXT, and theoperator canlater display itin a report. This
can be used as a tool to verify that startup of the node proceeded
withouterrors. If there isan error reported, the data may aidin fixing
the problem.
If a node is shut down, then rebooted, the existing BOOTRPT.TXT
filewill be renamed BOOTBAK.TXT, and a newBOOTRPT.TXTwill
be created. BOOTRPT.TXT and BOOTBAK.TXT can be used as
follows:
1. Displayandreview thedatafromthe“current”bootof thenode.
2. Address any reported problems.
3. Re-boot thenode.(This copies the previous boot data to a
backup file.)
4. Display the new boot data, and compare it to the previous data.
This will show whether the problem was fixed. Also, a problem
that occurred during the previous boot-up will often be cleared
up by re-booting.
To displaythedata fromthecurrentboot-up,press[C] at the Reports
menu(or [F], then[C] from the Main Menu). Todisplaythe data from
the previous boot-up (saved in a file called BOOTBAK.TXT), press
[D]at the Reports menu (or [F],[D] from the Main Menu).

Diagnostic Procedures 2-5
Boot Messages
Many boot messages are “normal” messages,andare described here
simply for information. Others are error messages, and include rec-
ommended action. After taking the recommendedactionforan error
message, rebootthe node. If the problem has not been corrected,
contact Cabletron Systems Technical Support.
Boot messages are listed below in alphabetical order.
Boot Time: nn/nn/19nn–nn:nn:nn
Meaning: This is the date and time of the current boot-up.
Action: None.
Buffers: Xmt count “n,” Xmt size “n,” Rcv count “n,” Rcv size “n”
Meaning: These values denote the numbers and sizes of the
pre-fetch buffers used by the LANinterface.
Action: None.
Checking configuration files
Meaning: Self-explanatory. The software checksto make sure
all files are valid.
Action: None.
Community Table file Read Error, System may not Boot Correctly
Meaning: There is a error in the database fileCOMPAR.DAT.
Action: Delete the file and create a new one by configuring
new SNMP Community Table records (described
in the User Guide).
Conversion Error
Meaning: The database file specified in the message dis-
played before this one (see Converting (FILENAME)
file ...) was not successfully converted to the new
releaseofFRX4000 software.
Action: Ifthe file is X25REC.DAT(nodeparameters),anew
default file will automaticallybe created.If anerror
occurs in any other file, delete the file and create a

2-6 FRX4000MaintenanceGuide,Rev 03
new one by configuring new records for that file
(described in the User Guide).
Conversion Successful
Meaning: The database file specified in the message dis-
played before this one (see Converting (FILENAME)
file...) was successfully converted to the new
releaseof FRX4000 software.
Action: None.
Converting (FILENAME) file ...
Meaning: The software is converting the specified file from
the earlier release of FRX4000 software to the new
release. (This happens during migration to anew
release.) The number of database files that exist
depends on the configuration in the earlier release.
Action: None.
Creating X25rec.dat file ...
Meaning: This message will follow Conversion Errorif that
error occurs during conversion of the node param-
eters file (X25REC.DAT).
Action: None—a new X25REC.DAT will be created auto-
matically.
Database Error: ERRMSG.TXT Invalid Size
Meaning: The event message file (ERRMSG.TXT) was cor-
rupted during migration to a new release.
Action: Copy ERRMSG.TXTvia file transfer ([B], [A], [B]
fromtheMainMenu—describedinthe UserGuide)
from a remote FRX4000 or FRX6000.
Database Error: X.25REC.DAT Not Present, Expects (current release)
Meaning: The database is missing the node parameters file
(X25REC.DAT). During boot-up, if this file is
missing, a new one is normally created automati-
cally. Failure to create this file indicates a serious
failure in the migration software.

Diagnostic Procedures 2-7
Action: Contact Cabletron Systems Technical Support.
Database Initialization Error: ERRMSG.TXT not found
Meaning: The file ERRMSG.TXTcontains all the event mes-
sages, and must be present in the software, but it is
missing.
Action: Copy ERRMSG.TXT via filetransfer ([B], [A], [B]
fromthe Main Menu—describedin the UserGuide)
from a remote FRX4000 or FRX6000.
Database Release “n” Matches Software Release, No Conversion
Necessary
Meaning: Self-explanatory.
Action: None.
Database Validation Error: Version “n.nn”, Expected (current release)
Meaning: The version of the database is incompatible with
that of the operating system. The FRX4000 will
save the database and open a new blank database.
Action: Check all database records (accessible under
Database operations from the Main Menu, and
described in the User Guide) for proper configu-
ration, and reconfigure where necessary.
Database Validation OK: Version “n.nn”
Meaning: The version of the database iscompatible with that
oftheoperating system.
Action: None.
Data Error: SubID “n” Skipped
Meaning: A subscriber ID in the Remote Subscriber file
(RSNSVC.DAT) does not exist in the SVC Sub-
scriber file(SVCSUB.DAT), and the remote sub-
scriber record will not be copied to the new
database.
Action: Createanewremote subscriber record (describedin
the User Guide).

2-8 FRX4000MaintenanceGuide,Rev 03
File Transfer Abort Error
Meaning: While waiting for a file transfer connection to
become established, an abort was attemptedfrom a
different ID (the one in the message) than thatused
to initiate the file transfer request.
Action: The abort must be initiated from the same ID that
was used to initiate the file transfer.
Initialization Error: Can’t Create Line Record/ Status Table
Meaning: There is a severe memory error.
Action: Check all the installed memory for proper seating.
If it is all securely installed, replaceeach module
and reboot, one ata time.
initLan: Could not allocate recv/xmit buffer “n”
Meaning: There is a severe memory error.
Action: Check all the installed memory for proper seating.
If it is all securely installed, replaceeach module
and reboot, one ata time.
IP Interface file Read Error, System may not Boot Correctly
Meaning: An error in the IP Interface file(IPISUB.DAT)
occurred during IP initialization.
Action: Delete the file and create a new one by configuring
IPInterface records (described in the User Guide).
IP Routing file Read Error, System may not Boot Correctly
Meaning: An error in the IP Routing file (IPRSUB.DAT)
occurred during IP initialization.
Action: Delete the file and create a new one by configuring
IPRouting records (described in the User Guide).
No remote subscribers for subID “n”
Meaning: No Remote Subscriber records existed in the
database for the specified SNAsubscriber (subID).
Action: Delete the SNA Subscriber recordorcreateRemote
Subscriber records.
